1990 VOLVO 240 light

Volvo 1990 240 Model
Two lights will be illuminated for 4-8 seconds after the starting (igni\
tion) key is turned to driving
position. One light is located in the instrument cluster and one in the \
console between the front seats.
A chime will sound at the same time if the driver has not fastened his s\
eat belt. The front and rear
outboard seats are provided with self-retracting inertia-reel belts.

To buckle:
Pull the belt out from the retractor far enough to insert the latch plat\
e into the buckle until a distinct
snapping sound is heard. The belt should not be twisted or turned.
Note: The lap belt should sit low and tight under
abdomen.

To unfasten, depress red push-button in buckle and let the belts rewind \
into their retractors.

Before exiting the car, check that the seat belt retracts fully after be\
ing unbuckled. If necessary, guide
the belt back into its retractor slot.

The seat belt retractors are normally "unlocked",. The retractors will l\
ock up as follows:
l if belt is pulled out rapidly
l during braking and acceleration
l if the vehicle is leaning excessively
l when driving in turns
Check seat belt mechanism function as follows:
1. Attach the seat belt. Pull rapidly on the strap.

2. WARNING! Check other traffic before performing this
check.

Brake firmly from approximately 30 mph (50 km/h) or turn in a tight ci\
rcle while pulling on the belt.
In all the above checks you should not be able to pull the belt out.
file:///K|/ownersdocs/1990/1990_240/90240_06.htm (4 of 9)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model

A self-diagnostic system incorporated in the sensor monitors the SRS. If\
a fault is detected, the "SRS"
warning light will illuminate. the light is included in the warning/indi\
cator light cluster in the instrument
panel. Normally, the SRS warning light will be illuminated along with th\
e other warning/indicator lights
when the ignition key is turned to the ON position (position II), and \
go out a short time after the engine
has been started. Check that this light is functioning properly every ti\
me the car is started.

The following items are monitored by the diagnostic system:
l Sensor unit electronics integrity.
l Reserve energy supply.
l Diagnostic output circuit.
l System voltage.
l Integrity of system connectors.
l Mercury switch closure.
l Gas generator ignitor
WARNING! If the SRS warning light stays on after the engine has started \
or if it comes on while you
are driving, drive the car to the nearest authorized Volvo Dealer for in\
spection as soon as possible.
ATTENTION! SRS VEHICLE!
THIS CAR IS EQUIPPED WITH A SUPPLEMENTAL RESTRAINT SYSTEM. TO PROVIDE
CONTINUED RELIABILITY, CERTAIN ELEMENTS OF THE SUPPLEMENTAL RESTRAINT
SYSTEM SHALL BE SERVICED OR REPLACED BY 1999. SEE OWNERS MANUAL FOR
FURTHER INFORMATION.
VOLVO

There is no maintenance to perform on the SRS yourself. The only periodi\
c maintenance recommended
on the SRS is that the air bag module and the sensor unit should be repl\
aced every ten years and that the
other components in the system (wiring, connectors, etc.) should also \
be inspected at this time. This
service must be performed by an authorized Volvo dealer.
file:///K|/ownersdocs/1990/1990_240/90240_06.htm (8 of 9)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model
NOTE: The driver's door can only be locked using the
key.

The lock buttons should not be In the down (locked) position during dr\
iving. In case of an accident, this
may hinder rapid access to the occupants of the vehicle.



Child safety locks

The buttons are located on the rear door jambs.
A The lock functions normally.
B The door cannot be opened from the inside.
WARNING: In the event of an accident, the rear seat passengers cannot op\
en the doors from the inside
with the buttons in position B.

Wagon model contains child safety lock on tailgate. The lock differs fro\
m that shown above. See section
titled "Wagon, tailgate".
pg. 33 Trunk lid/light
file:///K|/ownersdocs/1990/1990_240/90240_07.htm (2 of 6)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model
To reconnect the lock to the central locking system:

Withdraw key in vertical position



Trunk light

A Light always off.
B Light on when trunk lid is open.
pg. 34 Hood, Long load storage


To open the hood
file:///K|/ownersdocs/1990/1990_240/90240_07.htm (4 of 6)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model

Pull the release handle (located under the left side of the dash).
Lift the hood slightly, insert a hand under the center line of the hood \
and depress the safety catch handle.
Open the hood.
Check that the hood locks properly when closing.



Long load storage (except wagon)

A flap in the rear seat makes it possible to carry "long loads" such as \
skis, etc.
WARNING!
When braking rapidly the load could be displaced and cause injury to occ\
upants. Sharp edges on the
load should be covered for protection. It is essential that the "load" b\
e secured safely. Use belts locked
around the folded down armrest (see illustration).
WARNING!
Do no place heavy objects on the rear window shelf. These objects can be\
come dangerous projectiles
in the event of sudden braking. Always secure large or heavy objects wit\
h the seat belts.

An optional, specially designed, storage bag should also be used to avoi\
d soiling or tearing the
upholstery. Please note that the flap in the rear seat is intended only \
for light loads such as skis, wood
etc.
file:///K|/ownersdocs/1990/1990_240/90240_07.htm (5 of 6)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model
pg. 35 Rear/side view mirrors


Rear view mirror

A Normal position
B Night position, reduces glare from following headlights



Side-view mirrors

A Adjustment up/down
B Adjustment sideways

file:///K|/ownersdocs/1990/1990_240/90240_08.htm (1 of 4)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model


Power mirrors

A Adjustment up/down
B Adjustment sideways

Avoid using ice scrapers made of metal as they can easily scratch the mi\
rror surface.
WARNING!
The mirrors should always be adjusted before driving. Objects seen in th\
e wide angle right side view
mirror are closer than they appear to be.
pg. 36 Interior light, Sunroof, Refueling


Interior light
file:///K|/ownersdocs/1990/1990_240/90240_08.htm (2 of 4)12/30/2006 8:\
25:04 AM

Volvo 1990 240 Model

1 Light always on.
2 Light always off.
3 Light is on when either of the front or rear doors are opened.

The wagon model has a slightly different kind of interior lamp housing. \

On certain models a time delay device illuminates the interior light for\
approx. 15 seconds after closing
the driver's door. This facilitates finding starting (ignition) switch\
, etc., during darkness.



Sunroof (certain models)

The sunroof is operated by a handle located between the sun visors.
Unfold the handle and turn it counter-clockwise to open, clockwise to cl\
ose.
For safety reasons, the handle should always be folded when driving.
