1996 FORD PROBE engine

222 [SV18200(ALL)01/92]
half page art:0032038-BEngine coolant recovery reservoir and dipstick
*
[SV18500(ALL)01/95]
Adding engine coolant
*
[SV18600(ALL)05/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[SV18610(ALL)06/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
[SV18650(ALL)02/95]
Add engine coolant only to the recovery
reservoir Ð not to the radiator.If the coolant
level is low, add to the engine coolant recovery
reservoir container a 50/50 mixture of water and
the type of coolant that Ford specifies. Check the
coolant level again the next few times you drive
your vehicle.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

223 [SV18750(ALL)05/95]
RWARNING
Never remove the radiator cap or the
coolant system cap while the engine is
running or hot to avoid personal injury.
[SV20300(ALL)05/95]
2.5L Engine
[SV20305(ALL)04/95]
Before removing either cap, turn the engine off
and let it cool. Even when the engine is cool, be
careful when removing the caps.
[SV20310(ALL)04/95]
1. Locate the radiator breather cap and the
recovery reservoir cap in your engine
compartment. The cap on the left is the
radiator breather cap. The cap on the right is
the recovery reservoir cap.
[SV20320(ALL)04/95]
2. When the engine is cool, wrap a thick cloth
around the radiator breather cap and turn it
slowly to relieve pressure.
[SV20330(ALL)04/95]
3. Step back while the pressure releases.
[SV20335(ALL)04/95]
4. When you are sure all the pressure has been
released, use the cloth to turn and remove
cap.
[SV20340(ALL)04/95]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
[SV20345(ALL)04/95]
6. After the pressure has been released you
may open the recovery reservoir cap and
add engine coolant. Failure to follow this
procedure could result in serious personal
injury.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

224 [SV20350(ALL)05/95]2.0L Engine
*
[SV20355(ALL)03/95]
1. Before you remove the cap, turn the engine
off and let it cool. Even when the engine is
cool, be careful when you remove the
radiator cap.
*
[SV20360(ALL)05/95]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly
counterclockwise to the first stop.
*
[SV20370(ALL)03/95]
3. Step back while the pressure releases.
*
[SV20375(ALL)03/95]
4. When you are sure that all the pressure has
been released, use the cloth to turn and
remove cap.
*
[SV20380(ALL)03/95]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
*
[SV20390(ALL)01/95]
RWARNING
Failure to follow these instructions could
result in serious personal injury from hot
engine coolant or steam blowout and/or
damage to the engine cooling system or
engine.
*
[SV20400(ALL)02/95]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km). It is not
necessary and not recommended to use
supplemental coolant additives in your vehicle.
These additives may harm your engine cooling
system. Follow the recommended service interval
for changing your engine coolant.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

225
*
[SV20550(ALL)04/94]
NOTE: When you change or add engine
coolant, it is important to maintain
your engine coolant concentration
between 40%(-11ÊF [-24ÊC]) and 60%
(-62ÊF [-52ÊC]),depending on your local
climate conditions. Below 40% you will
lose freeze protection and above 60%
your engine may overheat on a warm
day.
[SV20570(ALL)05/95]
NOTE: Do not use an engine coolant that does
not meet all 14 requirements of Ford
specification ESE-M97B44-A. The use
of an improper coolant may void your
warranty for the engine cooling system.
Use only a premium nationally
recognized brand name engine coolant.
Do not use alcohol or methanol
anitifreeze. If you do not use the
proper coolant, the aluminum radiator
on your vehicle will corrode.
*
[SV20575(ALL)05/95]
Ford Motor Company expressly authorizes the
Ford Rotunda engine coolant recycling process
and chemicals. Use only Ford Rotunda recycled
engine coolant or an equivalent recycled engine
coolant that is certified by the supplier to meet
Ford specification ESE-M97B44-A.
%*
[SV20580(ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

