5458-2. Steps to take in an emergency
8
When trouble arises
the steam subsides.
If you do not see steam:
Carefully lift the hood.
3 After the hybrid system has
cooled down sufficiently,
inspect the hoses and radia-
tor core (radiator) for any
leaks.
Radiator
Cooling fan
If a large amount of coolant leaks,
immediately contact your Toyota
dealer.
4The coolant level is satisfac-
tory if it is between the
“FULL” and “LOW” lines on
the reservoir.
Reservoir
“FULL” line
“LOW” line 5
Add coolant if necessary.
Water can be used in an emer-
gency if engine coolant is unavail-
able.
If water was added in an emer-
gency, have the vehicle inspected
at your Toyota dealer as soon as
possible.
6Start the hybrid system and
turn the air conditioning sys-
tem on to check that the radi-
ator cooling fan operates and
to check for coolant leaks
from the radiator or hoses.
The fan operates when the air con-
ditioning system is turned on imme-
diately after a cold start. Confirm
that the fan is operating by check-
ing the fan sound and air flow. If it is
difficult to check these, adjust the
temperature control switch to “LO”
and turn the “A/C” switch ON and
OFF. After this, turn the air condi-
tioning system on and off repeat-
edly. (The fan may not operate in
freezing temperatures.)
7 If the fan is not operating:
Stop the hybrid system
immediately and contact your
Toyota dealer.
If the fan is operating:
Have the vehicle inspected at
the nearest Toyota dealer.
8 Check if “Engine Coolant
Temp High Stop in a Safe
A
B
A
B
C

5468-2. Steps to take in an emergency
Place See Owner’s Manual”
is shown on the multi-infor-
mation display.
If the message does not disappear:
Stop the hybrid system and contact
your Toyota dealer.
If the message is not displayed:
Have the vehicle inspected at the
nearest Toyota dealer.
■If “Hybrid System Over-
heated Output Power
Reduced” is shown on the
multi-information display
1 Stop the vehicle in a safe
place.
2 Stop the hybrid system and
carefully lift the hood.
3 After the hybrid system has
cooled down, inspect the
hoses and radiator core (radi-
ator) for any leaks.
Radiator
Cooling fan
If a large amount of coolant leaks,
immediately contact your Toyota
dealer.
4The coolant level is satisfac-
tory if it is between the “FULL” and “LOW” lines on
the reservoir.
Reservoir
“FULL” line
“LOW” line
5 Add coolant if necessary.
Water can be used in an emer-
gency if power control unit coolant
is unavailable.
If water was added in an emer-
gency, have the vehicle inspected
at your Toyota dealer as soon as
possible.
6After stopping the hybrid sys-
tem and waiting for 5 minutes
or more, start the hybrid sys-
tem again and check for the
multi-information display.
If the message does not disappear:
Stop the hybrid system and contact
your Toyota dealer.
If the message is not displayed:
The hybrid system temperature has
A
B
A
B
C

5478-2. Steps to take in an emergency
8
When trouble arises
dropped and the vehicle may be
driven normally.
However, if the message appears
again frequently, contact your
Toyota dealer.
WARNING
■When inspecting under the
hood of your vehicle
Observe the following precau-
tions.
Failure to do so may result in seri-
ous injury such as burns.
●If steam is seen coming from
under the hood, do not open the
hood until the steam has sub-
sided. The engine compart-
ment may be very hot.
●After the hybrid system has
been turned off, check that the
“READY” indicator is off.
When the hybrid system is oper-
ating, the gasoline engine may
automatically start, or the cool-
ing fan may suddenly operate
even if the gasoline engine
stops. Do not touch or approach
rotating parts such as the fan,
which may lead to fingers or
clothing (especially a tie, a scarf
or a muffler) getting caught,
resulting in serious injury.
●Do not loosen the coolant reser-
voir cap while the hybrid system
and radiator are hot.
High temperature steam or
coolant could spray out.
NOTICE
■When adding engine/power
control unit coolant
Add coolant slowly after the
hybrid system has cooled down
sufficiently. Adding cool coolant to
a hot hybrid system too quickly
can cause damage to the hybrid
system.
■To prevent damage to the
cooling system
Observe the following precau-
tions:
●Avoid contaminating the coolant
with foreign matter (such as
sand or dust, etc.).
●Do not use any coolant additive.

