1
INSTRUMENT PANEL
Illustration instruments and controls
Warning and indicator light symbols
CONTROLS AND EQUIPMENT
Keys,
central locking system .... 7, 8
Doors 9
Rear lid 11
Windows, mirrors 12, 13 Safety belts, head restraints . . . .14,19
Seats 20 Luggage compartment, pedals . 28,29
Brakes, Transmission 29, 32 Differential lock 33
Automatic-transmission 35 Steering lock/ignition/starter switch . 38
Starting procedures 39 Instrument cluster 40
Warning/indicator lights 43 Switches 46 Emergency flasher 46
Light switch, turn signals .... 46,48
Cruise control 49
Windshield wipers 50 Ventilation/Heating 51
Air conditioning 54
Heater 57
Sliding roof 62
Roof-rack 68 VEHICLE OPERATION
Break-in period - and afterwards . . 69
Operate your vehicle safety 70
Operate your vehicle economically
and minimize pollution 72
Trailer towing 73 Driving with the all-wheel drive ... 75
VEHICLE CARE
Fuel tank, fuel supply 85,86
Vehicle care (exterior/interior) . . 90, 93 Maintenance, inspection intervals . . 95 Engine compartment lid,
engine compartment 97 Lubricants, engine oil 98,99
Engine oil filter 101
Transmission oil 102
Power steering 103
Cooling system 104 Brake fluid 108
Battery 109
Windshield washers/wipers . . . 112,113
Tires/wheels 114 Difficult operating conditions .... 120
Winter driving 121
Accessories 122
DO-IT-YOURSELF SERVICE
Jack and tools 123 Spare wheel 124
Changing a wheel 125 Fuses, bulbs 128, 130 Adjusting headlights
134
Installing,
replacing the radio . . . . 135
Emergency starting 136
Emergency towing 138
Lifting vehicle . . 140
TECHNICAL DESCRIPTION
Engine, transmission 142
Steering,
suspension, brakes,
body, chassis 143 Emission-control-system 144
TECHNICAL DATA
Engine, spark plugs .
V-belts capacities . . Dimensions
Weights
Vehicle identification 146
147
148
150 151
CONSUMER INFORMATION
Service manuals 152
GAS STATION INFORMATION
Location of servicing points 156
ALPHABETICAL INDEX 158
www.westfaliaT3.info - a useful website for owners and enthusiasts of VW Westfalia T25 / T3 Campervans
Downloaded from www.Manualslib.com manuals search engine
TECHNICAL DATA
ENGINE
DATA/SPARK PLUGS
Engine Maximum
output
SAE net 90 hp at 4800 rpm
Maximum torque SAE net 117,3 ft lb at 3200 rpm
No.
of cylinders 4
Displacement 129 CID (2109 cm3)
Stroke 2.99 in (76 mm)
Bore
3.70 in (94 mm)
Compression
ratio
Fuelf)
9.0:1
Compression
ratio
Fuelf)
Regular
unleaded
Sparkplugs
Bosch
W7CC0
Beru
14L-7CU/14L-7C
Champion
N288
1) Minimum octane rating and
further
details see page 86.
Notes
Spark
plugs are replaced during the Volks
wagen scheduled Maintenance service. If
you replace the spark plugs between the
Volkswagen
Maintenance services, the
following should be noted: • Engine, spark plugs and the ignition
system are matched. To avoid faulty opera
tion
or engine damage, use only Original
Volkswagen
spark plugs. It is especially important to note the number of electrodes
and heat value. • Since spark plug specifications may
change
for technical reasons during a cur
rent
model year, we recommend
that
you
obtain your spark plugs from a Volks
wagen dealer who has the latest informa
tion.
146
www.westfaliaT3.info - a useful website for owners and enthusiasts of VW Westfalia T25 / T3 Campervans
Downloaded from www.Manualslib.com manuals search engine
TECHNICAL DATA
V-BELTS
CAPACITIES
for waterpump/alternator. 9.5 x 1100 LA
Fuel
tank 16.0 gal/60 liters
for A/C compressor . . . 12.5x1153 LA Syncro:
for power steering .... 9.5 x 1080 18.5 gal/70 liters Noteg
Reserve
(of
total
capacity) >. .. 2.5 gal/10 liters
The V-belts are among the most severely Coolin3
sVstem186
^t/17-5 ll,ers
stressed
parts of a vehicle. The belts there- Automatic
fore have very high quality requirements. transmission fluid (ATF) 3.2 qt/3.0 liters
When replacing a belt, it is not sufficient to Windshield washer container 4.3 qt/4.2 liters
use
just
any belt of the same
size.
