1996 NISSAN FRONTIER instrument panel

The instrument brightness control operates
when the light switch is in theorposition.
Turn the control to adjust the brightness of
the instrument panel lights.Push the switch on to warn other drivers
when you must stop or park under emer-
gency conditions. All turn signal lights flash.
WARNING
cWhen stalled or stopped on the road-
way under emergency conditions,
move the vehicle well off the road.cDo not use the hazard warning flash-
ers while moving on the highway
unless unusual circumstances force
you to drive so slowly that your ve-
hicle might become a hazard to other
traffic.
cSome state laws may prohibit the
use of the hazard warning flasher
switch while driving.
cTurn signals do not work when the
hazard warning flasher lights are on.
The flasher can be actuated with the ignition
switch in any position.
SIC0052SIC0050
INSTRUMENT BRIGHTNESS
CONTROLHAZARD WARNING FLASHER
SWITCH
1-12
ZX

1. Pull the hood lock release handle located
below the instrument panel; the hood
then springs up slightly.
2. Raise the lever at the front of the hood
with your fingertips and raise the hood.3. Insert the assist bar into the slot in the
front edge of the hood.
4. When closing the hood, reset the assist
bar to its original position, then slowly
close the hood and make sure it locks
into place.The glove box may be opened by turning
the key as shown.
WARNING
Keep glove box lid closed while driving
to prevent injury in an accident or dur-
ing a sudden stop.
APD0702SIC0055
HOOD RELEASE GLOVE BOX LOCK
(If so equipped)
2-4
ZX

Warning labels about the supplemental air
bag system are placed in the vehicle as
shown in the illustration.The supplemental air bag light, displaying
AIR BAG in the instrument panel, monitors
the circuits of the supplemental air bag. The
circuits monitored by the supplemental air
bag light are the diagnosis sensor unit, the
supplemental air bag module and all related
wiring.
When the ignition key is in the ON or START
position, the supplemental air bag warning
light illuminates for about 7 seconds and
then turns off. This means the system is
operational.
If any of the following conditions occur, the
supplemental air bag needs servicing and
APD0705APD0706
WARNING LABELS SUPPLEMENTAL AIR BAG
WARNING LIGHT
2-15
ZX

1 (Low gear):
Use this position when climbing steep hills
slowly or driving slowly through deep snow,
sand or mud, or for maximum engine brak-
ing on steep downhill grades.
Do not down shift into the 1 position at
speeds over 62 MPH (100 km/h), and do not
exceed 30 MPH (50 km/h) in the 1 position.
Accelerator downshift
Ð In D position Ð
For rapid passing or hill climbing, fully de-
press the accelerator pedal to the floor. This
shifts the transmission down into second
gear or first gear, depending on the vehicle
speed.
Overdrive switch
ON: For normal driving, push the overdrive
switch ON
with the selector lever
in the D position. The transmission is
upshifted into OVERDRIVE as the ve-
hicle speed increases.
The overdrive does not engage until the
engine has warmed up.
OFF: For driving up and down long slopes
where engine braking would be ad-
vantageous, push the switch OFF
.When cruising at a low speed or
climbing a gentle slope, you may feeluncomfortable shift shocks as the trans-
mission shifts between 3rd and over-
drive repeatedly. In this case, set the
overdrive switch in the OFF
position.
The indicator light in the instrument
panel comes on at this time.
When driving conditions change, reset the
overdrive switch in the ONposition.
Remember not to drive at high speeds for
extended periods of time with the overdrive
switch set in the OFF
position. This
reduces fuel economy.
ASD0702
4-8
ZX

