1996 FORD WINDSTAR keyless entry

Features
147
[FV04460(ALL)11/93]
10-1/2 pica
art:0050186-A
The power door lock switch in the cargo area
*
[FV04500(ALL)05/95]
NOTE: If the sliding door is open when all doors are locked
with the power door lock switch, the sliding door
automatically locks when it is closed.
*
[FV04600(ALL)01/93]
You can manually lock and unlock the doors using the manual
door locks to override the power locks.
% [FV04780(ALL)11/93]
Using the Keyless Entry System
(If equipped)
[FV04800(ALL)06/94]
If you have chosen the keyless entry system option for your
vehicle, you can lock or unlock the doors and liftgate without
using a key. The keypad is above the outside door handle on
the driver's side. See alsoRemote Entry Systemwhich follows
this description.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

148
[FV04900(ALL)10/93]
13-1/2 pica
art:0050107-A
The keyless entry system keypad
[FV05110(ALL)04/95]
When you bought your vehicle, you were given a computer
code that operates the system for your vehicle. For your
convenience, we have duplicated this code in two places.
*
[FV05120(ALL)02/95]
The code is:
*
[FV05130(ALL)02/95]
n
on your owner's wallet card found in the glove compartment
*
[FV05145(ALL)02/95]
n
taped to the computer module
[FV05160(ALL)04/95]
When you use the keyless entry system, the illuminated entry
system turns on the interior lights for 25 seconds and the
buttons on the keypad light up for five seconds.
*
[FV05170(ALL)01/93]
Do not push the keypad buttons with a key, ball-point pen,
pencil, or any other hard object since they could damage the
buttons.
%*
[FV05200(ALL)02/95]
Using the Keyless Entry System
*
[FV05300(ALL)02/95]
To operate the Keyless Entry System, you must be familiar with
the ªpersonal codeº and the ªpermanent code.º The personal
code is a code number that you select that is easy for you to
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

150
*
[FV06901(ALL)02/95]
To erase your personal code:
*
[FV07001(ALL)02/95]1.
Enter the original permanent code.
[FV07101(ALL)04/95]2.
Press the 1/2 button within five seconds of step #1.
*
[FV07201(ALL)02/95]3.
Wait six seconds.
[FV07250(ALL)11/93]4.
The keyless entry system automatically erases your personal
code. The system will now only respond to the permanent
code.
[FV07270(ALL)10/93]
Do not set a code that presents the numbers in sequential order,
such as 1/2, 3/4, 5/6, 7/8, 9/0. Studies show that people who
idly press the buttons usually press a sequential pattern. Also,
do not select a code that uses the same button five times.
Thieves can easily figure out these types of codes.
%*
[FV07300(ALL)01/93]
Unlocking the Doors with the Keyless Entry System
[FV07401(ALL)05/95]
You must unlock the driver's door before you unlock any of the
other doors. If you let more than five seconds pass between
pressing numbers, the system shuts down and you have to
enter the code again. The system has shut down if the keypad
light is out. If the keyless entry system does not work properly,
use the key or Remote Entry transmitter(s) to lock and unlock
the doors or liftgate until the system can be serviced.
[FV07501(ALL)02/95]1.
To unlock the driver's door, enter the code. All codes have 5
numbers. After you press the fifth number, the driver's door
unlocks.
[FV07601(ALL)06/94]2.
To unlock the passenger's door, sliding door and liftgate,
press 3/4 within five seconds of step #1, or re-enter the code
to open the driver's door then press 3/4.
*
[FV07701(ALL)02/95]
Locking the doors with the keyless entry system
*
[FV07801(ALL)03/94]
Along with unlocking your doors, you can use the keyless entry
system to lock the doors.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
151
[FV07901(ALL)06/94]
To lock all of the doors at the same time, press the 7/8 and 9/0
buttons at the same time. It is not necessary to first enter the
keypad code. This will also arm your Ford anti-theft system.
%*
[FV09301(ALL)08/94]
Battery Saver
[FV09302(ALL)06/94]
When the ignition switch is turned to OFF, the vehicle will turn
off battery voltage to the interior lamps after 45 minutes. (The
exterior lamps are not affected.) The purpose is to minimize
extended battery drain if the lights have inadvertently been left
on or if a door or the glove box is not completely closed.
However, the timer will be immediately reset to another 45
minutes if any of the following occurs:
[FV09304(ALL)11/93]
n
any door is open or closed
[FV09305(ALL)11/93]
n
the front door handle is lifted (for Illuminated Entry only)
[FV09306(ALL)11/93]
n
taking the key IN or OUT of the ignition switch
[FV09307(ALL)11/93]
n
the Keyless Entry keypad is used
[FV09308(ALL)11/93]
n
the Remote Entry transmitter is activated
%*
[FV09313(ALL)02/95]
Remote Entry System (If equipped)
[FV09316(ALL)06/94]
If your vehicle has the remote entry system, you can lock and
unlock the vehicle doors without using a key. The remote entry
system also has a personal alarm feature. The buttons that
control the system are located on the hand held transmitter that
come with your vehicle.
*
[FV09318(ALL)02/95]
The system will work with up to four transmitters. Your vehicle
came with two transmitters. Additional transmitters can be
ordered from your dealer.
*
[FV09319(ALL)02/95]
The remote entry features only operate with the ignition in the
OFF position.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
155
[FV09540(ALL)05/95]
n
the ignition key is turned to the ON position
[FV09545(ALL)05/95]
n
the brake pedal is pressed
[FV09550(ALL)05/95]
n
you shift through R (Reverse)
[FV09555(ALL)05/95]
n
the brake pedal is released
[FV09560(ALL)05/95]
The Autolock feature will repeat when:
[FV09565(ALL)05/95]
n
a door is opened and then all doors and the liftgate are
closed
[FV09570(ALL)05/95]
n
the brake pedal is released
[FV09575(ALL)05/95]
On vehicles with Keyless Entry, you can deactivate the system
by using the buttons for the keyless entry system if you do not
want to use the Autolock feature.
[FV09580(ALL)05/95]
The doors may not lock automatically at the correct time if the
driver:
[FV09585(ALL)05/95]
n
shifts through gears without pressing the brake
[FV09590(ALL)05/95]
n
shifts through gears quickly after starting the vehicle
[FV09595(ALL)05/95]
n
releases their foot from the brake while someone has stepped
out of the vehicle for a moment
[FV09600(ALL)05/95]
To deactivate the Autolock system:
[FV09605(ALL)05/95]1.
Enter your permanent five-digit entry code (not the user
code you may have set).
[FV09610(ALL)05/95]2.
Within five seconds, press and hold 7/8.
[FV09615(ALL)05/95]3.
Within five more seconds, press and release 3/4.
[FV09620(ALL)05/95]4.
Release 7/8.
[FV09625(ALL)05/95]
To reactivate the Autolock system, simply repeat the instructions
for deactivating the system. By re-entering the code that
deactivates the Autolock, the keyless entry system reinstates the
Autolock feature.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

