2022 MAZDA MODEL CX-9 Owners Manual

Specifications
▼Engine
Item
Specification
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 89.0 × 100 mm (3.50 × 3.94 in)
Displacement 2,488.5 ml (2,488.5 cc)
Compression ratio 10.5
▼Electrical System
Item
Classification
Battery
*112V-60Ah/20HR or 12V-65Ah/20HR
Spark-plug number Mazda Genuine spark plug
*2PY8V-18-110
*1 Check the battery installed on the vehicle and use a battery with an equal or higher performance. However, the
performance of the battery may vary even among the same battery types, consult an Authorized Mazda Dealer
for replacement.
*2 The spark plugs provide the SKY ACTIV-G its optimum performance. Consult an Authorized Mazda Dealer
for details.
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate coating on the
iridium alloy and platinum tips could be damaged.
▼ Lubricant Quality
Lubricant
Classification
Engine oil Refer to Recommended Oil on page 6-20.
Coolant FL-22 type
Automatic transaxle fluid
*1Mazda Genuine ATF FZ
Transfer case oil
*2Mazda Long Life Hypoid Gear Oil SG1
Rear differential oil
*2Mazda Long Life Hypoid Gear Oil SG1
Brake fluid SAE J1703 or FMVSS116 DOT-3
*1 Periodic replacement is unnecessary.
*2 Replacement is necessary when the component is submerged in water.
NOTE
Refer to Introduction on (page 6-2) for owner's responsibility in protecting your investment.
Specifications
Specifications
9-4
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

▼Capacities
(Approximate Quantities)
Item
Capacity
Engine oil With oil filter replacement
4.8 L (5.1 US qt, 4.2 Imp qt)
Without oil filter replacement 4.6 L (4.9 US qt, 4.0 Imp qt)
Coolant 9.9 L (10.5 US qt, 8.7 Imp qt)
Automatic transaxle fluid 8.0 L (8.5 US qt, 7.0 Imp qt)
Transfer case oil 0.45 L (0.48 US qt, 0.40 Imp qt)
Rear differential oil 0.35 L (0.37 US qt, 0.31 Imp qt)
Fuel tank FWD
72.0 L (19.0 US gal, 15.8 Imp gal)
AWD 74.0 L (19.5 US gal, 16.3 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
▼Dimensions
U.S.A. and Canada
Item
Vehicle specification
Overall length 5,075 mm (199.8 in)
Overall width 1,969 mm (77.5 in)
Overall height 1,752 mm (69.0 in)
Front tread 1,659 mm (65.3 in)
Rear tread 1,656 mm (65.2 in)
Wheelbase 2,928 mm (115.3 in)
Mexico
ItemVehicle specification
Overall length 5,075 mm (199.8 in)
Overall width 1,969 mm (77.5 in)
Overall height 1,747 mm (68.8 in)
Front tread 1,659 mm (65.3 in)
Rear tread 1,656 mm (65.2 in)
Wheelbase 2,928 mm (115.3 in)
▼We i g h t s
U.S.A. and Canada
Item
Weight
GVWR (Gross Vehicle Weight Rating) 2,641 kg (5,822 lbs)
Specifications
Specifications
9-5
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

ItemWeight
GAWR (Gross Axle Weight Rating) Front
1,250 kg (2,756 lbs)
Rear 1,427 kg (3,146 lbs)
Mexico
Item We i g h t
FWD AWD
GVW (Gross Vehicle Weight) Total 2,495 kg (5,500 lbs) 2,565 kg (5,655 lbs)
Front 1,180 kg (2,601 lbs) 1,205 kg (2,657 lbs)
Rear 1,315 kg (2,899 lbs) 1,360 kg (2,998 lbs)
GAW (Permissible axle load) Front 1,200 kg (2,646 lbs) 1,225 kg (2,701 lbs)
Rear 1,370 kg (3,020 lbs) 1,420 kg (3,131 lbs)
▼
Light Bulbs
Exterior light
Light bulb Category
Wat tage UN-R*1 (SAE)
HeadlightsDaytime running lightsParking lights*
Front side-marker lights*
Fog lights*
Signature wing illumination*
Side turn signal lightsHigh-mount brake lightRear side-marker lightsBrake lightsTaillightsLicense plate lights LED ― (―)
Parking lights/Front side-marker lights
*5W Y5W ( ― )
Front turn signal lights LED type
LED― (―)
Bulb type 21WY21W (7443NA)
Rear turn signal lights 21WY21W (7443NA)
Reverse lights 16W16W (921)
*1 UN-R stands for United Nations Regulation.
Specifications
Specifications
9-6*Some models.
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

