1996 FORD MUSTANG instrument panel

80 %
*
[IP00400( ALL)06/95]
The main controls for the climate control system,
clock, and radio are on the instrument panel.
%*
[IP00500( ALL)09/95]
NOTE: Any cleaner or polish that increases the
gloss (shine) of the upper part of the
instrument panel should be avoided.
The dull finish in this area is to help
protect the driver from undesirable
windshield reflection.
%
*
[IP00600( ALL)06/95]
The Climate Control Systems
[IP00700( ALL)03/91]
Your vehicle has one of two different climate
control systems. The two systems are:
[IP00710(M )06/93]
q
an optional heating and air conditioning
system
[IP01100(M )03/94]
q
a standard heating only system
*
[IP01400( ALL)06/95]
If you are not sure which system your vehicle
has, see the diagrams on the following pages.
% [IP01405(M )08/93]
The Optional Heating and Air
Conditioning System
[IP01410(M )08/93]
You can heat the inside of your vehicle, defrost
the windshield, and turn on the air conditioning
with the three knobs in the center of the
instrument panel:
[IP01415(M )08/93]
q
FAN
[IP01420(M )08/93]
q
TEMP
[IP01425(M )08/93]
q
SELECT
File:06rcipm.ex
Update:Wed Mar 27 09:30:23 1996

82 [IP01455(M )08/93]Under normal conditions, the SELECT knob
should be left in any position other than MAX
A/C or OFF when the vehicle is parked. This
allows the vehicle to ªbreatheº through the
outside air inlet duct.
% [IP01500(M )05/92]
The Heater Only System
[IP01600(M )01/89]
You can heat the inside of your vehicle, defrost
the windshield, or use the vents by adjusting the
three knobs in the center of the instrument
panel:
[IP01700(M )08/93]
q
FAN
[IP01800(M )08/93]
q
TEMP
[IP01900(M )08/93]
q
SELECT
[IP02000(M )05/95]
quarter page art:0010177-H
The knobs that control the standard heating only system
[IP02200(M )05/95]
To heat the inside of your vehicle, turn the
SELECT knob to FLOOR, turn the TEMP knob
all the way to the end of the red range (full
right) and turn the FAN knob to HI. After the
vehicle is warm, the temperature and blower
speed can be adjusted to maintain a comfortable
temperature.
% [IP02600(M )05/95]
To defrost the windshield and side windows,
turn the SELECT knob to Defrost symbol, turn
the TEMP knob to the end of the red range (full
right) and turn the FAN knob to HI.
File:06rcipm.ex
Update:Wed Mar 27 09:30:23 1996

83 [IP02700(M )05/95]
To heat the inside of your vehicle and defrost
the windshield and side windows at the same
time, turn the SELECT knob to MIX, turn the
TEMP knob into the red range, as required, and
turn the FAN knob to the desired speed between
LO and HI.
% [IP02800(M )05/95]
On mild days you may want to ventilate your
vehicle with outside air. Turn the SELECT knob
to VENT, turn the TEMP knob to the end of the
blue range (full left) and turn the FAN knob to
the desired speed. Air will be delivered through
the instrument panel registers.
[IP02900(M )03/94]
Under normal conditions, the SELECT knob
should be left in any position except OFF when
the vehicle is parked. This allows the vehicle to
ªbreatheº through the outside air inlet duct.
%
*
[IP31700(MBC )06/95]
Rear Window Defroster
(If equipped)
*
[IP32000( ALL)12/91]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window.
[IP32200(M )03/94]
The button for the rear window defroster is
located on the left side of the instrument panel
below the headlamp switch.
[IP32500(M )08/93]
one third page art:0010189-B
The button that controls the rear window defroster
File:06rcipm.ex
Update:Wed Mar 27 09:30:23 1996

87 %
*
[IP44500( ALL)01/95]
Lighting Up the Interior and Instrument
Panel
[IP44900(M )05/95]
With the headlamp knob in the parking lamps
or headlamps position, you can brighten or dim
the lights on the instrument panel. To do this,
rotate the headlamp knob clockwise (to dim the
lights) or counterclockwise (to brighten the
lights). Rotate the knob fully counterclockwise to
operate the interior lights.
[IP45150(M )03/95]
one third page art:0011307-A
The knob controls the light on the instrument panel and
the interior light
File:06rcipm.ex
Update:Wed Mar 27 09:30:23 1996

