Warning: Turn starting (ignition) switch OFF before replacing fuses. E\
xcessive heat may be created by
a short circuit. Care must be exercised while replacing blown fuses.

Some of the equipment listed below is optional

Refer to the fuse location chart at fuse box for fuses specific to your \
car.

1 Cigarette lighter, Power mirrors, Radio, Tailgate wiper/washer 8A
2 Windshield wiper/washer, Horn 16A
3 Heater blower 25A
4 Fuel feed (in-tank) pump, Lambda-sond heating element 8A
5 Turn signals, Back-up lights 16A
6 Main fuel pump relay 16A
7 Brake lights 8A
8 Central locking, Interior and glove compartment lights, Trunk and engi\
ne
compartment lights, Radio, Power antenna, Clock, Daytime running lights \
(Canada)* 8A
9 Hazard warning Flashers 8A
10 Power windows 16A
11 Heated rear window, 4th gear (automatic transmission) 16A
12 Air conditioning (with blower control), Power windows (relay),
Heated rear window (relay), Seat belt reminder, Cruise control 8A
13 Heated front seats, Daytime running lights - relay (Canada)* 16A
14 Rear fog lights 8A
15 Parking lights (left side), License plate light 8A
16 Parking lights (right side), Instruments and control panel lights, \
Shift indicator light 8A
Blade type fuse, serving LH-Jetronic fuel injection system. Located on t\
he left
wheel housing by the ignition coil 25A

* Note: Early production Canadian vehicles are not equipped with Daytime\
Running Lights.




Contents | Top of Page
file:///K|/ownersdocs/1990/1990_240/90240_16.htm (10 of 10)12/30/2006 \
8:25:10 AM

Volvo 1990 240 Model
Battery:
-capacity 450 A/90 min
Alternator:
-rated output 1120W, 80A Lights, 12 V US bulb
No. Power
Socket No.
of
bulbs
Headlights HBI/9004 45 W/65
W 2
Position lights, front 1157NA 21 W/24
cp
5 W/2.2 cp BaY 15d
2
Turn signals, front 1157NA 21 W/24
cp
5 W/2.2 cp BaY 15d
2
Turn signals, rear 1156 21 W/32
cp Ba 15 s
2
Brake light/ tail light 1157 21 W/31
cp
5 W/3 cp BaY 15d
2
High-mounted brake light 1156 21 W/32
cp Ba 15 s
1
Back-up lights 1156 21 W/32
cp Ba 15 s
2
Rear fog lights 1156 21 W/32
cp Ba 15 s
2
The following bulbs may be obtained from your nearest Volvo dealer:
file:///K|/ownersdocs/1990/1990_240/90240_20.htm (8 of 14)12/30/2006 8\
:25:15 AM

Volvo 1990 240 Model
Rear ash tray light 1.2 W W2x4.6d 1
License plate light, sedan 4 W Ba 9 s 2
License plate light,
wagon 5 W
S 8.5-8 2
Interior light 10 W S 8.5-8 1
Glove box light 2 W Ba 9 s 1
Instrument panel light 3 W W2.1x9.5d 2
Control panel light 1.2 W W2x4.6d 3
Shift positions, auto trans. 1.2 W W2x4.6d 1
Engine compartment light 15 W S 8.5-8 1
Trunk light 15 W S 8.5-8 1
Warning indicator lamps
Charging 1.2 W W2x4.6d 1
Turn signals 1.2 W W2x4.6d 2
Brake failure 1.2 W W2x4.6d 1
Parking brake 1.2 W W2x4.6d 1
Headlights 1.2 W W2x4.6d 1
Oil pressure 1.2 W W2x4.6d 1
