2021 TOYOTA C-HR spare tire

4878-1. Specifications
C-HR_OM_USA_OM10684U
8
Vehicle specifications
Tire information
Full-size tire
Compact spare tire
Typical tire symbols

4888-1. Specifications
C-HR_OM_USA_OM10684U
Tire size (P. 490)
DOT and Tire Identification Number (TIN) ( P. 4 8 9 )
Uniform tire quality grading
For details, see “Uniform Tire Q uality Grading” that follows.
Location of treadwear indicators ( P. 3 7 6 )
Tire ply composition and materials
Plies are layers of rubber-coated parallel cords. Cords are the strands
which form the p lies in a tire.
Radial tires or bias-ply tires
A radial tire has “RADIAL” on the sidewall. A tire not marked “ RADIAL”
is a bias-ply tire.
TUBELESS or TUBE TYPE
A tubeless tire does not have a tube and air is directly put into the tire.
A tube type tire has a tube insi de the tire and the tube mainta ins the air
pressure.
Load limit at maximum cold tire inflation pressure ( P. 380)
Maximum cold tire in flation pressure (P. 482)
This means the press ure to which a tire may be inflated.
Summer tires or all season tires ( P. 3 8 0 )
An all season tire has “M+S” on the sidewall. A tire not marked “M+S”
is a summer tire.
“TEMPORARY USE ONLY”
A compact spare tire is identified by the phrase “TEMPORARY USE
ONLY” molded on its sidewall. This tire is designed for tempora ry
emergency use only.

531What to do if... (Troubleshooting)
C-HR_OM_USA_OM10684U
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display. (P. 444)
●When a warning light turns on or a warning message is displayed , refer to
P. 434, 444.
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
( P. 449)
●Try the procedure for when the vehicle becomes stuck in mud, di rt, or
snow. ( P. 473)
A warning buzzer sounds w hen leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

543Alphabetical index
C-HR_OM_USA_OM10684U
Snow tires ................................ 306
Spare tire .................................. 449Inflation pressure .................. 482
Storage location .................... 450
Spark plug ................................ 480
Specifications .......................... 476
Speedometer .............................. 96
Sport mode............................... 281
Steering lock
Column lock release ..... 181, 186
Steering wheel ......................... 151
Adjustment ............................ 151
Audio switches
*
Meter control switches .......... 100
Telephone switches
*
“TRIP” switch .......................... 97
Stop lights ................................ 417
Storage feature ........................ 326
Stuck If the vehicle becomes
stuck ................................... 473
Sun visors ................................ 336 Switches
Audio remote control
switches
*
Automatic High Beam switch ................................. 209
Brake hold switch ................. 201
Cruise control switch ............ 266
Door lock switches................ 123
Emergency flashers switch ... 422
Engine switch ............... 180, 183
Fog light switch ..................... 214
Fuel filler door opener switch ................................. 222
Heated steering wheel .......... 321
Ignition switch ............... 180, 183
Light switches ....................... 204
LTA (Lane Tracing Assist) .... 254
Meter control switches .......... 100
Outside rear view mirror switches ............................. 154
Parking brake switch ............ 196
Power door lock switch ......... 123
Power window switches........ 157
Rear window and outside rear view mirror
defoggers switch ................ 315
Seat heater switches ............ 321
Talk switch
*
Telephone switches*
“TRIP” switch .......................... 97
Vehicle-to-vehicle distance
switch ................................. 266
VSC off switch ...................... 301
Window lock switch .............. 157
Windshield wiper and washer switch..................... 215
*: Refer to “MULTIMEDIA OWNER’S MANUAL”.

544Alphabetical index
C-HR_OM_USA_OM10684U
Tachometer ................................ 96
Tail lights .................................. 204Light switch ........................... 204
Replacing light bulbs............. 417
Talk switch
*
Telephone switches*
Theft deterrent system Engine immobilizer system ..... 84
Tire inflation pressure ............. 386 Maintenance data ................. 482
Warning light ......................... 437
Tire information ....................... 487 Glossary................................ 494
Size ....................................... 490
Tire identification number ..... 489
Uniform Tire Quality Grading............................... 492
Tire pressure warning system .................................... 377 Initializing .............................. 377
Installing tire pressure
warning valves and
transmitters......................... 377
Registering ID codes ............ 379
Warning light ......................... 437
Tires .......................................... 376 Chains................................... 307
Checking ............................... 376
If you have a flat tire ............. 449
Inflation pressure .................. 482
Replacing .............................. 449
Rotating tires......................... 376
Size ....................................... 482
Snow tires ............................. 306
Spare tire .............................. 449
Tire pressure warning
system ......... ....................... 377
Warning light ......................... 437 Tools ......................................... 450
Top tether strap ......................... 59
Total load capacity .................. 177
Towing
Dinghy towing ....................... 179
Emergency towing ................ 426
Towing eyelet ....................... 428
Trailer towing ........................ 178
Toyota Safety Sense 2.5 ........ 224
Automatic High Beam ........... 209
Dynamic radar cruise control with full-speed range .......... 266
LTA (Lane Tracing Assist) .... 246
PCS (Pre-Collision system) ........ 231
RSA (Road Sign Assist) ....... 261
Traction Control (TRAC) ......... 300
Transmission ........................... 190 Continuously variable transmission ....................... 190
If the shift lever cannot be shifted from P ..................... 193
M mode................................. 191
TRAC (Traction Control) ......... 300
Trip meters ................................. 96
Turn signal lights .................... 195 Replacing light
bulbs........... 409, 410, 414, 417
Turn signal lever ................... 195
Wattage ................................ 483
