Maintenance
9-26
Front windshield wiper blade
replacement
OGSR076067
Type A
1. Put the front windshield wipers into
the service position.
2. Raise the wiper arm and slightly rotate
the wiper blade assembly to expose
the plastic locking clip.
NOTICE
Do not allow the wiper arm to fall
against the windshield, since it may
chip or crack the windshield.
OGSR076066
OGSR076068
3. Press the clip (1) and slide the blade
assembly downward (2).
4. Lift it off the arm.
5. Install the blade assembly in the
reverse order of removal.
6. Return the wiper arm on the
windshield.

09
9-77
The emission control system of your
vehicle is covered by a written limited
warranty. Please see the warranty
information contained in the Service
Passport in your vehicle.
Your vehicle is equipped with an
emission control system to meet all
applicable emission regulations. There
are three emission control systems, as
follows.
(1) Crankcase emission control system
(2) Evaporative emission control system
(3) Exhaust emission control system
In order to ensure the proper function
of the emission control systems, it
is recommended that you have your
vehicle inspected and maintained
by an authorized HYUNDAI dealer in
accordance with the maintenance
schedule in this manual.
NOTICE
For the Inspection and Maintenance
Test (with Electronic Stability Control
(ESC) system)
To prevent the vehicle from misfiring
during dynamometer testing, turn
the Electronic Stability Control
(ESC) system off by pressing the ESC
switch (ESC OFF light illuminated).
After dynamometer testing is
completed, turn the ESC system back
on by pressing the ESC switch again.
1. Crankcase emission control
system
The positive crankcase ventilation system
is employed to prevent air pollution
caused by blow-by gases being emitted
from the crankcase. This system supplies
fresh filtered air to the crankcase through
the air intake hose. Inside the crankcase,
the fresh air mixes with blow-by gases,
which then pass through the PCV valve
into the induction system.
2. Evaporative emission control
system
The Evaporative Emission Control System
is designed to prevent fuel vapors from
escaping into the atmosphere.
Canister
Fuel vapors generated inside the fuel
tank are absorbed and stored in the
onboard canister. When the engine is
running, the fuel vapors absorbed in the
canister are drawn into the surge tank
through the purge control solenoid valve.
Purge Control Solenoid Valve (PCSV)
The purge control solenoid valve
is controlled by the Engine Control
Module (ECM); when the engine coolant
temperature is low during idling, the
PCSV closes so that evaporated fuel
is not taken into the engine. After the
engine warms-up during ordinary
driving, the PCSV opens to introduce
evaporated fuel to the engine.
EMISSION CONTROL SYSTEM

I
I-9
Light bulbs ........................................................................................................... 9-58
Front fog lamp .................................................................................................. 9-62
Headlamp, position lamp, turn signal lamp, Daytime Running Light (DRL)
replacement ...................................................................................................... 9-59
High mounted stop lamp replacement.............................................................. 9-65
Interior Light Bulb Replacement...................................................................... 9-66
License Plate Light Bulb Replacement ........................................................... 9-66
Rear combination lamp bulb replacement........................................................ 9-63
Side repeater lamp replacement ....................................................................... 9-63
Lighting ............................................................................................................... 5-67
Exterior lights ................................................................................................... 5-67
Interior lights .................................................................................................... 5-71
Luggage compartment lamp ............................................................................. 5-73
Welcome System .............................................................................................. 5-73
M
Maintenance services............................................................................................. 9-4
Owner maintenance precautions ........................................................................ 9-4
Owner’s responsibility ....................................................................................... 9-4
Manual climate control system ............................................................................ 5-81
Heating and air conditioning ............................................................................ 5-82
System maintenance ......................................................................................... 5-87
System operation .............................................................................................. 5-85
Mirrors ................................................................................................................. 5-39
Inside rearview mirror ...................................................................................... 5-39
Side View mirrors............................................................................................. 5-50
N
Navigation-Based Smart Cruise Control (NSCC) .............................................. 7-81
Limitations of Navigation-based Smart Cruise Control .................................. 7-84
Navigation-based Smart Cruise Control operation .......................................... 7-82
Navigation-based Smart Cruise Control settings ............................................. 7-81
O
Owner maintenance ............................................................................................... 9-5
Owner maintenance schedule ............................................................................. 9-6