Interior light
Light bulbCategory
Wattage UN-R*1
Overhead lights (Front)/Map lights
(Front) LED type LED ―
Bulb type
8―
Overhead lights (Center)/Map lights
(Center) LED type
LED ―
Bulb type 8―
Overhead light (Rear) LED type
LED ―
Bulb type 10―
Ambient lights
*LED ―
Vanity mirror lights
*LED type LED ―
Bulb type 2―
Luggage compartment light LED type
LED ―
Bulb type 8―
*1 UN-R stands for Unite d Nations Regulation.
▼Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally
fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation press
ure.
Refer to Tire Inflation Pressure on page 6-34.
Standard tire
(U.S.A. and Canada)
Tire size Inflation pressure
Front Rear
P255/60R18 107H 230 kPa (34 psi)230 kPa (34 psi)
P255/50R20 104V 230 kPa (34 psi)230 kPa (34 psi)
(Mexico)
Tire size Inflation pressure
Front Rear
P255/50R20 104V 230 kPa (2.3 bar, 33 psi) 230 kPa (2.3 bar, 33 psi)
Specifications
Specifications
*Some models.9-7
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

Temporary spare tire
(U.S.A. and Canada)
Tire sizeInflation pressure
T155/90D17 101M 420 kPa (60 psi)
(Mexico)
Tire sizeInflation pressure
185/80R17 99M 320 kPa (3.2 bar, 46 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 N·m (12―14 kgf·m, 80―108 ft·lbf)
▼ Fuses
Refer to Fuses on page 6-46.
Specifications
Specifications
9-8
CX-9_8KH5-EA-21K_Edition2_old
2021-9-16 14:11:22

10Index
10-1
CX-9_8KH5-EA-21K_Edition2_old2021-9-16 14:11:22

Index
A
Accessory Socket.............................. 5-60
Active Driving Display..................... 4-45
Adaptive Front Lighting System
(AFS)............................................... 4-105
Add-On Non-Genuine Parts and
Accessories........................................ 8-19
Advanced Key
Advanced keyless entry system... 3-10
Operational range........................ 3-11
Advanced Key Removed from Vehicle
Warning Beep.................................... 7-46
Advanced Smart City Brake Support
(Advanced SCBS)........................... 4-157
Collision warning.... .................. 4-159
Stopping the Advanced Smart City
Brake Support (Advanced SCBS)
system operation........................ 4-159
Air Bag Systems............................... 2-69
Air Bag/Seat Belt Pr etensioner System
Warning Beep.................................... 7-45
Antilock Brake System (ABS).......... 4-90
Armrest Box...................................... 5-71
AUTOHOLD..................................... 4-84
AUTOHOLD Warning Beep.............7-47
Automatic Transaxle......................... 4-47 Active Adaptive Shift (AAS)...... 4-49
Automatic transaxle controls....... 4-47
Direct mode................................. 4-56
Driving tips..................................4-57
Manual shift mode.......................4-50
Shift-lock system......................... 4-48
Transaxle ranges.......................... 4-48
B
Battery............................................... 6-30Maintenance.................................6-32
Replacement................................ 6-32
Specifications.................................9-4
Battery Runs Out.............................. 7-19
Jump-starting............................... 7-19
Blind Spot Monitoring (BSM)........ 4-109 Canceling operation of Blind Spot
Monitoring (BSM)..................... 4-113
Blind Spot Monitoring (BSM) Warning
Beep...................................................7-48
Body Lubrication.............................. 6-25
Bottle Holder..................................... 5-69
Brakes
Brake assist.................................. 4-83
Electric parking brake (EPB)...... 4-80
Foot brake....................................4-80
Pad wear indicator....................... 4-83
Warning light............................... 4-82
Break-In Period................................. 3-47
C
Capacities............................................ 9-5
Carbon Monoxide......... .................... 3-29
Cell Phones....................................... 8-20
Center Console.................................. 5-70
Child Restraint Categories of child-restraint
systems.........................................2-49
Child-restraint precautions.......... 2-44
Child-restraint system
installation................................... 2-49
Child-restraint system suitability for
various seat positions table..........2-51
Installing child-restraint
systems.........................................2-55
ISOFIX child-restraint systems
(Mexico)...................................... 2-64
LATCH child-restraint systems
(Except Mexico).......................... 2-64
Child Safety Locks for Rear Doors... 3-18
Climate Control System...................... 5-2 Dual-zone automatic climate
control............................................ 5-5
10-2
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22

