1996 Mercury Mercury Cougar Owner's Manuals

113
*
[FV08775( ALL)02/95]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
*
[FV08800(MBC )02/95]
quarter page art:0020790-A
Replacing the batteries
*
[FV08825(MBC )02/95]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
%*
[FV08850( ALL)02/95]
Replacement/additional transmitters
*
[FV08875(MBC )02/95]
In the event a transmitter is lost, return the
remaining transmitters to your dealer for
reprogramming of your remote entry system.
This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[FV08900(MBC )02/95]
Additional transmitters may be purchased from
your dealer (remote entry system will work with
up to four transmitters). Return your existing
transmitters to your dealer so the remote entry
system can be reprogrammed with your new
and existing transmitters.
File:rcfvc.ex
Update:Wed Jun 28 16:53:30 1995

114
*
[FV08925( ALL)02/95]
THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
%
*
[FV08950( ALL)02/95]
Windows
%*
[FV08980( BCGV)02/95]
Using the Power Windows
[FV08990(MBC )03/03]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control panel that operates the
windows.
*
[FV09050( ALL)01/95]
Power windows can only be opened or closed
when the ignition switch is in the ON or ACC
position.
*
[FV09075(MBCG )05/95]
RWARNING
Do not let children play with the power
windows. They may seriously hurt
themselves. Make sure occupants are clear
of the window(s) before closing.
File:rcfvc.ex
Update:Wed Jun 28 16:53:30 1995

115 [FV09200( BC )05/95]
half page art:0010233-G
The master controls on the driver's door
%*
[FV13100( BC )02/95]
Moon Roof (If equipped)
[FV13200( BC )05/95]
You can move the moon roof back to open the
glass panel, or you can tilt it up to ventilate the
vehicle. There is also an intermediate position
between closed and open which can reduce wind
noise at speeds between 30 and 45 miles per
hour (50 and 70 km/h).
*
[FV13300( BC )01/95]
The rocker type switch is used to open and close
the moon roof. You must press and hold the
switch until the desired position is reached. At
fully open, closed and intermediate positions, the
motor will automatically turn off. Release the
switch at this time to avoid motor damage.
File:rcfvc.ex
Update:Wed Jun 28 16:53:30 1995

116 [FV13400( BC )05/92]
two third page art:0010248-CThe switch for the moon roof
[FV13600( BC )07/93]
To open the moon roof, press and hold the rear
portion of the switch. The glass panel will move
to the intermediate position and stop. If the rear
of the switch is pressed again the glass panel
will move to the full open position and stop.
[FV13700( BC )07/93]
To close the moon roof, press and hold the front
portion of the switch. The glass panel will move
to the intermediate position and stop. Press and
hold the front of the switch again and the panel
will move to the fully closed position and stop.
File:rcfvc.ex
Update:Wed Jun 28 16:53:30 1995

117
*
[FV13800( BC )01/95]
To tilt the moon roof into vent position when
the glass panel is closed, press the front portion
of the switch.
*
[FV13900( BC )04/95]
To close from vent position, press and hold the
rear portion of the switch.
*
[FV14100( BC )01/95]
Occasionally wiping the outside guide rail covers
of the moon roof with a clean cloth will help
keep the moon roof working properly.
[FV14200( BC )05/89]
one third page art:0010250-B
The moon roof
*
[FV14300( BC )01/95]
RWARNING
Do not let children play with the moon
roof. They may seriously hurt themselves.
*
[FV14400( BC )01/95]
Sliding Shade
*
[FV14500( BC )01/95]
The moon roof has a sliding shade that you can
manually open or close to block the sun when
the glass panel is shut.
*
[FV14600( BC )01/95]
To close the sliding shade, pull the shade toward
the front of the vehicle. The shade automatically
opens and locks when the moon roof is opened.
File:rcfvc.ex
Update:Wed Jun 28 16:53:30 1995

118
%*
[FV15700( ALL)01/95]
Seats
%*
[FV15710( ALL)04/95]
Head Restraints
*
[FV15720( ALL)04/95]
If you use them properly, head restraints will
help protect your head and neck in a collision.
*
[FV15730( ALL)05/95]
A head restraint helps protect you best if you
position it behind your head and not behind
your neck.
*
[FV15740( ALL)02/95]
Standard head restraints
*
[FV15750( ALL)01/95]
You can adjust the head restraints for your
comfort and protection.
[FV15770( ALL)05/92]
one third page art:0010048-C
Adjusting the head restraint
% [FV15800(MBC )06/93]
Adjusting Manual Seats
*
[FV16000( ALL)02/89]
In the front seats, you can move the whole seat
forward or backward or tilt the back of the seat
forward or backward.
[FV16100(MBC )05/92]
To move the seats forward or backward:
[FV16200( BCGV)04/95]
1. Find the adjustment bar underneath the front
part of the seat.
[FV16400( BCGV)04/95]
2. Lift the bar to unlatch the seat.
*
[FV16600( ALL)04/95]
3. Move the seat to the desired position.
File:rcfvc.ex
Update:Wed Jun 28 16:53:30 1995

119 [FV16700( BCGV)04/95]
4. Release the bar to latch the seat in its new
position. Make sure the seat locks securely in
place.
[FV16900( BC )07/89]
quarter page art:0010252-A
The front seat adjustment bar
*
[FV17100(MBC )02/95]
To recline the front manual seats:
*
[FV17200( ALL)01/95]
1. On the side of the seat, find the handle for
the recliner.
*
[FV17300( ALL)04/95]
2. Lift the handle up and hold it in place.
*
[FV17400( ALL)01/95]
3. Lean against the back of the seat and adjust
it to the position you want. You can tilt the
seat back or bring it forward.
*
[FV17500( ALL)04/95]
4. Release the handle to lock the seat in its new
position.
*
[FV17600( ALL)05/95]
RWARNING
Never adjust the driver's seat or seatback
when the vehicle is moving.
*
[FV17700( ALL)05/95]
RWARNING
To reduce the risk of serious injury in a
collision, always drive and ride with your
seatback upright and the lap belt snug
and low across the hips.
File:rcfvc.ex
Update:Wed Jun 28 16:53:30 1995

120 %
*
[FV17900(MBC )01/95]
Seatback Recline
[FV18100( BC )03/90]
one third page art:0010256-A
Front seatback release levers
*
[FV18300( BC )01/95]
It is not necessary to use the emergency seatback
release lever for rear seat entry or exit. The
seatback remains unlocked with normal usage
and locks only during emergency stopping, upon
impact, or on steep downhill grades. The inertia
seatback latch will allow the seatback to rotate
approximately 5Ê forward before it locks. The
release is provided only to unlock the seatback
when parked on steep downhill grades or after a
collision.
*
[FV18400( BC )05/95]
RWARNING
A seatback which is folded forward even
a small degree may not lock properly in
the event of a sudden stop or collision.
File:rcfvc.ex
Update:Wed Jun 28 16:53:30 1995
