1993 CADILLAC DEVILLE engine

Downloaded from www.Manualslib.com manuals search engine Export - Remove the retaining spring and raise it up, out of the way.
Export - Reinstall new bulb into headlamp housing assembly, reinstall
rubber grommet and wiring harness.
292
_-

Downloaded from www.Manualslib.com manuals search engine Domestic or Export - Insert the headlamp assembly bracket guide into
the retainer as shown.
Then position headlamp assembly and reinstall fasteners.

Downloaded from www.Manualslib.com manuals search engine Taillight Bulb Replacement
4. Remove the upper
I and lower tom
1
screws and remove
the bezel.

Downloaded from www.Manualslib.com manuals search engine 2. Push up on the
taillight housing and
gently remove
it.

Downloaded from www.Manualslib.com manuals search engine h
3. Press the bulb
housing lever,
rotate the housing
counterclockwise
1/6 turn and
remove it.
! ..: ’,
5
Y
4. Push and rotate bulb counterclockwise to remove bulb.
Once you have replaced the burned out bulb, just reverse the steps
to
reassemble the taillight.

Downloaded from www.Manualslib.com manuals search engine CENTER HIGH MOUNTED STOP MP
BULB REPUCEMENT
(Sedan Only)
To gain assess to the bulbs, gently pull the back panel located inside the
rear storage compartment.
Turn the socket
1/4 turn to remove it.

Downloaded from www.Manualslib.com manuals search engine I 2. Disconnect the
wiring harness
connector from the
socket.

Downloaded from www.Manualslib.com manuals search engine L
I 1
3. Remove the two
screws,
and then
remove
the
pedestal.
4. Remove the two
housing screws.
