Under certain conditions, the Check Engine Warning Light may
come on if the fuel cap is not properly installed. If the Check
Engine Warning Light comes on and you suspect that the fuel
cap is not properly installed, pull off the road as soon as it is
safely possible and turn off the engine. Remove and replace the
cap, making sure it is properly seated.
*
[LG02600(ALL)05/95]
After completing the three consecutive warm up cycles and on
the fourth engine start up, the Check Engine Warning Light
should turn off. If the light does not go off after the fourth
engine re-start, have your vehicle serviced by your dealer or a
qualified technician.
%*
[LG02700(ALL)01/95]
Charging System Light
[LG02801(ALL)11/93]
This light indicates that your battery is not being charged. The
light comes on briefly during the display self-test every time
you turn your ignition key to the ON position. The light will go
off when the key is turned to the START position. The light
should stay off when the self-test is done if the engine is
running and the alternator is charging.
*
[LG03100(ALL)01/95]
If the light stays on or comes on when the engine is running,
have the electrical system checked as soon as possible.
[LG03150(ALL)02/94]
6 pica art:0050149-B
The charging system light
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
77
*
[LG06860(ALL)10/93]
Gauges
%*
[LG06900(ALL)01/95]
Fuel Gauge
[LG07040(ALL)03/94]
The fuel gauge displays approximately how much fuel is in the
fuel tank only when the ignition is ON. For proper fuel gauge
indication after adding fuel, the ignition should be in the OFF
position while the vehicle is being refueled.
[LG07080(ALL)03/94]
The fuel gauge indicator may also vary slightly when the
vehicle is in motion. With the ignition OFF, the fuel gauge
indicator may drift from the ignition ON position as well.
[LG07090(ALL)08/94]
10-1/2 pica
art:0050235-A
Fuel gauge Ð base cluster
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
83
%*[LG9580(ALL)09/93]
Electronic Cluster (If Equipped)
[LG09600(ALL)03/94]
The Electronic Cluster works only when your ignition is in the
ON position. Each time you start your vehicle, the displays go
through a self-test by lighting up all segments for about one
second and then turning off all segments for about one second,
before displaying actual gauge readings. (The turn signal and
high beam indicators do not light during the self-test. The LOW
OIL light may remain on throughout the self-test and for several
seconds after normal readings are displayed.) This self-test
demonstrates that all of the display segments are working
properly.
[LG09620(ALL)03/94]
The electronic cluster has three major functions to provide you
with information about your vehicle's operating status:
[LG09650(ALL)10/93]
n
Warning and Indicator Lights
[LG09661(ALL)10/93]
n
Electronic Gauges
[LG09670(ALL)12/93]
n
The Fuel Computer
[LG10801(ALL)12/93]
Warning and Indicator Lights
%*
[LG10820(ALL)02/95]
Safety Belt Warning Light and Chime
*
[LG10823(ALL)03/95]
This warning light and chime remind you to fasten your safety
belt. The following conditions will take place:
[LG10826(ALL)02/95]
n
If the driver does not fasten the safety belt before the
ignition is turned to ON, the chime will sound for four (4) to
eight (8) seconds and the light will illuminate for one (1) to
two (2) minutes, or until the safety belt is fastened.
[LG10829(ALL)02/95]
n
If the driver fastens the safety belt before the ignition is
turned to ON, the chime will not sound and the light will
not illuminate.
[LG10832(ALL)02/95]
n
If the safety belt is buckled while the light is on and the
chime is sounding, both the light and the chime turn off.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
85
%*
[LG10861(ALL)01/95]
Air Bag Readiness Light
[LG10871(ALL)11/93]
This light indicates that the Air Bag system is not functional
and needs to be serviced. The light illuminates for
approximately six seconds when the ignition is turned to the
ON position to verify that the indicator bulb is working. If the
light fails to illuminate, flashes continuously, or remains on,
have the air bag system serviced as soon as possible.
[LG10881(ALL)11/93]
6 pica art:0050153-B
The air bag readiness light
%*
[LG10901(ALL)01/95]
Charging System Light
[LG10911(ALL)11/93]
This light indicates that your battery is not being charged. The
light comes on briefly during the display self-test every time
you turn your ignition key to the ON position. The light will go
off when the key is turned to the START position. The light
should stay off when the self-test is done if the engine is
running and the alternator is charging.
*
[LG10913(ALL)01/95]
If the light stays on or comes on when the engine is running,
have the electrical system checked as soon as possible.
[LG10915(ALL)11/93]
6 pica art:0050149-B
The charging system light
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
89
% [LG11001(ALL)02/95]
Oil Pressure Light
[LG11005(ALL)06/94]
6 pica art:0050150-B
The oil pressure light
[LG11010(ALL)11/93]
This light indicates the engine's oil pressure, not the oil level.
