IN CASE OF EMERGENCY205
(Continued)
NOTE:
Your vehicle may be transmitting data as authorized by
the subscriber.
 Never place anything on or near the vehicle’s LTE
(voice/data) or 4G (data) and GPS antennas. You could
prevent LTE (voice/data) or 4G (data) and GPS signal
reception, which can prevent your vehicle from placing
an emergency call. An operable LTE (voice/data) or 4G
(data) network connection and a GPS signal is required
for the SOS Call system to function properly.
NOTE:Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
Automatic SOS — If Equipped
Automatic SOS is a hands-free safety service that can
immediately connect you with help in the event that your
vehicle’s airbags deploy. Please refer to your provided
radio supplement for complete information.
JACKING AND TIRE CHANGING —
IF EQUIPPED
Use this QR code to access your digital
experience.
PREPARATIONS FOR JACKING

1. Park the vehicle on a firm, level surface as far from
the edge of the roadway as possible. Avoid icy or
slippery areas.

2. Turn on the Hazard Warning Flashers.
3. Apply the parking brake.
4. Place the gear selector into PARK (P).
5. Turn off the ignition.
CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
WARNING!
 Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off the
road to avoid the danger of being hit when operating
the jack or changing the wheel.
 Being under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never put any part of your body
under a vehicle that is on a jack. If you need to get
under a raised vehicle, take it to a service center
where it can be raised on a lift.
Never start or run the engine while the vehicle is on
a jack.
 The jack is designed to be used as a tool for changing
tires only. The jack should not be used to lift the
vehicle for service purposes. The vehicle should be
jacked on a firm level surface only. Avoid ice or slip -
pery areas.
WARNING!
Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off the
road to avoid being hit when operating the jack or
changing the wheel.
WARNING!
7

23_LD_OM_EN_USC_t.book Page 205

206IN CASE OF EMERGENCY
6. Block both the front and rear of the wheels diagonally
opposite of the jacking position using the provided
wheel chocks. For example, if changing the driver’s
front wheel, chock the passenger’s rear wheel.

Wheel Blocked Example

NOTE:
Passengers should not remain in the vehicle when the
vehicle is being lifted or raised.
JACK LOCATION/SPARE TIRE STOWAGE
The jack, tools and spare tire are stowed under the load
floor in the trunk.

Spare Tire And Jack Location

NOTE:
The spare tire must be removed in order to access the
jack.
Follow these steps to access the jack and spare tire:

1. Open the trunk.

2. Lift up the load floor by using the pull strap.
3. Rotate the fastener securing the spare tire counter -
clockwise to remove it.

Spare Tire Fastener

4. Remove the spare tire.
5. Rotate the fastener securing the jack counter -
clockwise to remove it.

Jack Fastener

23_LD_OM_EN_USC_t.book Page 206

IN CASE OF EMERGENCY207
(Continued)
6. Remove the wheel chocks, jack and lug wrench
assembly from under the spare tire. Turn the jack
screw to the left to loosen the lug wrench, and remove
the wrench from the jack assembly.
JACKING INSTRUCTIONS

Jack Warning Label

1. Remove the spare tire, jack, wheel chocks, and lug wrench.

2. If equipped with aluminum wheels where the center cap covers the lug nuts, use the lug wrench to pry the
center cap off carefully before raising the vehicle.
NOTE:When the following label is present, the spare tire must be
used for the rear wheel(s) only. For a flat front tire, you
must first install the spare on one of the rear tires. Then,
follow the jacking instructions for front tire replacement
and replace the front road wheel with the wheel removed
from the rear of the vehicle.

