SERVICING AND MAINTENANCE241
AUTOMATIC TRANSMISSION —
I
F EQUIPPED
Special Additives
The manufacturer strongly recommends against using any
special additives in the transmission. Automatic
Transmission Fluid (ATF) is an engineered product and its
performance may be impaired by supplemental additives.
Therefore, do not add any fluid additives to the
transmission. Avoid using transmission sealers as they
may adversely affect seals.
Fluid Level Check
The fluid level is preset at the factory and does not require
adjustment under normal operating conditions. Routine
fluid level checks are not required; therefore the
transmission has no dipstick. An authorized dealer can
check your transmission fluid level using special service
tools. If you notice fluid leakage or transmission
malfunction, visit an authorized dealer immediately to
have the transmission fluid level checked. Operating the
vehicle with an improper fluid level can cause severe
transmission damage.
Fluid And Filter Changes
Under normal operating conditions, the fluid installed at
the factory will provide satisfactory lubrication for the life
of the vehicle.
Routine fluid and filter changes are not required. However,
change the fluid and filter if the fluid becomes
contaminated (with water, etc.), or if the transmission is
disassembled for any reason.
Selection Of Lubricant
It is important to use the proper transmission fluid to
ensure optimum transmission performance and life. Use
only the manufacturer's specified transmission fluid
Úpage 278. It is important to maintain the transmission
fluid at the correct level using the recommended fluid.
NOTE:No chemical flushes should be used in any transmission;
only the approved lubricant should be used.
ALL-WHEEL DRIVE (AWD) —
I
F EQUIPPED

The All-Wheel Drive system consists of a transfer case and
front differential. The exterior surface of these components
should be inspected for evidence of fluid leaks. Confirmed
leaks should be repaired as soon as possible.
The transfer case fluid fill/inspection plug is located in the
middle of the rear housing. To inspect the transfer case fluid
level, remove the fill/inspection plug. The fluid level should
be even with the bottom of the hole. Use this plug to add
fluid as required.
The front differential fill plug is located on the outer cover
near the half shaft attachment. To inspect the differential
fluid level, remove the fill plug. The fluid level should be
even with or slightly below the bottom of the hole.

Fluid Changes
For the proper maintenance intervals Úpage 223.
REAR AXLE
Fluid Level Check

Checking the fluid level while the vehicle is on level ground
and has been stationary for 15 minutes will improve the
accuracy of the fluid level reading.
Check the fluid level by removing the fill plug on the axle.
The fluid level should be 1-2.5 mm below the fill plug. Add
fluid, if necessary, to maintain the proper level

Ú
page 278.

Change Axle Fluid
For the proper maintenance intervals Úpage 223.
CAUTION!
Do not use chemical flushes in your transmission as the
chemicals can damage your transmission components.
Such damage is not covered by the New Vehicle Limited
Warranty.
CAUTION!
If a transmission fluid leak occurs, visit an authorized
dealer immediately. Severe transmission damage may
occur. An authorized dealer has the proper tools to
adjust the fluid level accurately.
CAUTION!
Using a transmission fluid other than the
manufacturer’s recommended fluid may cause
deterioration in transmission shift quality and/or torque
converter shudder
Úpage 278.
8

23_LA_OM_EN_USC_t.book Page 241

242SERVICING AND MAINTENANCE
FUSES
General Information
The fuses protect electrical systems against excessive
current.
When a device does not work, you must check the fuse
element inside the blade fuse for a break/melt.
Also, please be aware that using power outlets for
extended periods of time with the engine off may result in
vehicle battery discharge.

