5116-3. Do-it-yourself maintenance
CAMRY_U
6
Maintenance and care
Install a new light bulb and then install the bulb base to the light
unit by inserting it and turning it clockwise.
Install the light unit.
Align the tabs and push the light
unit toward the front of the vehi-
cle to install it.
Install the 2 bolts.
7
Rear turn signal lightsRear side ma rker lights
8
9

5126-3. Do-it-yourself maintenance
CAMRY_U
Install the cover.
Remove the protective tape.
■Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.
● Headlights
● Daytime running lights
● Parking lights (LED type)
● Front turn signal lights (LED type)
● Front side marker lights (LED type)
● Side turn signal lights (if equipped)
● Tail lights
● Rear side marker lights (LED type)
● Stoplights
● Rear turn signal lights (LED type)
● Back-up lights (LED type)
● High mounted stoplight
● License plate lights
■LED light bulbs
The lights other than the front turn signal/parking lights (bulb type), front side
marker lights (bulb type), back-up lights (bulb type), rear tur n signal lights
(bulb type) and rear side marker lights (bulb type) consist of a number of
LEDs. If any of the LEDs burn out, take your vehicle to your To yota dealer to
have the light replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not
indicate a malfunction.
Contact your Toyota dealer for more information in the followin g situations:
● Large drops of water have built up on the inside of the lens.
● Water has built up inside the headlight.
10
11

516
CAMRY_U
7-1. Essential information
Press the switch.
All the turn signal lights will flash.
To turn them off, press the switch
once again.
■Emergency flashers
●If the emergency flashers are used for a long time while the engine is not
operating, the battery may discharge.
● If any of the SRS airbags deploy (inflate) or in the event of a strong rear
impact, the emergency flashers will turn on automatically.
The emergency flashers will turn off automatically after operating for approx-
imately 20 minutes. To manually turn the emergency flashers off, press the
switch twice.
(The emergency flashers may not turn on automatically depending on the
force of the impact and conditions of the collision.)
Emergency flashers
The emergency flashers are used to warn other drivers when the
vehicle has to be stopped on the road due to a breakdown, etc.

5898-1. Specifications
8
Vehicle specifications
CAMRY_U
*1: Light bulbs not listed in this table are LED bulbs.
*2: If equipped
Light bulbs*1
Light bulbsBulb No.WTy p e
ExteriorFront side marker
lights (bulb type)
W5W 5 A
Front turn signal/
parking lights
(bulb type) 7444NA 28/8 B
Rear turn signal lights
(bulb type) WY21W 21 B
Rear side maker lights
(bulb type) W5W 5 A
Back-up lights
(bulb type) 921 16 A
InteriorRear interior light
*2
8C
Door courtesy lights
*2 5A
Trunk light 5A
A: Wedge base bulbs (clear)
C: Double end bulbs B: Wedge base bulbs (amber)

6108-2. Customization
CAMRY_U■
Power windows, and moon roof* or panoramic moon roof*
(
 P. 179, 183, 187)
*: If equipped
■
Moon roof* (  P. 183)
*: If equipped
■
Automatic light control system ( P. 231)
FunctionDefault settingCustomized setting
Key linked operationOffOn—O
Wireless remote control
linked operationOffOn (open only)—O
Wireless remote control
linked operation signal
(buzzer)
OnOff—O
12
FunctionDefault settingCustomized setting
Linked operation of com-
ponents when key is
used (open only)
Slide onlyTilt only—O
Linked operation of com-
ponents when wireless
remote control is used
Slide onlyTilt only—O
12
FunctionDefault settingCustomized setting
Light sensor sensitivityStandard-2 to 2OO
Time elapsed before
headlights automatically
turn off after doors are
closed
30 seconds
Off
OO60 seconds
90 seconds
12