For safe
operation, use only Original Volkswagen
Rear
window washer container 1.1 qt/1.0 liters
V-belts
specially designed for your Engine oil
vehicle.
The correct belts can be obtained
with
filter
change 4.8 qt/4.5 liters at your Volkswagen dealership.
without
filter
change 4.2 qt/4.0 liters
Do
not
fill
above "max" mark.
The oil level should be checked while topping up.
Difference between "min" and "max" marks
on the dipsticks is approx. 1 qt/1 liter
www.westfaliaT3.info - a useful website for owners and enthusiasts of VW Westfalia T25 / T3 Campervans
Downloaded from www.Manualslib.com manuals search engine
I TECHNICAL DATA
DIMENSIONS
Station
Kombi
Camp-
Pick-up
Wagon
mobile
in mm in mm in mm in mm
Length 179.9 4570
179.9 4570 179.9
4570 179.9
4570
Width 72.6 1845
72.6 1845 72.6
1845 72.6 1845
Height (unladen) .... 77.2
1960 77.2
1960 81.6 2075 75.9 1930
Angle
of approach .... 21° 21° 21° 21°
Angle
of depature .... 19° 19° 19° 19°
Wheelbase
96.9 2460 96.9 2460 96.9 2460 96.9 2460
Front track 62.4
1585 62.4
1585 62.4 1585 62.4 1585
Rear
track 61.8 1570
61.8 1570
61.8 1570 61.8 1570
Ground
clearance
with
gross
vehicle weight
front
7.5
190 7.5 190
7.5 190 7.5 190
rear 8.0
204 8.0 204 8.0 204 8.0 204
Turning circle diameter . approximately 35
ft/10.7
(wall
to wall)
Ramp
angle 22° 22° 22° 22°
Ground
clearance is reduced by approximately 1.2 in (30 mm)
on vehicles having a lowered
chassis.
When driving up steep ramps, on rough roads, over curbs, etc. it is
important
to remember
that
some parts of your car are close
to the ground, such as spoilers or exhaust system components.
Be
sure to avoid damage.
148
www.westfaliaT3.info - a useful website for owners and enthusiasts of VW Westfalia T25 / T3 Campervans
Downloaded from www.Manualslib.com manuals search engine
TECHNICAL DATA
Syncro Station
Kombi Camp-
Pick-up
Syncro Wagon
mobile
in mm in mm in
mm in mm
Length 179.9 4570 179.9 4570 179.9
4570 179.9 4570
Width 72.6 1845
72.6 1845 72.6
1845 73.6 1870
Height (unladen) .... 78.3
1990 78.3 1990 82.8
1990 77.2
1960
Angle of approach .... 22°
22° 22°
22°
Angle of depature .... 19°
19° 19°
19°
Wheelbase 96.6
2455 96.6 2455 96.6
2455 96.6
2455
Front track 61.7
1568 61.7 1568 61.7
1568 61.4
1560
Rear track 61.4 1560 61.4
1560 61.4
1560 61.4
1560
Ground clearance with
gross vehicle weight front 8.5
215 8.5 215
8.5 215 8.5
215
rear 7.6 193
7.6 193
7.6 193
7.6 139
Turning circle diameter . approximately 36 ft/10.9 (wall to wall)
Wading depth 11.3 290 11.3 290
11.3 290 11.3
290
Ramp angle 24°
24° 24°
24°
When driving up steep ramps, on rough roads, over curbs, etc. it is important to remember that some parts of your car are close
to the ground, such as spoilers or exhaust system components. Be sure to avoid damage.
149
www.westfaliaT3.info - a useful website for owners and enthusiasts of VW Westfalia T25 / T3 Campervans
Downloaded from www.Manualslib.com manuals search engine
TECHNICAL DATA
WEIGHTS
The vehicle capacity weight (max. load), the
Gross
Vehicle Weight Rating
(GVWR),
and
the
Gross
Axle Weight Ratings
(GAWR)
for
front
and rear, are listed on the
Safety
Compliance Sticker on the
left
door-
jamb.
The gross vehicle weight rating includes the weight
of the
basic
vehicle plus
full
fuel tank,
oil and
coolant, plus max. load which combines passenger (150 pounds/
68 kg per designated seating position) and luggage weight. Luggage weight
is not
increased
by the use of a
roof rack,
unless
passenger capacity
is
reduced
accordingly.
The gross axle weight rating
is the
maxi mum load
that
can be applied
at
each axle
of the vehicle.
Syncro
When driving off-road,
the
Gross
Vehicle
Weight
(GVWR)
must
be
reduced
by 440
lbs (200 kg).