Blade Fuses

Underhood Fuses
The Front Power Distribution Center is located in the
engine compartment. This module contains fuses and
relays. Fuse cavity location and descriptions are printed
on the inside of the power distribution center cover.
WARNING!
When replacing a blown fuse, always use an appro -
priate replacement fuse with the same amp rating as
the original fuse. Never replace a fuse with another
fuse of higher amp rating. The use of a fuse with a
rating other than indicated may result in a dangerous
electrical system overload. If a properly rated fuse
continues to blow, it indicates a problem in the circuit
that must be corrected. Never replace a blown fuse
with metal wires or any other material. Do not place
a fuse inside a circuit breaker cavity or vice versa.
Failure to use proper fuses may result in serious
personal injury, fire and/or property damage.
 Before replacing a fuse, make sure that the ignition
is off and that all the other services are switched off
and/or disengaged.
 If the replaced fuse blows again, contact an
authorized dealer.
 If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, transmission system) or steering
system blows, contact an authorized dealer.
1 — Fuse Element
2 — Blade Fuse with a good/functional fuse element
3 — Blade fuse with a bad/not functional fuse element
(blown fuse)
CAUTION!
When installing the power distribution center cover, it is
important to ensure the cover is properly positioned
and fully latched. Failure to do so may allow water to get
into the power distribution center and possibly result in
an electrical system failure.

23_LA_OM_EN_USC_t.book Page 242

273
TECHNICAL SPECIFICATIONS
VEHICLE IDENTIFICATION NUMBER (VIN)
The VIN is on the left front corner of the instrument panel.
The VIN is visible from outside of the vehicle through the
windshield.

Windshield VIN Location

NOTE:It is illegal to remove or alter the VIN.
BRAKE SYSTEM
Your vehicle is equipped with dual hydraulic brake
systems. If either of the two hydraulic systems lose normal
capability, the remaining system will still function. There
will be some loss of overall braking effectiveness.This may be evident by increased pedal travel during
application, greater pedal force required to slow or stop,
and potential activation of the Brake Warning Light.
In the event power assist is lost for any reason (for
example, repeated brake applications with the engine off),
the brakes will still function. The effort required to brake
the vehicle will be much greater than that required with
the power system operating.
WHEEL AND TIRE TORQUE SPECIFICATIONS
Proper lug nut/bolt torque is very important to ensure that
the wheel is properly mounted to the vehicle. Any time a
wheel has been removed and reinstalled on the vehicle,
the lug nuts/bolts should be torqued using a properly
calibrated torque wrench using a six-sided (hex) deep wall
socket.
TORQUE SPECIFICATIONS
**Use only authorized dealer recommended lug nuts/
bolts and clean or remove any dirt or oil before tightening.
Inspect the wheel mounting surface prior to mounting the
tire and remove any corrosion or loose particles.

Wheel Mounting Surface

Tighten the lug nuts/bolts in a star pattern until each
nut/bolt has been tightened twice. Ensure that the socket
is fully engaged on the lug nut/bolt (do not insert it
halfway).
NOTE:If in doubt about the correct tightness, have them checked
with a torque wrench by an authorized dealer or service
station.
Lug Nut/Bolt
Torque **Lug Nut/Bolt
Size Lug Nut/Bolt
Socket Size
130 ft-lb
(176 N·m) M14 x 1.50 22 mm
9

23_LA_OM_EN_USC_t.book Page 273

274TECHNICAL SPECIFICATIONS
After 25 miles (40 km), check the lug nut/bolt torque to be
sure that all the lug nuts/bolts are properly tightened.

Torque Patterns

FUEL REQUIREMENTS
While operating on gasoline with the required octane
number, hearing a light knocking sound from the engine is
not a cause for concern. However, if the engine is heard
making a heavy knocking sound, see a dealer
immediately. Use of gasoline with a lower than
recommended octane number can cause engine failure
and may void the New Vehicle Limited Warranty.
Poor quality gasoline can cause problems such as hard
starting, stalling, and hesitations. If you experience these
symptoms, try another brand of gasoline before
considering service for the vehicle.
3.6L ENGINE
Do not use E-85 flex fuel or ethanol blends greater than
15% in this engine.
This engine is designed to meet all emission
regulations and provide excellent fuel economy
and performance when using high-quality
unleaded regular gasoline having an octane
rating of 87 as specified by the (R+M)/2 method. The use
of higher octane premium gasoline will not provide any
benefit over regular gasoline in these engines.
5.7L ENGINE (WITH AUTOMATIC
T
RANSMISSION)
Do not use E-85 flex fuel or ethanol blends greater than
15% in this engine.
This engine is designed to meet all emission
regulations and provide satisfactory fuel
economy and performance when using high
quality unleaded gasoline having a posted
octane number range of 87 to 89 as specified by the
(R+M)/2 method. The use of 89 octane plus gasoline is
recommended for optimum performance and fuel
economy.
5.7L ENGINE (WITH MANUAL
T
RANSMISSION)
Do not use E-85 flex fuel or ethanol blends greater than
15% in this engine.
This engine is designed to meet all emission
regulations, provide optimal fuel economy and
performance when using high-quality unleaded
premium gasoline having a posted octane
number of 91 as specified by the (R+M)/2 method. The
use of 91 or higher octane premium gasoline is required
for this engine.
WARNING!
To avoid the risk of forcing the vehicle off the jack, do
not tighten the lug nuts/bolts fully until the vehicle has
been lowered. Failure to follow this warning may result
in personal injury.

