1996 NISSAN QUEST headlight bulb

Passenger compartment
If the electrical equipment does not operate,
check for an open fuse.
1. Remove the key from the ignition.
2. Open the fuse box cover. Refer to the
fuse label on the fuse box cover to locate
the fuse in question.
3. Remove the fuse with the fuse puller.
4. If the fuse is open, replace it with a new
fuse.Never use a fuse of a higher amperage
rating than that specified on the fuse box
cover.
5. If a new fuse opens again, have the
electrical system checked and repaired
by your NISSAN dealer.
HEADLIGHTS
The headlight is a semi-sealed beam type
which uses a replaceable headlight (halo-
gen) bulb. A bulb can be replaced from
inside the engine compartment without re-
moving the headlight assembly.
CAUTION
High pressure halogen gas is sealed
inside the halogen bulb. The bulb may
break if the glass envelope is scratched
or the bulb is dropped.
ADI0580ADI0048
LIGHT BULBS
7-19
ZB13-DX

Hold the plastic base when handling
the bulb. Never touch the glass enve-
lope.
Removing the headlight bulb
1. Disconnect the negative battery cable.
2. Disconnect the electrical connector from
the rear end of the bulb.
3. Turn the bulb retaining ring counterclock-
wise until it is free from the headlight
reflector, then remove it.
4. Remove the headlight bulb by pulling
straight rearward. Do not shake or rotate
the bulb when removing it.
Replacing the headlight bulb
1. Insert the bulb into the headlight reflector
with the flat side of the plastic base facing
upward.
2. Install the bulb retaining ring and turn it
clockwise until it stops.
3. Push the electrical connector into the
bulb plastic base until it snaps and stops.
CAUTION
DO NOT TOUCH THE BULB.
cUse the same number and wattage
as originally installed:
Wattage 55/65
Bulb no. 9007
cAiming is not necessary after replac-
ing the bulb. When aiming adjust-
ment is necessary, contact your NIS-
SAN dealer.
cDo not leave the bulb out of the
headlight reflector for a long period
of time as dust, moisture, and smoke
may enter the headlight body and
affect the performance of the head-
light.
7-20
ZB13-DX

Replacement procedures
All lights (except for headlights) are either
type A, B, C or D. When replacing a bulb,
first remove the lens and/or cover.
ADI0577
ADI0044
7-22
ZB13-DX

Ignition switch .............................................. 4-4
Increasing fuel economy............................ 4-11
Indicator lights and chimes (See warning/
indicator lights and chimes)
Inertia fuel shut-off switch.......................... 5-10
Inside mirror ............................................... 2-76
Installing the license plate ......................... 9-11
Instrument brightness control .................... 1-16
Interior lights .............................................. 1-23
J
Jump starting ...................................... 5-7, 7-11
K
Key ............................................................... 2-2
Keyless entry (See multi-remote control system)
L
Labels
Air conditioner specification label ......... 9-11
Emission control information label........ 9-10
Engine serial number ............................. 9-9
F.M.V.S.S. certification label ................ 9-10
Vehicle identification number plate ........ 9-9
Warning labels (for SRS) ..................... 2-45
License plate
Installing the license plate .................... 9-11Light
Air bag warning light............................. 2-45
Bulb check/instrument panel .................. 1-6
Bulb replacement.................................. 7-20
Cornering light ...................................... 1-16
Headlight control switch ....................... 1-12
Headlights ............................................. 7-19
Interior lights ......................................... 1-23
Light bulbs ............................................ 7-19
Luggage compartment lights ................ 1-23
Spotlights .............................................. 1-15
Warning/indicator lights and chimes ...... 1-6
Lock
Child safety sliding door lock ................. 2-4
Door locks............................................... 2-2
Fuel filler lid and cap ............................ 2-15
Power door lock...................................... 2-5
Rear door lock ...................................... 2-11
Luggage compartment lights ..................... 1-23
Luggage rack ............................................. 2-14
M
Maintenance
General maintenance ............................. 8-2
Inside the vehicle.................................... 8-3
Maintenance precautions ....................... 7-2
Outside the vehicle ................................. 8-2
Periodic maintenance schedules ............ 8-5
Seat belt maintenance.......................... 2-57
Under the hood and vehicle ................... 8-4
Manual front seat adjustment .................... 2-26Manual rear windows................................. 1-21
Mirror
Inside mirror.......................................... 2-76
Outside mirror control ........................... 2-75
Outside mirrors ..................................... 2-76
Vanity mirror ......................................... 2-76
Multi-remote control system ........................ 2-7
O
Odometer ..................................................... 1-4
Oil
Capacities and recommended fuel/
lubricants ................................................ 9-2
Changing engine oil................................ 7-6
Changing engine oil filter........................ 7-7
Checking engine oil level ....................... 7-5
Engine oil ................................................ 7-5
Engine oil and oil filter recommendation... 9-4
Outside mirror control ................................ 2-75
Outside mirrors .......................................... 2-76
Overdrive switch .......................................... 4-7
Overheat
If your vehicle overheats ........................ 5-9
Owner's manual order form ....................... 9-20
P
Parking
Parking brake check ............................. 7-16
Parking brake operation ......................... 4-8
Parking/parking on hills ........................ 4-12
10-3
ZX
