Driving Your Windstar
247
%*
[DR10200(ALL)01/95]
Driving in Bad Weather
%*
[DR10300(ALL)01/95]
Slippery roads
[DR10400(ALL)02/95]
n
Drive cautiously on wet or snowy roads.
*
[DR10500(ALL)03/95]
n
Do not quickly move the steering wheel unless necessary.
*
[DR10600(ALL)01/93]
n
Drive more slowly than you would normally.
[DR10650(ALL)02/95]
n
Do not use speed control.
*
[DR10700(ALL)01/95]
n
Give your vehicle more distance to stop.
*
[DR10800(ALL)01/93]
n
Use the ªsqueezeº technique for braking as described in
previous braking sections.
*
[DR10900(ALL)02/93]
n
Consider using one of the lower gears.
*
[DR11000(ALL)01/93]
RWARNING
To avoid skidding and losing control on slippery roads,
do not downshift into 1 (First) when you are moving
faster than 20 mph (30 km/h).
*
[DR11100(ALL)01/93]
RWARNING
The Anti-Lock Brake System may not prevent brake
lock-up on extremely slippery surfaces.
%*
[DR11200(ALL)01/95]
High water
*
[DR11300(ALL)05/90]
Do not drive through flooded areas unless you are sure that the
water is below the bottom of the wheel hubs.
*
[DR11400(ALL)01/93]
If you must drive through high water, drive slowly. You may
have limited traction or wet brakes so allow extra stopping
distance because your vehicle will not stop as quickly as usual.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

258
*
[DR20900(ALL)01/93]
Trailer towing tips
*
[DR21000(ALL)11/89]
Before starting on a trip, practice turning, stopping and backing
in an area away from heavy traffic. Get to know the ªfeelº of
the vehicle/trailer combination.
*
[DR21100(ALL)01/93]
Practice backing up. Back up very slowly, with someone outside
at the rear of your trailer to guide you. Place your hand at the
bottom of the steering wheel and move it in the direction you
want the rear of the trailer to swing. Slight movement of the
steering wheel results in a much larger movement of the rear of
the trailer.
*
[DR21200(ALL)11/89]
When turning, drive slightly beyond the normal turning point
so the trailer wheels will clear curbs or other obstructions.
*
[DR21300(ALL)01/93]
Allow more room for stopping with a trailer attached. Trailer
brakes should be applied first, whether manually or
automatically controlled, when approaching a stop.
*
[DR21400(ALL)01/93]
For an easy-to-operate vehicle/trailer combination, the trailer
tongue load should be approximately 10-15% of the loaded
trailer weight.
*
[DR21500(ALL)02/94]
Make a thorough check of your equipment before starting out
on the road. After you have traveled about 50 miles (80 km),
stop in a protected area and double-check your hitch and
electrical connections. Also check trailer wheel lug nuts for
tightness.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

Roadside Emergencies
267
%*
[RE03800(ALL)01/93]
Changing a Flat Tire
*
[RE03900(ALL)01/95]
If you get a flat tire while you are driving, do not apply the
brake heavily. Instead, gradually decrease the speed. Hold the
steering wheel firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off the ignition, set
the parking brake, and turn on the hazard flashers.
% [RE04000(ALL)02/95]
Using the Spare Tire
*
[RE04100(ALL)03/94]
Your vehicle has a temporary spare tire (unless you ordered the
optional full-size spare tire). This spare tire is smaller than a
regular tire and is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon as you can. This
spare tire is marked with the words TEMPORARY USE ONLY
so that you can easily identify it.
*
[RE04200(ALL)01/93]
RWARNING
If you use the temporary spare tire continuously or do
not follow these precautions, the tire could fail, causing
you to lose control of the vehicle, possibly injuring
yourself or others.
*
[RE04300(ALL)02/95]
When you drive with the temporary spare tire, DO NOT:
*
[RE04500(ALL)02/95]
n
exceed 50 mph (80 km/h) under any circumstances
*
[RE04600(ALL)01/93]
n
load your vehicle so that it is heavier than the maximum
vehicle load rating listed on the tire decal
*
[RE04700(ALL)01/93]
n
tow a trailer
*
[RE04800(ALL)01/93]
n
use tire chains
*
[RE04900(ALL)01/93]
n
try to repair the temporary spare tire or remove it from its
wheel
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

