4-5. Using the driving support systems
Driving
Approximately 100 cm (3.3 ft.)
Approximately 150 cm (4.9 ft.)
Approximately 60 cm (2.0 ft.)
Approximately 115 cm (3.8 ft.)
(vehicles with front side sensors
and rear side sensors)
The diagram shows the detection range
of the sensors. Note that the sensors
cannot detect objects that are
extremely close to the vehicle.
For details regarding object detection in
the side areas. ( P.305)
The range of the sensors may change
depending on the shape of the object,
etc.
■Multi-information display and head-up display (if equipped)
When an object is detected by a sens or, the approximate distance to the
object will be displayed on the multi- information display and head-up dis-
play (if equipped). (As the distance to the object becomes short, the dis-
tance segments may blink.)
The front side sensor displays and rear side sensor displays (if equipped)
are not shown until a scan of the side areas is completed.
Approximate distance to object: 150 cm (4.9 ft.) to 60 cm (2.0 ft.)* (Rear
center sensor)
*: Automatic buzzer mute function is enabled. ( P.310)
Approximate distance to object: 100 cm (3.3 ft.) to 60 cm (2.0 ft.)* (Front
center sensor)
*: Automatic buzzer mute function is enabled. ( P.310)
Approximate distance to object: 60 cm (2.0 ft.) to 45 cm (1.5 ft.)*(except
front side sensor, rear side sensor)
115 cm (3.8 ft.) to 70 cm (2.3 ft.)* (Front side sensor, rear side sensor)
Multi-information displayHead-up display
Multi-information displayHead-up display
