Radiator Cap Tester
Radiator Cap
30° or More
B04467
Radiator Cap Tester
- COOLINGRADIATOR
CO-15
1776 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ON-VEHICLE INSPECTION
1. REMOVE RADIATOR CAP
CAUTION:
To avoid the danger of being burned, do not remove the ra-
diator cap while the engine and radiator are still hot, as fluid
and steam can be blown out under pressure.
2. INSPECT RADIATOR CAP
NOTICE:

If the radiator cap has contaminations, always rinse
it with water.

Before using a radiator cap tester, wet the relief valve
and pressure valve with engine coolant or water.

When performing steps (a) and (b) below, keep the
tester at an angle of over 30° above the horizontal.
(a) Using a radiator cap tester, slowly pump the tester and
check that air is coming from the vacuum valve.
Pump speed: 1 push/(3 seconds or more)
NOTICE:
Push the pump at a constant speed.
If air is not coming from the vacuum valve, replace the radiator
cap.
(b) Pump the radiator cap tester, and measure the relief valve
opening pressure.
Pump speed: 1 push within 1 second
NOTICE:
This pump speed is for the first pump only (in order to close
the vacuum valve). After this, the pump speed can be re-
duced.
Standard opening pressure:
93 - 123 kPa (0.95 - 1.25 kgf/cm
2, 13.5 - 17.8 psi)
Minimum opening pressure:
78 kPa (0.8 kgf/cm
2, 11.4 psi)
HINT:
Use the tester's maximum reading as the opening pressure.
If the opening pressure is less than minimum, replace the radia-
tor cap.
3. INSPECT COOLING SYSTEM FOR LEAKS
(a) Fill the radiator with coolant and attach a radiator cap tes-
ter.
(b) Warm up the engine.
(c) Pump it to 118 kPa (1.2 kgf/cm
2, 17.1 psi), and check that
the pressure does not drop.
If the pressure drops, check the hoses, radiator or water pump
for leaks. If no external leaks are found, check the heater core,
cylinder block and head.
4. REINSTALL RADIATOR CAP

CO0IQ-06
A09750
P/S Air HoseRadiator
Reservoir Tank
Intake Air
Connector
Radiator Assembly
EVAP HoseV-Bank Cover
Engine Under Cover No.1
N´m (kgf´cm, ft´lbf) : Specified torque Generator
Drive Belt
A/C CompressorA/C Compressor
Connector
A/T Oil Cooler Hose
Fan with
Fluid Coupling
Fan Pulley
49 (500, 36)
5.0 (50, 43 in.´lbf)
18 (185, 13)
Air Hose
x 8Fan Shroud Fuel Return
Hose
20 (200, 15)
A/T Oil Cooler
Hose
A/C Discharge
Tube
Clamp
Bracket WireClamp
Clamp
Lower Radiator Hose
Bracket
- COOLINGWATER PUMP
CO-3
1764 Author
: Date
:
2004 LAND CRUISER (RM1071U)
WATER PUMP
COMPONENTS

B04470
RH No.3 Timing Belt Cover
LH No.3 Timing Belt CoverNo.2 Timing Belt Cover
Camshaft Position
Sensor Connector
Engine Wire
Oil Cooler Pipe
Timing Belt
Fan Bracket Drive Belt Timing Pulley
Timing Belt Tensioner Dust Boot
N´m (kgf´cm, ft´lbf) : Specified torqueCover Plate
7.5 (80, 66 in.´lbf)
16 (160, 12)
39 (400,29)
245 (2,500, 181)
32 (330, 24)
16 (160, 12)
7.5 (80, 66 in.´lbf)
Water Bypass
Hose
CO-4
- COOLINGWATER PUMP
1765 Author
: Date
:
2004 LAND CRUISER (RM1071U)

B04471
Generator Wire
Generator Connector
Wire Clamp
Generator
Crankshaft PulleyDrive Belt Tensioner
No.1 Timing Belt Cover
Timing Belt
Timing Belt Guide
(Crankshaft Angle Sensor Plate)No.2 Idler Pulley
Timing Belt Cover SpacerGasket
N´m (kgf´cm, ft´lbf) : Specified torque

