1990 VOLVO 240 light

Volvo 1990 240 Model
pg. 14 Starting (ignition) switch, Turn signals
Starting (ignition) switch/steering wheel lock

O Locked position: remove the key to lock the steering wheel.
I Intermediate position: certain circuits (heater blower, cigarette lig\
hter, accessories, etc.) on.
II Drive position: key position when engine is running.
III Starting position: release the key when engine starts. The key retur\
ns automatically to
drive position.
The steering wheel lock may be under tension when the car is parked. Tur\
n the steering wheel slightly to
free the ignition key.
A chime will sound if the starting key is in the ignition lock and the f\
ront door on the driver's side is
open. The chime will also sound if the headlights or parking lights are \
on when the door is open. The
chime goes off when the front door is closed.

file:///K|/ownersdocs/1990/1990_240/90240_03.htm (1 of 7)12/30/2006 8:\
25:02 AM

Volvo 1990 240 Model

Turn signals

1 Signal lever engaged for normal turns.
Note: A defective turn signal bulb will cause turn signal indicator and \
remaining signal lights to flash
more rapidly than normal.

2 Lane change position. In maneuvers such as lane changing, the driver c\
an flash the turn signals by
moving the turn signal lever to the first stop and holding it there. The\
lever will return to the neutral
position when released.

3 High and low beam switching (Headlight switch in position
).
Move the lever towards the steering wheel and release it.

3 Headlight flasher (Headlight switch in position
or 0).
Move the lever towards the steering wheel. The headlight high beam will \
be on until the lever is
released.
pg. 15 Rear fog lights, Lighting
file:///K|/ownersdocs/1990/1990_240/90240_03.htm (2 of 7)12/30/2006 8:\
25:02 AM

Volvo 1990 240 Model

Rear fog lights

The rear fog lights are considerably brighter than the normal tail light\
s and should be used only when
atmospheric conditions, such as fog, rain, snow, smoke or dust reduce th\
e daytime or nighttime visibility
of other vehicles to less than 500 ft. (152 meters). (The headlights \
must be switched on.)
Note: Local regulations governing the use of these lights may
vary.


Headlights and position lights

0 All lights off*
Parking lights on*
Headlights and parking lights on
Switch from upper to lower beams, and vice versa, by moving the turn sig\
nal switch lever on the left
side of the steering column towards the steering wheel. The parking ligh\
ts can be used without switching
on the starting (ignition) key.
* Canadian models equipped with daytime running lights: Headlights and p\
arking lights on when
file:///K|/ownersdocs/1990/1990_240/90240_03.htm (3 of 7)12/30/2006 8:\
25:02 AM

Volvo 1990 240 Model
starting (ignition) switch is switched on.


A chime will sound if the starting (ignition) key is in the switch loc\
k when the door is open. The chime
goes off when the driver's door is closed. If the headlight switch is in\
position
, all lights will go out
when starting (ignition) switch is switched off.

Instrument panel lamps rheostat

Clockwise - brighter
Counterclockwise - dimmer
pg. 16 Windshield wipers, Tailgate window wiper, Washer nozzles

Wiper/washer

1 Intermittent wiper
file:///K|/ownersdocs/1990/1990_240/90240_03.htm (4 of 7)12/30/2006 8:\
25:02 AM

Volvo 1990 240 Model
NOTE: the cruise control cannot be engaged at speeds below 22 mph (35
km).

3. Depress SET SPEED switch (2).

Operating brake pedal or clutch pedal (where applicable)
This will automatically disengage the cruise control. Previously selecte\
d cruise speed is retained in the
memory and by momentarily setting the switch to RESUME position that spe\
ed will be re-engaged.

If the cruise control is already engaged, the cruising speed can be incr\
eased by depressing the SET
SPEED button (2). The vehicle will then maintain the current speed.
WARNING!
The cruise control should not be used in heavy traffic or when driving o\
n wet or slippery roads.
If the gear shift is moved to Neutral while the cruise control is engage\
d, then depress the brake pedal
momentarily, or set the cruise control switch (1) to OFF. This will di\
sengage the cruise control and
prevent overreving the engine.
NOTE: When driving on a grade, actual vehicle speed may vary slightly fr\
om the set cruise control
speed.