23_LA_OM_EN_USC_t.book Page 274

285
INDEX
AAbout Your Brakes ................................................ 74, 273
Adaptive Cruise Control (ACC) .................................84, 85
Adding Engine Coolant (Antifreeze) ............................ 238
Adding Washing Fluid .................................................. 230
Additives, Fuel .............................................................. 275
Advance Phone Connectivity ....................................... 142
Air Bag........................................................................... 180 Advance Front Air Bag ............................................ 180
Air Bag Operation.................................................... 181
Air Bag Warning Light ............................................. 179
Enhanced Accident Response ...................... 184
, 222
Event Data Recorder (EDR).................................... 222 Front Air Bag ........................................................... 180
If Deployment Occurs ............................................. 183
Knee Impact Bolsters ............................................. 181
Maintaining Your Air Bag System .......................... 184
Maintenance ........................................................... 184
Redundant Air Bag Warning Light ......................... 179
Side Air Bags ........................................................... 181
Transporting Pets.................................................... 196
Air Bag Light ................................................. 63
, 179, 196
Air Cleaner, Engine (Engine Air Cleaner Filter) ........... 233
Air Conditioner Maintenance ...................................... 234
Air Conditioner Refrigerant .......................................... 234
Air Conditioner System ................................................ 234
Air Conditioning ............................................................... 45
Air Conditioning Filter ........................................... 49
, 234
Air Conditioning System..................................................45 Air Conditioning, Operating Tips ..................................... 48Air Filter......................................................................... 233 Air Pressure
Tires.......................................................................... 261
Alarm Arm The System.................................................. 19
, 20
Panic........................................................................... 13
Rearm The System .................................................... 20
Security Alarm..................................................... 19
, 66
Alarm System Security Alarm............................................................ 19
All Wheel Drive Towing ...................................................................... 222
All Wheel Drive (AWD)...................................................241
Alterations/Modifications Vehicle.......................................................................... 8
Alternate Tire Service Kit — If Equipped

b
.............. 211
Android Auto........................................................ 144, 145
Android auto™
b
....................................................... 144
Antifreeze (Engine Coolant) ............................... 238, 277
Disposal ...................................................................239
Anti-Lock Brake System (ABS) ..................................... 159
Anti-Lock Warning Light.................................................. 66
Apple CarPlay ...................................................... 144
, 147
Apple carplay® ¹ ...........................................................146
Arming System Security Alarm............................................................ 19
Assist, Hill Start ............................................................. 162
Audio Settings ............................................................... 131
Audio Systems (Radio) ................................................. 106
Auto Down Power Windows............................................ 52
Automatic Door Locks .................................................... 24 Automatic Headlights ..................................................... 41 Automatic High Beams .................................................. 40
Automatic Temperature Control (ATC) .......................... 48
Automatic Transmission ................................................ 79 Adding Fluid .................................................... 241
, 279
Fluid And Filter Change........................................... 241
Fluid Change ........................................................... 241
Fluid Level Check .................................................... 241
Fluid Type .......................................................241
, 279
Special Additives ..................................................... 241
Automatic Transmission Limp Home Mode ................. 81
AutoPark ......................................................................... 72
Autostick Operation ................................................................... 82
AWD Towing...................................................................... 222
Axle Fluid....................................................................... 279
Axle Lubrication ............................................................ 279
BBack Up Camera............................................................. 96
Battery.................................................................... 64, 231
Charging System Light .............................................. 64
Keyless Key Fob Replacement................................. 13
Location ................................................................... 231
Belts, Seat..................................................................... 196
Blind Spot Monitoring .................................................. 164
Bluetooth Connecting To A Particular Mobile PhoneOr Audio Device After Pairing ............................ 139
Body Mechanism Lubrication ...................................... 235
B-Pillar Location ........................................................... 258
11

