2022 ACURA RDX rear view mirror

Contents
Child Safety P. 64Exhaust Gas Hazard P. 77Safety Labels P. 78
Tailgate P. 173 Security System P. 183Windows P. 186
Operating the Switches Around the Steering Wheel P. 193 Mirrors P. 213
Interior Convenience Items P. 230 Climate Control System P. 247
Audio Error Messages P. 332General Information on the Audio System P. 336
Bluetooth ® HandsFreeLink ® P. 389 AcuraLink ® P. 419
Off-Highway Driving Guidelines P. 441 When Driving P. 443 AcuraWatchTM P. 483
Multi-View Rear Camera* P. 564 Surround View Camera System*P. 566 Refueling P. 574
Maintenance Under the Hood P. 590 Replacing Light Bulbs P. 603
Checking and Maintaining Tires P. 612 Battery P. 621 Remote Transmitter Care P. 623
Accessories and Modifications P. 633
Handling of the Jack P. 659 Engine Does Not Start P. 660 If the Battery Is Dead P. 663
Fuses P. 674 Emergency Towing P. 681
If You Cannot Open the Tailgate P. 683 Refueling P. 684
Devices that Emit Radio Waves P. 689 Reporting Safety Defects P. 690 Emissions Testing P. 691
Client Service Information P. 697
Quick Reference GuideP. 6
Safe DrivingP. 31
Instrument PanelP. 79
ControlsP. 153
FeaturesP. 253
DrivingP. 429
MaintenanceP. 579
Handling the UnexpectedP. 635
InformationP. 685
IndexP. 698
22 ACURA RDX-31TJB6300.book 5 ページ ２０２１年８月２日　月曜日　午前１１時０分

Visual Index
8
Quick Reference Guide
❚Rearview Mirror (P 213)
❚Shift Button
Electronic Gear Selector
(P 451)
❚Driver’s Front Airbag (P 49)
❚Glove Box (P 233)
❚Passenger’s Front Airbag (P 49)
❚HomeLink® Buttons (P 387)
❚Interior Fuse Box Type A (P 677)
❚Dynamic Mode Switch (P459 )
❚Front Passenger’s Knee Airbag (P 54)
❚True Touchpad Interface (P 261)
❚USB Port (P 255)
❚Driver’s Knee Airbag (P 54)
❚USB Ports* (P 256)
❚Power Window Switches (P 186)
❚Memory Buttons (P 211)
❚SET Button (P 211)
❚Master Door Lock Switch (P 171)
❚Door Mirror Controls (P 214)
❚Hood Release Handle (P 591)
❚Power Tailgate Button (P 177)
❚Interior Fuse Box Type C (P 679)
❚Rear Seat Heater Buttons* (P 246)
❚Interior Fuse Box Type B (P 678)
22 ACURA RDX-31TJB6300.book 8 ページ ２０２１年８月２日　月曜日　午前１１時０分

Visual Index
10
Quick Reference Guide
❚How to Refuel (P 575)
❚High-Mount Brake Light (P 606)
❚Opening/Closing the Tailgate (P173)
❚Rear Wiper (P 206, 610)
❚Taillights, Brake and Rear Side Marker Lights (P 197, 605)
❚Rear Turn Signal Lights (P 196, 604)
❚Multi-View Rear Camera* (P 564)
❚Rear License Plate Light (P 197, 606)
❚Tailgate Outer Handle (P 178, 182)
❚Taillights/Brake and Back-Up Lights (P 197, 606)
❚Windshield Wipers (P 204, 607)
❚Power Door Mirrors (P 214)
❚Maintenance Under the Hood (P 590)
❚Fog Lights* (P 200, 603)
❚Tires (P 612, 637, 645)
❚Door Lock/Unlock Control (P 160)
❚Front Turn Signal Lights (P 196, 603)
❚Parking/Daytime Running Lights (P 197, 603)
❚Side Turn Signal Lights (P 196, 603)
❚Headlights (P 197, 603)
❚Front Side Marker Lights (P197, 603)
❚Surround View Camera System* (P 566)
❚Rearview Camera Washer* (P 204)
22 ACURA RDX-31TJB6300.book 10 ページ ２０２１年８月２日　月曜日　午前１１時０分

24
Quick Reference Guide
AcuraWatchTM (P483)
AcuraWatch
TM is a driver support system
which employs the use of two distinctly
different kinds of sensors, a radar sensor
located behind the emblem, and a front
sensor camera mounted to the interior side
of the windshield, behind the rearview
mirror.
AcuraWatch
TM is a driver support system
which employs the use of three distinctly
different kinds of sensors, a radar sensor
located behind the emblem, a front sensor
camera mounted to the interior side of the
windshield, behind the rearview mirror, and
the sonar sensors located in the front and
rear bumpers.
Models without Low Speed Braking Control
Models with Low Speed Braking Control
All models
Front Sensor
Camera
Radar Sensor
Models with Low Speed Braking Control
Sonar Sensors
Collision Mitigation
Braking System
TM
(CMBS
TM) (P486)
The system can assist you when it
determines there is a possibility of your
vehicle colliding with a vehicle or a
pedestrian detected in front of your vehicle.
The CMBS
TM is designed to alert you when
the potential for a collision is determined, as
well as to reduce your vehicle speed to help
minimize collision severity when a collision is
deemed unavoidable.
Low Speed Braking
Control
* (P497)
Using sonar sensors lo cated on the front and
rear bumpers, this system detects if there is
danger of a potential collision with a wall or
other obstacle during normal driving. The
system then assists in av oiding collisions and
reducing damage from impact through
assistive braking.
22 ACURA RDX-31TJB6300.book 24 ページ ２０２１年８月２日　月曜日　午前１１時０分

