2023 SUBARU BRZ sensor

SRS Airbag (Supplemental Restraint System Airbag)
88
- Right-hand side
- Left-hand side
 Airbag control module (including
impact sensor and rollover sensor)
 Frontal airbag module
- Driver’s side
- Front passenger’s side
 Knee airbag module
- Driver’s side
 Side impact sensor
- Center pillar left-hand side
- Center pillar right-hand side
- Forward of rear wheel house left-
hand side
- Forward of rear wheel house right-
hand side
- Door left-hand side
- Door right-hand side
 Side airbag module
- Driver’s side
- Front passenger’s side
 Curtain airbag module
- Right-hand side
- Left-hand side
 Front seatbelt pretensioner and adap-
tive force limiter
- Front passenger's side
 Front seatbelt pretensioner
- Driver's side
 Seatbelt buckle switch
- Front passenger’s side 
Front passenger’s occupant detection
sensor
 Front passenger’s frontal airbag ON
and OFF indicator
 All related wiring
■ SRS Airbag System
Servicing
WARNING
If the warning light exhibits any of
the following conditions, immedi-
ately stop the vehicle in a safe
place, and consult a SUBARU
dealer. Unless a technician checks
and repairs the system as needed,
the seatbelt pretensioners and/or
the SRS airbag will not operate
properly in the event of a collision,
which may result in injury. Flashing or flickering of the
warning light No illumination of the warning
light when the ignition switch is
first turned to the “ON” position Continuous illumination of the
warning light Illumination of the warning light
while driving
WARNING
 When discarding an airbag
module or scrapping the entire
vehicle damaged by a collision,
consult your SUBARU dealer. The SRS airbag has no user-
serviceable parts. Do not use
electrical test equipment on any
circuit related to the SRS airbag
system. For required servicing of
the SRS airbag, consult your
nearest SUBARU dealer.
Tampering with or disconnecting
the system’s wiring could result
in accidental inflation of the SRS
airbag or could make the system
inoperative, which may result in
serious injury.
CAUTION
If you need service or repair in
areas indicated in the following list,
have the work performed by an
authorized SUBARU dealer. The
SRS airbag control module, impact
sensors and airbag modules are
stored in these areas.
BRZ_U.book 88 ページ ２０２２年３月２９日　火曜日　午後３時５９分

SRS Airbag (Supplemental Restraint System Airbag)
90
Always consult your SUBARU dealer if
you want to install any accessory parts on
your vehicle.
■ How to Contact the Vehicle
Manufacturer concerning
Modifications for Persons
with Disabilities That May
Affect the Advanced Airbag
SystemChanging or moving any parts of the front
seats, rear seat, se atbelts, front bumper,
front side frame, radiator panel, instru-
ment panel, combination meter, steering
wheel, steering colu mn, tire, suspension
or floor panel can affect the operation of
the SUBARU advanced airbag system. If
you have any questions, you may contact
the following SUBARU distributors.
of Columbia>
Subaru of America, Inc.
Customer Advocacy Department
One Subaru Drive
P.O. Box 9103
Camden, NJ 08101-9877
1-800-SUBARU3 (1-800-782-2783)

Subaru Hawaii
2850-A Pukoloa St., 
Honolulu, HI 96819
877-215-0338

- Installation of additional elec- trical/electronic equipment
such as a mobile two-way
radio on or near the SRS
airbag system components
and/or wiring is not advisable.
This could interfere with
proper operation of the SRS
airbag system.- Modifications on or inside the
door panels for the purpose of
a speaker replacement or
sound insulation
 The impact sensors, which detect
the pressure of an impact, are
located in the doors. Do not
modify any components of the
doors or door trims, such as the
addition of door speakers for
example. Any modifications to
the doors will create a risk of the
airbag system becoming inopera-
tive or unintended airbag deploy-
ment.
CAUTION
Do not perform any of the following
modifications. Such modifications
can interfere with proper operation
of the SRS airbag system.
 Attachment of any equipment
(bush bar, winches, snow plow,
skid plate, etc.) other than
genuine SUBARU accessory
parts to the front end. Modification of the suspension
system or front end structure. Installation of a tire of different
size and construction from the
tires specified on the vehicle
placard attached to the driver’s
center pillar or specified for indi-
vidual vehicle models in this
Owner’s Manual. Attachment of any equipment
(side steps or side sill protectors,
etc.) other than genuine SUBARU
accessory parts to the side body.
BRZ_U.book 90 ページ ２０２２年３月２９日　火曜日　午後３時５９分