23_LA_OM_EN_USC_t.book Page 285

286
Brake Assist System .................................................... 160
Brake Control System .................................................. 160
Brake Fluid .......................................................... 240
, 279
Brake System ...................................................... 240, 273
Fluid Check..................................................... 240, 279
Master Cylinder ....................................................... 240
Parking ....................................................................... 74
Warning Light ................................................... 64
, 273
Brake/Transmission Interlock........................................79
Break-In Recommendations, New Vehicle .................... 74
Brightness, Interior Lights .............................................. 43
Bulb Replacement ....................................................... 250
Bulbs, Light.......................................................... 198
, 250
CCamera, Rear ..................................................................96
Capacities, Fluid ........................................................... 277
Caps, Filler Fuel .............................................................................96
Oil (Engine) .............................................................. 228
Radiator (Coolant Pressure)................................... 239
Car Washes .................................................................. 270
Carbon Monoxide Warning .......................................... 198
Cargo Vehicle Loading..........................................................97
Cargo Net .........................................................................55
CD.................................................................................. 133
Cellular Phone .............................................................. 158
Certification Label ...........................................................98
Chains, Tire................................................................... 267
Chart, Tire Sizing .......................................................... 255
Check Engine Light (Malfunction Indicator Light) .........70
Checking Your Vehicle For Safety ............................... 196
Checks, Safety.............................................................. 196 Child Restraint .............................................................. 185
Child Restraints
Booster Seats .......................................................... 187
Child Seat Installation ............................................. 194How To Stow An unused ALR Seat Belt .................192Infant And Child Restraints ..................................... 186
Lower Anchors And Tethers For Children............... 188
Older Children And Child Restraints....................... 187
Seating Positions ..................................................... 188
Clean Air Gasoline ........................................................ 275
Cleaning Wheels .....................................................................266
Climate Control ............................................................... 45
Cold Weather Operation ................................................. 74
Compact Spare Tire ...................................................... 265
Contract, Service .......................................................... 282
Controls ......................................................................... 125
Cooling Pressure Cap (Radiator Cap) ..........................239
Cooling System ............................................................. 237 Adding Coolant (Antifreeze) ....................................238
Coolant Level ................................................. 238
, 239
Cooling Capacity ...................................................... 277
Disposal Of Used Coolant ....................................... 239 Drain, Flush, And Refill............................................238
Inspection ................................................................ 239
Points To Remember............................................... 239
Pressure Cap ...........................................................239
Radiator Cap ............................................................239Selection Of Coolant (Antifreeze) ........ 238
, 277, 278
Corrosion Protection ..................................................... 270
Cruise Control ................................................................. 84
Cruise Control (Speed Control) ...................................... 84 Cruise Light ..................................................................... 69 Cupholders
Illuminated................................................................. 50
Customer Assistance ................................................... 280
Customer Programmable Features ............................. 107
Cybersecurity ................................................................ 106
DDaytime Running Lights ................................................. 40 Dealer Service .............................................................. 231
Defroster, Windshield .................................................. 197
De-Icer, Remote Start .................................................... 19
Delay (Intermittent) Wipers............................................ 44
Deleting A Phone .......................................................... 139
Deluxe Vehicle Security System .................................... 20
Diagnostic System, Onboard ......................................... 69Dimmer Control .............................................................. 43Dipsticks Oil (Engine) .............................................................. 230
Disabled Vehicle Towing .............................................. 221
Disc Drive ...................................................................... 133
Disconnecting ............................................................... 139
Disposal Antifreeze (Engine Coolant) .................................... 239
Disturb........................................................................... 141
Door Ajar ......................................................................... 64
Door Ajar Light ................................................................ 64
Door Locks Automatic .................................................................. 24
Remote Keyless Entry ............................................... 12
Doors ............................................................................... 21
Drag & Drop .................................................................. 123
Drive Modes.................................................................. 154
Driver Memory Presets ................................................ 131
Driver Memory Settings ................................................. 27

