Table of contents
General and important labels ........... 1Identification numbers .................... 1
Primary Identification (PRI-ID)
number............................................ 1
Craft Identification Number (CIN) ....... 1
Engine serial number.......................... 1
Manufactured date label .................... 2
Model information ........................... 3
Builder’s plate .................................... 3
Important labels .............................. 4
Warning labels.................................... 5
Other labels ........................................ 8
Safety information ........................... 10 Limitations on who may operate the watercraft ............................. 10
Cruising limitations ........................ 11
Operation requirements ................ 12
Recommended equipment ........... 14
Hazard information........................ 15
Watercraft characteristics ............. 15
Wakeboarding and water-skiing ... 17
Safe boating rules ......................... 18
Enjoy your watercraft responsibly ................................. 19
Description....................................... 20 Watercraft glossary ....................... 20
Location of main components ...... 21
Control function operation ............. 25 Watercraft control functions ......... 25
Yamaha Security System
(VX DELUXE / VX CRUISER / VX
LIMITED) ....................................... 25
Engine stop switch (VX-C)................ 26
Engine start/stop switch (VX / VX DELUXE / VX CRUISER / VX
LIMITED) ....................................... 26
Engine shut-off switch .................... 26
Start switch (VX-C) ........................... 27
Throttle lever .................................... 27 RiDE lever (VX / VX DELUXE /
VX CRUISER / VX LIMITED) .......... 28
Steering system................................ 28
Cooling water pilot outlet ................. 28
Water separator................................ 29
Watercraft operation ...................... 30 Watercraft operation functions ..... 30
Shift system (VX / VX DELUXE /
VX CRUISER / VX LIMITED) .......... 30
Watercraft operation modes (VX DELUXE / VX CRUISER / VX
LIMITED) .................................... 33
Reverse assist .................................. 33
T.D.E. (thrust directional
enhancer) ...................................... 34
No-wake mode ................................. 35
Drive control mode ........................... 36
Cruise assist ..................................... 37
Instrument operation ...................... 39 Multifunction information center (VX-C / VX) ................................. 39
Information display ........................... 39
Multifunction information center (VX DELUXE / VX CRUISER / VX
LIMITED) .................................... 44
Operation buttons ............................ 45
Display.............................................. 45
Home screen ................................... 46
Information screen .......................... 47
Drive control mode screen .............. 47
Setting menu screen ....................... 47
Engine lock screen .......................... 49
Warning function .............................. 49
Audio system (equipped models) ...................................... 52
Audio control .................................... 52
UF4N71E0.book Page 1 Thursday, August 5, 2021 11:58 AM

Instrument operation
45
EJU45951Operation buttons
This model is equipped with a touchpad con-
trol to operate the multifunction information
center.
D-pad
Operate the d-pad to switch or select
screens for each item.
If the right side of the d-pad is pushed when
the home screen is displayed, the multifunc-
tion information center switches in the follow-
ing order.
Home screen → Drive control screen → En-
gine lock screen → Setting screen → Infor-
mation screen → Home screen
“BACK” button
Push this button to go back to the previous
screen.
Push and hold the “BACK” button and the
“OK” button simultaneously to display the
home screen.
“OK” button
Push this button to select the currently high-
lighted item.
TIP
Push this button to stop the buzzer when a
warning is activated.
EJU46290Display
The display is configured as shown below.
Screen tab bar
When each symbol is selected, the watercraft
information, function settings, and other in-
formation are shown in the center display.
(See page 46 for information on each screen.)
Center display
The center display shows the watercraft in-
formation, function settings, and other infor-
mation according to the symbol on the
screen tab bar that is selected.
Warning bar
The warning bar is shown when an error or
malfunction is detected.
Push the “OK” button of the touchpad control
when the warning symbol is displayed to
show the warning description, error code,
and other information in the center display.
(See page 49 for information about the warn-
ing descriptions.)
1 D-pad
2 “BACK” button
3 “OK” button
1
23
1Screen tab bar
2 Center display
1 Warning bar
14.3V
km/h
RPM
2
1
1
UF4N71E0.book Page 45 Thursday, August 5, 2021 11:58 AM