Keyless Access with Push-Button Start System
98▼Operating ranges1) Antenna
2) Operating range (approximately 16 to
32 in (40 to 80 cm))
1) LED indicator
When the access key fob is within either of
the operating ranges of the doors, the
LED indicator on the access key fob
flashes. When the keyless access func-
tions are disabled, the LED indicator does
not flash unless a button on the access
key fob is pressed.NOTE If the access key fob is placed too
close to the vehicle body, the keyless
access functions may not operate
properly. If it does not operate prop-
erly, repeat the operation from farther
away.
 If the access key fob is placed near
the ground or in an elevated location
from the ground, even if it is in the indi-
cated operating range, the keyless
access function may not operate prop-
erly.
 When the access key fob is within
the operating range, it is possible for
anyone, even someone who is not
carrying the access key fob, to operate
the keyless access function. Note that
the keyless access function can be
operated only by the door handle, door
lock sensor or trunk opener button in
the operating range in which the
access key fob is detected.
 It is not possible to lock the doors,
trunk lid and fuel filler lid using the keyless access function when the

access key fob is inside the vehicle.
However, depending on the status of
the access key fob and the environ-
mental conditions, the access key fob
may be locked inside the vehicle.
Before locking the vehicle, make sure
that you have the access key fob.
 When the battery of the access key
fob is discharged, or when operating it
in a location with strong radio waves or
noise (e.g., near a radio tower, power
plant, broadcast station or an area
where wireless equipment is used), or
while talking on a cell phone, the oper-
ating ranges may be reduced, or the
keyless access function may not
operate. 
In such a case, perform the procedure
described in "Locking and Unlocking"
 P326.
 The doors may lock or unlock when
the car is being washed or exposed to
a significant amount of water that
touches the door handle while the key
fob is still in the operating range.
▼ How to lock and unlock
It is possible to perform the following oper-
ations when you are carrying the access
key fob.
 Lock and unlock the doors and the fuel
filler lid
2
2
1
2
1
1204127202501
1
BRZ_U.book 98 ページ ２０２２年３月２９日　火曜日　午後３時５９分

Keyless Access with Push-Button Start System
99
Keys and Doors2
– CONTINUED –
Unlock the trunk lidNOTEIt is not possible to lock the doors
and fuel filler lid using the keyless
access function when the push-button
ignition switch is in the “ACC” or “ON”
position. Refer to "Switching Power
Status" P125.
 If the door handle is gripped with a
gloved hand, the door lock may not be
released.
 If the door lock sensor is touched
four times or more repeatedly, the
system will ignore the sensor opera-
tion.
 When performing the locking proce-
dure too quickly, locking may not
complete.
 If any of the doors are not fully
closed, an electronic chirp sounds 5
seconds to alert you that the doors are
not properly closed.
 It is possible to lock a closed door
even if the other door is open. After
performing the locking procedure,
close the opened door to lock it.
 Within 3 seconds after locking the
doors using the keyless access func-
tion, it is not possible to unlock doors
using the keyless access function. 
When locking, be sure to carry the
access key fob to prevent locking the
access key fob in the vehicle.
 The setting of th e hazard warning
flasher operation and the volume of the
audible signal can be changed by your
SUBARU dealer. Contact your
SUBARU dealer for details. The setting
of the hazard warning flasher operation
can be changed by operating the
center information display. For details,
refer to "Car settings" P165.
▽ Locking with the door lock
sensor1) Door lock sensorCarry the access key fob, close all doors
and touch the door lock sensor on the
door handle. All doors including the fuel filler lid will be locked. Also, an electronic

chirp will sound once and the hazard
warning flashers will flash once.
NOTEAfter touching the door lock sensor to
lock all of the doors, if you touch the
door lock sensor twice more to
attempt the lock oper ation without first
unlocking the doors, nothing will hap-
pen, even if the door lock sensor is
touched. In this case, perform the
unlocking operation once first. You
can then touch the door lock sensor to
lock the doors.
▽UnlockingCarry the access key fob, and touch the
sensor behind the door handle.
1
204128
204129
BRZ_U.book 99 ページ ２０２２年３月２９日　火曜日　午後３時５９分