Acceleration
Momentary acceleration, such as for passing, does not interrupt cruise c\
ontrol operation. The previously
selected speed will be maintained without having to set switch to RESUME\
.

To disengage the cruise control system:
Set switch (1) to position OFF, or depress brake pedal, or depress clu\
tch pedal (where applicable).
Switching off the starting (ignition) switch will automatically diseng\
age the cruise control system.




Contents | Top of Page
file:///K|/ownersdocs/1990/1990_240/90240_03.htm (7 of 7)12/30/2006 8:\
25:02 AM

Volvo 1990 240 Model
cleaner, otherwise damage to the printed circuit will occur.

Hazard warning flasher

The four-way flasher should be used to indicate that the vehicle has bec\
ome a traffic hazard.
Note: Regulations regarding the use of the hazard warning flasher may va\
ry from state to
state.
pg. 19 Parking brake

Parking brake (hand brake)

The lever is situated between the front seats. The brake is applied to t\
he rear wheels.
The PARKING BRAKE reminder light on the instrument panel comes on whenev\
er the parking brake
lever is not fully released and the ignition is on.
Always use the parking brake (hand brake) when parked.
In order to obtain the best possible performance of the parking brake, t\
he brake linings should be broken
in. (See section titled "Break-in period".)

file:///K|/ownersdocs/1990/1990_240/90240_04.htm (2 of 5)12/30/2006 8:\
25:02 AM

Volvo 1990 240 Model

Seat heaters

The front seats are equipped with electrically-heated backrests and seat\
cushions. The switches engage
the heating which then is thermostatically controlled. It switches on au\
tomatically when the temperature
drops below 60°F (15°C) and switches off at approx. 95°F (35\
°C). pg. 20 Cigarette lighter, Ash trays

Cigarette lighter

To operate, depress the knob fully. When the knob automatically releases\
, the cigarette lighter is ready
for use.
The starting (ignition) switch must be ON for the cigarette lighter to\
function.

file:///K|/ownersdocs/1990/1990_240/90240_04.htm (3 of 5)12/30/2006 8:\
25:02 AM

Volvo 1990 240 Model

Operating instructions are contained in the manuals associated with each\
model.
These manuals are placed in the cars when the equipment is installed.
Your Volvo Dealer will be able to assist you with any questions regardin\
g the operation of this
equipment.

Radio antenna mast
Note: Always lower the antenna mast when entering automatic car wash. Re\
tractable antennas should
be cleaned and lubricated every 5,000 miles (8,000 km). On fixed (rem\
ovable) mast antennas, be sure
to unscrew and remove the antenna before entering an automatic car wash \
or a garage with low
overhang.

The following information may help to explain differences between car ra\
dio reception and radio
reception in the home.

Signal sending
FM waves do not follow the earth's surface and do not bounce against the\
atmosphere as AM waves do.

Cross modulation
When receiving a weak signal in the vicinity of another, stronger signal\
, both stations may be received
simultaneously.

Weak reception (fading)
Because of the limited range of FM senders and the way FM waves spread, \
this problem usually occurs
with FM reception.
Mountains or similar obstacles can sometimes cause disturbances.

Multipath Distortion
FM Signals are typically "line-of-sight", and very reflective. Their ref\
lectivity to objects such as
buildings, mountains, even other passing vehicles, causes the condition \
known as multipath distortion.
This distortion is the result of the reflected signal, and the direct si\
gnal reaching your antenna at slightly
different times causing a cancellation of all signals. This condition wi\
ll sound like hissing, or static.
Very little can be done to eliminate this problem, however, lowering the\
treble on your radio could help
mask these disturbances thereby allowing you to achieve optimum pleasure\
from your audio system.
