1163-2. Opening, closing and locking the doors
sound and the power back door will begin
closing automatically. When the power
back door is closed, all of the doors will
lock simultaneously and operation signals
will indicate that all of the doors have been
locked.
If the switch is pr essed while the power
back door is closing, the operation will
stop.
Pressing the switch again will open the
power back door automatically.
■Closing the power back door using
the back door handle
Lower the power back door using the
back door handle, then a buzzer will
sound and the power back door will
automatically close.
■Hands Free Power Back Door (if
equipped)
1 While carrying an electronic key,
stand within the smart access sys-
tem with push-button start opera- tion range, approximately 19.7 to
23.6 in. (50 to 60 cm) from the
rear bumper.
Kick sensor
Hands Free Power Back Door
operation detection area
Smart access system with
push-button start operation detec-
tion area (
P.125)
2 Perform a kick operation by mov-
ing your foot to within approxi-
mately 3.9 in. (10 cm) of the rear
bumper and then pulling it back.
 Perform the entire kick operation
within 1 second.
 The Hands Free Power Back Door
will not start operating while a foot is
detected under the rear bumper.
 Operate the Hands Free Power
Back Door without contacting the
rear bumper with your foot.
 If another electronic key is in the
cabin or luggage compartment, it
may take slightly longer than normal
A
B
C

1183-2. Opening, closing and locking the doors
●When an electronic key is carried within
the operation range.
■Hands free close & lock function oper-
ating conditions (vehicles with Hands
Free Power Back Door)
This function can be operated when all of
the following conditions are met:
• The hands free close & lock function set- ting is on.
• The Hands Free Powe r Back Door oper-
ating conditions are met.
• An electronic key is not detected within the vehicle.
• All of the doors ot her than the power
back door are closed.
• The power switch is off.
■Back door closer
In the event that the power back door is left
slightly open, the back door closer will auto-
matically close it to the fully closed position.
●The back door closer can function when
the power switch is in any mode.
●The power back door can be opened
using the back door opener switch even if
the back door closer is operating.
■Operation of the power back door
●When the power back door begins to
operate, the emergency flashers will flash
and a buzzer will sound.
●When the power back door is disabled,
the power back door will not operate but
can be opened and closed manually.
●The power back door turns to manual
operation when the back door opener
switch is pressed while the power back
door is in an automatic opening/closing
operation.
●If anything obstructs the power back
door while opening, a buzzer will sound
and the power back door will stop imme-
diately. If anything obstructs the power
back door while closing, a buzzer will
sound and the power back door will auto-
matically move slightly in the opposite
direction and then stop.
■Back door reserve lock function
This function reserves the locking of the
power back door when the power back
door is open. If the following operations are
performed, all of th e doors except the
power back door will lock and then the
power back door will lock when it is com-
pletely closed.
1 Close all of the doors, except the power
back door.
2 Perform an automatic closing operation
of the power back door and lock the
doors using the wire less remote control
(  P.107) or smart access system with
push-button start ( P.109) while the
power back door is closing.
Also, if the back door does not fully close
due to the operation of the jam protection
function, etc., while the back door is auto-
matically closing after a reserve lock opera-
tion is performed, the reserve lock function
is canceled and all the doors will unlock.
■Situations in which the close & lock
function may not operate properly
In the following situations, the close & lock
function may not operate properly:
●If the switch on th e lower part of the
power back door ( P.115) is pressed by
a hand which is holding an electronic key
●If the switch on th e lower part of the
power back door ( P.115) is pressed
when the electronic key is in a bag, etc.
that is placed on the ground
●If the switch on th e lower part of the
power back door ( P.115) is pressed
with the electronic key not near the vehi-
cle.
■Situations in which the Hands Free
Power Back Door may not operate
properly (if equipped)
In the following situations, the Hands Free
Power Back Door may not operate prop-
erly:
●When a foot remain s under the rear
bumper
●If the rear bumper is strongly hit with a
foot or is touched for a while