However, if your engine's oil level is low, it could affect the oil
pressure. The light will come on briefly during the display
self-test every time you turn your key to the ON position. The
light will go off when the key is turned to the START position.
The light should stay off when the self-test is done if the engine
is running with normal oil pressure. If the light comes on while
the engine is running, you have lost oil pressure and continued
operation will cause severe engine damage.
*
[LG11020(ALL)03/95]
If you lose engine oil pressure:
*
[LG11030(ALL)03/95]1.
Pull off the road as soon as safely possible.
*
[LG11040(ALL)11/94]2.
Shut off the engine immediately. If you do not stop the
engine as soon as safely possible, severe engine damage
could result.
[LG11050(ALL)06/94]3.
Check the engine's oil level. (See ªChecking and Adding
Engine Oilº in theServicing Your Vehiclechapter of this
Owner Guide.) If you do not follow these instructions, you
or others could be injured. To ensure an accurate reading,
your vehicle should be on level ground.
[LG11060(ALL)10/93]4.
If the level is low, add only as much oil as necessary before
you start the engine again. Do not overfill. Do not operate
the engine if the light is on regardless of the oil level.
Contact your nearest dealer for further service.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
91
% [LG11255(ALL)03/94]
Low Windshield Washer Fluid Level Warning Light
[LG11257(ALL)11/93]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
[LG11258(ALL)03/94]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
[LG11260(ALL)12/93]
6 pica art:0050062-B
The low windshield washer indicator light
*
[LG11265(ALL)06/95]
Speed Control Indicator
[LG11270(ALL)05/95]
A SPEED CONTROL light is displayed in the optional electronic
instrument cluster when the speed control system is engaged.
The display will turn off when the brake pedal is pressed or if
speed control is shut off.
*
[LG11275(ALL)05/95]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when it is
active.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

94indicate at the top of the NORMAL band. This is also
acceptable.
[LG11700(ALL)04/95]
If, under any circumstances, the bars move above the NORMAL
band, the temperature symbol will flash and a chime will sound
to alert the driver that the engine coolant is overheating and
continued operation may cause engine damage.
*
[LG11800(ALL)01/95]
If your engine coolant overheats:
*
[LG11900(ALL)03/95]1.
Pull off the road as soon as it is safely possible.
*
[LG12000(ALL)03/95]2.
Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
*
[LG12100(ALL)05/95]3.
Let the engine cool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.
[LG12200(ALL)11/93]4.
Check the coolant level following the instructions on
checking and adding coolant to your engine in this Owner
Guide. Seeengine coolantin the index. If you do not follow
these instructions, you or others could be injured.
*
[LG12300(ALL)01/95]
If the coolant continues to overheat, have the coolant system
serviced.
[LG12400(ALL)06/94]
If the temperature gauge displays only the top two and bottom
two bars, the temperature indication system is indicating that it
requires servicing. Take the vehicle to a dealership for service as
soon as possible.
%*
[LG12600(ALL)01/95]
Fuel Gauge
[LG12700(ALL)03/94]
The fuel gauge displays approximately how much fuel you have
in the fuel tank. The number of bars illuminated in the display
indicates fuel level. Your ignition must be in the ON position to
read the fuel gauge. Read the fuel level at the top bar that is lit.
When only one bar on the gauge is lit, the fuel pump symbol
on the gauge will flash to warn you of a low fuel level
condition.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
95
[LG12800(ALL)10/93]
If the fuel gauge displays only the top two bars and bottom two
bars, or if the Distance to Empty function in the fuel computer
displays CO or CS, you must have the fuel indication system
serviced.
[LG12900(ALL)10/93]
Turn your ignition to OFF while fueling to obtain an accurate
fuel gauge indication. If you do not turn your ignition off, the
fuel gauge will not display the new fuel level immediately, but
will slowly increase to the correct value.
[LG13000(ALL)03/94]
7-1/2 pica art:0050156-B
The fuel gauge
%*
[LG13100(ALL)01/95]
Speedometer
[LG13200(ALL)08/94]
The electronic speedometer in the left center of the cluster has
two displays that indicate how fast your vehicle is moving in
miles or kilometers per hour. Press the fuel computer E/M
(English/Metric) button to switch between MPH and km/h. The
main digital speedometer indicates speed up to 120 MPH
(199 km/h). The secondary bar graph speedometer indicates
approximate speed up to 120 MPH in steps of 4 MPH
(180 km/h in steps of 6 km/h). The bar graph speedometer
shows your approximate speed relative to the full scale, and it
gives you a visual indication of how fast your speed is changing
when you accelerate or decelerate.
[LG13300(ALL)10/93]
Your vehicle may not actually be able to travel at the maximum
speeds indicated by the speedometer due to a speed limiter in
the Electronic Engine Control module. The purpose of the
limiter is to maintain vehicle speed below a specified limit to
ensure safe vehicle operation.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