Keyless Access with Push-Button Start System
102NOTEPress the trunk opener button ten
times to enter “0”.
 Change the PIN code frequently to
protect your vehic le from theft.
 If you have lent your vehicle to
another person, confirm that the PIN
code has not been changed or deleted.
If the PIN code has been changed or
deleted, reregister a new PIN code.
 If you make an error during the
registration procedure, press the “ ”
or “ ” button on the access key fob.
Then, start over from the procedure
described in “Registration for a PIN
code”.
 To protect your ve hicle from theft,
you cannot register “00000” to “99999”
or “12345” as a PIN code.
 Do not register your vehicle license
plate number or simple numbers such
as “11122” or “12121” as a PIN code.
Doing so will increase the risk of
vehicle theft.
 When you try to register “22222”,
the registered PIN code will be deleted.
You cannot unlock the doors by PIN
Code Access until a new code is regis-
tered.
 After registering a new PIN code,
make sure that you can unlock the
doors using the PIN code. 
The PIN code cannot be deleted
while the keyless access function is
disabled by operating the access key
fob.
 Reregister the PIN code in the
following case. - When you forget the PIN code
- When you want to change the
PIN code
▼ Unlocking
Perform steps (1) to (5) of step 5
described in “Registration”.NOTE You cannot unlock by PIN Code
Access in the following cases. - When the access key fob is
within the operating ranges
- When the ignition switch is in the
“ACC” or “ON” position
 If you make an operation error
during the unlocking procedure, start
over with the unlocking procedure
after waiting for 5 seconds or longer.
 To protect your vehic le from theft, a
buzzer will sound if incorrect PIN
codes are entered five times continu-
ously. If this occurs, you cannot unlock
the doors by PIN Code Access for 5
minutes.
■ Power Saving FunctionTo protect the access key fob battery and
the vehicle battery, the keyless access
function will be disabled as follows.
 When the keyless access function and
the remote keyless entry system have not
been used:
(1) 5 days after the push-button igni-
tion switch has been turned off,
communication between the antennas
and the access key fob will be stopped.
(2) 9 days after step (1), the sensors
(both lock sensor and unlock sensor)
on the passenger’s door will be
disabled.
 When the access key fob has been left
in the operating range for 10 minutes or
longer while all doors are locked, the
keyless access function will be disabled.
▼ Recovery from power saving modeWhen one of the following operations is
performed, the keyless access function
will be recovered.
 Unlock by gripping the door handle
(only when the sensors on the
passenger’s door are not disabled) or
pressing the trunk opener button on the
trunk lid
 Lock or unlock by the remote keyless
entry system
BRZ_U.book 102 ページ ２０２２年３月２９日　火曜日　午後３時５９分

Alarm System
114the battery from going dead. The following
interior lights are affect ed by this function.NOTEThe default setting for this function
is set as “operational”. The opera-
tional/non-operation al setting of this
function can be changed by a SUBARU
dealer. Contact your SUBARU dealer to
change the setting.
 When leaving the vehicle, please
make sure that all doors are completely
closed.
 The battery drainage prevention
function does not operate when the
ignition switch is in “ACC” or “ON”
position.
 The battery drainage prevention
function for the pu sh-button ignition
switch. For details, refer to "Battery
drainage prevention function" P126.
2-5. Alarm SystemThe alarm system helps to protect your
vehicle and valuables from theft. The horn
sounds and the hazard warning flashers
flash if someone attempts to break into
your vehicle.
The system can be armed or disarmed
with the keyless access function or access
key fob.
The system will not be activated when the
push-button ignition switch is in the “ACC”
or “ON” position.
Your vehicle’s alarm system has been set
for deactivation at the time of shipment
from the factory. You can set the system
for activation yourself or have it done by
your SUBARU dealer. Refer to "Alarm
System Setting" P115.■ Alarm System OperationWhen the alarm system is armed, it is trig-
gered by the opening any of the doors, the
trunk lid or engine hood.
The alarm system will activate the
following alarms when triggered.
 The vehicle’s horn will sound for 60
seconds.
 The hazard warning flashers, head-
lights, side marker lights, tail lights and
map lights will flash for 60 seconds.
NOTEThe alarm system can be set to trigger
the illumination of the map lights (illu-
minates only when the door interlock
switch is in the “DOOR” position).■ Arming the SystemThe alarm system becomes armed when
the following operation is performed.
1. Close all windows and turn the ignition
switch to the “OFF” position.
2. Carry the key and get out of the
vehicle.
3. Make sure that the engine hood is
locked.
4. Lock the doors using any of the
following methods.
Locking using the remote keyless
entry system. For details, refer to
"Remote Keyless Entry System"
 P109.
 Locking using the keyless access
function. For details, refer to "Locking
with the door lock sensor" P99.
 Locking using the power door
locking switch. For details, refer to
"Locking using power door locking
switch" P112.
Item Switch
posi-tion Automatically turn-
ing off
Map lights DOOR Approximately 20
minutes later
Ignition
switch light ―
Approximately 20
minutes later
BRZ_U.book 114 ページ ２０２２年３月２９日　火曜日　午後３時５９分

