1996 LINCOLN CONTINENTAL key

/!\ WARNINGAlways set the parking brake fully and makesure that the gearshift is securely latched in P(Park). Never leave your vehicle unattendedwhile it is running.You can tell a column-mounted gearshift is securely
latched in P (Park) if the lever is adjacent to the P
(Park) and you cannot move it without pulling it
toward you and rotating it downward.
You can tell a console-mounted gearshift is securely
latched in P (Park) if the lever is adjacent to the P
(Park) and you cannot move it without pushing in the
thumb button.
The gearshift will lock when you turn the key to the
LOCK position. When the gearshift is in any
position except P (Park), the ignition key cannot be
turned to the LOCK position or removed from the
steering column. To remove the key, the gearshift
lever must be in P (Park).
184Traction ControlÔ Ô (If equipped)
Your vehicle may be equipped with the
optional Traction ControlÔ, system. This
system helps prevent wheel spin in order to
improve tire traction and is an especially useful
feature when you drive in hilly areas or on
slippery, icy or snowy roads.
When the Traction Control system is
controlling wheelspin, an electric motor sound
may be heard from the engine compartment and
engine acceleration may seem slower. This is
normal.
Traction ControlÔ works automatically by
rapidly applying and releasing the brakes and
reducing engine torque to prevent one or both
of the front drive wheels from spinning during
acceleration.
During the Traction ControlÔ function, which
most often occurs during low speed
acceleration on slippery surfaces, a noise may
be heard coming from the engine compartment.
This is normal and may last for a few seconds
during the acceleration of the vehicle.

Brakes
Applying the Brakes
Your vehicle has anti-lock disc brakes on all four
wheels. They adjust automatically as the brake pads
wear down.
When you press down hard on the brake pedal, the
wheels will not lock and slide. The Anti-lock Brake
System (ABS) automatically starts releasing and
reapplying the front brakes independently and the
rear brakes together whenever your wheels start to
lock. When this happens, you will feel the brake
pedal pulsate. This is an indication that the ABS
system is working correctly and is normal.
Each time you turn the ignition key to the ON
position, the anti-lock brake system will function
through one test cycle. When this happens, the ANTI-
LOCK light will come on for up to five seconds and a
clunk may be felt in the pedal. If the light stays on
longer than five seconds, shut off theengine and restart. If it remains on, it means the
anti-lock brake system is disabled and should be
serviced immediately to restore the benefits of
the anti-lock feature. Normal braking is not
affected unless the brake warning light is also lit.
The And-lock Brake System has self-check
capabilities. As described above, the system
turns on the ANTI-LOCK light each time you
start your engine. After the engine is started
and the ANTI-LOCK light turns off, the system
performs another test the first time the vehicle
reaches 14 m.p.h. (22 km/h). The system turns
on the ABS pump motor for approximately 1/2
second. At this time, a mechanical noise may
be heard. This is a normal part of the self-
check feature. If a malfunction is found during
this check the ANTI-LOCK light will come on.
Do not drive with your foot resting on the
brake pedal; you will wear out the linings and
increase your vehicle's stopping distance.
Brake rotor damage may also eventually occur.
187

NOTE: If you are driving down a long or steep hill,
shift to a lower gear and do not apply your brakes
continuously. If you apply your brakes continuously,
they may overheat and become less effective.
Occasional brake squeal during light to moderate
stops does not affect the function of the brake system
and is normal. However, if the squeal becomes
louder or more frequent, have your brakes inspected
by your dealer or a qualified service technician.
Ford Motor Company has not found any detrimental
effects of popular mobile radio transmitting
equipment installed on vehicles with the anti-lock
brake system, if the equipment is installed according
to the manufacturer's instructions. However, if
mobile radio transmitting
188equipment is installed in your vehicle and, if
either the anti-lock brake system cycles or the
ANTI-LOCK light comes on at any time other
than right after you turn the key to the ON
position or during a sudden stop, have your
mobile radio dealer inspect the installation.
Parking Brake
The parking brake should be used whenever
you park your vehicle.
The parking brake is suspended just below the
lower left corner of the instrument panel.
To set the parking brake while parking your
vehicle, apply the brake pedal with your right
foot and hold it while you push the parking
brake down firmly and fully with your left foot.