1213-2. Opening, closing and locking the doors
3
Before driving
WARNING
●If the operating conditions of the
power back door (P.117) are no lon-
ger met, a buzzer may sound and the
power back door may stop opening or
closing. The power back door must
then be operated manually. Take extra
care on an incline in this situation, as
the power back door may move sud-
denly.
●On an incline, the power back door
may suddenly shut af ter it opens. Make
sure the power back door is fully open
and secure.
●In the following situations, the power
back door may detect an abnormality
and automatic operation may be
stopped. In this case, the power back
door must then be operated manually.
Take extra care in this situation, as the
stopped power back door may sud-
denly open or close, causing an acci-
dent.
• When the power back door contacts an obstacle
• When the 12-volt battery voltage sud- denly drops, such as when the power
switch is turned to ON mode or the
hybrid system is started during auto-
matic operation
●If a bicycle carrier or similar heavy
object is attached to the power back
door, the power back door may not
operate, causing a malfunction, or the
power back door may suddenly shut
again after being opened, causing
someone’s hands, arms, head or neck
to be caught and in jured. When install-
ing an accessory part to the power
back door, using a genuine Lexus part
is recommended.
■Jam protection function
Observe the following precautions.
Failure to do so may cause death or seri-
ous injury.
●Never use any part of your body to
intentionally activa te the jam protec-
tion function.
●The jam protection function may not
work if something gets caught just
before the power back door fully
closes. Be careful not to get fingers
caught or anything else.
●The jam protection function may not
work depending on the shape of the
object that is caught. Be careful not to
catch fingers or anything else.
■Hands Free Power Back Door (if
equipped)
Observe the following precautions.
Failure to do so may cause death or seri-
ous injury.
●Check the safety of the surrounding
area to make sure there are no obsta-
cles or anything that could cause any
of your belongings to get caught.
●Exhaust gasses cause the exhaust
pipes to become quite hot. When
operating the Hands Free Power Back
Door, be careful not to touch the
exhaust pipe.
●Do not operate the Hands Free Power
Back Door if there is little space under
the rear bumper.

1223-2. Opening, closing and locking the doors
NOTICE
■Back door spindles
The power back door is equipped with
spindles that hold the power back
door in place.
Observe the following precautions.
Failure to do so may cause damage to
the back door spindle , resulting in
malfunction.
●Do not attach any foreign objects, such
as stickers, plastic sheets, or adhesives
to the spindle rod.
●Do not attach any accessories other
than genuine Lexus parts to the power
back door.
●Do not place your ha nd on the spindle
or apply lateral forces to it.
■To prevent back door closer malfunc-
tion
●Do not apply excessive force to the
power back door while the back door
closer is operating. Applying excessive
force may cause the back door closer
to malfunction.
●If the power back door is opened and
closed repeatedly in a short amount of
time, the back door closer may stop
operating. In this case, manually open
the power back door once and wait for
a while before attempting to close it
again.
A
A
■To prevent malfunction of the power
back door
●Make sure that there is no ice between
the power back door and frame that
would prevent movement of the power
back door. Operating the power back
door when excessive load is present
on the power back door may cause a
malfunction.
●Do not apply excessive force to the
power back door while the power
back door is operating.
●Take care not to damage the sensors
installed on the right and left edges of
the power back door (
P.119) with a
knife or other sharp object. If a sensor
is disconnected, the power back door
will not close automatically.
■Close & lock function/Hands free
close & lock function
When closing the power back door using
the close & lock function/hands free
close & lock function, a different buzzer
than the normal one will sound before
the operation begins.
To check that the operation has started
correctly, check that a different buzzer
than the normal one has sounded.
Additionally, when the power back door
is fully closed and locked, operation sig-
nals will indicate that all of the doors have
been locked.
Before leaving the vehicle, make sure
that the operational signals have oper-
ated and that all of the doors are locked.
■Hands Free Power Back Door pre-
cautions (if equipped)
The kick sensor is lo cated behind lower
center part of the rear bumper. Observe
the following to ensure that the Hands
Free Power Back Door function operates
properly:

1253-2. Opening, closing and locking the doors
3
Before driving
■Antenna locationAntennas outside the cabin
Antennas inside the cabin
Antenna outside the luggage compart-
ment
■Effective range (areas within which the
electronic key is detected)When locking or unlocking the doors
The system can be operated when the
electronic key is within about 2.3 ft. (0.7 m)
of an outside door handle. (Only the doors
detecting the key can be operated.)
When starting the hybrid system or
changing power switch modes
The system can be operated when the
electronic key is inside the vehicle.
■Alarms and warning messages
An alarm sounds and warning messages
are displayed on the multi-information dis-
play to protect against unexpected acci-
dents or theft of the vehicle resulting from
erroneous operation. When a warning mes-
sage is displayed, take appropriate mea-
sures based on the displayed message.
(  P.428)
When only an alarm sounds, circumstances
and correction procedures are as follows.
●When an exterior alarm sounds once for
5 seconds
●When an interior alarm sounds continu-
ously
Smart access system with
push-button start
The following operations can be
performed simply by carrying the
electronic key on your person, for
example in your pocket. The driver
should always carry the electronic
key.
 Locks and unlocks the doors
( P.109)
 Locks and unlocks the back door
( P.114)
 Starts and stops the hybrid system
( P.184)
A
B
C
SituationCorrection
procedure
An attempt was made to
lock the vehicle while a
door was open.Close all of the
doors and lock
the doors
again.
A
B