Spare Tire Label

WARNING!
A loose tire or jack thrown forward in a collision or hard
stop could endanger the occupants of the vehicle.
Always stow the jack parts and the spare tire in the
places provided. Have the deflated (flat) tire repaired or
replaced immediately.
WARNING!
Carefully follow these tire changing warnings to help
prevent personal injury or damage to your vehicle:
Always park on a firm, level surface as far from the
edge of the roadway as possible before raising the
vehicle.
 Turn on the Hazard Warning Flashers.
 Apply the parking brake firmly and set an automatic
transmission in PARK.
 Chock the wheel diagonally opposite the wheel to be
raised.
Never start or run the engine with the vehicle on a
jack.
 Do not let anyone sit in the vehicle when it is on a
jack.
 Do not get under the vehicle when it is on a jack. If
you need to get under a raised vehicle, take it to a
service center where it can be raised on a lift.
 Only use the jack in the positions indicated and for
lifting this vehicle during a tire change.
 If working on or near a roadway, be extremely careful
of motor traffic.
 To assure that spare tires, flat or inflated, are
securely stowed, spares must be stowed with the
valve stem facing the ground.
WARNING!
7

23_LD_OM_EN_USC_t.book Page 207

208IN CASE OF EMERGENCY
3. Before raising the vehicle, use the lug wrench to
loosen, but not remove, the lug nuts on the wheel
with the flat tire. Turn the lug nuts counterclockwise
one turn while the wheel is still on the ground.
Placement for the front and rear jacking locations are
critical. See the following images for proper jacking lo -
cations.

Jacking Locations

4. Place the jack underneath the lift area that is closest to the flat tire. Turn the jack screw clockwise to firmly
engage the jack saddle with the lift area of the sill
flange.

Front Lifting Point
Front Jacking Location Rear Lifting Point
Rear Jacking Location

CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated in the Jacking
Instructions for this vehicle.

23_LD_OM_EN_USC_t.book Page 208

280
Door LocksAutomatic ...................................................................23
Child-Protection Door Lock — Rear Doors ................24
Doors................................................................................ 21
Drag & Drop.................................................................. 128
Drive Modes ................................................................. 159
Driver Memory Presets ................................................ 135
Driver’s Seat Back Tilt ....................................................28
Driving Through Flowing, Rising, Or ShallowStanding Water .................................................. 110
EElectric Brake Control System..................................... 165Anti-Lock Brake System ......................................... 164
Electronic Roll Mitigation .............................. 165
, 168
Electric Remote Mirrors ..................................................36 Electronic Power Distribution Center (Fuses) ............ 238
Electronic Speed Control (Cruise Control) ..................... 86Electronic Stability Control (ESC) ................................ 166
Electronic Throttle Control Warning Light...................... 69Emergency Gas Can Refueling .................................... 215
Emergency, In Case Of Freeing Vehicle When Stuck .................................. 218
Hazard Warning Flasher ......................................... 202
Jacking..................................................................... 205
Jump Starting ................................................. 213
, 214
Towing ..................................................................... 219
Emission Control System Maintenance.........................75
Engine .................................................................. 225
, 226
Air Cleaner ............................................................... 229 Break-In Recommendations ..................................... 79
Checking Oil Level .................................................. 227Compartment ................................................. 225
, 226 Compartment Identification....................................225
Coolant (Antifreeze)....................................... 234
, 271
Cooling .....................................................................234
Exhaust Gas Caution ............................................... 201
Fails To Start .............................................................. 78
Flooded, Starting ....................................................... 78
Fuel Requirements ........................................ 268
, 270
Jump Starting................................................. 213, 214
Oil .......................................................... 228, 270, 271
Oil Filler Cap ............................................................. 225
Oil Filter ....................................................................229 Oil Selection ................................................... 228
, 270
Oil Synthetic ............................................................. 229
Overheating ............................................................. 216
Starting....................................................................... 76
Engine Oil Life Reset