9. Lug nutThe lug nuts on the wheel
7.Place any ornaments in the trunk.
8.Put the tire, jack, and wrench away. Make
sure the jack is securely fastened so it does not
rattle when You drive.
9.Unblock the wheels.
10. Turn on the air suspension switch.After replacing a flat tire with the temporary spare
tire, the flat tire can be secured in the trunk tub by
placing the "J" hook through a lug nut hole in the
wheel with the tire and wheel lying at an angle.
Anti-Theft Wheel Lug Nuts
(If equipped)
If your vehicle has this option, one of the lug nuts on
each wheel locks and must be unlocked with a special
key. The key and registration card are attached to the
lug wrench and stored with the spare tire. If you lose
the key, send the registration card to the manufacturer
(not the dealer) to get a replacement key.
NOTE: If entire lug wrench/lug nut key assembly is
lost, see Your nearest Ford Or Lincoln-Mercury
dealer who has access to a master set of keys.
DO NOT USE A POWER IMPACT WRENCH
ON THE LUG NUT KEY
209

Lug nut key Anti-theft lug nutThe anti-theftft lug nut and key
Removing the anti-theft lug nut
Insert the key over the locking lug nut. Make sure
that you hold the key square to the lug nut. If you
hold the key on an angle, you may damage the key
and the lug nut.
Place the lug nut wrench over the lug nut key and
apply pressure on the key with the wrench. Turn the
wrench in a counterclockwise direction to remove
the lug nut.
210Replacing the anti-theft lug nut
Insert the key over the locking lug nut. Place the lug
nut wrench over the lug nut key and, while applying
pressure on the key, install the lug nut.
If the Engine Cranks But Does Not
Start or Does Not Start After a
Collision
The Fuel Pump Shut-off Switch
If the engine cranks but does not start or if you have
had a collision, the fuel pump shut-off switch may
have been triggered. The shut-off switch is a device
that stops the fuel pump when your vehicle has been
involved in a substantial jolt.
For information on how to check and reset the fuel
pump shut-off switch, see Fuel pump shut-off switch
in the Index.

LINCOLN
Registered Key Ring
For that special look of distinction. you have been
provided a pull apart Registered Key Ring. This
Key Ring carries the prestigious Lincoln Star Logo
and is registered on the reverse side to facilitate its
return should it ever become lost.
The Key Ring is located inside the Owner Guide
Portfolio, complete with instructions. Once you fill
out the registration card and mail it to us, we will
keep your name, address and registration number on
file. Should you lose your key ring, all the finder
has to do is drop it in any mail box; we will then
forward it to you.
To order an extra Key Ring, simply fill out the order
form below, or call our toll free number, 1-800-
7350482. Please enclose payment of $15-00
(available in the United States only) for each Key
Ring ordered (checks, money orders and Visa or
MasterCard are accepted; please no cash or CODS).
Michigan residents add 6% Sales Tax. Make
checks Payable to Lincoln Key Ring Headquarters.Bottom swivels only,
and not removable.
Slide button down to
remove ring
MAIL TO:PLEASE SEND ___KEY RINGS
Lincoln Key Ringat $15.00 Each $_____
HeadquartersMI Residents at 6%___
P.O. Box 760546Total $____
Lathrop Village, MI 49076Enclosed is my Check forAllow 2-3 Weeks for delivery.
Bill my VISA MASTERCARD
Credit Card Account Number Expiration Date...
SHIP TO: NAME ADDRESS CITY AND STATE ZIP SIGNATURE

Precautions When Servicing Your
Vehicle
Be especially careful when inspecting or servicing
your vehicle. Here are some general precautions
for your safety: Do not work on a hot engine. The engine
cooling fan may come on unexpectedly. Always
turn the engine off and let it cool./!\ WARNINGThe cooling fan is automatic and may comeon at any time. Always disconnect thenegative terminal of the battery beforeworking near the fan. If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair. Do not work on a vehicle in an enclosed space
with the engine running, unless you are sure you
have enough ventilation. Never get under a vehicle while it is supported by a
jack only. If you must work under a vehicle, use
safety stands. Keep all lit cigarettes and other smoking materials
away from the battery and all fuel-related parts.
If you disconnect the battery, the engine must
“relearn" its idle conditions before your vehicle will
drive properly. To find out how the engine does this,
see Battery in this chapter.
Working with the engine off.
1. Set the parking brake fully and make sure that the
gearshift is securely latched in P (Park).
2.Remove the key from the ignition after you turn
the engine off.
233

Fuse
LocationFuse Amp
RatingDescription2810A
· Shift interlock
· VDM logic power
· Instrument cluster logic power
· Rear defrost control2910A
· Luxury RCU station signal
· Navigation module signal3010A
· Heated mirror right
· Heated mirror left3115A
· Voltage dimming for FCU
and stand alone clock
· Courtesy lamps in the doors
Rear reading lamps
· Map lamps
· RH & LH I/P courtesy lamps
· Engine compartment lamp
· Visor lamps
· Storage bin lamp (5 passenger
only)
· Luggage compartment lamp
· Glove box lamp3215A
· Speed control brake deact
switch
· Stop lamp switchFuse
LocationFuse Amp
RatingDescription33(Not used)3415A
· Back-up L & R lamp ext.
· DRL module (Canada only)
· EATC clutch
· Speed control logic
· IMRC3520A
· L & R heated seat module power36(Not used)37(Not used)3810A
· OBD 11 scan tool connection3910A
· DSM logic power
· DDM logic power
· Door lock switches
· Keyless keypad switch
· Memory set switch
· Driver seat switch
· Power mirror switch4010A
· Blend door actuator
· LTPS4120A
· Door locks (DDM)271
