ILLUMINATION CONTROL LOGIC
On some audio-units, when the instru-
ment panel lights are on, the letters on op-
erable buttons of the mode in current use
light up together with the mode selection
and eject buttons.
RADIO RECEPTION
Usually, a problem with radio reception
does not mean there is a problem with
your radio-it is just the normal result of
conditions outside the vehicle.
For example, nearby buildings and terrain
can interfere with FM reception. Power
lines or telephone wires can interfere with
AM signals. And of course, radio signals
have a limited range, and the farther you
are from a station, the weaker its signal
will be. In addition, reception conditions
change constantly as your vehicle moves.
Here are some common reception prob-
lems that probably do not indicate a prob-
lem with your radio:
FM
Fading and drifing stationsÐGenerally,
the effective range of FM is about 40 km
(25 miles). Once outside this range, you
may notice fading and drifting, which in-
crease with the distance from the radio
transmitter. They are often accompanied
by distortion. Multi-pathÐFM signals are reflective,
making it possible for two signals to reach
your antenna at the same time. If this hap-
pens, the signals will cancel each other
out,
causing a momentary flutter or loss of
reception.
Static and flutteringÐThese occur when
signals are blocked by buildings, trees, or
other large objects. Increasing the bass
level may reduce static and fluttering.
Station swappingÐIf the FM signal you
are listening to is interrupted or weak-
ened, and there is another strong station
nearby on the FM band, your radio may
tune in the second station until the original
signal can be picked up again.
AM
FadingÐAM broadcasts are reflected by
the upper atmosphere-especially at
night. These reflected signals can inter-
fere with those received directly from the
radio station, causing the radio station to
sound alternately strong and weak. Station interferenceÐwhen a reflected
signal and a signal received directly from
a radio station are very nearly the same
frequency, they can interfere with each
other,
making it difficult to hear the broad-
cast.
StaticÐAM is easily affected by external
sources of electrical noise, such as high
tension power lines, lightening, or electri-
cal motors. This results in static.
CARING FOR YOUR CASSETTE PLAY-
ER AND TAPES
For high performance from your cassette
player and tapes:
Clean the tape head and other parts regu-
larly.
 A dirty tape head or tape path can de-
crease sound quality and tangle your
cassette tapes. The easiest way to
clean them is by using a cleaning tape.
(A wet tape is recommended.)
Use high-quality cassettes.
 Low-quality cassette tapes can cause
many problems, including poor sound,
inconsistent playing speed, and
constant auto-reversing. They can
also get stuck or tangled in the cas-
sette player.
ÐCar audio system operating
hints
ProCarManuals.com

91
Do not use a cassette if it has been
damaged or tangled or if its label is
peeling off.
 Do not leave a cassette in the player if
you are not listening to it, especially if
it is hot outside.
 Store cassettes in their cases and out
of direct sunlight.
 Avoid using cassettes with a total play-
ing time longer than 100 minutes (50
minutes per side). The tape used in
these cassettes is thin and could get
stuck or tangled in the cassette player.
CARING FOR YOUR COMPACT DISC
PLAYER AND DISCS
 Use only compact discs labeled as
shown.
 Extremely high temperatures can
keep your compact disc player from
working. On hot days, use the air con-
ditioning to cool the vehicle interior be-
fore you listen to a disc.
 Bumpy roads or other vibrations may
make your compact disc player skip.
 If moisture gets into your compact disc
player, you may not hear any sound
even though your compact disc player
appears to be working. Remove the
disc from the player and wait until it
dries.
Handle compact discs carefully, espe-
cially when you are inserting them.
Hold them on the edge and do not
bend them. Avoid getting fingerprints
on them, particularly on the shiny side.
 Dirt, scrapes, warping, pin holes, or
other disc damage could cause the
player to skip or to repeat a section of
a track. (To see a pin hole, hold the disc
up to the light.)
 Remove discs from the compact disc
player when you are not listening to
them. S tore them in their plastic cases
away from moisture, heat, and direct
sunlight.
To clean a compact disc: Wipe it with a
soft, lint-free cloth that has been damp-
ened with water. Wipe in a straight line
from the center to the edge of the disc (not
in circles). Dry it with another soft, lint-
free cloth. Do not use a conventional re-
cord cleaner or anti-static device.
ProCarManuals.com

92
A new disc may have rough edges on
its inner and outer perimeter. Remove
the rough edges by pressing the side
of a ball-point pen or pencil against
the inner and outer perimeter of the
disc as shown.
If you continue to play a disc with rough
edges, flakes will fall on to the signal side
of the disc and cause sound skipping or
other problems.
Compact disc players use invisible
laser beam which could cause haz-
ardous radiation exposure if di-
rected outside the unit. Be sure to
operate the player correctly as
instructed.CAUTION
!
ProCarManuals.com