Index
I-10
P
Parking brake ....................................................................................................... 9-22
Checking the parking brake.............................................................................. 9-22
R
Rear Cross-Traffic Collision-Avoidance Assist (RCCA) .................................. 7-102
Rear Cross-Traffic Safety system malfunction and limitations ..................... 7-108
Rear Cross-Traffic Safety system operation................................................... 7-104
Rear Cross-Traffic Safety system settings ..................................................... 7-103
Rear View Monitor (RVM) ................................................................................. 7-99
Rear View Monitor malfunction and limitations............................................ 7-101
Rear View Monitor operation ......................................................................... 7-100
Rear View Monitor settings............................................................................ 7-100
Recommended lubricants and capacities ............................................................. 2-13
Recommended SAE viscosity number ............................................................. 2-14
Refrigerant label .................................................................................................. 2-16
Reporting safety defects ...................................................................................... 2-18
Reverse Parking Distance Warning (PDW) ....................................................... 7-113
Reverse Parking Distance Warning malfunction and precautions ................. 7-114
Reverse Parking Distance Warning operation ................................................ 7-113
Reverse Parking Distance Warning settings .................................................. 7-113
S
Safe Exit Warning (SEW) ................................................................................... 7-49
Safe Exit Warning malfunction and limitations .............................................. 7-52
Safe Exit Warning operation ............................................................................ 7-51
Safe Exit Warning Settings............................................................................... 7-50
Safety messages ..................................................................................................... 1-4
Scheduled maintenance services............................................................................ 9-7
Maintenance Under Severe Usage Conditions ................................................. 9-11
Normal Maintenance Schedule .......................................................................... 9-8
Seat belts .............................................................................................................. 3-20
Additional seat belt safety precautions............................................................. 3-27
Care of seat belts .............................................................................................. 3-29
Seat belt restraint system .................................................................................. 3-22
Seat belt safety precautions .............................................................................. 3-20
Seat belt warning light...................................................................................... 3-21

Index
I-12
T
Theft-alarm system .............................................................................................. 5-35
Tire Pressure Monitoring System (TPMS) (Type A) ............................................. 8-9
Low tire pressure telltale .................................................................................. 8-10
TPMS (Tire Pressure Monitoring System) malfunction indicator ................... 8-10
Tire Pressure Monitoring System (TPMS) (Type B) ........................................... 8-13
Changing a tire with TPMS .............................................................................. 8-16
Check tire pressure ........................................................................................... 8-13
Low tire pressure position and tire pressure telltale......................................... 8-15
Low tire pressure warning light ....................................................................... 8-15
Tire pressure monitoring system ...................................................................... 8-14
TPMS malfunction indicator ............................................................................ 8-16
Tire specification and pressure label ................................................................... 2-15
Tires and wheels .......................................................................................... 2-11,9-33
All Season Tires ............................................................................................... 9-43
Check tire inflation pressure ............................................................................ 9-34
Low aspect ratio tires ....................................................................................... 9-44
Radial-Ply Tires ................................................................................................ 9-44
Recommended cold tire inflation pressures ..................................................... 9-33
Snow Tires ........................................................................................................ 9-43
Summer Tires ................................................................................................... 9-43
Tire care............................................................................................................ 9-33
Tire maintenance .............................................................................................. 9-37
Tire replacement ............................................................................................... 9-36
Tire rotation ...................................................................................................... 9-35
Tire sidewall labeling ....................................................................................... 9-38
Tire Terminology and Definitions ................................................................... 9-41
Tire traction ...................................................................................................... 9-37
Wheel alignment and tire balance .................................................................... 9-36
Wheel replacement ........................................................................................... 9-37
Towing ................................................................................................................. 8-33
Emergency Towing .......................................................................................... 8-35
Removable Towing Hook ................................................................................ 8-34
Tie-down Hook................................................................................................. 8-36
Towing service ................................................................................................. 8-33
Trademarks ........................................................................................................ 5-123
Trailer Towing ..................................................................................................... 6-75