To apply:pull the lever out.
To release:pull out slightly and turn the
lever, then push it in completely. Before
driving, be sure the parking brake warning
light goes out.The cruise control allows driving at a fixed
speed between 30 and 90 MPH (50 and 140
km/h) without keeping your foot on the
accelerator pedal.
To turn on the cruise control,push the
main switch on. The CRUISE CONT indica-
tor light comes on.
To set at cruising speed,accelerate your
vehicle to the desired speed, push the
COAST/SET switch and release it. The
CRUISE light in the instrument panel comes
on. Take your foot off the accelerator pedal.
Your vehicle maintains the set speed.To pass another vehicle,depress the ac-
celerator pedal. When you release the
pedal, the vehicle returns to the previously
set speed.
cThe vehicle may not maintain the set
speed when going up or down steep hills.
If this happens, drive without the cruise
control.
To cancel the preset speed,use one of
the following three methods:
a) Push the CANCEL button; the CRUISE
light goes out.
IC0177ASD0703
PARKING BRAKE
OPERATIONCRUISE CONTROL
4-11
ZX

When planning to drive your NISSAN
vehicle in another country,you should
first find out if the fuel available is suitable
for your vehicle's engine.
Using fuel with too low an octane rating may
cause engine damage. All gasoline vehicles
can be operated with unleaded gasoline.
Therefore, avoid driving your vehicle in ar-
eas where appropriate fuel is not available.
When transferring the registration of
your vehicle to another country, state,
province or district,it may be necessary to
modify the vehicle to meet local laws and
regulations.
The laws and regulations for motor vehicle
emission control and safety standards vary
according to the country, state, province or
district; therefore, vehicle specifications
may differ.
When any vehicle is to be taken into
another country, state, province or dis-
trict and registered, its modifications,
transportation and registration are the
responsibility of the user. NISSAN is not
responsible for any inconvenience that
may result.
VEHICLE IDENTIFICATION NUM-
BER PLATE
The vehicle identification number plate is
attached to the top of the instrument panel
on the driver's side. This number is the
identification for your vehicle and is used in
the vehicle registration.
VEHICLE IDENTIFICATION
NUMBER (Chassis number)
CA0018CA0030
REGISTERING YOUR
VEHICLE IN ANOTHER
COUNTRYVEHICLE IDENTIFICATION
9-12
ZX

10 Index
A
Air bag (See supplemental restraint system)
Air bag warning light .................................. 2-15
Air cleaner housing filter ............................ 7-15
Air conditioner
Air conditioner operation ........................ 3-5
Air conditioner service ............................ 3-9
Air conditioner specification label ......... 9-14
Air conditioning system refrigerant and
lubricant recommendations .................... 9-8
Air flow charts .............................................. 3-6
AM-FM electronic tuning radio with
cassette player........................................... 3-11
AM-FM electronic tuning radio with
cassette player (100 W) ............................ 3-16
Anchor point locations ............................... 2-25
Antenna (manual) ...................................... 3-20
Anti-lock brake system, rear (R-ABS) ....... 4-26
Audio system
AM-FM electronic tuning radio with
cassette player ..................................... 3-11
AM/FM electronic tuning radio with
cassette player (100 W) ....................... 3-16
Cassette tape operation .............. 3-13, 3-19
Auto-lock free-running hubs ...................... 4-15
Automatic
Automatic transmission fluid ................... 7-9Driving with automatic transmission ....... 4-6
B
Battery........................................................ 7-13
Brake
Brake fluid ..................................... 7-11, 9-3
Brake booster ....................................... 7-19
Brake pedal .......................................... 7-18
Brake pad wear indicators ............ 1-9, 7-18
Parking brake check ............................. 7-17
Parking brake operation ....................... 4-11
Rear anti-lock brake system (R-ABS) .. 4-26
Break-in schedule ...................................... 4-13
Bulb check/instrument panel ....................... 1-6
Bulb replacement ....................................... 7-22
C
Capacities and recommended
fuel/lubricants ............................................... 9-2
Cargo (see vehicle loading information).... 9-15
Cassette tape operation ................... 3-13, 3-19
Cassette player (See audio system)
CB radio or car phone ............................... 3-21
Center and side ventilators.......................... 3-2
Child restraints for infants and small
children ...................................................... 2-22Cigarette lighter (accessory) and ash
tray ............................................................. 1-13
Cleaning exterior and interior ...................... 6-2
Clock/audio system.................................... 3-11
Clock/instrument cluster .............................. 1-5
Clutch fluid ................................................. 7-11
Clutch pedal ............................................... 7-19
Cold weather driving cautions ................... 4-27
Controls
Audio controls ............................. 3-11, 3-16
Heater and air conditioner controls ........ 3-3
Coolant
Capacities and recommended
fuel/lubricants.......................................... 9-2
Changing engine coolant........................ 7-5
Checking engine coolant level ............... 7-4
Engine coolant temperature gauge ........ 1-4
Cruise control............................................. 4-11
Cup holder ................................................. 1-13
D
Daytime running light system
(Canada only) ............................................ 1-10
Digital clock (See clock/instrument cluster)
Dimensions and weights............................ 9-11
Door locks .................................................... 2-2
Drive belts .................................................. 7-14
ZX