Servicing Your Windstar
303
*
[SV03700(ALL)02/95]
RWARNING
Do not start your engine with the air cleaner removed
and do not remove it while the engine is running.
%*
[SV03800(ALL)03/95]
To open the hood:
[SV03900(ALL)12/93]1.
Pull the hood release lever located below the instrument
panel to the left of the steering wheel.
[SV04000(ALL)11/93]
13-1/2 pica
art:0050053-B
Hood release lever location
[SV04100(ALL)10/93]2.
Go to the front of the vehicle and release the secondary
hood latch under the hood in the front center of the vehicle.
*
[SV04200(ALL)01/93]3.
Lift the hood and release the prop rod from its retaining
clip. Place the end of the prop rod in the prop rod hole
provided on the underside of the hood.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

Servicing Your Windstar
339
*
[SV33900(ALL)01/95]
RWARNING
Do not let the reservoir for the master cylinder run dry.
This may cause the brakes to fail.
%*
[SV34100(ALL)02/95]
Power Steering Fluid
*
[SV34200(ALL)01/95]
Check the level of the power steering fluid at least twice a
year (i.e., every Spring and Fall).
*
[SV34300(ALL)03/95]
To check the level of your power steering fluid:
[SV34400(ALL)02/95]1.
Start the engine and let it run until the power steering fluid
reaches normal operating temperature. The power steering
fluid will reach the right temperature after at least five
minutes of idling or at least one mile (1 km) of driving.
*
[SV34500(ALL)01/95]2.
While the engine idles, turn the steering wheel back and
forth several times. Make sure that the cap assembly is
installed at this time.
*
[SV34600(ALL)03/93]3.
Then turn the engine off.
*
[SV34700(ALL)01/93]4.
Check the fluid level in the power steering fluid reservoir.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

340
[SV34800(ALL)10/93]
13-1/2 pica
art:0050163-A
The power steering fluid cap
[SV34900(ALL)03/94]5.
If the power steering fluid is low, add fluid in small
amounts, continuously checking the level, until the fluid is
between the minimum (MIN) and maximum (MAX) lines on
the dipstick. Do not overfill.
[SV34950(ALL)10/93]6.
Make sure the cap is free of all dirt prior to re-installing to
prevent pump damage.
*
[SV35000(ALL)06/94]
Use only power steering fluid that meets Ford Specification
ESW-M2C33-F, such as Ford Premium Power Steering Fluid,
E6AZ-19582-AA or an equivalent Type F Automatic Transaxle
Fluid with a Ford registration number (an 8-digit number
beginning with ª2Pº printed on the fluid container).
*
[SV35100(ALL)03/95]
NOTE: If the power steering fluid is low, do not drive your
vehicle for a long period of time before adding fluid.
This can damage the power steering pump.
*
[SV35200(ALL)01/93]
If you must check the power steering fluid when it is cold,
make sure that the fluid reaches at least the minimum (MIN)
mark. The reading will only be accurate if the fluid temperature
is approximately 70Ê to100ÊF (21Ê to 38ÊC).
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

385
Index
Controls (continued)
steering column................... 129
Coolant (see Engine coolant)
drain and flush................... 323
preparing for storage................ 368
proper solution................... 321
refill capacities................... 363
specifications..................320, 365
temperature gauge................ 78,93
Cruise control (see Speed control)............ 137
Cupholder(s)..................... 187
Customer Assistance Center, Ford (U.S.)......... 284
D
Dashboard (see Instrument panel)............ 105
Daytime running light system............. 122
Defrost
rear window.................... 117
windshield..................... 106
Dispute Settlement Board................ 286
Doors........................ 143
door ajar warning light.............. 74,90
lubricant specifications................ 365
Driving under special conditions
bad weather.................... 247
heavy load..................... 248
high speed..................... 246
high water..................... 247
slippery roads................... 247
towing a trailer................... 249
E
Electrical system
operating when the engine is off............ 55
relays....................... 350
Electronic sound system
atenna....................... 128
File:wnixs.ex
Update:Tue Mar 19 08:12:49 1996

392
Mileage, calculating fuel economy............ 314
Mirrors
automatic dimming rearview mirror.......144, 190
heated....................... 190
rearview...................... 188
vanity mirror, illuminated.............. 191
Motorcraft parts.................... 364
O
Octane rating..................... 310
Odometer
description.................... 79,96
trip odometer..................... 80
Oil (see Engine oil).................. 316
On-board diagnostic (OBD II) system.......... 361
Order forms, service information............ 198
Overdrive...................... 237
P
Panic alarm feature, remote entry system........ 152
Parking brake
operation...................... 244
warning light................... 68,84
Parts (see Motorcraft Parts)............... 364
PCV valve, specifications................ 364
Power door locks................... 146
Power features
door locks..................... 146
lumbar support................... 170
mirrors....................... 189
seats........................ 169
windows...................... 160
Power steering
dipstick...................... 339
driving with power steering............. 240
fluid, checking and adding.............. 339
fluid, specifications................. 365
servicing...................... 240
