2021 YAMAHA VX Owners Manual

Table of contents
Raising the reverse gate (VX / VX DELUXE / VX CRUISER /
VX LIMITED) ................................ 108
Jumping the battery ....................... 108
Towing the watercraft .................... 109
Submerged watercraft ................... 109
Index ............................................... 111
UF4N70E0.book Page 3 Tuesday, October 6, 2020 5:13 PM

General and important labels
1
EJU36452
Identification numbers
Record the Primary Identification (PRI-ID)
number, Craft Identification Number (CIN),
and engine serial number in the spaces pro-
vided for assistance when ordering spare
parts from a Yamaha dealer. Also record and
keep these ID numbers in a separate place in
case your watercraft is stolen.
EJU30284Primary Identification (PRI-ID) number
The PRI-ID number is stamped on a plate at-
tached inside the engine compartment. (See
page 54 for seat removal and installation pro-
cedures and page 59 for information on the
seat storage compartment.)
MODEL:
VX1050G-W (VX-C)
VX1050F-W (VX)
VX1050E-W (VX DELUXE)
VX1050D-W (VX DELUXE)
VX1050C-W (VX CRUISER)VX1050B-W (VX CRUISER)
VX1050A-W (VX LIMITED)
EJU36551Craft Identification Number (CIN)
The CIN is stamped on a plate attached to
the aft deck.
1
Primary Identification (PRI-ID) number loca-
tion
1 Craft Identification Number (CIN) location
1
MODELYAMAHA MOTOR CO.,LTD.
ASSEMBLED IN U.S.A. WITH FOREIGN AND DOMESTIC COMPONENTS.
ASSEMBLÉ EN U.S. AVEC DES COMPOSANTS ÉTRANGERS ET
DOMESTIQUES. PRI-I.D.
1
UF4N70E0.book Page 1 Tuesday, October 6, 2020 5:13 PM

General and important labels
2
EJU30312Engine serial number
The engine serial number is stamped on a
plate attached to the engine unit. (See page
54 for seat removal and installation proce-
dures.)
EJU44090Manufactured date label
This label is attached to the port side of the
air filter case. (See page 54 for seat removal
and installation procedures.)
1Engine serial number location
1
1Manufactured date label location
1
UF4N70E0.book Page 2 Tuesday, October 6, 2020 5:13 PM

General and important labels
3
EJU30321
Model informationEJU30333Builder’s plate
Watercraft with this label conform to certain
portions of the European Parliament directive
relating to machinery.
Part of the information is given on the build-
er’s plate affixed on the craft. A full explana-
tion of this information is given in the relevant
sections of this manual.
Design category of this personal water-
craft: C
Category C:
This watercraft is designed to operate in
winds up to Beaufort force 6 and the associ-
ated wave heights (significant wave heights
up to 2 m (6.56 ft); see the following TIP).
Such conditions may be encountered in ex-
posed inland waters, in estuaries, and in
coastal waters in moderate weather condi-
tions.
TIP:
The significant wave height is the mean
height of the highest one-third of the waves,
which approximately corresponds to the
wave height estimated by an experienced
observer. However, some waves will be dou-
ble this height.
1Builder’s plate location
1
YAMAHA MOTOR CO., LTD.
WATERCRAFT DESIGN CATEGORY : C
MAXIMUM CAPACITIES
2500 Shingai, Iw ata, Shizuoka, Japan
Max. 3
Max. + = 240kg (530 lbs)
UF4N70E0.book Page 3 Tuesday, October 6, 2020 5:13 PM

General and important labels
4
EJU30454
Important labels
Read the following labels before using this watercraft. If you have any questions, consult a
Yamaha dealer.
1
6
2
3
5
10947
8
UF4N70E0.book Page 4 Tuesday, October 6, 2020 5:13 PM

General and important labels
5
EJU35914Warning labels
If any of these labels are damaged or missing, contact a Yamaha dealer for replacements.
1 VX-C/VX
UF4N70E0.book Page 5 Tuesday, October 6, 2020 5:13 PM

General and important labels
6
F3V-U41B1-30
1 VX DELUXE/VX CRUISER/VX LIMITED
2
UF4N70E0.book Page 6 Tuesday, October 6, 2020 5:13 PM

General and important labels
7
F3V-U41B1-10
F1B-U415B-11
F1S-U415B-11
F3V-U416A-10
F3V-U416A-30
3
4
5