b
................................................ 65
Enhanced Accident Response Feature ............. 188, 220
Ethanol .......................................................................... 269
Exhaust Gas Cautions ..................................................201
Exhaust System .................................................. 201
, 233
Exterior Lighting .............................................................. 40
Exterior Lights ........................................................40
, 201
FFilters Air Cleaner ............................................................... 229
Air Conditioning ................................................52
, 230
Engine Oil ................................................................. 229
Engine Oil Disposal..................................................229
Flashers ......................................................................... 202 Hazard Warning ....................................................... 202
Turn Signals ...............................................43
, 74, 201
Flash-To-Pass .................................................................. 42
Flooded Engine Starting ................................................. 78 Floor Console .................................................................. 53
Fluid Capacities ............................................................ 270
Fluid Leaks.................................................................... 201
Fluid Level Checks
Brake........................................................................ 236
Cooling System........................................................ 234Engine Oil................................................................. 227
Fluid, Brake................................................................... 272
Fog Lights........................................................................ 42
Fold-Flat Seats ................................................................ 28
Folding Rear Seats ......................................................... 29
Forward Collision Warning ........................................... 172
Four-Way Hazard Flasher ............................................. 202
Freeing A Stuck Vehicle ............................................... 218
Fuel................................................................................ 268 Additives .................................................................. 268
Clean Air .................................................................. 268
Ethanol..................................................................... 269Gasoline ................................................................... 268
Materials Added ...................................................... 268
Methanol ................................................................. 269
Octane Rating.................................................268
, 271
Requirements .................................................268, 270
Specifications .......................................................... 271
Tank Capacity .......................................................... 270
Fuses ............................................................................. 238
GGarage Door Opener (HomeLink) .................................. 36 Gasoline, Clean Air ....................................................... 268
Gasoline, Reformulated ............................................... 268
Gear Ranges ................................................................... 82
Glass Cleaning .............................................................. 266

23_LD_OM_EN_USC_t.book Page 280

281
Gross Axle Weight Rating ................................... 102, 103
Gross Vehicle Weight Rating .............................. 102, 103
GVWR ............................................................................ 102
HHazard Driving Through Flowing, Rising, OrShallow Standing Water .................................... 110
Hazard Warning Flashers ............................................ 202
Head Restraints .............................................................. 33
Head Rests ...................................................................... 33
Headlights Automatic ...................................................................42
Cleaning................................................................... 265
High Beam/Low Beam Select Switch .......................41
Lights On Reminder ...................................................42
On With Wipers ..........................................................42
Passing ....................................................................... 42
Switch .........................................................................40
Time Delay..................................................................42
Washers................................................................... 227
Heated Mirrors ................................................................36 High Beam/Low Beam Select (Dimmer) Switch ...........41
Hill Start Assist ............................................................. 167
Hitches Trailer Towing .......................................................... 105
Holder, Coin .....................................................................53
HomeLink (Garage Door Opener) ..................................36
Hood Prop ........................................................................59 Hood Release ..................................................................59
IIgnition............................................................................. 15 Switch......................................................................... 15
Illuminated Cupholder .................................................... 54 Indicator Lights Blue ............................................................................ 74
Green.......................................................................... 73
White .......................................................................... 74
Yellow ......................................................................... 73
Information Center, Vehicle ........................................... 64
Inside Rearview Mirror ................................... 34
, 35, 202
Instrument Cluster ................................................... 61, 63
Descriptions ............................................................... 74
Display................................................................. 63
, 65
Instrument Cluster
b
................................................... 63
Instrument Panel Lens Cleaning ................................. 266
Interior Appearance Care ............................................. 265
Interior Lights .................................................................. 43
JJack Location ................................................................ 206
Jacking And Tire Changing — If Equipped
b
............. 205
Jump Starting ...................................................... 213, 214
KKey Fob Arm The System......................................................... 19
Panic Alarm ................................................................ 13
Programming Additional Key Fobs ........................... 14
Unlatch The Trunk ..................................................... 13
Key Fob Battery Service (Remote Keyless Entry) ......... 13 Key Fob Programming (Remote Keyless Entry)............ 14
Keyless Enter 'n Go™ .............................................. 22
, 78
Enter The Trunk......................................................... 13
Passive Entry ............................................................. 22
Passive Entry Programming ..................................... 22
Keys ................................................................................. 12
LLane Change And Turn Signals ..................................... 43
Lane Change Assist ........................................................ 43 LaneSense ...................................................................... 98Lap/Shoulder Belts ...................................................... 178
Latches ......................................................................... 201 Hood........................................................................... 59
Lead Free Gasoline ...................................................... 268
Leaks, Fluid................................................................... 201
Life Of Tires ................................................................... 257
Light Bulbs ...........................................................201
, 246
Lights ............................................................................. 201 Adaptive Cruise Control (ACC) Set WithTarget Vehicle ...................................................... 73
Adaptive Cruise Control (ACC) Set Without Target Vehicle ...................................................... 73
Air Bag...................................................... 68
, 183, 200
Automatic Headlights ............................................... 42
Brake Assist Warning.............................................. 167
Brake Warning.................................................. 68
, 267
Bulb Replacement .................................................. 246
Cruise .................................................................. 73
, 74
Daytime Running....................................................... 41
Dimmer Switch, Headlight ........................................ 41
11

