1990 HONDA PRELUDE service indicator

Brakes

Brake System Design
The diagonally-separated dual service brake systemis designed so half the
system will still provide
braking action if the other
half fails.However, stopping the car with only half the system will require
more pedal pressure and pedal travel than normal. Also, the distance
required to stop will be longer using only half the brake system. If
the brakes fail suddenly, downshift to a lower gear for increased engine braking, and pull off the road as soon as possible.
It is dangerous to drive your car with a problem in either the
brake electrical or hydraulic system; have your dealer check
both systems if you suspect brake trouble. Do not ride the brakes, In other words, don't put your foot on
the brake pedal unless you intend to brake. This causes excessive brake wear and can damage, or lead to loss of braking
effectiveness through overheating. Your brake lights may also
confuse drivers behind you.Driving through deep water may affect the brakes.
Check their effectiveness by pressing the brake pedal gently.If the car does not slow down at the normal rate, continue
gently applying the brakes, while maintaining a safe speed, until
they dry out and normal performance returns.
Brake Wear
Both front and rear brakes should be inspected for wear at the
intervals shown in the maintenance schedule on page 78
When the brakes require maintenance, use only genuine Honda replacement parts or their equivalent.
Brake Wear Indicators
Your car is equipped with audible brake wear indicators. When the
brake pads need to be replaced, the wear indicators will make a "screeching" sound or a high pitch chirp.

NOTE:

Due to some driving habits or climates, brakes may "squeal" when
you first apply them or when you have them partially applied; this is normal, and does not indicate excessive wear. The wear indicator
makes a "screeching" sound while the brakes are applied.ProCarManuals.comMain Menu t s

The condition of the battery can be determined by checking the
test indicator. Service as required according to the label on the
battery.

Any corrosion around the positive and negative terminals should be washed off with a solution of baking soda and warm water. Dry the
terminals and then coat them with grease.
The battery gives off explosive gases; keep sparks, flames andcigarettes away. Provide adequate ventilation when charging orusing the battery in an enclosed space.
The battery contains sulfuric acid (electrolyte). Contact with skin or eyes may cause severe burns. Wear protective clothing
and a face shield.
— If electrolyte gets on your skin, flush with water.
— If electrolyte gets in your eyes, flush with water for at least
15 minutes and call a physician immediately.
Electrolyte is poisonous.
— If swallowed, drink large quantities of water or milk and follow with milk of magnesia or vegetable oil and call a physician.
KEEP OUT OF REACH OF CHILDREN.

Battery

TEST INDICATOR

TERMINAL
TERMINAL
ProCarManuals.comMain Menu t s

Index
(cont'd)
Air Conditioner

Operation.....................................
43

Service.......................................108

Air Filte
r ...........................................95
Air Pressure, Tires........................105
Aluminum Alloy Wheels...............111
Antifreeze ..................See
"Radiator coolant"
Anti Lock Brakes(ALB) ..................18 ALB Warning Light .....................
24

ALB Fluid
.....................................
99
Anti-theft Steering

Column Lock

System.........................................58

Appearance Care .........................
110

Ashtrays..........................................38
Audio System
.................................
47
Automatic Transmission

Driving Technique ......................68

Fluid.............................................87
Operation....................................67

Shift Lever

Position
Indicator .................................
21 Battery
Charging System Warning

Light.......................................23

Jump Starting ...........................119 Maintenance .............................100

Specification ........................... 126

Beeper System Fasten Seat Belt Beeper ............13
Key Reminder .............................58

Light Reminder Chime ................30

Belts,Seat...............See "Seat Belts"
Brake Lamp Warning Light.............25
Brakes Brake Failure Warning Light .......................................23
Brake Fluid...................................99
Brake System Design .................98
Brake Wear .................................98
Brake Wear Indicators................98

Parking Brake ..............................39

Parking Brake Warning Light .......................................23
Break-in Period ..................................2

Bulb

Replacement.............................103
Specification .............................126
Buzzer ............See "Beeper System"
Capacities......................................125

Care and Cleaning.........................110

Catalytic Converter .....................134
Certification Label ........................127

Chains,Tires ................................. 106

Child Restraint System ..................14
Cigarette Lighter .............................38

Clock................................................37

COMPACT Spare Tire .................114Coolant Temperature Gauge .........20
Cooling(with A/C) ...........................44 Cooling System ...............................88
Crankcase Emission ControlSystem ..........................................
130
Cruise Control
Opeartion...................................
35Indicator .....................................22
Defogger.........................................28
Defroster .........................................45

Dimmer Switch, Headlights...........31
Doors
Locks............................................3

Warning Light ............................25
Emergency
Changing Flat Tire ...................116

Hazard Warning System ..........33If the Retractable Headlights do not operate ...................123

If the Sunroof Won't
Close .....................................54
If Your Car Gets Stuck ...........122
Jump Starting .........................119Towing.....................................121Warning and
Indicator

Lights....................................21
ProCarManuals.comMain Menu t s

Keys
Door Locks ..................................3
Glove box ..................................39
Trunk Lid Lock ............................4
Ignition ........................................58

Key Reminder Beeper...............58Keys.............................................3
Lap/Shoulder Belts
................................Se
e "Seat Belts"

Light

Bulb Replacement...................103
Fuse Replacement ..................101
Light Reminder
Chime ..............30

Operation.................................30

Warning and Indicator Light
......................................................21
Locks

Fuel Filler Door ..........................56
Doors..........................................3

Glove Bo
x ..................................39

Trunk Lid......................................4

Anti-theft Steering

Column

Lock.......................................58

Lumbar Support,Driver's .................7
Maintenace Schedule
and

Records......................................76

Manual Transmission Maximum Allowable Speeds
....................................................66

Oil........................................86
Recommended Shift
Speeds

....................................................66

Shifting.....................................65

Meters Gauges.......See
"Gauges"
Mirrors Power Mirrors ...........................29
Rear View Mirrors ....................29 Numbers, Identification................ 127

Octane Rating,
Gasoline

.......................................... See "Fuel"
Odometer ........................................20Oil

Engine Oil ...................................83

Fluid Locations ..........................82Transmission Oil/Fluid ..............86Oil Pressure Warning Light.......22
Power Steering Fluid ................97
Operation In
Foreign Countries

..........................................................56

Panel Brightness Control ...............33
Parking Brake.................................
39

Power

Mirrors .......................................29
Steering .....................................
97

Windows................................40

PGM-FI System............................131
Pressures, Tire Inflation...............105
Preventive Service.......................

112
(cont'd)
Radiator Coolant .............................88

Radio ................................................47

Rear View Mirrors ..........................29
Rear Window Defogger ..................28
Reminder Lights
..........................See "Warning lights"ProCarManuals.comMain Menu t s

Tread Wear................................... 128

Trip Meter........................................20

Trunk.................................................4

Trunk Access From
Rear Seat ................................9

Trunk Lid......................................4
Trunk Light ................................34
Trunk-Open
Indicator Light .......................25

Turn Signals.....................................30

Vehicle Identification Number
....................................................127

Ventilation .......................................41
Warning Lights ................................21

Warranty Service .........................135
Washer
Reservoir Capacity ...................
27

Windshield Washer ...................27
Washing.........................................110

Waxing ..........................................111

Wheels...........................................111

Windows
Appearance Care....................
110

Power Windows .......................40

Windshield Defogger .......................28
Windshield Washer.........................27
Windshield Wipers ..........................27
Wiper Blades
...................................94

Wipers

Windshield Wipers ....................27
ProCarManuals.comMain Menu t s