WARNING
•
The actual
gross
axle
weight
rating
at the
front
and rear axles should not
exceed the permissible weights, and
their
combination must not exceed the
Gross
Vehicle Weight Rating.
•
Exceeding permissible
weight
ratings can result in vehicle damage,
accidents and personal injury.
Note
The vehicle capacity weight figures apply when
the
load
is
distributed evenly
in the
vehicle (passengers
and
luggage). When
transporting
a
heavy load
in the
luggage
compartment,
the
load should be carried
as
near
to
the rear axle as possible so
that
the
vehicle's
handling
is not
impaired.
On no
account should
you
exceed
the
maximum
permissible axle loads
or the
maximum
gross
vehicle weight. Always remember
that
the vehicle's handing
will
be
affected by
the
extra
load,
and
adjust your speed accordingly.
Roof
weights
The maximum permissible roof weight
on
the station wagon
and
kombi
is 220 lb,
100
kg. The
roof luggage rack
on the
campmobile
with
pop-up roof allows only 110 lb/50 kg.
For
more details see page 68.
Maximum permissible
trailer
weights
Braked
trailer 900 kg (2,000 lb.) Unbraked trailer 600 kg (1,3201b.)
Tongue load 75 kg
(
1651b.)
Do not exceed the
weight
limitations of
your
trailer
hitch.
150
www.westfaliaT3.info - a useful website for owners and enthusiasts of VW Westfalia T25 / T3 Campervans
Downloaded from www.Manualslib.com manuals search engine
TECHNICAL
DATA
VEHICLE
IDENTIFICATION
The
Vehicle
Identification
Number
(VIN)
is
located on the instrument panel on the
driver's side so
that
it is visible
from
the
out
side
through the windshield.
The
safety
compliance
sticker
is
your assurance
that
your new vehicle
complies
with
all applicable Federal Motor
Vehicle
Safety Standards which were in effect at the
time
the vehicle was manufac
tured. You can
find
this sticker on the
left
doorjamb. It shows the month and year of
complete and incomplete (campmobile
only) production and the vehicle identifica
tion
number of your vehicle
(perforation)
as
well as the
Gross
Vehicle
Weight Rating
and the
Gross
Axle Weight Rating. The
Vehicle
Identification
Label
is
located on the
left
side under the
dash
board.
The label contains the following information:
1. Production control no.
2.
Vehicle identification no.
3.
Type code number
4.
Type designation
5.
Engine and transmission code
letter
6. Paint
no./Interior
7. Optional equipment nos.
Vehicle
data 2 to 7 are also found in your
Maintenance
booklet. The
Engine
Number
is
located on the
right
side of the engine
block.
151
www.westfaliaT3.info - a useful website for owners and enthusiasts of VW Westfalia T25 / T3 Campervans
Downloaded from www.Manualslib.com manuals search engine
ALPHABETICAL INDEX
page
Introduction 2
Instrument illumination 46
Instrument panel 4 Instruments 40
Interior light 63,133
Jack and tools 123 Jack points 126
Keys 7
Kickdown 37
Lane changer 48
License plate lights 133 Lifting vehicle 140
Light switch 46 Light alloy wheels 92
Lights 46,130
Locks 7
Lubricants 98
Luggage compartment 28
Maintenance 95
Maintenance booklet 2
Manual Transmission 32 Manual Transmission Oil 102
Mirrors 13
Notes to owner 2 page
Octane rating 86
Oil change 100
Oil filter changing 101 Oil pressure warning light 43
OXS (Oxygen sensor) 144
Parking 31,145
Parking brake 31 Pedals 29
Power steering 103
Power windows 12
Radio 5, 135
Rear lid 11 Rear seat bench/bed combination 26
Rear view mirrors 13
Rear window defogger 47
Rear window wiper/washer 50
Refill Tank 105
Reverse 32
Roof rack 68
Safe driving hints 70
Safety belts 14
Safety belts warning light 18
Safety compliance sticker 151
Seats 20 Secondary heat exchanger 53
Selector lever 35 page
Service manuals 152 Side marker lights 132
Sliding door 10 Sliding roof 62
Sliding windows 12
Snow chains 119 Spare wheel 124
Spark plugs 146
Speedometer 40
Speed ranges 69
Starter switch 38 Starting procedures 39
Steering lock 38
Stopping engine 39
Sunroof 62 Sun visors 67
Switches 46
Swivel seats 22 Syncro Differential lock 33
Driving with the-all-wheel-drive . . 75
Snow chains 119
Technical Information 142 Towing 139
Tachometer 41
Tail lights 132
Technical data 146
www.westfaliaT3.info - a useful website for owners and enthusiasts of VW Westfalia T25 / T3 Campervans
