1990 VOLVO 240 octane

Volvo 1990 240 Model

1 Data plate
2 Oil filler cap, engine
3 Oil dipstick, engine
4 Brake fluid reservoir
5 Washer fluid reservoir
6 Expansion tank, coolant
7 Battery
8 Oil reservoir, power steering
9 Fuse, engine control pg. 60 Fuel requirements
Unleaded Fuel

Each Volvo has a catalytic converter and must use only unleaded gasoline\
(as specified on the
instrument panel and by a label near the filter inlet). U.S. and Canadi\
an regulations require that pumps
delivering unleaded gasoline be labeled "UNLEADED". Only these pumps hav\
e nozzles which fit your
car's filler inlet. It is unlawful to dispense leaded fuel into a vehicl\
e labelled "unleaded gasoline only".

Leaded gasoline damages the catalytic converter and the oxygen sensor sy\
stem. Repeated use of leaded
gasoline will lessen the effectiveness of the emission control system an\
d could result in loss of emission
warranty coverage. State and local vehicle inspection programs will make\
detection of misfueling easier,
possibly resulting in emission test failure for misfueled vehicles.

Octane Rating

Volvo recommends the use of premium unleaded gasoline with an (R+M)/2 \
rating of 91. This is
generally equivalent to a Research Octane Number (RON) of 95 or higher\
.

Deposit Control Gasolines

Volvo recommends the use of gasolines that contain "Deposit Control" add\
itives. These additives are
specially formulated to prevent the build up of certain injector and int\
ake system deposits. Fuels
containing "Deposit Control" additives are usually advertised as contain\
ing them and may have
additional claims to "clean injectors and intake valves" or similar word\
ing.
file:///K|/ownersdocs/1990/1990_240/90240_13.htm (2 of 9)12/30/2006 8:\
25:08 AM

Volvo 1990 240 Model

Oil level between dipstick marks. The distance between the marks represe\
nts approx. 1 US qt. = 1 liter.
Fill with multigrade oil

Check without removing the cap that the brake fluid level is above the M\
in-mark. Brake and clutch fluid
DOT 4.

Coolant level between the expansion tank marks. Mixture: 50 percent anti\
-freeze and 50 percent water.

Washer fluid reservoir should be filled with water and solvent (wintert\
ime: windshield washer anti-
freeze).

Electrolyte level 1/4" - 3/8" (5 - 10 mm) above plates. Fill distilled\
water only, never acid. Check level
in conjunction with normal service or once a year.
Never operate engine in closed unventilated areas.

Changing a wheel, see pages 84, 85
a bulb, see pages 76-80
a fuse, see page 81

Fuel: Octane rating 95 RON Unleaded, 91 (R+M)/2
Min. 91 RON Unleaded, 87 (R+M)/2 Inside back cover