5488-2. Steps to take in an emergency
1Stop the hybrid system. Set
the parking brake and shift
the shift lever to P.
2 Remove the mud, snow or
sand from around the stuck
tire.
3 Place wood, stones or some
other material to help provide
traction under the tires.
4 Restart the hybrid system
5 Shift the shift lever to D or R
and release the parking
brake. Then, while exercising
caution, depress the acceler-
ator pedal.
■When it is difficu lt to free the
vehicle
Press to turn off TRAC.
(  P.382)
If the vehicle becomes
stuck
Carry out the following pro-
cedures if the tires spin or
the vehicle becomes stuck
in mud, dirt or snow:
Recovering procedure
WARNING
■When attempting to free a
stuck vehicle
If you choose to push the vehicle
back and forth to free it, make
sure the surrounding area is clear
to avoid striking other vehicles,
objects or people. The vehicle
may also lunge forward or lunge
back suddenly as it becomes free.
Use extreme caution.
■When shifting the shift lever
Be careful not to shift the shift
lever with the accelerator pedal
depressed.
This may lead to unexpected
rapid acceleration of the vehicle
that may cause an accident
resulting in dea th or serious
injury.
NOTICE
■To avoid damaging the trans-
mission and other compo-
nents
●Avoid spinning the wheels and
depressing the accelerator
pedal more than necessary.
●If the vehicle remains stuck
even after these procedures are
performed, the vehicle may
require towing to be freed.

597What to do if... (Troubleshooting)
tem can be started in a tem-
porary way. (P.538)
 Is the 12-volt battery dis-
charged? ( P.539)
 Is the power switch in ON?
If you cannot release the shift
lever by depressing the brake
pedal with the power switch in
ON ( P.286)
 It is locked automatically to
prevent theft of the vehicle.
( P.280)
 Is the window lock switch
pressed?
The power window except for
the one at the driver’s seat
cannot be operated if the win-
dow lock switch is pressed.
( P.248)
 The auto power off function
will be operated if the vehicle
is left in ACC or ON (the
hybrid system is not operat- ing) for a period of time.
(
P.283)
 The seat belt reminder light is
flashing
Are the driver and the passengers
wearing the seat belts? ( 
P.518,
519
)
 The parking brake indicator is
on
Is the parking br ake released?
( 
P.290)
Depending on the situation,
other types of warning buzzer
may also sound. ( P.511, 523)
 Did anyone inside the vehicle
open a door during setting the
alarm?
The sensor detects it and the
alarm sounds. ( P.73)
To stop the alarm, turn the power
switch to ON or start the hybrid sys-
tem.
 Is the message displayed on
the multi-information display?
Check the message on the
multi-information display.
The shift lever cannot be
shifted from P even if you
depress the brake pedal
The steering wheel can-
not be turned after the
hybrid system is stopped
The windows do not open
or close by operating the
power window switches
The power switch is
turned off automatically
A warning buzzer sounds
during driving
An alarm is activated and
the horn sounds (if
equipped)
A warning buzzer sounds
when leaving the vehicle

Alphabetical Index603
Eco drive mode ...................... 377
EDR (Event data recorder)......... 8
E-Four (Electronic On-Demand AWD system) ........................ 381
Elapsed time ........................... 176
Electric motor Location.................................. 76
Specification ......................... 552
Electric Power Steering (EPS) Function ............................... 381
Warning light ........................ 513
Electronically Controlled Brake System (ECB) ....................... 380
Electronic key Battery-saving function......... 218
If the electronic key does not operate properly ................. 537
Replacing the battery ........... 493
Electronic sunshade .............. 252 Jam protection function ........ 253
Operation ............................. 252
Emergency, in case of If a warning buzzer sounds .. 511
If a warning light turns on ..... 511
If a warning message is dis-played................................. 523
If the 12-volt battery is dis- charged .............................. 539
If the electronic key does not operate properly ................. 537
If the fuel filler door cannot be opened ............................... 536
If the hybrid sy stem will not start
........................................... 534
If the vehicle is trapped in rising water .................................. 506
If you have a flat tire ............. 527
If you lose your keys ............ 536
If you think something is wrong ........................................... 509
If your vehicle becomes stuck ........................................... 548 If your vehicle has to be stopped
in an emergency .................505
If your vehicle needs to be towed ...........................................507
If your vehicle ove rheats ......544
Emergency flashers ...............504
Energy monitor .......................187
Engine Compartment........................460
Exhaust gas precautions ........49
Hood .....................................457
How to start the hybrid system...........................................279
Identification number ............551
If the hybrid sys tem will not start
...........................................534
If your vehicle has to be stopped in an emergency .................505
Overheating ..........................544
Power switch ........................279
Engine coolant Capacity ...............................553
Checking ..............................462
High coolant temperature warn-ing light ...............................512
Preparing and checking before winter ..................................387
Warning light ........................512
Engine oil Capacity ...............................552
Checking ..............................460
Preparing and checking before winter ..................................387
Warning light ........................512
Enhanced Vehicle Stability Con- trol (Enhanced VSC ) .............381
Enhanced VSC (Enhanced Vehi- cle Stability Control).............381
EPS (Electric Po wer Steering)
Function................................381
Warning light ........................513
EV/HV mode selection switch .78