153
Controls
This chapter explains how to operate the various controls necessary for driving.
Clock.................................................. 154
Locking and Unlocking the Doors Key .................................................. 156
Low Keyless Remote Signal Strength ... 159
Locking/Unlocking the Doors from the Outside .......................................... 160
Locking/Unlocking the Doors from the Inside ............................................. 169
Childproof Door Locks ..................... 171
Auto Door Locking/Unlocking .......... 172
Tailgate .............................................. 173
Security System Immobilizer System .......................... 183 Security System Alarm...................... 183
Windows ........................................... 186
Panoramic Roof ................................. 189
Operating the Switches Around the Steering Wheel ENGINE START/STOP Button............. 193
Turn Signals ..................................... 196
Light Switches.................................. 197
Fog Lights
*...................................... 200
Daytime Running Lights ................... 200
Auto High-Beam .............................. 201
Wipers and Washers ........................ 204
Brightness Control ........................... 208
Rear Defogger/Heated Door Mirror Button ........................................ 207
Heated Windshield Button*............. 207
Driving Position Memory System ...... 210
Adjusting the Steering Wheel .......... 212
Mirrors Interior Rearview Mirror ................... 213
Power Door Mirrors ......................... 214
Seats .................................................. 216
Interior Convenience Items .............. 230
Climate Control System Using Automatic Climate Control .... 247
Automatic Climate Control Sensors ... 252
* Not available on all models
22 ACURA RDX-31TJB6300.book 153 ページ ２０２１年８月２日　月曜日　午前１１時０分

213
Controls
Mirrors
Interior Rearview Mirror
Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.
When you are driving after dark, the
automatic dimming rearview mirror and
automatic dimming power door mirrors
reduce the glare from headlights behind you,
based on inputs from the mirror sensor. Press
the auto button to turn this function on and
off. When activated, the auto indicator comes
on.
■Automatic Dimming Power Door Mirrors* and Rearview
Mirror
1 Mirrors
Keep the inside and out side mirrors clean and
adjusted for best visibility.
Adjust the mirrors befo re you start driving.
2 Front Seats P. 216
Auto Button
Sensor1Automatic Dimming Power Door Mirrors* and Rearview Mirror
The auto dimming function cancels when the
transmission is in
( R.
* Not available on all models
22 ACURA RDX-31TJB6300.book 213 ページ ２０２１年８月２日　月曜日　午前１１時０分

377
uuCustomized Features u
Continued
Features*1:Default SettingSetup Group
Customizable Features DescriptionSelectable Settings
VehicleMeter Setup Speed Limit Information Select whether the speed limit
information source is camera located
behind the rearview mirror or the
navigation system. You can also turn
off speed limit information. Traffic Sign
Recognition
*1/
Navigation /Off
Speed Limit Information Selects whether the speed limit
information should be displayed on
head-up display
*/meter.
On
*1/
Off
Models with navigation system
Models without navigation system
* Not available on all models
22 ACURA RDX-31TJB6300.book 377 ページ ２０２１年８月２日　月曜日　午前１１時０分

Continued431
uuBefore Driving uDriving Preparation
Driving
• Store or secure all items on board properly.
u Carrying too much cargo, or improperly storing it, can affect your vehicle’s
handling, stability, sto pping distance, and tires, and make it unsafe.
2Maximum Load Limit P. 433
•Do not pile items higher than the seat height.
u They can block your view and may be thrown forward in the event of sudden
braking.
• Do not place anything in the front seat footwells. Make sure to secure the floor
mat.
u An object or unsecured floor mat can in terfere with your brake and accelerator
pedal operation while driving.
• If you have any animals on board, do not let them move around in the vehicle.
u They may interfere with driv ing and a crash could occur.
• Securely close and lock al l doors and the tailgate.
2Locking/Unlocking the Doors from the Inside P. 169
•Adjust your seating position properly.
u Adjust the head restraint, too.
2Seats P. 216
2 Adjusting the Front and Rear Outer Head Restraint Positions P. 225
•Adjust the mirrors and steering wheel properly.
u Adjust them while sitting in the proper driving position.
2 Adjusting the Steering Wheel P. 212
2 Mirrors P. 213
■Interior Checks1Interior Checks
The headlight aim is set by the factory, and does not
need to be adjusted. Howeve r, if you regularly carry
heavy items in the cargo area or tow a trailer, have
the aiming readjusted at a dealer or by a qualified
technician.
22 ACURA RDX-31TJB6300.book 431 ページ ２０２１年８月２日　月曜日　午前１１時０分