156
% [FV09630(ALL)05/95]
Anti-Theft System (if equipped)
*
[FV09635(ALL)05/95]
When armed, this system helps protect your vehicle against
break-ins or theft.
%*
[FV09640(ALL)05/95]
When an unauthorized entry occurs, the system triggers and
will:
*
[FV09645(ALL)05/95]
n
flash the headlamps, parking lamps, and alarm indicator
lamp
*
[FV09650(ALL)05/95]
n
honk the horn
*
[FV09655(ALL)05/95]
n
disable the starting circuit to prevent the vehicle from being
started
%*
[FV09660(ALL)05/95]
Arming the system
*
[FV09665(ALL)05/95]1.
Remove the key from the ignition. The hood must be closed
to arm the system.
*
[FV09670(ALL)05/95]2.
Open any door. The alarm indicator light will start flashing
to remind you to arm the system.
*
[FV09675(ALL)05/95]3.
Lock the doors by using the power door lock switch. The
alarm indicator light will now glow steadily.
[FV09680(ALL)05/95]4.
Close all doors. The alarm indicator light will then remain
on steadily for 30 seconds and then go out. When the light
goes out, the system is armed.
*
[FV09685(ALL)05/95]
NOTE: Be sure to close all doors completely. If not, the alarm
indicator light will remain on. Remember, your
anti-theft system is armed only after the alarm
indicator light remains on steadily for approximately
30 seconds after the last door is closed, and then goes
out.
*
[FV09690(ALL)05/95]
You can also arm the anti-theft system with the factory installed
remote entry system or the keyless entry system by following
this sequence:
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
157
*
[FV09695(ALL)05/95]1.
Remove the key from the ignition. The hood must be closed
to arm the system
*
[FV09700(ALL)05/95]2.
Close all of the doors.
[FV09705(ALL)05/95]3.
Press the remote entry transmitter LOCK button or use the
keyless entry system by pressing 7/8 and 9/0 at the same
time. The alarm indicator will come on for 30 seconds to
show the alarm is arming and then turn off to show that it
has armed.
[FV09710(ALL)05/95]
The anti-theft system is designed to work with the factory
installed remote keyless entry system. It may not work with
other remote entry systems.
%*
[FV09715(ALL)05/95]
Disarming an untriggered anti-theft system
[FV09720(ALL)05/95]
You can disarm the system by unlocking either front door or
the liftgate with your door key. Turn the key all the way to the
end of travel or the system will not disarm.
[FV09725(ALL)05/95]
You can also disarm the system by unlocking the driver's door
by using the UNLOCK button of the remote entry transmitter or
by using the five-digit unlock code on the keyless entry system
keypad.
*
[FV09731(ALL)04/95]
If the system is armed and you remain in your vehicle, simply
insert the key into the ignition and turn it to ON. This disarms
the system and allows you to open the door and exit without
triggering the system.
%*
[FV09791(ALL)05/95]
Disarming a triggered system
*
[FV09801(ALL)05/95]
The alarm can be disarmed by:
*
[FV09811(ALL)04/95]
n
unlocking any door with the key, or
*
[FV09821(ALL)05/95]
n
using the UNLOCK button of the remote entry transmitter
[FV09825(ALL)11/93]
n
using the five-digit unlock code on the keyless entry keypad
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

295
Accessories
[AC00500(ALL)12/93]
Ford Accessories for Your Windstar
[AC00600(ALL)11/93]
Many accessories for your Windstar are available through your
local authorized dealer. These accessories have been designed to
meet your needs and are custom designed to complement the
style and aerodynamics of your vehicle. Some of the available
accessories are listed below.
*
[AC00700(ALL)01/93]
Safety, Comfort, and Convenience
*
[AC00800(ALL)06/93]
Comfort and Convenience
[AC00900(ALL)04/95]
Engine Block Heater (Standard in Canada)
Remote Keyless Entry
*
[AC01000(ALL)01/93]
Protection and Appearance Equipment
[AC01100(ALL)04/95]
Aero Running Boards
Molded Running Boards
Carpet Floor Mats
Cleaners, Waxes and Polishes
Front End Cover
Front End Mini Cover
Lubricants and Oils
Side Window Shields
Styled Wheel Protector Locks
Rear Air Deflector
Door Edge Guards
File:wnacs.ex
Update:Tue Mar 19 08:17:13 1996
