1996 FORD THUNDERBIRD engine

171
*
[DR09782( BC )01/95]
The Traction Assist
TM
system can be manually
turned off, to allow wheelspin if you want, by
pushing the TRACTION ASSIST switch (located
on the console) when the vehicle is not in the
Traction Assist
TM
mode. The word ªOFFº in the
switch will light up to indicate the system is off.
The Traction AssistTM
system will automatically
be on each time the engine is started. During
ordinary driving, it is recommended to leave the
system turned on. The Traction Assist
TM
system
will then always be ready to operate when
needed.
[DR09783( BC )03/94]
one third page art:0011288-A
The Traction Assist
TM
switch
[DR09785( BCGV)03/95]
During the Traction Assist
TM
function, which
most often occurs during low speed acceleration
on slippery surfaces, a noise may be heard
coming from the engine compartment. This noise
is created by the ABS pump and is normal and
may last for a few seconds during the
acceleration of the vehicle.
*
[DR09790( BCGV)03/95]
In general, this system improves your vehicle's
stability and acceleration performance when road
conditions warrant. Traction Assist
TM
is fully
effective up to approximately 25 mph
(40 km/h). At 25 mph (40 km/h) the function
begins to taper off until it no longer operates
above 34 mph (55 km/h).
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

172 [DR09793( BCGV)01/95]If the Traction Assist
TM
system is cycled
excessively, the system will shut down to
prevent the rear brakes from overheating.
During this shutdown period, the word OFF in
the traction assist switch will be illuminated
showing that the traction assist system is
inoperative. A cooling down period is required
to prevent damage to the rear brakes. This time
period varies and depends on brake usage
during the cooling down period. Anti-Lock
braking is not affected and will function
normally during the cool down period.
[DR09795( BCGV)05/95]
NOTE: Traction-Lok axles are not an available
option on vehicles equipped with
traction assist.
*
[DR09800( ALL)01/95]
Steering Your Vehicle
%*
[DR09900( ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[DR09950( ALL)04/95]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
*
[DR10000( ALL)01/95]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
[DR10200( BCGV)12/94]
Speed Sensitive Power Steering
(If equipped)
[DR10401( BC )06/94]
The steering system in 4.6L engine vehicles is
speed sensitive. This means that the steering
effort is light for parking and heavier for
highway driving. However, if you have to
swerve around an object or another vehicle, your
steering will have full power assist.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

175 [DR13500( BC )03/95]
one third page art:0010315-A
The parking brake
*
[DR13800( BCGV)05/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is securely
latched in P (Park).
[DR14050( BC )03/95]
To release the parking brake, press down on the
pedal until you hear a click. Lift your foot off
the pedal. The brake is now released and will
reset to lock the next time you press the pedal,
located below the lower left corner of the
instrument panel. The Brake System Warning
Light will glow if the parking brake is not fully
released when the engine is running.
*
[DR14200( ALL)03/95]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[DR14300( ALL)01/93]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

177
*
[DR16200( BCGV)01/93]
RWARNING
To avoid skidding and losing control on
slippery roads, do not downshift into First
(1) when you are moving faster than
20 mph (32 km/h).
*
[DR16225( ALL)03/95]
RWARNING
If your vehicle has speed control, do not
use it on slippery roads. You could lose
control of your vehicle and could injure
someone.
[DR16300(MBC )03/92]
If your vehicle gets stuck (for example, in mud
or snow), you may try to ªrockº it out of the
spot. Shift, in a steady rhythm, between forward
and reverse gears. At the same time, press
lightly on the accelerator.
*
[DR16400( ALL)05/95]
RWARNING
Do not spin the wheels at over 35 mph
(55 km/h). The tires may fail and injure a
passenger or bystander.
[DR16500( ALL)12/94]
By moving the vehicle backward and forward,
you may gain enough momentum to move out
of the spot. Do not rock the vehicle for more
than a few minutes. This may overheat the
engine, damage the transmission, or damage the
tires. If you are still stuck after a minute or two
of rocking, call for a tow truck.
%*
[DR16700( ALL)01/95]
High water
*
[DR16800( ALL)01/95]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel rims.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

184 %
*
[DR22600( ALL)01/95]
Driving While You Tow
*
[DR22650( ALL)01/95]
Be especially careful when driving while you
tow a trailer. Never drive faster than 45 mph
(70 km/h) when you tow in hilly country on
hot days. Also, anticipate stops so that you can
brake gradually.
[DR22950(MBC )09/93]
If you tow in Overdrive while riding through
hilly country, your vehicle may frequently shift
between Overdrive and Third gears. To prevent
your vehicle from shifting too much, depress the
Transmission Control Switch (TCS). This will
also give the engine more power going up hills
and better engine braking going down hills.
%*
[DR23000( ALL)01/95]
If you use the speed control while you are
towing on very long, steep grades, the speed
control may shut off.
*
[DR23100( ALL)01/95]
Servicing your vehicle if you tow
*
[DR23200( ALL)08/93]
If you tow a trailer for a long distance, your
vehicle will need to be serviced more frequently
than usual. Refer to theMaintenance Schedule and
Recordbooklet for additional information.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

185
Roadside Emergencies
%*
[RE00400( ALL)03/95]
Jump-Starting Your Vehicle
*
[RE00450( ALL)01/95]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start from a booster battery
to start your vehicle.
*
[RE00500( ALL)02/95]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[RE00600( ALL)02/95]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
%*
[RE00700( ALL)05/95]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[RE00800( ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996

186
*
[RE00900( ALL)05/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE01000( ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to jump-start
and connecting the jumper cables in the order they
are given. If in doubt, call for road service.
*
[RE01100( ALL)03/95]
Preparing Your Vehicle
[RE01150( ALL)11/90]
NOTE: also see label on battery.
*
[RE01200( ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01300( ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[RE01500( ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01600( ALL)02/95]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996

187 %
*
[RE01700( ALL)05/95]
Connecting the jumper cables
*
[RE01800( ALL)03/95]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[RE01900( ALL)04/95]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[RE02000( ALL)03/95]
3. Connect one end of the second cable to the
negative (s) terminal of the booster battery
Ð NOT to the discharged battery.
[RE02100( ALL)01/95]
4. Connect the other end of that cable to a
good metallic surface on the engine or frame
of the disabled vehicle making sure it is
clear of any rotating engine components. The
following illustrations show where you can
find a metallic surface.
*
[RE02200( ALL)05/95]
RWARNING
Do not connect the end of the second
cable to the negative (s) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996