Increasing fuel economy............................ 4-13
Indicator lights and chimes
(See warning/indicator lights and chimes)
Inside mirror ............................................... 2-27
Instrument brightness control .................... 1-12
Interior light and cargo light ....................... 1-14
J
Jack
Pantograph type ..................................... 5-5
Screw type .............................................. 5-6
Jump seat .................................................. 2-11
Jump starting ............................................... 5-8
K
Key ............................................................... 2-2
L
Labels
Air conditioner specification label ......... 9-14
Emission control information label........ 9-14
Engine serial number ........................... 9-13
F.M.V.S.S. certification label ................ 9-13
Vehicle identification number plate ...... 9-12
Warning labels (for SRS) ..................... 2-15
Light
Supplemental air bag warning light ...... 2-15
Bulb check/instrument panel .................. 1-6Bulb replacement.................................. 7-22
Headlight and turn signal switch .......... 1-10
Headlights ............................................. 7-20
Interior light and cargo light .................. 1-14
Light bulbs ............................................ 7-20
Map light ............................................... 1-14
Warning/indicator lights and chimes ...... 1-6
Lock
Door locks............................................... 2-2
Free-running lock (see hubs)
Glove box lock ........................................ 2-4
Power door lock...................................... 2-3
Luggage (see vehicle loading information). 9-15
M
Maintenance
General maintenance ............................. 8-2
Inside the vehicle.................................... 8-3
Maintenance precautions ....................... 7-2
Outside the vehicle ................................. 8-2
Periodic maintenance schedules ............ 8-5
Seat belt maintenance.......................... 2-21
Under the hood and vehicle ................... 8-4
Manual antenna ......................................... 3-20
Manual-lock free-running hubs .................. 4-19
Manual window .......................................... 1-15
Map light .................................................... 1-14
Mirror
Inside mirror.......................................... 2-27
Outside mirror remote control ............. 2-26
Outside mirrors ..................................... 2-26Vanity mirror ......................................... 2-27
O
Octane rating (see fuel)
Odometer ..................................................... 1-3
Oil
Capacities and recommended
fuel/lubricants.......................................... 9-2
Changing engine oil................................ 7-7
Changing engine oil filter........................ 7-8
Checking engine oil level ....................... 7-6
Engine oil ................................................ 7-6
Engine oil and oil filter
recommendation ..................................... 9-6
Opera window ............................................ 1-17
Outside mirror remote control .................. 2-26
Outside mirrors .......................................... 2-26
Overdrive switch .......................................... 4-8
Overheat
If your vehicle overheats ........................ 5-9
Owner's manual order form ....................... 9-26
P
Pantograph type jack ................................... 5-5
Parking
Parking brake check ............................. 7-17
Parking brake operation ....................... 4-11
Parking/parking on hills ........................ 4-24
Periodic maintenance schedules ................. 8-5
10-3
ZX