Index
Front Air Conditioner....................5-5
Fully Automatic Type....................5-5
Operating tips................................ 5-2
Operating Tips............................... 5-2
Rear Air Conditioner................... 5-11
Vent operation................................5-3
Vent Operation...............................5-3
Vent Operation (Front).................. 5-3
Vent Operation (Rear)................... 5-9
Collision warning.............................. 7-49
Coming Home Light......................... 4-62
Cruise Control................................. 4-235 Cruise control switc h.................4-235
Cruise main indication (white)/cruise
set indication (green)................. 4-236
Cup Holder........................................ 5-67
Customer Assistance.... ....................... 8-2
D
Daytime Running Lights................... 4-63
Defogger
Mirror...........................................4-70
Rear window........... .................... 4-70
Dimensions.......................................... 9-5
Display...............................................4-11
Distance Recognition Support System
(DRSS)............................................ 4-121 Indication on display................. 4-121
Door Locks........................................3-12
Driver Attention Aler t (DAA).........4-125
Drive Selection..................................4-97
Driving In Flooded Ar ea...................3-52
Driving on Uneven Road.................. 3-53
Driving Tips Automatic transaxle.....................4-57
Break-in period............................ 3-47
Driving in flooded a rea............... 3-52
Driving on uneven road...............3-53
Floor mat..................................... 3-49
Hazardous driving.. ..................... 3-48
Overloading............. .................... 3-52
Rocking the vehicle. .................... 3-49
Saving fuel and protection of the
environment................................. 3-47
Turbocharged vehicles.................3-54
Winter driving............................. 3-50
Dynamic Stability Control (DSC)..... 4-93
TCS/DSC indicator light............. 4-93
E
Electric parking brake (EPB)............ 4-80
Electric Parking B rake (EPB) Warning
Beep...................................................7-47
Emergency Starting Push-starting................................ 7-22
Starting a flooded engine............ 7-22
Emergency Towing Towing description...................... 7-25
Towing hooks............. ................. 7-26
Emission Control System..................3-28
Engine Coolant.........................................6-22
Engine compartment overview.... 6-19
Exhaust gas..................................3-29
Hood release................................ 6-17
Oil................................................ 6-20
Starting...........................................4-5
Essential Information.......................... 6-2
Event Data Recorder......................... 8-21
Exhaust Gas...................................... 3-29
Exterior Care..................................... 6-52 Aluminum wheel maintenance.... 6-57
Bright-metal maint enance........... 6-56
Maintaining the fini sh................. 6-53
Plastic part maintenance.............. 6-57
F
Flasher
Hazard warning........................... 4-72
Headlights.................................... 4-58
10-3
CX-9_8KH5-EA-21K_Edition2_old 2021-9-16 14:11:22
