1994 TOYOTA CAMRY relay

17
1. NORMALLY
OPENOpens and
closes circuits,
thereby
stopping (1) or
allowing (2)
current flow.
RESISTOR
An electrical component with a
fixed resistance, placed in a circuit
to reduce voltage to a specific
value.
RESISTOR, TAPPED
A resistor which supplies two or
more different non adjustable
resistance values.
SENSOR (Thermistor)
A resistor which varies its
resistance with temperature.
SHORT PIN
Used to provide an unbroken
connection within a junction block.
SOLENOID
An electromagnetic coil which
forms a magnetic field when
current flows, to move a plunger,
etc.SWITCH, DOUBLE THROW
A switch which continuously
passes current through one set
of contacts or the other.
SWITCH,
IGNITION
A key operated switch with
several positions which allows
various circuits, particularly the
primary ignition circuit, to
become operational.
Wires are always
drawn as straight lines
on wiring diagrams.
Crossed wires (1)
without a black dot at
the junction are not
joined; crossed wires
(2) with a black dot or
octagonal (
) mark at
the junction are spliced
(joined) connections. RELAY, DOUBLE THROW
A relay which passes current
through one set of contacts or the
other.
SENSOR, ANALOG SPEED
Uses magnetic impulses to open
and close a switch to create a
signal for activation of other
components.TRANSISTOR
A solidstate device typically used
as an electronic relay; stops or
passes current depending on the
voltage applied at ªbase.º SWITCH, WIPER PARK
Automatically returns wipers to
the stop position when the wiper
switch is turned off. SWITCH, MANUAL SPEAKER
An electromechanical device
which creates sound waves from
current flow.
2. NORMALLY
CLOSED
RESISTOR, VARIABLE or
RHEOSTAT
A controllable resistor with a
variable rate of resistance.
Also called a potentiometer or
rheostat. 2. NORMALLY
OPEN RELAY
1. NORMALLY
CLOSEDBasically, an electrically
operated switch which may
be normally closed (1) or
open (2).
Current flow through a
small coil creates a
magnetic field which either
opens or closes an
attached switch.
(2) SPLICED WIRES
(1) NOT
CONNECTED

[Instrument Panel]
18
RELAY LOCATIONS
[Engine Compartment]

20
RELAY LOCATIONS
: J/B No. 1Instrument Panel Left(See Page 18)

22
RELAY LOCATIONS
: J/B No. 2Engine Compartment Left(See Page 18)

[J/B No. 3 Inner Circuit]
24
RELAY LOCATIONS
: J/B No. 3Behind Combination Meter(See Page 18)

(for 1MZ±FE)
(for 5S±FE)
26
RELAY LOCATIONS
5: R/B No. 5Engine Compartment Left(See Page 18)
6: J/B No. 6Behind Glove Box(See Page 18)

28
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
[1MZ±FE]
A 2 A/C Triple Pressure SW (A/C Dual and Single Pressure F 1 Front Airbag Sensor LH
SW) F 2 Front Airbag Sensor RH
A 3 A/C Magnetic Clutch and Lock Sensor F 3 Front Clearance Light LH
A 4 ABS Actuator F 4 Front Clearance Light RH
A 5 ABS Actuator F 5 Front Side Marker LH
A 6 ABS Relay F 6 Front Side Marker RH
A 7 ABS Relay F 7 Front Turn Signal Light LH
A 8 ABS Speed Sensor Front LH F 8 Front Turn Signal Light RH
A 9 ABS Speed Sensor Front RH F 9 Front Wiper Motor
F 10 Fuse Box
B 2 Brake Fluid Level SW F 16 Fuse Box
F 18 Fuse Box
C 2 Cruise Control Actuator
C 17 Camshaft Position Sensor G 1 Generator (Alternator)
C 18 Crankshaft Position Sensor G 2 Generator (Alternator)
D 1 Data Link Connector 1 (Check Connector) H 1 Headlight Hi LH
D 2 Distributor H 2 Headlight Hi RH
H 3 Headlight Lo LH
E 1 EGR Gas Temp. Sensor H 4 Headlight Lo RH
E 2 Electronic Controlled Transmission Solenoid H 5 Horn LH
E 4 Engine Coolant Temp. Sensor (EFI Water Temp. H 6 Horn RH
Sensor) H 11 Heated Oxygen Sensor (Bank 1 Sensor 1)
E 5 Engine Coolant Temp. Sensor (Water Temp. Sensor) H 12 Heated Oxygen Sensor (Bank 2 Sensor 1)
(for Cooling Fan)

30
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
[5S±FE]
A 1 A/C Condenser Fan Motor E 1 EGR Gas Temp. Sensor
A 2 A/C Triple Pressure SW (A/C Dual and Single Pressure E 2 Electronic Controlled Transmission Solenoid
SW) E 3 Electronic Controlled Transmission Solenoid
A 3 A/C Magnetic Clutch and Lock Sensor E 4 Engine Coolant Temp. Sensor (EFI Water Temp.
A 4 ABS Actuator Sensor)
A 5 ABS Actuator E 5 Water Temp. SW (for Cooling Fan)
A 6 ABS Relay
A 7 ABS Relay F 1 Front Airbag Sensor LH
A 8 ABS Speed Sensor Front LH F 2 Front Airbag Sensor RH
A 9 ABS Speed Sensor Front RH F 3 Front Clearance Light LH
F 4 Front Clearance Light RH
B 1 Back±Up Light SW (M/T) F 5 Front Side Marker LH
B 2 Brake Fluid Level SW F 6 Front Side Marker RH
F 7 Front Turn Signal Light LH
C 2 Cruise Control Actuator F 8 Front Turn Signal Light RH
F 9 Front Wiper Motor
D 1 Data Link Connector 1 (Check Connector) F 10 Fuse Box
D 2 Distributor F 16 Fuse Box
F 17 Fuse Box
F 18 Fuse Box
G 1 Generator (Alternator)
G 2 Generator (Alternator)