23_LD_OM_EN_USC_t.book Page 281

283
Synthetic.................................................................. 229
Viscosity................................................................... 270
Onboard Diagnostic System .................................... 74
, 75
Operating Precautions ....................................................74
Operator Manual Owner's Manual ...................................................... 276
Outside Rearview Mirrors ...............................................35
Overheating, Engine..................................................... 216
PPaddle Shift Mode ..........................................................83 Paddle Shifters................................................................83Paint Care ..................................................................... 264
Pair (link) Uconnect Phone To A mobile Phone

b
... 142
Panic Alarm .....................................................................13
Parking Brake ..................................................................79
ParkSense System, Rear ................................................94
Passing Light ...................................................................42
Passive Entry ...................................................................22
Performance....................................................................65
Personalized Main Menu Bar ...................................... 128
Pets ............................................................................... 199
Phone Mode ................................................................. 140
Pinch Protection .............................................................. 58
Placard, Tire And Loading Information ....................... 252
Power Brakes ..................................................................... 267
Deck Lid Release ....................................................... 59
Distribution Center (Fuses) .................................... 242 Door Locks .................................................................21
Mirrors ........................................................................36
Outlet (Auxiliary Electrical Outlet) ............................. 55
Seats...........................................................................30
Steering ...................................................................... 85 Sunroof....................................................................... 57
Tilt/Telescoping Steering Column ............................ 25
Windows..................................................................... 56
Power Seats Forward ...................................................................... 30
Lumbar ....................................................................... 31
Rearward.................................................................... 30
Recline ....................................................................... 31
Pregnant Women And Seat Belts ................................ 182
Preparation For Jacking ............................................... 205
Presets .......................................................................... 135
Pretensioners Seat Belts................................................................. 182
Programmable Features .............................................. 112
RRadial Ply Tires ............................................................. 256
Radiator Cap (Coolant Pressure Cap) ......................... 235
Radio Presets .....................................................................135
Radio Controls .............................................................. 130
Radio Mode ...................................................................130
Radio Operation .................................................. 130
, 163
Radio Remote Controls ................................................ 129
Rain Sensitive Wiper System ......................................... 46
Rear Axle (Differential) ................................................. 237
Rear Camera ................................................................. 100
Rear Cross Path ............................................................171
Rear ParkSense System................................................. 94
Rear Seats, Folding ........................................................ 29
Rear Wheel Drive (RWD) Towing ...................................................................... 220
Recreational Towing ..................................................... 109
Reformulated Gasoline ................................................ 268 Refrigerant .................................................................... 230
Release, Hood ................................................................ 59
Reminder, Lights On....................................................... 42
Reminder, Seat Belt ..................................................... 178
Remote Control Starting System ......................................................... 16
Remote Keyless Entry Arm The Alarm ........................................................... 19
Panic Alarm ............................................................... 13
Programming Additional Key Fobs ........................... 14
Unlatch The Trunk ..................................................... 13
Remote Sound System (Radio) Control ...................... 129
Remote Starting Exit Remote Start Mode............................................ 17
Uconnect Customer Programmable Features......... 18
Uconnect Settings ..................................................... 18
Remote Starting System ................................................ 16 Remote Trunk Release .................................................. 59
Replacement Bulbs ...................................................... 246
Replacement Tires ....................................................... 258
Reporting Safety Defects ............................................. 276
Restraints, Child ........................................................... 190
Restraints, Head............................................................. 33
Rocking Vehicle When Stuck ....................................... 218
Rotation, Tires .............................................................. 263
SSafety ............................................................................ 128
Safety Checks Inside Vehicle....................................... 199
Safety Checks Outside Vehicle .................................... 201
Safety Defects, Reporting ............................................ 276
Safety Features ............................................................ 128
Safety Information, Tire ............................................... 248
Safety Tips .................................................................... 199
11

23_LD_OM_EN_USC_t.book Page 283
