2023 TOYOTA COROLLA HYBRID horn

1463-4. Adjusting the steering wheel and mirrors
3-4.Adjusting the steering wheel and mirrors
1Hold the steering wheel and
push the lever down.
2 Adjust to the ideal position by
moving the steering wheel
horizontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
To sound the horn, press on or
close to the mark.
Steering wheel
Adjustment procedure
WARNING
■Caution while driving
Do not adjust the steering wheel
while driving.
Doing so may cause the driver to
mishandle the vehicle and cause
an accident, resul ting in death or
serious injury.
■After adjusting the steering
wheel
Make sure that the steering wheel
is securely locked.
Otherwise, the steering wheel
may move suddenly, possibly
causing an accident, and resulting
in death or serious injury. Also,
the horn may not sound if the
steering wheel is not securely
locked.
Horn

4067-2. Steps to take in an emergency
One of the following may be the
cause of the problem:
Vehicles with a smart key sys-
tem: The electronic key may
not be functioning properly.
( P.408)
 There may not be sufficient
fuel in the vehicle’s tank.
Refuel the vehicle.
 There may be a malfunction
in the immobilizer system.
( P. 8 7 )
 Vehicles without a smart key
system: There may be a mal-
function in the steering lock
system.
 Vehicles with a smart key sys-
tem: The hybrid system may
be malfunctioning due to an
electrical problem such as
electronic key battery deple-
tion or a blown fuse. However,
depending on the type of mal- function, an interim measure
is available to start the hybrid
system. (
P.406)
One of the following may be the
cause of the problem:
 The 12-volt battery may be
discharged. ( P.410)
 The 12-volt battery terminal
connections may be loose or
corroded. ( P.323)
One of the following may be the
cause of the problem:
 The 12-volt battery may be
discharged. ( P.410)
 One or both of the 12-volt bat-
tery terminals may be discon-
nected. ( P.323)
Contact your Toyota dealer if the
problem cannot be repaired, or if
repair procedures are unknown.
When the hybrid system does
not start, the following steps can
If the hybrid system
will not start
Reasons for the hybrid sys-
tem not starting vary
depending on the situation.
Check the following and
perform the appropriate
procedure:
The hybrid system will not
start even though the cor-
rect starting procedure is
being followed. ( P.172)
The interior lights and
headlights are dim, or the
horn does not sound or
sounds at a low volume.
The interior lights and
headlights do not turn on,
or the horn does not
sound.
Emergency start function
(vehicles with a smart key
system)

465What to do if... (Troubleshooting)
(P.172)
 Is the electronic key any-
where detectable inside the
vehicle? ( P.136)
 Is the electronic key battery
weak or depleted?
In this case, the hybrid system can
be started in a temporary way.
(  P.409)
 Is the 12-volt battery dis-
charged? ( P.410)
 Is the power switch in ON?
If you cannot release the shift lever
by depressing the brake pedal with
the power switch in ON. ( P.181)
 It is locked to prevent theft of
the vehicle if the key is pulled
from the power switch.
( P.171)
 Is the window lock switch
pressed?
The power window except for the
one at the driver’s seat cannot be
operated if the win dow lock switch
is pressed. ( P.152)
 The auto power off function
will be operated if the vehicle
is left in ACC or ON (the
hybrid system is not operat-
ing) for a period of time.
( P.176)
 The seat belt reminder light is
flashing
Are the driver and the passenger
wearing the seat belts? ( P.375)
 The parking brake indicator is
on
Is the parking br ake released?
(  P.183)
Depending on the situation,
other types of warning buzzer
may also sound. ( P.372, 382)
 Did anyone inside the vehicle
open a door during setting the
alarm?
Do one of the following to deac-
tivate or stop the alarms:
 Unlock the doors.
 Turn the power switch to ACC
or ON, or start the hybrid sys-
The shift lever cannot be
shifted from P even if you
depress the brake pedal
The steering wheel can-
not be turned after the
hybrid system is stopped
(vehicles without a smart
key system )
The windows do not open
or close by operating the
power window switches
The power switch is
turned off aut omatically
( v e h i c l e s w i t h a s m a r t k e y
system)
A warning buzzer sounds
during driving
An alarm is activated and
the horn sounds

471Alphabetical Index
Fuses ....................................... 354
G
Gauges ................................ 96, 99
Glove box ................................ 289
Glove box light ....................... 289
H
Head restraints ....................... 144
HeadlightsAHB (Automatic High Beam) 191
Light switch .......................... 189
Headlights/daytime running lightsReplacing light bulbs ............ 357
Heated steering wheel ........... 284
Heaters Automatic air conditioning sys-tem ..................................... 278
Heated steering wheel ......... 284
Outside rear view mirrors ..... 280
Seat heaters ......................... 284
High mounted stoplight Replacing light bulbs ............ 357
High-voltage components ....... 82
Hill-start assist control .......... 266
Hood Open .................................... 316
Hooks Coat hooks ........................... 299
Retaining hooks (floor mat) .... 24
Horn ......................................... 146
Hybrid battery (tr action battery)
Location.................................. 82
Specification ......................... 422
Warning message .................. 86
Hybrid battery (traction battery) air intake vent ....................... 347
Hybrid battery (traction battery) air vents .................................. 85 Hybrid system ....
.......................77
Emergency shut off system ....86
Energy monitor/consumption screen................................. 116
EV drive mode ......................178
High voltage components .......82
Hybrid system precautions .....82
If the hybrid sys tem will not start
...........................................406
Overheating ..........................415
Power (ignition) switch .170, 172
Predictive efficient drive .........80
Regenerative braking .............78
Starting the hybrid system ..170, 172
Hybrid System Indicator ........104
Hybrid transmissio n ...............180
Hybrid vehicle dri ving tips.....271
I
I/M test .....................................312
Identification
Engine ..................................421
Vehicle ..................................420
Ignition switch (power switch) .......................................170, 172Auto power off fun ction .........176
Changing the power switch modes.................................176
If your vehicle has to be stopped in an emergency .................363
Illuminated entry system .......287
Immobilizer system ..................87
Indicators ..................................94
Initialization Items to initialize ...................452
Maintenance .........................309
Power windows ....................150
Inside rear view m irror ...........147
Instrument panel light control98, 101