23_LA_OM_EN_USC_t.book Page 286

287
Driver’s Seat Back Tilt ....................................................28
DrivingThrough Flowing, Rising, Or Shallow Standing Water .................................................. 105
EElectric Brake Control System..................................... 160Anti-Lock Brake System ......................................... 159
Electronic Roll Mitigation .............................. 160
, 163
Electrical Power Outlets..................................................50 Electronic Power Distribution Center (Fuses) ............ 242
Electronic Stability Control (ESC) ................................ 161
Electronic Throttle Control Warning Light...................... 65Emergency Trunk Release.............................................. 55
Emergency, In Case Of Freeing Vehicle When Stuck .................................. 220
Jacking..................................................................... 202
Jump Starting ................................................. 216
, 217
Towing ..................................................................... 221
Emission Control System Maintenance.........................70
Engine .................................................................. 228
, 229
Air Cleaner ............................................................... 233 Break-In Recommendations ..................................... 74
Checking Oil Level .................................................. 230Compartment ................................................. 228
, 229
Compartment Identification ................................... 228 Coolant (Antifreeze) ................................................ 238
Cooling..................................................................... 237
Exhaust Gas Caution .............................................. 198
Fails To Start .............................................................. 74
Flooded, Starting ....................................................... 74
Fuel Requirements ................................................. 274 Jump Starting ................................................. 216
, 217
Oil ...........................................................231, 277, 278 Oil Filler Cap ............................................................. 228
Oil Filter ....................................................................233Oil Selection ................................................... 231
, 277
Oil Synthetic ............................................................. 232
Starting....................................................................... 71
Engine Oil Life Reset

b
............................................... 59
Enhanced Accident Response Feature ............. 184, 222
Ethanol .......................................................................... 275
Exhaust Gas Cautions ..................................................198
Exhaust System .................................................. 198
, 237
Exterior Lighting .............................................................. 39
Exterior Lights ........................................................39
, 198
FFiller Location Fuel ......................................................... 96
Filters Air Cleaner ............................................................... 233
Air Conditioning ................................................49
, 234
Engine Oil ................................................................. 233
Engine Oil Disposal..................................................233
Flashers ......................................................................... 199 Hazard Warning ....................................................... 199
Turn Signals ...............................................42
, 69, 198
Flash-To-Pass .................................................................. 41
Flooded Engine Starting ................................................. 74
Fluid Capacities ............................................................277
Fluid Leaks ....................................................................198
Fluid Level Checks Brake ........................................................................ 240
Cooling System ........................................................ 238
Engine Oil ................................................................. 230
Transfer Case .......................................................... 241 Fluid, Brake................................................................... 279
Fog Lights........................................................................ 42
Fold-Flat Seats ......................................................... 28
, 30
Forward Collision Warning ........................................... 167
Freeing A Stuck Vehicle ............................................... 220
Fuel................................................................................ 274 Additives .................................................................. 275
Clean Air .................................................................. 275
Ethanol..................................................................... 275Filler Cap (Gas Cap) .................................................. 96
Gasoline ................................................................... 274
Materials Added ...................................................... 275
Methanol ................................................................. 275
Octane Rating.................................................274
, 278
Requirements .......................................................... 274
Specifications .......................................................... 278
Tank Capacity .......................................................... 277
Fueling ............................................................................ 96 Fuses ............................................................................. 242
GGarage Door Opener (HomeLink) .................................. 36Gas Cap (Fuel Filler Cap) ............................................... 96
Gasoline, Clean Air ....................................................... 275
Gasoline, Reformulated ............................................... 275
Gear Ranges ................................................................... 79
Glass Cleaning .............................................................. 272
Gross Axle Weight Rating ........................................ 98
, 99
Gross Vehicle Weight Rating .................................. 98, 99
GVWR .............................................................................. 98
11

