(e) Connect the following connectors:(1) Throttle position sensor connector
(2) w/ TRAC:Sub±throttle position sensor connector
(3) w/ TRAC: Sub±throttle actuator connector
27. REINSTALL HEATER WATER VALVE
(a) Install the water valve and bracket assembly with the 2 bolts.
(b) Install the engine wire clamp with the bolt.
(c) Connect the VSV connector.
28. REINSTALL RH NO.3 TIMING BELT COVER
(a) Install the 3 gaskets to the timing belt cover.
(b) Fit the portion A of the timing belt cover, matching it with the lower high±tension cord cover.
(c) Install the timing belt cover with the 3 bolts.
29. REINSTALL VSV FOR EVAP SYSTEM Install the VSV with the 2 bolts.
30. REINSTALL LH NO.3 TIMING BELT COVER
(a) Install the 3 gaskets to the timing belt cover.
(b) Install the cord grommet to the high±tension cord (from the LH ignition coil).
(c) Install the cord grommet to the timing belt cover.
(d) Fit the portion A of the timing belt cover, matching it with the lower high±tension cord cover.
(e) Install the timing belt cover with the 4 bolts.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±29
WhereEverybodyKnowsYourName

(b) Connect the tester probe of a timing light to the high ±tension
cord for No.6 cylinder.
(c) Using a timing light, check the ignition timing.
Ignition timing: 8 ± 12 5 BTDC @ idle
(Transmission in neutral position)
If the ignition timing is not as specified, check that following
conditions are normal:
w Throttle valve fully closed
w Continuity between terminals IDL1 and E2 of the throttle
position sensor
w Valve timing
(d) Remove the SST from the DLC1. SST 09843±18020
5. DISCONNECT TACHOMETER AND TIMING LIGHT FROM ENGINE
6. REINSTALL UPPER HIGH±TENSION CORD COVER
(a) Fit portion A of the upper high±tension cord cover matching the top of the lower high±tension cord cover.
(b) Push the front side of the upper high±tension cord cover, and
fit the front side claw groove of the upper high±tension cord
cover to the claw of the lower high ±tension cord cover.
(c) Install the upper high±tension cord cover with the 2 bolts.
±
1UZ±FE ENGINE ENGINE MECHANICALEG±33
WhereEverybodyKnowsYourName

Troubleshooting
If the CO/HC concentration does not comply with regulations,
perform troubleshooting in the order given below.
(a) Check main heated oxygen sensor operation.
(See MFI System on page EG±400)
(b) See the table below for possible causes, and then inspect and correct the applicable causes if necessary.
 CO HC Problems\
 \
Causes
 Normal High Rough idle\
 \
1. Faulty ignitions:








\


\

Incorrect timing
   \
 \
Fouled, shorted or improperly gapped plugs
   \
 \
Open or crossed high±tension cords
   \
 \
Cracked distributor cap
   \
 \
2. Incorrect valve clearance   \
 \
3. Leaky EGR valve








\


\
4. Leaky intake and exhaust valves
   \
 \
5. Leaky cylinder
 Low High Rough idle\
 \
1. Vacuum leaks:
   (Fluctuating HC reading)\
 \

PCV hose
   \
 \
EGR valve








\


\

Intake manifold
   \
 \
Throttle body
   \
 \
IAC valve
   \
 \
Brake booster line
   \
 \
2. Lean mixture causing misfire

High

High

Rough idle\


\
1. Restricted air filter
   (Black smoke from exhaust)\
 \
2. Faulty MFI systems:
   \
 \

Faulty pressure regulator
   \
 \
Clogged fuel return line
   \
 \
Defective ECT switch   \
 \
Faulty ECM








\


\

Faulty injector
   \
 \
Faulty throttle position sensor
   \
 \
Faulty volume air flow meter
V02130
EG±36±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

15. CHECK CYLINDER COMPRESSION PRESSURE
(a) Reconnect the battery negative (±) cable.
(b) Insert a compression gauge into the spark plug hole.
(c) Fully open the throttle.
(d) Wh ile cra n kin g th e en g in e , me a su re th e co mp re ssio npressure.
HINT: Always use a fully charged battery to obtain engine
speed of 250 rpm or more.
(e) Repeat steps (b) through (d) for each cylinder. NOTICE: This measurement must be done in as short a
time as possible.
Compression pressure:
1,226 kPa (12.5 kgf/cm
2, 178 psi) or more
Minimum pressure: 981 kPa (10.0 kgf/cm
2, 142 psi)
Difference between each cylinder: 98 kPa (1.0 kgf/cm
2, 14 psi) or less
(f) If the cylinder compression in one or more cylinders is low,pour a sm all amount of engine oil into the cylinder through the
spark plug hole and repeat steps (b) through (d) for cylinders
with low compression.
w If adding oil helps the compression, it is likely that the
piston rings and/or cylinder bore are worn or damage.
w If pressure stays low, a valve may be sticking or seating
is improper, or there may be leakage past the gasket.
(g) Disconnect the battery negative (±) cable.
16. REINSTALL SPARK PLUGS
Using a 16 mm plug wrench, install the 8 spark plugs.
Torque: 18 N Vm (180 kgf Vcm, 13 ft Vlbf)
17. R E C O N N E C T H I G H ± T E N S I O N C O R D S TO S PA R K
PLUGS
18. RECONNECT RH CAMSHAFT POSITION SENSOR CONNECTOR
(a) Connect the camshaft position sensor connector.
(b) Install the camshaft position sensor connector to the ignition
coil bracket.
EG±40
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