93
1. Air Flow Selector
2. Air Intake Selector
3. A/Cº Button (on some models)
4. Fan Speed Selector
5. Temperature Selector
Air conditioning systemÐ
ÐControls
ProCarManuals.com

94
Fan speed selector
Turn the knob to adjust the fan speed ± to
the right to increase, to the left to de-
crease.
Temperature selector
Turn the knob to adjust the temperature ±
to the right to warm, to the left to cool.
Air flow selector
Press one of the buttons to select the
vents used for air flow. An indicator light
will illuminate to show which air flow mode
is being selected.
1 Panel ÐAir flows mainly from the in-
strument panel vents.
2 Bi-level ÐAir flows from both the floor
vents and the instrument panel vents.
3 Floor ÐAir flows mainly from the floor
vents.
4 Floor/Windshield ÐAir flows mainly
from the floor vents and windshield vents.
5 Windshield ÐAir flows mainly from
the windshield vents. For details about air flow selector settings,
see the illustration after A/Cº button.
On models with air conditioning, pressing
the windshield button turns on the defrost-
er-linked air conditioning. This is to clean
up the front view more quickly. When the
windshield button is pressed, the air con-
ditioning and A/Cº button indicator come
on regardless of whether or not the A/Cº
button is pressed in.
Pressing another air flow button turns off
the air conditioning.
ProCarManuals.com

95
Air Intake selector
Press the button to select the air source.
An indicator light will illuminate to show
which air intake mode is being selected.
1 RecirculateÐRecirculates the air in-
side the vehicle.
2 Fresh ÐDraws outside air into the sys-
tem. A/Cº button
To turn on the air conditioning, press the
A/Cº button. The A/Cº button indicator
will come on. To turn the air conditioning
off, press the button again.
If the A/Cº button indicator flashes, there
is a problem in the air conditioning system
and the air conditioning automatically
shuts off. If this happens, take your ve-
hicle to a Toyota dealer for service.
ProCarManuals.com

1: For air conditioning
96

To cool off your Toyota after it has been
parked in the hot sun, drive with the
windows open for a few minutes. This
vents the hot air, allowing the air condi-
tioning to cool the interior more quickly.

Make sure the air intake g rilles in front
of the windshield are not blocked (by
leaves or snow, for example).

On humid days, do not blow cold air on
the windshield. The windshield could
fog up because of the difference in air
temperature on the inside and outside
of the windshield.

Keep the area under the front seats
clear to allow air to circulate through-
out the vehicle.

On cold days, move the fan speed to
HIº for a minute to help clear the in-
take ducts of snow or moisture. This
can reduce the amount of fogging on
the windows.
ÐAir flow selector settings ÐOperating tips
ProCarManuals.com

97
Heating
For best results, set controls to:Fan speedÐAny setting except OFFº
Temperature Ð Towards WARM
(red zone)
Air intakeÐ FRESH (outside air)
Air flowÐ FLOOR
Air conditioning ÐOFF

For quick heating, select recirculated
air for a few minutes. To keep the win-
dows from fogging, select fresh after
the vehicle interior has been warmed.

Press the A/Cº button on for dehumid-
ified heating.

Choose floor/windshield air flow to
heat the vehicle interior while defrost-
ing or defogging the windshield. Air conditioning
For best results, set controls to:
Fan speedÐAny setting except OFFº
Temperature Ð Towards COLD
(blue zone)
Air intakeÐ FRESH (outside air)
Air flowÐ PANEL
Air conditioning ÐON
For quick cooling, move the air intake
selector to recirculate for a few min-
utes.
Ventilation
For best results, set controls to:
Fan speedÐAny setting except OFFº
Temperature Ð Towards COLD
(blue zone)
Air intakeÐ FRESH (outside air)
Air flowÐ PANEL
Air conditioning ÐOFF
Defogging and defrosting
The inside of the windshield
For best results, set controls to:
Fan speedÐAny setting except OFFº
Temperature Ð Towards WARM
(red zone) to heat;
COLD (blue zone)
to cool
Air intakeÐ FRESH (outside air)
Air flowÐ WINDSHIELD
Pressing the windshield button turns on
the defroster-linked air conditioning. This
is to clean up the front view more quickly.
When the windshield button is pressed,
the air conditioning and the A/Cº button
indicator always come on regardless of
whether or not the A/Cº button is pressed
in.
Pressing another air flow button turns off
the air conditioning.

On humid days, do not blow cold air on
the windshieldÐthe difference be-
tween the outside and inside tempera-
tures could make the fogging worse.