639Alphabetical index
CAMRY_U
Flat tire...................................... 543
Floor mats .................................. 26
FluidAutomatic transaxle .............. 581
Brake .................................... 583
Washer ................................. 472
Front interior light ................... 406
Front passenger occupant classification system .............. 49
Front passenger’s seat belt reminder light ........................ 531
Front personal lights ............... 407
Front seats ............................... 167 Adjustment ............................ 167
Cleaning................................ 444
Correct driving posture ........... 28
Head restraints ..................... 171
Seat heaters ......................... 402
Seat ventilators ..................... 402
Front side marker lights
Light switch ........................... 231
Replacing light bulbs..... 504, 512
Wattage ................................ 589 Front turn signal lights
Replacing light bulbs .... 503, 512
Turn signal lever ................... 223
Wattage ................................ 589
Fuel
Capacity................................ 577
Fuel gauge.............................. 94
Fuel pump shut off system ... 527
Information............................ 590
Refueling .............................. 244
Type.............................. 577, 590
Warning light......................... 531
Fuel consumption ................... 134
Fuel filler door ......................... 244 Refueling .............................. 244
When the fuel filler door cannot be opened .............. 247
Fuel pump shut off system..... 527
Fuses ........................................ 499
Garage door opener ................ 432
Gauges ....................................... 94
Glove box ................................. 410
Grocery bag hooks.................. 415
F
G

641Alphabetical index
CAMRY_U
JackPositioning the jack ............... 459
Vehicle-equipped jack........... 544
Jack handle .............................. 544
Jam protection function Moon roof.............................. 184
Panoramic moon roof ........... 188
Power window....................... 180
Keyless entry Smart key system ......... 147, 156
Wireless remote control......................... 148, 157
Keys .......................................... 140 Battery-saving function ......... 163
Electronic key ....................... 140
Engine switch................ 209, 211
If the electronic key does not operate properly ........... 559
If you lose your keys ............. 144
Key number plate.................. 140
Keyless entry ........................ 141
Mechanical key ..................... 142
Replacing the battery ............ 494
Warning buzzer..................... 162
Wireless remote control ........ 141
Knee airbags .............................. 36 Lane Tracing Assist (LTA) ...... 270
Language (multi-
information display)...... 107, 124
LATCH anchors ......................... 69
Lever Auxiliary catch lever.............. 457
Hood lock release lever ........ 457
Internal trunk release lever ... 158
Shift lever.............................. 217
Tilt and telescopic steering lock release lever ............... 173
Turn signal lever ................... 223
Wiper lever ........................... 240
License plate lights
Light switch ........................... 231
Replacing light bulbs ............ 512
Light bulbs
Replacing.............................. 502
Wattage ................................ 589
Lights
Automatic High Beam ........... 236
Headlight switch ................... 231
Illuminated entry system ....... 408
Interior lights ......................... 406
Interior lights list.................... 405
Personal lights ...................... 407
Replacing light bulbs ............ 502
Trunk light ............................. 158
Turn signal lever ................... 223
Vanity lights .......................... 416
Wattage ................................ 589
Load capacity .......................... 206
Lock steering column ............. 214
LTA (Lane Tracing Assist) ...... 270
J
K
L
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

644Alphabetical index
CAMRY_U
Radar cruise control (dynamic radar cruise control) ............. 306
Radar cruise control (dynamic radar cruise
control with full-speed
range) ..................................... 290
Radiator .................................... 467
Radio
*
RCTA (Rear Cross Traffic Alert) ..... 345 RCTA Function ..................... 347
Rear Camera Detection Function ................................. 354
Rear Cross Traffic Alert .......... 345
RCTA Function ..................... 347
Rear interior light..................... 406 Wattage ................................ 589
Rear passengers’ seat belt reminder light ........................ 531
Rear personal lights ................ 407
Rear seat
Folding down ........................ 169
Rear side marker lights
Light switch ........................... 231
Replacing light bulbs..... 509, 512
Wattage ................................ 589 Rear turn signal lights
Replacing light bulbs .... 509, 512
Turn signal lever ................... 223
Wattage ................................ 589
Rear view mirror
Inside rear view mirror .......... 175
Outside rear view mirrors ..... 177
Rear view monitor system
*
Rear window
defogger................. 383, 389, 397
Refueling .................................. 244
Capacity................................ 577
Fuel types ............................. 577
Opening the fuel tank cap..... 246
When the fuel filler door cannot be opened .............. 247
Replacing
Electronic key battery ........... 494
Fuses .................................... 499
Light bulbs ............................ 502
Tires...................................... 543
Wireless remote control battery ................................ 494
Reporting safety defects for U.S. owners...................... 616
Resetting the message indicating maintenance
is required.............................. 448
Road Sign Assist ..................... 285
RSA (Road Sign Assist) .......... 285
R