23_LA_OM_EN_USC_t.book Page 287

289
Interior ........................................................................42
License .................................................................... 253
Lights On Reminder ...................................................41
Malfunction Indicator (Check Engine) ...................... 67
Map.............................................................................42
Park ..................................................................... 41
, 68
Passing ....................................................................... 41
Reading ...................................................................... 42
Seat Belt Reminder ...................................................64
Security Alarm ............................................................66
Service ..................................................................... 250
Traction Control ...................................................... 162
Turn Signals .............................................. 42
, 69, 198
Vanity Mirror............................................................... 35
Warning Instrument Cluster Descriptions .........65
, 69
Load Shed Battery Saver On ..........................................62
Load Shed Electrical Load Reduction............................ 62
Load Shed Intelligent Battery Sensor ............................ 62
Loading Vehicle ........................................................ 97
, 98
Capacities...................................................................98
Tires ......................................................................... 258
Locks Auto Unlock ................................................................24
Automatic Door ..........................................................24
Power Door .................................................................22
Low Tire Pressure System ........................................... 168
Lubrication, Body ......................................................... 235
Lug Nuts/Bolts ............................................................. 273
MMaintenance ...................................................................53
Maintenance Free Battery ........................................... 231
Maintenance Schedule....................................... 223
, 224
Malfunction Indicator Light (Check Engine) ..................67 Manual
Park Release............................................................218Service .....................................................................283
Manual Transmission .................................. 76
, 240, 241
Fluid Level Check .......................................... 240, 241
Map/Reading Lights ....................................................... 42
Media Mode .................................................................. 133
Memory Seat ................................................................... 27 Memory Settings............................................................. 27
Methanol ....................................................................... 275
Mirrors ............................................................................. 35 Electric Powered ........................................................ 36
Heated........................................................................ 36
Outside ....................................................................... 35
Rearview ...........................................................35
, 199
Vanity.......................................................................... 35
Modifications/Alterations Vehicle.......................................................................... 8
Monitor, Tire Pressure System..................................... 168
Mopar Parts .................................................................. 282
Multi-Function Control Lever .......................................... 40
NNew Vehicle Break-In Period .......................................... 74
OOccupant Restraints ..................................................... 172
Octane Rating, Gasoline (Fuel) .......................... 274, 278
Oil Change Indicator ....................................................... 59 Reset .......................................................................... 59
Oil Filter, Change .......................................................... 233
Oil Filter, Selection........................................................ 233
Oil Pressure Light............................................................ 65 Oil, Engine ........................................................... 231
, 278 Capacity ................................................................... 277
Checking .................................................................. 230
Dipstick .................................................................... 230
Disposal ................................................................... 233
Filter ......................................................................... 233
Filter Disposal.......................................................... 233
Identification Logo .................................................. 232
Materials Added To ................................................. 233
Pressure Warning Light ............................................ 65
Recommendation...........................................231
, 277
Synthetic .................................................................. 232
Viscosity ................................................................... 277
Onboard Diagnostic System .......................................... 69
Operating Precautions ................................................... 69
Operator Manual Owner's Manual ...................................................... 283
Outside Rearview Mirrors .............................................. 35
PPaddle Shift Mode .......................................................... 82
Paddle Shifters ............................................................... 82 Paint Care ..................................................................... 270
Pair (link) Uconnect Phone To A mobile Phone

b
... 137
Panic Alarm ..................................................................... 13 Parking Brake ................................................................. 74
ParkSense System, Rear ............................................... 92
Passenger Seat Easy Entry .................................................................. 33
Passing Light .................................................................. 41
Performance ................................................................... 60
Performance Shift Indicator .......................................... 59
Personalized Main Menu Bar ...................................... 123
Pets ............................................................................... 196
Phone Mode ................................................................. 135
11

23_LA_OM_EN_USC_t.book Page 289
