2021 TOYOTA CAMRY Accessories, Audio & Navigation (in English)

171-1. Basic function
1
Quick guide
CAMRY_CAMRY HV(TMMK)_Navi_(U)
Weather alert display*1, 2
( P.182)
• Select to display important
weather information for the current
location or along the route.
Indicate during data commu-
nication performed via Data
Communication Module
(DCM)
*3
The reception level of Data
Communication Module
(DCM) display
*3 ( P. 1 7 )
The reception level of the
connected phone display
( P. 1 7 )
Remaining battery charge
display ( P. 1 8 )
Bluetooth
® phone connection condition display (
P. 1 8 )
Wi-Fi
® connection condition
display
*2, 3 (  P. 1 7 )
*1: Premium Audio only
*2: This function is not available in
some countries or areas.
*3: Vehicles with DCM
●The number of status icons that
can be displayed differs depend-
ing on the displayed screen.
The level of reception does not
always correspond with the level
displayed on the cellular phone.
The level of reception may not
be displayed depending on the
phone you have.
When the cellular phone is out
of the service area or in a place
inaccessible by radio waves,
/ is displayed.
“Rm” is displayed when receiv-
ing in a roaming area. While
roaming, display “Rm” top-left
on the icon.
The receiving area may not be
displayed depending on the type
of Bluetooth
® phone you have.
While connected with cellular
phone
Status icon
Status icons are displayed
at the top of the screen.
Status icon explanation
A
B
C
D
E
F
5HFHSWLRQOHYHOGLVSOD\
LevelIndicators
Poor
Excellent
G

181-1. Basic function
CAMRY_CAMRY HV(TMMK)_Navi_(U)
While using Data Communi-
cation Module (DCM)
While using Wi-Fi® hotspot
●When Wi-Fi® hotspot is off, no
item is displayed.
The amount displayed does not
always correspond with the
amount displayed on the Blue-
tooth
® device.
The amount of battery charge
left may not be displayed
depending on the type of the
Bluetooth
® device connected.
This system does not have a
charging function. An antenna for the Bluetooth
®
connection is built into the
instrument panel.
The condition of the Bluetooth
®
connection may deteriorate and
the system may not function
when a Bluetooth
® phone is
used in the following conditions
and/or places:
The cellular phone is obstructed
by certain objects (such as
when it is behind the seat or in
the glove box or console box).
The cellular phone is touching or
is covered with metal materials.
Leave the Bluetooth
® phone in a
place where the condition of the
Bluetooth
® connection is good.
LevelIndicators
Poor
Excellent
LevelIndicators
No connection
Connected
Remaining battery charge
display
Remaining chargeIndicators
Empty
Full
Bluetooth® connection
condition display
IndicatorsConditions
(Blue)
Indicates that the con-
dition of the Blue-
tooth
® connection is
good.
(Gray)
While in this condition,
sound quality during
phone calls may dete-
riorate.
Indicates that the cel-
lular phone is not con-
nected via Bluetooth
®.

191-1. Basic function
1
Quick guide
CAMRY_CAMRY HV(TMMK)_Navi_(U)
Press the “MENU” button, then
select “Setup” to display the
“Setup” screen. The items
shown on the “Setup” screen
can be set.
Audio/Audio PlusSelect to change the selected
language, operation sound
settings, etc. ( P. 6 5 )
Select to set Bluetooth
®
device and Bluetooth
® sys-
tem settings. ( P. 4 3 )
Select to set audio settings.
( P.156)
Select to set the phone
sound, contacts, message
settings, etc. ( P.267)
Select to set the voice set- tings. (
P.69)
Select to set vehicle informa-
tion. ( P.71)
Select to set Wi-Fi
® connec-
tion settings.
*1, 2 (  P. 5 3 )
Select to set Toyota apps set-
tings.
*2 (  P.299)
*1: Vehicles with DCM
*2: This function is not available in
some countries or areas.
Premium Audio
Select to change the selected
language, operation sound
settings, etc. ( P.65)
“Setup” screen
“Setup” screen
A
B
C
D
E
F
G
H
A