89 %
*
[IP47270( ALL)04/95]
Cleaning the Interior Lamps
*
[IP47290( ALL)04/95]
Your interior dome lamps and map lamps are
plastic and should be cleaned with a mild
detergent diluted in water. Rinse them with clear
water.
%
*
[IP47300( ALL)03/95]
Clock
[IP47455(M )05/95]
quarter page art:0011163-B
The digital clock
[IP47500( ALL)05/95]
1. To set the hour, press and hold the H
button. When the desired hour appears,
release the button.
[IP47600( ALL)05/95]
2. To set the minutes, press and hold the M
button. When the desired minute appears,
release the button.
%*
[IP49400( ALL)04/95]
Cleaning the Instrument Panel Lens
*
[IP49500( ALL)04/95]
Clean the instrument panel lens with a soft cloth
and a glass cleaner, such as Ford Ultra-Clear
Spray Glass Cleaner, or equivalent. Do not use
paper towel or any abrasive cleaner to clean the
lens as these may cause scratches.
File:06rcipm.ex
Update:Wed Mar 27 09:30:23 1996

92
*
[SC02301( ALL)03/95]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
*
[SC02401( ALL)08/95]
For lane changes, move the lever far enough to
signal but not to latch. The lever will return to
the off position when you release it.
%*
[SC02700( ALL)05/95]
High Beams
*
[SC02800( ALL)05/95]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[SC02900( ALL)05/95]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
[SC02955(M )06/93]
NOTE: The fog lamps will turn off if you put
high beams on while fog lamps are on.
%*
[SC03200( ALL)08/95]
Flashing the Lights
*
[SC03300( ALL)06/95]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
%
*
[SC03500( ALL)08/95]
Windshield Wipers and Washer
*
[SC03600( ALL)03/95]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
[SC03750( ALL)01/95]
Rotate the end of the lever away from you to
activate the wipers. The first seven detents are
interval wipe positions, the eighth detent is the
LO position and the ninth detent is the HI
position.
*
[SC03800( ALL)01/95]
To turn the wipers off, turn the knob toward
you to the OFF position.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

180 %
*
[DR01900( ALL)01/95]
Driving
[DR01945(M )05/95]
Your vehicle's gearshift is console-mounted on
the floor. The Transmission Control Switch (TCS)
is located on the console to the right of the
gearshift handle and is marked ªO/Dº. The
Transmission Control Indicator Light is located
on the instrument panel. You can put the
gearshift lever in any of the several positions.
[DR01951(MBC )03/95]
The OVERDRIVE OFF light is off (not
illuminated) during normal vehicle operation.
This allows the transmission to upshift and
downshift from 1st through 4th gears. When the
TCS is pressed, the Transmission Control
Indicator Light will illuminate (O/D OFF) on the
instrument panel. When this O/D OFF is
illuminated the transmission will upshift and
downshift from 1st through 3rd gears.
[DR01957( ALL)11/94]
If the O/D OFF light does not come ªonº when
the TCS is depressed or if the light ªFLASHESº
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transmission.
[DR01965(M )06/93]
To return the transmission to normal operation
(1st through 4th gear) depress the TCS marked
ªO/Dº again. This switch may be used to cancel
overdrive any time the vehicle is being driven.
Each time your vehicle is started, the overdrive
system will automatically be in the normal
overdrive mode and the light will not be
illuminated.
%*
[DR02010(MBC )05/95]
When to use D (Overdrive)
*
[DR02100( ALL)01/95]
Overdrive is the usual driving position for an
automatic overdrive transmission. It works the
same way Drive works, automatically upshifting
or downshifting as the vehicle speeds or slows.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

196 %
*
[DR21650( ALL)01/95]
Connecting the safety chains
*
[DR21700( ALL)01/95]
Always attach the trailer's safety chains to your
vehicle. They help protect your trailer if the
hitch breaks.
*
[DR21800( ALL)01/95]
To connect the trailer's safety chains:
*
[DR21900( ALL)01/95]
1. Cross the chains under the trailer tongue
and attach them to your vehicle's frame or
hook retainers. Never attach the safety
chains to your vehicle's bumper. The bumper
is not designed to bear the weight of a
trailer.
*
[DR22000( ALL)01/95]
2. Make sure that you leave enough slack in
the chains to allow you to turn corners.
*
[DR22100( ALL)01/95]
If you use a rental trailer, follow the instructions
that the rental agency gives you.
%*
[DR22150( ALL)01/95]
Connecting the trailer's brakes
*
[DR22200( ALL)01/95]
Electric brakes and manual, automatic, or
surge-type hydraulic brakes are safe if you
install them properly and adjust them according
to the manufacturer's instructions. Be sure that
your trailer's brakes meet local and federal
regulations.
[DR22250( ALL)03/95]
If your vehicle is equipped with the optional
trailer tow package, provisions have been made
under the instrument panel for installation of an
electronic brake controller.
*
[DR22300( ALL)05/95]
RWARNING
Do not connect a trailer's hydraulic brake
system directly to your vehicle's brake
system. Your vehicle may not have
enough braking power and your chances
of having a collision greatly increase.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996