1263-2. Opening, closing and locking the doors
■If “Key Left inside Vehicle” is shown on
the multi-information display
An attempt was made to lock the doors
using the smart access system with
push-button start while the electronic key
was still inside the vehicle. Retrieve the elec-
tronic key from the vehicle and lock the
doors again.
■Battery-saving function
The battery-saving fu nction will be acti-
vated in order to prevent the electronic key
battery and the 12-volt battery from being
discharged while the vehicle is not in opera-
tion for a long time.
●In the following situations, the smart
access system with pu sh-button start may
take some time to unlock the doors.
• The electronic key has been left in an
area of approximately 6 ft. (2 m) of the
outside of the vehicle for 10 minutes or
longer.
• The smart access system with push-but- ton start has not been used for 5 days or
longer.
●If the smart access system with push-but-
ton start has not been used for 14 days or
longer, the doors cannot be unlocked at
any doors except the driver’s door. In this
case, take hold of the driver’s door han-
dle, or use the wireless remote control or
the mechanical key, to unlock the doors.
■Turning an electronic key to bat-
tery-saving mode
When battery-saving mode is set, battery
depletion is minimized by stopping the elec-
tronic key from re ceiving radio waves. Press twice while pressing and holding
. Confirm that the electronic key indica-
tor flashes 4 times.
While the battery-saving mode is set, the
smart access system with push-button start
cannot be used. To cancel the function,
press any of the electronic key buttons.
■Conditions affecting operation
The smart access system with push-button
start, wireless remote control and immobi-
lizer system use weak radio waves. In the
following situations, the communication
between the electronic key and the vehicle
may be affected, preventing the smart
access system with push-button start, wire-
less remote control and immobilizer system
from operating properly. (Ways of coping:
 P.447)
●When the electronic key battery is
depleted
●Near a TV tower, electric power plant,
gas station, radio stat ion, large display,
airport or other fac ility that generates
strong radio waves or electrical noise
●When the electronic key is in contact
with, or is covered by the following metal-
lic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
●When other wireless keys (that emit radio
waves) are being used nearby
●When carrying the electronic key
together with the following devices that
emit radio waves
• Portable radio, cellular phone, cordless
phone or other wireless communication
SituationCorrection
procedure
The power switch was
turned to ACCESSORY
mode while the driver’s
door was open (The
driver’s door was opened
when the power switch
was in ACCESSORY
mode).
Turn the power
switch off and
close the
driver’s door.

1283-2. Opening, closing and locking the doors
detection area, it may take slightly longer
to unlock the doors after the door handle
is gripped.
●Fingernails may scrape against the door
during operation of the door handle. Be
careful not to injure fingernails or dam-
age the surface of the door.
■When the vehicle is not driven for
extended periods
●To prevent theft of the vehicle, do not
leave the electronic key within 6 ft. (2 m)
of the vehicle.
●The smart access syst em with push-but-
ton start can be deactivated in advance.
●Setting the electronic key to battery-sav-
ing mode helps to reduce key battery
depletion. ( P.126)
■To operate the system properly
Make sure to carry the electronic key when
operating the system. Do not get the elec-
tronic key too close to the vehicle when
operating the system from the outside of the
vehicle.
Depending on the position and holding
condition of the electronic key, the key may
not be detected correctly and the system
may not operate properly. (The alarm may
go off accidentally, or the door lock preven-
tion may not operate.)
■If the smart access system with
push-button start does not operate
properly
●If the doors cannot be locked or unlocked
and the back door cannot be opened,
perform the following.
• Bring the electronic key close to the door handle and perform a lock or unlock
operation.
• Bring the electronic key close to the but- ton on the back door ( P.114) and press
the button.
• Use the wireless remote control.
If the doors cannot be locked or unlocked
by perform the above, use the mechanical
key. ( P.447) However, if the mechanical
key is used while the al arm system is set, the
warning will sound. ( P.75)
●If the hybrid system cannot be started,
refer to  P.448
■Customization
Some functions can be customized.
(  P.480)
■If the smart access system with
push-button start has been deactivated
in a customized setting
●Locking and unlockin g the doors: Use
the wireless remote control or mechani-
cal key. ( P.109, 114, 447)
●Starting the hybrid system and changing
power switch modes: P.448
●Stopping the hybrid system: P.186

1363-3. Adjusting the seats
■Before folding the rear seatbacks
1 Stow the center seat seat belt
buckle.
2 Lower the rear seat head restraints
to the lowest position. ( P.145)
■Folding the rear seatbacks (manual
seat)
Using the seatback angle adjust-
ment lever
Pull the lever and fold the rear seat-
back.
Using the lever in the luggage com-
partment
Pull the lever and fold the rear seat-
back.
■Folding the rear seatbacks (power
seat)
Press and hold the fo ld switch until the
rear seatback begins to operate.
A buzzer will sound and then the operation
will start. When the operation is com-
pleted, the buzzer will sound again.
To stop the operation partway, press either
side of the switch for the operating seat.
Any rear seat operat ion switch for the
operating seat, regardless of location, can
be used to stop the operation. (A buzzer
may sound depending on the position that
the rear seatback is stopped.)
Using the seatback angle adjust-
ment switch
If the rear seatback is reclined, adjust it
to the most upright position and then
press the switch again.
Using the switch in the luggage
compartment
Folding the second-row seat
seatbacks (RX450h)