Alphabetical Index605
Heated steering wheel ......... 407
Hybrid battery (traction battery)........................................... 115
Outside rear view mirrors ..... 398
Seat heaters ......................... 407
High coolant temperature warn- ing light ................................. 512
High mounted stoplight Replacing light bulbs ............ 497
High voltage components ....... 87
Hill-start assist control .......... 381
Hood ........................................ 457 Warning message ................ 523
Hooks Cargo hooks ......................... 417
Coat hooks ........................... 435
Retaining hooks (floor mat) .... 26
Horn ......................................... 232
HV mode .................................... 77
Hybrid battery (tr action battery)
Charging............................... 123
Location.................................. 87
Specification ......................... 552
Hybrid battery (traction battery) charge mode ........................... 79
Hybrid system ACC...................................... 283
Acoustic Vehicle Alerting System............................................. 85
Brake Override System ........ 259
Drive-Start Control ............... 259
Emergency shut off system .... 91
Energy monitor/consumption screen ................................ 187
High voltage components....... 87
How to start the hybrid system ........................................... 279
Hybrid System Indicator ....... 165
If the hybrid sy stem will not start
........................................... 534
If your vehicle has to be stopped in an emergency................. 505 Ignition switch (power switch)
...........................................279
Overheating ..........................544
Plug-in hybrid system precau- tions ......................................87
Plug-in hybrid vehicle driving tips .............................................92
Power (ignition) switch .........279
Regenerative braking .............82
Starting the hybrid system ....279
Hybrid System Indicator ........165
Hybrid transmissio n ...............285
S mode .................................288
I
I/M test .....................................454
Identification Engine ..................................551
Vehicle..................................550
Ignition switch (power switch) ...............................................279Auto power off fun ction.........283
Changing the power switch modes.................................283
If your vehicle has to be stopped in an emergency .................505
Starting the hybrid system ....279
Immobilizer system ..................72
Indicators ................................160
Initialization Items to initialize ...................582
Maintenance .........................451
Moon roof .............................250
Panoramic moon r oof ...........253
Power back door ..................212
Power windows ....................246
Tire pressure warning system ...........................................474
Inside rear view m irror ...233, 234
Instrument panel light control ...............................................169
Interior lights...........................410

Alphabetical Index609
Warning light ........................ 513
Power switch .......................... 279 Auto power off function ........ 283
Changing the power switch modes ................................ 283
If your vehicle has to be stopped in an emergency................. 505
Starting the hybrid system.... 279
Power windows Catch protection function ..... 246
Door lock linked window opera-tion ..................................... 247
Jam protection function ........ 246
Operation ............................. 246
Window lock switch .............. 248
Pre-Collision System (PCS) Enabling/disabling the pre-colli-sion system ........................ 317
Function ............................... 315
Warning light ........................ 514
Warning message ........ 313, 526
Predictive efficient drive .......... 85
R
Radar cruise control Dynamic radar cruise control with full-speed range .......... 336
Radiator ................................... 463
RCTA (Rear Cross Traffic Alert) RCTA Function............. 347, 353
Warning message ................ 348
Rear Cross Traffic Alert (RCTA) ............................................... 347
Rear passengers’ seat belt reminder light ....................... 519
Rear seat ................................. 225 Folding down the rear seatbacks........................................... 226
Head restraints ..................... 230
Seat heaters ......................... 408
Rear side marker lights Light switch .......................... 295 Replacing light bulbs ............497
Rear turn signal lights Replacing light bulbs ............497
Turn signal lever . ..................289
Wattage ................................556
Rear view mirror Digital Rear-view Mirror ........234
Inside rear view mirror ..........233
Outside rear view mirrors .....244
Rear window defogger ...........398
Rear window wiper .................304
Refueling ............ .....................306
Capacity ...............................551
Fuel types .....................551, 557
If the fuel filler door cannot be opened ...............................536
Opening the fuel tank cap ....307
Regenerative braking ...............82
Remote Air Conditioning System ...............................................405
Replacing Electronic key battery ...........493
Fuses....................................495
Light bulbs ............................497
Tires .....................................527
Wiper insert ..........................489
Reporting safety defects for U.S. owners ...................................584
Resetting the message indicat- ing maintenance is required 451
Road accident cautions ...........89
Road Sign Assist ....................333
RSA (Road Sign Assist) .........333
S
Safety Connect .........................66
Seat belt reminder light..518, 519
Seat belts...................................29 Adjusting the seat belt shoulder anchor height........................31
Automatic Locking Retractor (ALR) ....................................31
