1996 FORD PROBE jump cable

170
*
[RE01010(ALL)06/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE01100(ALL)12/89]
RWARNING
Do not push-start your vehicle. You could
damage the catalytic converter. For further
information, seeJumper Cablesin the
Index.
*
[RE01200(ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
*
[RE01300(ALL)03/95]
Preparing Your Vehicle
*
[RE01400(ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01500(ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[RE01600(ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
File:prrep.ex
Update:Fri Jun 23 19:34:36 1995

171
*
[RE01700(ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01800(ALL)03/95]
5. Turn on the heater fan in both vehicles.
Press the DEFROST button. Turn off all
other switches and gauges.
%*
[RE01900(ALL)05/95]
Connecting the jumper cables
*
[RE02000(ALL)03/95]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[RE02100(ALL)04/95]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[RE02200(ALL)05/95]
3. Connect one end of the second cable to the
negative (-) terminal of the booster battery
Ð NOT to the discharged battery.
*
[RE02300(ALL)04/95]
4. Connect the other end of the second cable to
a good metallic surface on the engine or
frame of the disabled vehicle.
*
[RE02400(ALL)05/95]
RWARNING
Do not connect the end of the second
cable to the negative (-) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
File:prrep.ex
Update:Fri Jun 23 19:34:36 1995

172 [RE02500(ALL)02/92]
two third page art:0030135-CThe sequence for connecting the jumper cables
*
[RE02800(ALL)03/95]
Jump-Starting
*
[RE02900(ALL)03/95]
1. Make sure that the jumper cables are not in
the way of moving engine parts, then start
the booster vehicle. Run the engine at a
moderate speed.
*
[RE03000(ALL)03/95]
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle.
It may take a couple of tries before the
vehicle starts. If the vehicle does not start
after several attempts, there may be a
different problem.
File:prrep.ex
Update:Fri Jun 23 19:34:36 1995

173
*
[RE03100(ALL)03/95]
3. When both vehicles are running, let them
idle for a few minutes to charge the
discharged battery.
*
[RE03200(ALL)03/95]
Removing jumper cables
[RE03300(ALL)01/95]
1.Always remove the jumper cables in
reverse order.Remove the negative (-) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[RE03400(ALL)05/95]
2. Remove the negative (-) cable from the
booster battery.
*
[RE03500(ALL)03/95]
3. Remove the positive (+) cable from the
booster battery.
*
[RE03600(ALL)05/95]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[RE03700(ALL)04/95]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
You may need to use a battery charger to fully
recharge the battery.
*
[RE03750(ALL)03/95]
If you need to replace your battery, seeBattery
in theServicing Your Vehiclechapter.
*
[RE03800(ALL)03/95]
Changing a Tire
*
[RE03900(ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
File:prrep.ex
Update:Fri Jun 23 19:34:36 1995

Index 299
I
Identification Number, Vehicle (VIN) . . . 193
Idle
relearning.............. 173
speed................. 45
Ignition
positions of the ignition......... 37
removing the key............ 41
Infant seats (see Safety seats)........ 24
Instrument cluster............. 51
mechanical............... 52
Instrument panel
lighting up panel and interior...... 72
location of components......... 63
J
Jack
operation.............. 177
positioning.............. 177
Jump-starting your vehicle
attaching cables............ 171
disconnecting cables.......... 173
K
Keys
positions of the ignition......... 37
removing from the ignition....... 41
stuck in lock position.......... 37
L
Lamps
checking............... 256
daytime running light system...... 78
flashing the lamps........... 81
fog lamps............... 74
hazard flashers............. 81
high beams.............. 80
instrument panel, dimming....... 72
File:prixp.ex
Update:Fri Jun 23 19:30:26 1995