226 %
*
[SV20600(ALL)01/95]
Use Ford Premium Cooling System Fluid or an
equivalent engine coolant that meets Ford
Specification ESE-M97B44-A. Do not use alcohol
or methanol antifreeze and do not use engine
coolant mixed with alcohol or methanol
antifreeze. If you do not use the proper coolant,
the aluminum radiator on your vehicle will
corrode.
*
[SV20700(ALL)04/93]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep an engine coolant in your
engine that has a protection rating of at least
-20ÊF (-29ÊC), orwhatever protection rating is
appropriate for the climate in which you live.
*
[SV20800(ALL)03/95]
To find out how much engine coolant mixture
your vehicle's coolant system can hold, seeRefill
capacities for fluidsin the Index.
*
[SV20900(ALL)02/95]
You may add water by itself only in an
emergency, but you should replace it with a
50/50 mixture as soon as possible.
*
[SV21000(ALL)01/95]
Have your dealer check the engine cooling
system for leaks if you have to add a quart
(liter) of engine coolant more than once a month.
*
[SV21200(ALL)05/95]
Engine coolant drain and flush
*
[SV21300(ALL)05/94]
The proper procedures to completely drain and
flush the engine cooling system can be found in
the Service Manual for your vehicle or you can
see your dealer. See the order form located
before this chapter. Follow these recommended
procedures to ensure that your vehicle has the
specified engine level and 50/50 mixture of
cooling system fluid and water.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

227 [SV21450(ALL)05/95]
Refilling the engine coolant Ð 2.0L engine
*
[SV21500(ALL)03/95]
When the entire engine cooling system is to be
drained and refilled, use the following
procedure:
*
[SV21600(ALL)01/89]
1. Remove the radiator cap.
*
[SV21700(ALL)06/89]
2. With the engine off and cool, add a 50/50
mixture of recommended engine cooling
system fluid and water until the radiator is
full.
*
[SV21800(ALL)07/93]
3. Replace and fully tighten the radiator cap,
then unscrew the cap to the first stop.
*
[SV21900(ALL)06/89]
4. Start and idle the engine until the radiator
upper hose is warm (this indicates the
thermostat is open and engine coolant is
flowing through the entire system).
[SV22000(ALL)04/95]
5. Shut the engine off and check the fluid level
in the radiator. Add more fluid if necessary.
[SV22005(ALL)03/94]
6. When the radiator is filled to the proper
level, replace the coolant system cap and
tighten both caps completely.
[SV22010(ALL)01/92]
Refilling the engine coolant Ð 2.5L engine
[SV22015(ALL)04/95]
When the entire cooling system is to be drained
and refilled, use the following procedure:
[SV22020(ALL)04/93]
1. Locate the radiator breather cap and the
coolant system cap in your engine
compartment. The cap on your right
(driver's side) is the radiator breather cap.
The cap on your left (passenger's side) is the
coolant system cap.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

228 [SV22025(ALL)04/95]
three fourths page art:0032104-BLocation of coolant system caps and coolant reservoir Ð
2.5L engine
[SV22028(ALL)02/92]
2. Remove the radiator breather cap and the
coolant system cap.
[SV22030(ALL)02/92]
3. With the engine off and cool, add a 50/50
mixture of recommended engine coolant
fluid and water to the radiator, using the
coolant system cap opening, until the
radiator is full. You should be able to see the
fluid through the radiator breather cap
opening.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

229 [SV22035(ALL)02/92]
4. Replace the radiator breather cap and the
coolant system cap and tighten to the first
stop.
[SV22050(ALL)02/92]
5. Start and idle the engine until the radiator
upper hose is warm. The warm hose
indicates the thermostat is open and the
engine coolant is flowing through the entire
system.
[SV22060(ALL)02/92]
6. Shut the engine off and check the fluid level
in the radiator through the coolant system
cap opening. Add more fluid if necessary.
[SV22070(ALL)02/92]
7. When the radiator is filled to the proper
level, replace the coolant system cap and
tighten both caps completely.
%*
[SV22100(ALL)11/94]
Checking hoses
*
[SV22200(ALL)01/89]
Check all engine and heater system hoses and
hose connections for deterioration, leaks, and
loose hose clamps as specified in the
maintenance schedule. Repair or replace with
Motorcraft hoses or equivalent as necessary.
%
*
[SV22300(ALL)03/95]
Windshield Washer Fluid and
Wipers
*
[SV22350(ALL)03/95]
Washer Fluid
[SV22500(ALL)01/95]
Check the level of the windshield washer fluid
every time you stop for fuel. The reservoir for
the windshield washer fluid is located in the
engine compartment. Visual inspection can
determine if the washer fluid is adequate. Do
not operate the washer when the reservoir is
empty.