16. REMOVE HEATER WATER VALVE FROM BODY
(a) Disconnect the VSV connector.
(b) Disconnect the bolt holding the engine wire clamp to thewater valve bracket.
(c) Remove the 2 bolts, and disconnect the water valve and bracket assembly.
17. REMOVE THROTTLE BODY
(a) Disconnect the following connectors: (1) Throttle position sensor connector
(2) w/ TRAC:
Sub±throttle position sensor connector
(3) w/ TRAC: Sub±throttle actuator connector
(b) Remove the 2 bolts and 2 nuts, and disconnect the throttle body from the air intake chamber.
(c) Disconnect the following hoses, and remove the throttle body:
(1) PCV hose from throttle body
(2) Water bypass hose from throttle body
(d) Remove the throttle body gasket.
18. REMOVE AIR INTAKE CHAMBER
(a) Disconnect the following hoses: (1) Brake booster vacuum hose from union on air intake
chamber
(2) Vacuum hose (from VSV for heater water valve) from air
intake chamber
EG±80
±
1UZ±FE ENGINE ENGINE MECHANICAL
WhereEverybodyKnowsYourName

(l) Install the accelerator bracket with the bolt and stud bolt.
(m) Install 2 new gaskets and union with the union bolt.
Torque: 29 NVm (300 kgf Vcm, 22 ft Vlbf)
(n) Connect the following hoses:
(1) Brake booster vacuum hose to union on air intake cham-
ber
(2) Vacuum hose (from VSV for heater water valve to air in-
take chamber
29. INSTALL THROTTLE BODY
(a) Disconnect the following hoses: (1) PCV hose to throttle body
(2) Water bypass hose to throttle body
(b) Install a new gasket and throttle body with the 2 bolts and 2 nuts.
Torque: 18 N Vm (185 kgf Vcm, 13 ft Vlbf)
HINT: Use bolt 40 mm (1.57 in.) in length.
(c) Install the water bypass pipe (from the rear bypass joint) to the clamp on the engine wire cover.
(d) Connect the following connectors: (1) Throttle position sensor connector
(2) w/ TRAC: Sub±throttle position sensor connector
(3) w/ TRAC: Sub±throttle actuator connector
±
1UZ±FE ENGINE ENGINE MECHANICALEG±129
WhereEverybodyKnowsYourName

6. REMOVE THROTTLE BODY WITH INTAKE AIRCONNECTOR
(a) Disconnect the following hoses and connectors:(1) PCV hose
(2) Three vacuum hoses
(3) VSV (for EGR) connector
(4) Throttle position sensor connector
(5) IAC valve connector
(6) (w/ TRAC)
Sub±throttle position sensor connector
(7) (w/ TRAC) Sub±throttle actuator connector
(8) (USA spec. only)
EGR gas temperature sensor connector
(b) Remove the four bolts and two nuts holding the intake air connector to the intake chamber.
(c) Remove the VSV nut.
(d) Disc onnect the two water by±pass hoses from the
throttle body. Plug the hose ends.
(e) Remove the throttle body with the intake air connector and gasket.
7. REMOVE NO. 3 TIMING BELT COVER AND CYLINDER
HEAD REAR COVER
(a) Remove the oil filler cap.
(b) Using a 5 mm hexagon wrench, remove the ten bolts,No. 3 timing belt cover and cylinder head rear cover.
8. DISCONNECT HIGH±TENSION CORDS FROM SPARK PLUGS
(a) Remove the bolt holding the cord clamp from thecylinder head.
(b) Disconnect the two high±tension cord clamps from the No. 3 cylinder head cover.
(c) Disconnect the high±tension cords at the rubber boot. Do not pull on the cords.
NOTICE: Pulling on or bending the cords may damage
the conductor inside.
±
ENGINE MECHANICAL Engine Tune±UpEM±11
WhereEverybodyKnowsYourName

16. REINSTALL THROTTLE BODY WITH INTAKE AIRCONNECTOR
(a) Place a new gasket so the protrusion face the intakechamber, and set the throttle body with intake air
connector.
(b) Connect the two water by±pass hoses to the throttle body.
(c) Install the VSV nut.
(d) Install the air intake connector with the four bolts and two
nuts.
Torque: 21 N Vm (210 kgf Vcm, 15 ft Vlbf)
(e) Connect the following hoses and connectors:
(1) PCV hose
(2) Three vacuum hoses
(3) VSV (for EGR) connector
(4) Throttle position sensor connector
(5) IAC valve connector
(6) (w/ TRAC) Sub±throttle position sensor connector
(7) (w/ TRAC) Sub±throttle actuator connector
(8) (USA spec. only) EGR gas temperature sensor connector
17. REINSTALL THROTTLE BODY BRACKET Install the throttle body bracket with the four nuts.
Torque: 21 N Vm (210 kgf Vcm, 15 ft Vlbf)
18. REINSTALL EGR PIPE
(a) Install a new gasket and the EGR pipe with the two bolts.
Torque: 21 N Vm (210 kgf Vcm, 15 ft Vlbf)
(b) Tighten the union nut.
Torque: 64 N Vm (650 kgf Vcm, 47 ft Vlbf)
EM±18±
ENGINE MECHANICAL Engine Tune±Up
