2022 TOYOTA CAMRY warning

5988-1. Specifications
CAMRY_U
This information has been prepared in accordance with regulations
issued by the National Highway Tr affic Safety Administration of the
U.S. Department of Transportation.
It provides the purchasers and/or prospective purchasers of Toyota
vehicles with info rmation on uniform ti re quality grading.
Your Toyota dealer will help answer any questions you may have as
you read this information.
■DOT quality grades
All passenger vehicle tires must conform to Federal Safety Requ ire-
ments in addition to these grades. Quality grades can be found
where applicable on the tire sidewall between tread shoulder an d
maximum section width.
For example: Treadwear 200 Traction AA Temperature A
■Treadwear
The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a s peci-
fied government t est course.
For example, a tire graded 150 would wear one and a half (1 - 1 /2)
times as well on the governmen t course as a tire graded 100.
The relative performance of tires depends upon the actual condi -
tions of their use. Performance ma y differ significantly from the norm
due to variations in driving habits, service practices and diff erences
in road characteristics and climate.
■Traction AA, A, B, C
The traction grades, from highest to lowest, are AA, A, B and C ,
and they represent the tire’s ability to stop on wet pavement a s
measured under controlled conditions on specified government te st
surfaces of asphalt and concrete.
A tire marked C may have p oor traction performance.
Warning: The traction grade assigned to this tire is based on b raking
(straight ahead) traction tests and does not include cornering (turn-
ing) traction.
Uniform Tire Quality Grading

5998-1. Specifications
8
Vehicle specifications
CAMRY_U■
Temperature A, B, C
The temperature grades are A (
the highest), B, and C, representing
the tire’s resistance to the ge neration of heat and its ability to dissi-
pate heat when tested under contr olled conditions on a specified
indoor laboratory test wheel.
Sustained high temperature can c ause the material of the tire to
degenerate and reduce tire life, and excessive temperature can lead
to sudden tire failure.
Grade C corresponds to a level of performance which all passeng er
car tires must meet under the Fe deral Motor Vehicle Safety Stan-
dard No. 109.
Grades B and A represent higher levels of performance on the labo-
ratory test wheel than the minimum required by law.
Warning: The temperature grades of a tire assume that it is pro perly
inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can c ause heat buildup and possible t ire
failure.

6088-2. Customization
CAMRY_U■
Door lock (
P. 147, 156, 559)
*: Vehicles with a smart key system
■
Smart key system* and wireless remote control
(  P. 147, 156, 161)
*: If equipped
FunctionDefault settingCustomized setting
Unlocking using a key Driver’s door
unlocked in one step, all doors
unlocked in two steps All doors unlocked in
one step. —O
Automatic door lock
Shift position
linked door lock-
ing operationOff
OOSpeed linked door locking operation
Automatic door unlock
Shift position linked door
unlocking opera-
tionOff
OODriver’s door linked
door unlocking oper-
ation
Locking/unlocking of the
trunk when all doors are
locked/unlocked
*
OnOff—O
12
FunctionDefault settingCustomized setting
Operation buzzer vol-
ume5Off to 7OO
Operation signal
(Emergency flashers) On Off O O
Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked 60 seconds
Off
OO
30 seconds
120 seconds
Open door warning
buzzerOnOff —O
12

6138-2. Customization
CAMRY_U
8
Vehicle specifications
WARNING
■During customization
As the engine needs to be running during customization, ensure that the
vehicle is parked in a place with adequate ventilation. In a closed area such
as a garage, exhaust gases including harmful carbon monoxide (CO) may
collect and enter the vehicle. This may lead to death or a seri ous health
hazard.
NOTICE
■ During customization
To prevent battery discharge, ensure that the engine is running while cus-
tomizing features.

614
CAMRY_U
8-3. Items to initialize
Items to initialize
The following items must be initialized for normal system opera-
tion after such cases as the battery being reconnected, or main -
tenance being performed on the vehicle:
ItemWhen to initializeReference
Message indicating mainte-
nance is required
(on some models)• After the maintenance is per- formedP. 448
Tire pressure warning sys-
tem
• When the tire inflation pres-sure is changed such as
when changing traveling
speed or load weight
• When the tire inflation pres- sure is changed such as
when the tire size is
changed
• When rotating the tires
• After performing the trans-
mitter ID code registration
procedure
P. 475

632What to do if... (Troubleshooting)
CAMRY_U
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (P. 210)
Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( P. 2 1 4 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 179)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a peri od of
time. ( P. 214)
●The seat belt reminder light is flashing
Are the driver and the passenger wearing the seat belts? ( P. 531)
●The parking brake indicator is on
Is the parking brake released? (P. 224, 225)
Depending on the situation, other types of warning buzzer may also sound.
( P. 528, 538)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
The engine switch is tur ned off automatically
(vehicles with a smart key system)
A warning buzzer sounds during driving

633What to do if... (Troubleshooting)
CAMRY_U
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 82)
●Vehicles without a smart key system:
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart key system:
To stop the alarm, turn the engine switch to IGNITION ON mode o r start
the engine.
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( P. 538)
●When a warning light turns on or a warning message is displayed , refer to
P. 528, 538.
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. ( P. 543)
●Try the procedure for when the vehicle becomes stuck in mud, di rt, or
snow. ( P. 570)
An alarm is activated and the horn sounds
A warning buzzer sounds w hen leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

634
CAMRY_U
Alphabetical index
Alphabetical index
AAC disc*
ABS (Anti-lock Brake System)...... 322
Warning light ......................... 528
A/C ............................ 382, 387, 394
Air conditioning filter ............. 492
Automatic air conditioning
system ....... ................. 387, 394
Manual air conditioning system ......... ....................... 382
Air conditioning filter .............. 492
Air conditioning system .................... 382, 387, 394
Air conditioning filter ............. 492
Automatic air conditioning
system ....... ................. 387, 394
Manual air conditioning system ......... ....................... 382 Airbags ....................................... 36
Airbag operating conditions .... 45
Airbag preca utions for
your child .............................. 39
Airbag warning light .............. 528
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............. 45
Curtain shield airbag precautions........................... 42
Front passenger occupant
classification syst em ............ 49
General airbag precautions .... 39
Locations of airbags ............... 36
Modification and disposal of airbags ............................. 44
Side airbag operating
conditions ............................. 45
Side airbag precautions .......... 39
Side and curtain shield airbags operating
conditions ............................. 45
Side and curtain shield
airbags precautions .............. 39
SRS airbag instructions for Canadian owners ............... 619
SRS airbags ........................... 36
A