201-1. Basic function
CAMRY_CAMRY HV(TMMK)_Navi_(U)
Select to set Bluetooth®
device and Bluetooth
® sys-
tem settings. ( P. 4 3 )
Select to set audio settings.
( P.156)
Select to set the phone
sound, contacts, message
settings, etc. ( P.267)
Select to set the voice set-
tings. ( P.69)
Select to set vehicle informa-
tion such as maintenance
information. ( P.71)
Select to set memory points
(home, favorites entries,
areas to avoid), or naviga-
tion details. ( P.108)
Select to set Wi-Fi
® connec-
tion settings.
*1, 2 (  P.53)
Select to set Toyota apps set-
tings.
*2 (  P.299)
Select to set traffic informa-
tion settings.
*2 (  P.116)
Select to set data services
settings.
*2 (  P.184)
*1: Vehicles with DCM
*2: This function is not available in
some countries or areas.
*: Audio with DCM/Audio Plus with DCM/Premium Audio only
Useful information, such as the
fuel consumption, weather, etc.,
is available on the information
screen.
The information screen can be
reached by the following meth-
ods:
1 Press the “MENU” button.
2 Select “Info”.
3 Select the desired item.
Select to display the energy
monitor
*1 or fuel consumption
screen.
*2
Select to display traffic infor-
mation.
*3, 4 (  P.85)
Select to display weather
information.
*3, 4 (  P.182)
Select to display the vehicle
alert history.
*4, 5
*1: Vehicles with hybrid system
*2: Refer to the “OWNER’S MAN- UAL”.
B
C
D
E
F
G
H
I
J
K
Infor mation screen
Information screen*
A
B
C
D

211-1. Basic function
1
Quick guide
CAMRY_CAMRY HV(TMMK)_Navi_(U)
*3: Premium Audio only
*4: This function is not available in some countries or areas.
*5: Vehicles with DCM

221-2. Navigation operation
CAMRY_CAMRY HV(TMMK)_Navi_(U)
1-2.Navigation operation
*: Premium Audio
1Press the “MAP” button.
 The current position of the
vehicle is displayed on the
map screen.
■Displaying the map screen
The following operations can
also be performed.
 Changing the map direction
( P. 7 9 )
 Displaying 3D map ( P.79)
 Changing the map color
( P. 1 1 3 )
 Displaying the micro city map (
P.79)
1 Select the desired point on
the map screen.
 The map screen can be
scrolled by touching, dragging
or flicking it. ( P. 3 0 )
 Press the “MAP” button to
return to the current position.
Operating the map
screen*
Displaying the current
position of the vehicle on
the map screen
Moving the map screen

231-2. Navigation operation
1
Quick guide
CAMRY_CAMRY HV(TMMK)_Navi_(U)
■Zooming in the map
1 Select or pinch out on the
map screen. ( P.78)
■Zooming out the map
1 Select or pinch in on the
on the map screen. ( P.78)
*: Premium Audio
1Press the “MAP” button.
2 Select .
3 There are different kinds of
methods to search for a des-
tination. ( P. 8 8 )
4 Select “Go”.
 Check that the route overview
is displayed. ( P. 9 7 )
Zooming in/out the mapGuiding the route*
Setting the destination

241-2. Navigation operation
CAMRY_CAMRY HV(TMMK)_Navi_(U)
5Select “OK”.
 Selecting routes other than
the one recommended
( P. 9 8 )
 Guidance to the destination is
displayed on the screen and
can be heard via voice guid-
ance.
When route guidance is no lon-
ger necessary, such as when
you know the rest of the route to
your destination, the destination
can be deleted.
1 Press the “MAP” button.
2 Select .
3 Select “Yes” when the confir-
mation screen appears.
 When more than 1 destination
has been set, a list will be dis- played on the screen. Select
the item(s) to be deleted.
Deleting destinations
