1992 HONDA PRELUDE Owners Manual

Interior Care, Corrosion Protection
Windows
Clean the windows, inside and out,
with a commercially-available glass
cleaner. You can also use a mixture of one part white vinegar to ten
parts water. This will remove the
haze that builds up on the inside of
the windows. Use a soft cloth or
paper towels to clean all glass and
clear plastic surfaces.
The rear window defogger wires
are bonded to the inside of the glass.
Wiping vigorously up-and-down
can dislodge and break the defog-
ger wires. When cleaning the rear
window, use gentle pressure and
wipe side-to-side.
Air Fresheners

If you want to use an air freshener/
deodorizer in the interior of your
car, it is best to use a solid type.
Some liquid air fresheners contain
chemicals that may cause parts of
the interior trim and fabric to crack or discolor.
If you use a liquid air freshener,
make sure you fasten it securely so
it does not spill as you drive.
Corrosion Protection

Two factors normally contribute to causing corrosion in your car:
1. Moisture trapped in body cavi-
ties. Dirt and road salt that col-
lects in hollows on th
e underside
of the car stays damp, promotin
g
corrosion in that area.

2. Remova l
of paint and protective

coatings from the exterior and
underside of the car.

Many corrosion-preventive mea
-
sures are built into your Honda.
You can help keep your car from
corroding by performing some
simple periodic maintenance: Repair chips and scratches in the
paint as soon as you discover
them.
Appearance Care

NOTICEProCarManuals.comMain Menu Table of Contents s t

Corrosion Protection, Body Repairs
Inspect and clean out the drain
holes in the bottom of the doors
and body.
Check the floor coverings for
dampness. Carpeting and floor mats may remain damp for a long
time, especially in winter. This dampness can eventually cause
the floor panels to corrode.
Use a high-pressure spray to
clean the underside of your car.
This is especially important in
areas that use road salt in winter. It is also a good idea in humid
climates and areas subject to salt
air. Cars equipped with ABS
have a sensor and wiring at each
wheel. Be careful not to damage
them.

Have the corrosion-preventive
coatings on the underside of your
car inspected and repaired
periodically.
Body Repairs

Body repairs affect your car's
resistance to corrosion. If your car
needs repairs after a collision, pay
close attention to the parts used in
the repair and the quality of the
work.
Make sure the repair facility uses

genuine Honda replacement body
parts. Some companies make
sheetmetal pieces that seem to
duplicate the original Honda body parts, but are actually inferior in fit,
finish, and quality. Once installed,
they do not give the same high- quality appearance and level of
corrosion resistance. When reporting your collision to
the insurance company, tell them
you want genuine Honda parts
used in the repair. Although most insurers recognize the higherquality of original parts, some may
try to specify that the repairs be
done with the "lowest cost" parts

available. You should investigate

this before any repairs are begun.
Take your car to your authorized Honda dealer for inspection after
the repairs are completed. He can make sure that quality materials
were used, and that corrosion-
preventive coatings were applied to
all repaired and replaced parts.

Appearance Car e
ProCarManuals.comMain Menu Table of Contents s t

Taking Care of the Unexpected
This section covers the more- common problems that motorists
experience with their cars. It gives
you information about how to
safely evaluate the problem and
what to do to correct it. If the problem has stranded you on the
side of the road, you may be able to
get going again. If not, you will also
find instructions on getting your
car towed. Compact Spare Tire..................... 184
Changing a Flat Tire................... 185
If Your Engine Won't Start........ 190 Nothing Happens...................... 190
The Starter OperatesNormally................................ 191
Jump Starting................................ 191 If Your Engine Overheats.......... 193
Low Oil Pressure.......................... 195
Charging System Indication ...... 196
Check Engine Light..................... 197
Closing the Sunroof ..................... 198
Fuses............................................... 199 Checking and Replacing.........
200

Towing...........................................
202

Taking Car e
of the UnexpectedProCarManuals.comMain Menu s t

Compact Spare Tire

Your car has a compact spare tire
that takes up less space. Use this
spare tire as a temporary replace-
ment only. Get your regular tire
repaired or replaced and put back
on your car as soon as you can.
Check the inflation of the compact
spare tire every time you check the
other tires. It should be inflated to: 415 kPa (4.15 kg/cm2, 60 psi)
Follow these precautions whenever

you are using the compact spare

tire:

Do not exceed 50 mph (80 km/h)
under any circumstances. This tire gives a harsher ride and
less traction on some road sur-
faces than the regular tire. Use
greater caution while driving on

this tire.
Do not mount snow chains on the

compact spare.

The wheel
of the compact spare
tire is designed especially to fit
your car. Do not use your spare
tire on another car unless it is the
same make and model. The compact spare tire has a
shorter tread life than a regular
tire. Replace it when you can see
the tread wear indicator bars. The
replacement should be the same
size and design tire, mounted on
the same wheel. The compact spare
tire is not designed to be mounted
on a regular wheel, and the com- pact wheel is not designed for
mounting a regular tire.

Taking Care of the Unexpected
INDICATOR

LOCATION

MARK

TREAD WEARINDICATOR

BARProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire
If you
have a flat tire while driving,
stop in a safe place to change it.
Stopping in traffic or on the shoul-
der of a busy road is dangerous.
Drive slowly along the shoulder
until you get to an exit or an area to stop that is far away from the traf-
fic lanes.
1. Park the car on firm, level ground away from traffic. Turnon the hazard warning lights and
turn the ignition to LOCK (0). 2. Put the transmission in Park
(automatic) or Reverse (5-speed).
Set the parking brake.
3. Open the trunk. Raise the trunk floor by lifting up on the back

edge.

4. Take the tool kit out of the trunk. 5. Unscrew the wing bolt and take
the spare tire out of the trunk.

Taking Care of the Unexpected
CONTINUED

The car can easily roll off the

jack, seriously injuring anyone
underneath.

Follow the directions for chang-

ing a tire exactly, and never

get under the car when it is

supported only by the jack.
TRUNK FLOOR

JACK

SPARE TIRE

TOOL KITProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire
6. The jack is behind a cover in the right fender. Remove the cover
by turning the handle clockwise,
then pulling on the cover. 7. Turn the jack's end bracket
counterclockwise to loosen it,
then remove the jack. 8. Loosen the four wheel nuts 1/2
turn with the wheel wrench.

Taking Care of the Unexpected
HANDLE
COVER JACKProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire
9. Locate
the jacking point nearest
the tire you need to change. It is
pointed to by an arrow molded
into the underside of the body.
Place the jack under the jacking
point. Turn the end bracket
clockwise until the top of the
jack contacts the jacking point. Make sure the jacking point tab
is resting on the jack notch. 10.Use the extension and wheel
wrench as shown to raise the car
until the flat tire is off the
ground. 11.Remove the wheel nuts and flat
tire. Temporarily place the flat
tire on the ground with theoutside surface of the wheel
facing up. The outside surface
contacting the ground could
damage the wheel surface.

Taking Care of the Unexpected
CONTINUED

EXTENSION

JACKING

POINT
WHEEL

WRENCHProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire

12.Before mounting
the spare tire,

wipe any dirt off the mounting
surface of the wheel and hub
with a cloth.

13.Put on
the spare tire. Put the

wheel nuts back on finger-tight,
then tighten them in a crisscross
pattern with the wheel wrench
until the wheel is firmly against
the hub. Do not try to tighten
them fully.

14.Lower th e
car to the ground and

remove the jack.

Taking Car
e
of the Unexpected
BRAKE HUBProCarManuals.comMain Menu Table of Contents s t