Instrument operation
52
EJU46301
Audio system (equipped models)
This model is equipped with an audio system
that can be connected via Bluetooth.
EJU46312Audio control
This model is equipped with an audio control
to operate the audio system.
Power button
Press this button to turn the audio system on.
Play/Pause button
Press this button to play or pause. Cursor button “ / ”
Press these buttons to skip to the previous or
next track.
Cursor button “ / ”
Press these buttons to adjust the volume.
To connect an external device:
(1) Turn on the Bluetooth function of the ex-
ternal device, and then search for this
audio system.
(2) Turn the audio system on by pushing the power button on the audio control.
(3) Select this audio system to connect to it.
To disconnect an external device:
Turn the Bluetooth function of the external
device off.
1 Speaker
1 12V DC outlet
2 USB charger
3 Audio control
4 Cursor button
5 Play/Pause button
6 Power button
11
1
3
65
4
2
UF4N71E0.book Page 52 Thursday, August 5, 2021 11:58 AM

Index
111
Jet thrust nozzle and reverse gate check (VX / VX DELUXE /
VX CRUISER / VX LIMITED) ................. 74
Jumper cables, connecting.................... 107
L
Labels, important ....................................... 4
Labels, other .............................................. 8
Labels, warning .......................................... 5
Launching the watercraft ......................... 78
Learning to operate your watercraft ........ 77
Leaving the watercraft ............................. 80
Limitations on who may operate the watercraft.............................................. 10
Long-term storage ................................... 94
Lubrication ............................................... 94
M
Main components, location of ................. 21
Maintenance ............................................ 97
Manufactured date label ............................ 2
Model information ...................................... 3
Multifunction information center check ... 76
Multifunction information center (VX DELUXE / VX CRUISER /
VX LIMITED).......................................... 44
Multifunction information center (VX-C / VX) ............................................ 39
N
No-wake mode ........................................ 35
O
Oil pressure warning ................................ 42
Operating in weeded areas ...................... 89
Operating the watercraft .......................... 80
Operating the watercraft in reverse or neutral (VX / VX DELUXE /
VX CRUISER / VX LIMITED) ................. 83
Operating your watercraft ........................ 77
Operation buttons .................................... 45
Operation requirements ........................... 12
P
Periodic maintenance chart ..................... 98
Post-launch checks ................................. 75
Post-operation care ................................. 91
Pre-launch checks ................................... 70
Pre-operation check points ..................... 70
Pre-operation checklist ............................ 68 Primary Identification (PRI-ID) number....... 1
Pull-up cleats (VX CRUISER /
VX LIMITED) .......................................... 57
R
Raising the reverse gate (VX / VX DELUXE / VX CRUISER /
VX LIMITED) ........................................ 107
Reboarding grip ....................................... 55
Reboarding step (VX / VX DELUXE /
VX CRUISER / VX LIMITED).................. 55
Recommended equipment ...................... 14
Reverse assist .......................................... 33
RiDE lever checks (VX / VX DELUXE / VX CRUISER / VX LIMITED).................. 72
RiDE lever (VX / VX DELUXE / VX CRUISER / VX LIMITED).................. 28
Riding position ......................................... 78
Rustproofing ............................................ 95
S
Safe boating rules .................................... 18
Safety equipment check .......................... 74
Seat storage compartment ...................... 59
Seats ........................................................ 54
Setting menu screen ................................ 47
Shift indicator (VX).................................... 41
Shift system check (VX / VX DELUXE /
VX CRUISER / VX LIMITED).................. 76
Shift system (VX / VX DELUXE / VX CRUISER / VX LIMITED).................. 30
Speedometer ........................................... 39
Start switch (VX-C) ................................... 27
Starting off ............................................... 87
Starting off from a trailer .......................... 87
Starting the engine on water .................... 78
Steering system ....................................... 28
Steering system checks ........................... 71
Stern drain plug checks ........................... 75
Stern eyes ................................................ 56
Stopping the engine ................................. 79
Stopping the watercraft ........................... 82
Storage compartment checks.................. 74
Storage compartments ............................ 57
Submerged watercraft ........................... 108
Switch checks .......................................... 73