Non-reusable partWater Inlet Housing
Assembly
Water Pump
O-Ring

Gasket
O-Ring
39 (400, 29)
34.5 (350, 25)
18 (185, 13)
21 (215, 15)
- COOLINGWATER PUMP
CO-5
1766 Author
: Date
:
2004 LAND CRUISER (RM1071U)

CO0IS-01
B04067Air HoleWa t e r
Hole
- COOLINGWATER PUMP
CO-7
1768 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT WATER PUMP
(a) Visually check the air hole and water hole for coolant leak-
age.
If leakage is found, replace the water pump and timing belt.
(b) Turn the pulley, and check that the water pump bearing
moves smoothly and quietly.
If necessary, replace the water pump.
2. INSPECT TIMING BELT COMPONENTS
(See page EM-20)

CO0IT-01
B04463
Connect
New O-Ring
B03030
Seal Width
2 - 3 mm
New O-Ring
CO-8
- COOLINGWATER PUMP
1769 Author
: Date
:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL WATER PUMP
(a) Install a new O-ring to the water bypass pipe end.
(b) Apply soapy water to the O-ring.
(c) Connect the water pump to the water bypass pipe end.
(d) Install the water pump and new gasket with the 5 bolts, 2
stud bolts and nut. Uniformly tighten the bolts, stud bolts
and nut in several passes.
Torque:
Bolt: 21 N´m (215 kgf´cm, 15 ft´lbf)
Stud bolt and nut: 18 N´m (185 kgf´cm, 13 ft´lbf)
HINT:
Use bolts 35 mm (1.38 in.) in length.
2. INSTALL WATER INLET AND INLET HOUSING AS-
SEMBLY
(a) Remove any old packing (FIPG) material and be careful
not to drop any oil on the contact surfaces of the water in-
let housing and water pump.

Using a razor blade and gasket scraper, remove all
the old packing (FIPG) material from the gasket sur-
faces and sealing groove.

Thoroughly clean all components to remove all the
loose material.

Using a non-residue solvent, clean both sealing
surfaces.
(b) Apply seal packing to the sealing groove of water inlet
housing as shown in the illustration.
Seal packing: Part No. 08826-00100 or equivalent

Install a nozzle that has been cut to a 2 - 3 mm (0.08
- 0.12 in.) opening.

Parts must be assembled within 5 minutes of ap-
plication. Otherwise the material must be removed
and reapplied.

Immediately remove nozzle from the tube and rein-
stall cap.
(c) Install a new O-ring to the water inlet housing.
(d) Apply soapy water on the O-ring.
(e) Attach the water inlet housing end to the front water by-
pass joint hole.

B04460
AB
- COOLINGWATER PUMP
CO-9
1770 Author
: Date
:
2004 LAND CRUISER (RM1071U)
(f) Install the water inlet and housing assembly with the 2
bolts. Alternately tighten the bolts.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
HINT:
Each bolt length is indicated in the illustration.
Bolt length:
76 mm (3.00 in.) for A
22 mm (0.87 in.) for B
3. INSTALL NO.2 IDLER PULLEY (See page EM-22)
4. INSTALL TIMING BELT (See page EM-22)
5. FILL WITH ENGINE COOLANT
6. START ENGINE AND CHECK FOR ENGINE COOLANT
LEAKS
7. RECHECK ENGINE COOLANT LEVEL

CO0IR-01
B04460
B04461
CO-6
- COOLINGWATER PUMP
1767 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. DRAIN ENGINE COOLANT
2. REMOVE TIMING BELT (See page EM-15)
3. REMOVE NO.2 IDLER PULLEY (See page EM-15)
4. REMOVE WATER INLET AND INLET HOUSING AS-
SEMBLY
(a) Disconnect the water bypass hose from the water inlet
housing.
(b) Remove the 2 bolts holding the water inlet housing to the
water pump.
(c) Disconnect the water inlet housing from the front water
bypass joint, and remove the water inlet and inlet housing
assembly.
(d) Remove the O-ring from the water inlet housing.
5. REMOVE WATER PUMP
(a) Remove the 5 bolts, 2 stud bolts, nut, water pump and
gasket.
(b) Remove the O-ring from the water bypass pipe.