Meters and Gauges
129
Instruments and Controls3
– CONTINUED –
■Fuel GaugeThe fuel gauge shows the approximate
amount of fuel remaining in the tank.
When the ignition switch is in the “OFF” or
“ACC” position, the fuel gauge shows “E”
even if the fuel tank contains fuel.
The gauge may move slightly due to fuel
level movement in the tank (e.g., during
braking, turning or acceleration).NOTEYou will see the “ ” sign in the fuel
gauge. This indicates that the fuel filler
lid is located on the right side of the
vehicle.
■ Engine Coolant Temperature
GaugeThe temperature gauge shows engine
coolant temperature when the ignition
switch is in the “ON” position.
The coolant temperature will vary in
accordance with the outside temperature
and driving conditions.
We recommend that you drive moderately
until the pointer of the temperature gauge
reaches near the middle of the range.
Engine operation is optimum with the
engine coolant at this temperature range
and high revving operation when the
engine is not warmed up enough should
be avoided.
■ Outside TemperatureDisplays the outside temperature within
the range of -40°F (-40°C) to 122°F
(50°C). Low outside temperature indicator
comes on when the ambient temperature
is 37°F (3°C) or lower.NOTEThe outside temperature indicator
shows the temperature around the
sensor. However, the temperature may
not be indicated correctly or the
update may be delayed in the follow-
ing conditions.
 While parking or driving at low
speeds
 When the outside temperature
changes suddenly (example: when
going in and out of an underground
parking area or when passing through
a tunnel)
 When starting the engine after being
parked for a certain period of time
306783
B02099
CAUTION
If the pointer exceeds the normal
operating range, safely stop the
vehicle as soon as possible.Refer to "Engine Overheating"
 P319.
BRZ_U.book 129 ページ ２０２２年３月２９日　火曜日　午後３時５９分

Warning and Indicator Lights
139
Instruments and Controls3
– CONTINUED –
If this light illuminates while driving,
never brake suddenly. Instead, per-
form the following procedure. Oth-
erwise an accident involving
serious vehicle damage and serious
personal injury could occur.1) Keep driving straight ahead while
gradually reducing speed.2) Slowly pull off the road to a safe
place.If this light still illuminates while
driving after adjusting the tire pres-
sure, a tire may have significant
damage and a fast leak that causes
the tire to lose air rapidly. If you
have a flat tire, replace it with a
spare tire as soon as possible.
When a spare tire is mounted or a
wheel rim is replaced without the
original pressure sensor/transmitter
being transferred, the Low tire pres-
sure warning light will illuminate
steadily after blinking for approxi-
mately one minute. This indicates
the TPMS is unable to monitor all
four road wheels. Contact your
SUBARU dealer as soon as possi-
ble for tire and sensor replacement
and/or system resetting. If the light
illuminates steadily after blinking
for approximately one minute,
promptly contact a SUBARU dealer
to have the system inspected.
CAUTION
The tire pressure monitoring sys-
tem is NOT a substitute for manu-
ally checking tire pressure. The tire
pressure should be checked period-
ically (at least monthly) using a tire
gauge. After any change to tire
pressure(s), the tire pressure moni-
toring system will not re-check tire
inflation pressures until the vehicle
is first driven mo re than 25 mph (40
km/h). After adjusting the tire pres-
sures, increase the vehicle speed to
at least 25 mph (40 km/h) to start the
TPMS re-checking of the tire infla-
tion pressures. If the tire pressures
are now above the severe low pres-
sure threshold, the low tire pres-
sure warning light should turn off a
few minutes later. Therefore, be
sure to install the specified size for
the front and rear tires.
BRZ_U.book 139 ページ ２０２２年３月２９日　火曜日　午後３時５９分
