1996 FORD MUSTANG steering

187
wheels to continue to roll while you are slowing
down, which lets you steer properly.
[DR11300( ALL)03/95]
On vehicles without anti-lock brakes, extreme
braking can make the wheels lock and slide,
possibly decreasing your control of the steering.
If you lock the wheels, release the brake pedal
and repeat the ªsqueezeº technique.
[DR11310( ALL)05/95]
Braking with ABS brakes
[DR11400( ALL)03/95]
On vehicles with anti-lock brakes, the wheels
will not lock and slide when you press down
hard on the brake pedal. The anti-lock brakes
automatically start releasing and reapplying the
front brakes independently and the rear brakes
together whenever your wheels start to lock. Do
not ªpumpº the brake pedal on vehicles
equipped with anti-lock brakes. When this
happens, you will feel the brake pedal pulse.
This ªpulseº may be an unfamiliar feeling but it
is normal and indicates the ABS is working as
designed.
*
[DR11650( ALL)05/95]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[DR11700( ALL)09/95]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
%*
[DR11800( ALL)10/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

190
%*
[DR14500( ALL)01/95]
Driving Under Special Conditions
%*
[DR14600( ALL)01/95]
Tips for Safe Driving
*
[DR14700( ALL)07/95]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[DR14800( ALL)03/95]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
%*
[DR15200( ALL)01/95]
Driving in Bad Weather
%*
[DR15300( ALL)01/95]
Slippery roads
*
[DR15400( ALL)03/95]
Drive cautiously on wet or snowy roads:
*
[DR15500( ALL)03/95]
q
Do not quickly move the steering wheel
unless necessary.
*
[DR15600( ALL)01/95]
q
Drive slower than you normally would.
*
[DR15700( ALL)02/95]
q
Do not use speed control.
*
[DR15800( ALL)01/95]
q
Give your vehicle more distance to stop.
*
[DR15900( ALL)03/92]
q
Pump the brake pedal steadily and evenly to
avoid locking your wheels. (Does not apply
to vehicles with anti-lock brakes.)
*
[DR16000( ALL)02/93]
q
Consider using one of the lower gears.
*
[DR16100(M )05/95]
RWARNING
To avoid losing control on slippery roads,
do not downshift into Low with the
automatic transmission when moving
faster than 20 mph (32 km/h). Do not
downshift into First with the manual
transmission when moving faster than
5 mph (8 km/h).
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

205 [RE03810(M )09/95]
NOTE: If your vehicle is equipped with a 3.8L
engine you will need to perform
additional steps after your vehicle has
been jump started. SeeReadiness for
Inspection/Maintenance Testingin
Servicing Your Vehicle Chapter.
%
*
[RE03900( ALL)03/95]
Changing a Tire
*
[RE04000( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
%*
[RE04100( ALL)03/95]
The Temporary Spare Tire
[RE04225(MBC )03/94]
You have a high pressure temporary spare tire.
This spare tire is smaller than a regular tire and
is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon
as you can. This spare tire is marked with the
words ªTEMPORARY USE ONLYº so that you
can easily identify it.
*
[RE04250( ALL)01/95]
NOTE: Extended use of other than
conventional spare tires on a
Traction-Lok rear axle could result in a
permanent reduction in effectiveness.
This loss of effectiveness does not
affect normal driving and should not
be noticeable to the driver.
*
[RE04300( ALL)01/93]
RWARNING
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing
you to lose control of the vehicle, possibly
injuring yourself or others.
File:12rcrem.ex
Update:Wed Mar 27 09:34:49 1996

274 [SV33450(M )05/95]
one third page art:0011349-AThe brake fluid reservoir Ð 4.6L engines
*
[SV33700( ALL)01/95]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
*
[SV33750( ALL)01/95]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
%
*
[SV34800( ALL)03/95]
Power Steering Fluid
*
[SV34900( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
%*
[SV35000( ALL)03/95]
Checking and Adding Power Steering
Fluid
[SV35055(M )10/95]
3.8L SFI engine (check warm)
*
[SV35100( ALL)02/95]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

275
*
[SV35200( ALL)01/95]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[SV35300( ALL)05/95]
3. Turn the engine off.
%*
[SV35400(MBC )03/94]
4. Check the fluid level on the dipstick (which
is highlighted in yellow in your vehicle). The
fluid level should be between the arrows in
the FULL HOT range, which is marked on
the side of the dipstick, opposite the side
marked FULL COLD. Do not add fluid if the
level is within the FULL HOT range.
*
[SV35500(MBC )07/94]
5. If the power steering fluid is low, add fluid
in small amounts, continuously checking the
level, until you reach the FULL HOT range.
Do not overfill.
*
[SV35600(MBC )03/95]
6. When you are finished, put the dipstick back
in and make sure that it fits snugly.
[SV35700(MBC )12/94]
half page art:0010485-C
The dipstick for power steering fluid
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

276 [SV35875(M GV)03/95]Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX.
*
[SV35900( ALL)01/95]
If the power steering fluid is low, do not drive
your vehicle for a long period of time before
adding fluid. This can damage the power
steering pump.
*
[SV36100(MBC )02/95]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the FULL
COLD range on the dipstick. The reading will
only be accurate if the fluid temperature is
approximately 50 to85ÊF (10 to 30ÊC).
[SV36105(M )10/95]
NOTE: The brakes on the 4.6L engine vehicles
are powered by power steering fluid
from the power steering pump. The
fluid level in the power steering
reservoir will rise and fall due to the
amount of charge in the brake booster
accumulator. Therefore the following is
required.
[SV36157(M )10/95]
4.6L SFI engine (check cold)
[SV36170(MBC )03/95]
1. Check the fluid level when the system is
COLD (allow at least one half hour after
driving for the power steering fluid to cool).
[SV36171(MBC )10/95]
2. Locate the power steering reservoir mounted
to the front upper left-hand corner of the
engine.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

277 [SV36174(M )10/95]
NOTE: Brake fluid and power steering fluid
CAN NOT be mixed. Only add brake
fluid to the brake master cylinder
reservoir. Only add power steering
fluid to the power steering reservoir.
[SV36179(M )10/95]
3. Visually verify that the fluid level is above
the MIN line adjacent to the reservoir ªsight
window.º
[SV36183(M )10/95]
4. If the power steering fluid is below the MIN
line, remove the cap and add fluid in small
amounts until the level is between the MIN
and MAX lines.
[SV36186(M )10/95]
5. Reinstall the reservoir cap.
[SV36188(M)02/96]
It is normal for the fluid level to be above the
MAX line after the brake pedal has been pushed
several times with the engine off. (If you want
to double check it; restart the engine and turn
steering wheel to full right turn, the full left turn
and then turn engine off and re-check fluid
level. It should be between the MIN and MAX
line.)
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

278 [SV36195(M )10/95]
half page art:0011388-AFluid level for power steering
[SV36225(M )03/95]
Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX.
*
[SV36250(MBC )03/95]
NOTE: If the power steering fluid is low, do
not drive your vehicle for a long
period of time before adding fluid.
This can damage the power steering
pump.
% [SV36300(MBC )12/94]Fuses, High Current Fuses and
Circuit Breakers
*
[SV36400( ALL)03/95]
Fuses (conventional and high current) and circuit
breakers protect your vehicle's wiring system
from overloading. If electrical parts in your
vehicle are not working, the system may have
been overloaded and blown a fuse or tripped a
circuit breaker. Before you replace or repair any
electrical parts, check the appropriate fuses
(conventional and high current) or circuit
breakers.
