4567-2. Steps to take in an emergency
Lexus dealer.
If “Hybrid System Overheated Out-
put power reduced” is shown on the
multi-information display
1 Stop the vehicle in a safe place.
2 Stop the hybrid system and care-
fully lift the hood.
3 After the hybrid system has cooled
down, inspect the hoses and radia-
tor core (radiator) for any leaks.
Radiator
Cooling fans
If a large amount of coolant leaks, immedi-
ately contact your Lexus dealer.
4The coolant level is satisfactory if it
is between the “FULL” and “LOW”
lines on the reservoir.
Reservoir
“FULL” line
“LOW” line 5
Add coolant if necessary.
Water can be used in an emergency if
coolant is unavailable.
6Start the hybrid system and check if
“Hybrid System Overheated Out-
put power reduced” is shown on
the multi-information display.
If the message does not disappear:
Stop the hybrid system and contact
your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the
nearest Lexus dealer.
A
B
A
B
C
WARNING
■When inspecting under the hood of
your vehicle
Observe the following precautions.
Failure to do so may result in serious
injury such as burns.
●If steam is seen coming from under the
hood, do not open the hood until the
steam has subsided. The engine com-
partment may be very hot.

4577-2. Steps to take in an emergency
7
When trouble arises
1Stop the hybrid system. Shift the
shift lever to P and set the parking
brake.
2 Remove the mud, snow or sand
from around the front wheels.
3 Place wood, stones or some other
material under the front wheels to
help provide traction.
4 Restart the hybrid system.
5 Shift the shift lever to D or R and
release the parking brake. Then,
while exercising caution, depress
the accelerator pedal.
■When it is difficult to free the vehicle
Press to turn off TRAC.
WARNING
●After the hybrid system has been
turned off, check that the “READY”
indicator is off.
When the hybrid system is operating,
the gasoline engine may automatically
start, or the cooling fans may suddenly
operate even if the gasoline engine
stops. Do not touch or approach rotat-
ing parts such as the fans, which may
lead to fingers or cl othing (especially a
tie, a scarf or a muffler) getting caught,
resulting in serious injury.
●Do not loosen the radiator cap and the
coolant reservoir caps while the hybrid
system and radiator are hot.
High temperature steam or coolant
could spray out.
NOTICE
■When adding engine/power control
unit coolant
Add coolant slowly after the hybrid sys-
tem has cooled down sufficiently. Adding
cool coolant to a hot hybrid system too
quickly can cause damage to the hybrid
system.
■To prevent damage to the cooling sys-
tem
Observe the following precautions:
●Avoid contaminating the coolant with
foreign matter (such as sand or dust,
etc.).
●Do not use any coolant additive.
If the vehicle becomes stuck
Carry out the following proce-
dures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Recovering procedure

511What to do if... (Troubleshooting)
If you cannot release the shift lever by
depressing the brake pedal with the power
switch in ON mode (P.192)
It is locked automatically to prevent
theft of the vehicle. ( P.185)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( P.155)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or ON mode (the
hybrid system is not operating) for a
period of time. ( P.187)
 The seat belt reminder light is flash-
ing
Are the driver and the passengers wearing
the seat belts? ( P.421)
 The parking brake indicator is on
Is the parking brake released? ( P.195)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.418, 428) 
Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.75)
Do one of the following to stop the
alarms:
 Unlock the doors.
 Turn the power switch to ACCES-
SORY or ON mode, or start the
hybrid system.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.428)
 When a warning light turns on or a
warning message is displayed, refer
to P.418, 428.
 Stop the vehicle in a safe place and
replace the flat tire with the spare
tire. ( P.432)
The steering wheel cannot be
turned after the hybrid system is
stopped
The windows do not open or
close by operating the power
window switches
The power switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed
When a problem has occurred
If you have a flat tire

516Alphabetical Index
If the electronic key does not operate properly....................................................... 447
If the fuel filler door cannot be opened ......................................................................... 446
If the hybrid system will not start ........ 444
If the vehicle is trapped in rising water411
If you have a flat tire .................................. 432
If you lose your keys................................. 446
If you think something is wrong ........... 417
If your vehicle becomes stuck............. 457
If your vehicle has to be stopped in an
emergency ................................................. 410
If your vehicle needs to be towed ....... 413
If your vehicle overheats ........................ 454
Energy monitor ..................................... 99, 100
Engine ACCESSORY mode ...............................187
Compartment ............................................... 371
Engine switch................................................ 184
Hood................................................................369
How to start the hybrid system ........... 184
Identification number .................................461
If the hybrid system will not start ........ 444
If your vehicle has to be stopped in an
emergency ................................................. 410
Ignition switch (power switch) ............. 184
Overheating................................................. 454
Power switch ................................................ 184
Tachometer ..................................................... 83
Engine coolant Capacity ......................................................... 464
Checking ....................................................... 373
Preparing and checking before winter........................................................................... 291
Engine coolant temperature gauge ....... 83
Engine oil Capacity ......................................................... 463
Checking ......................................................... 371
Preparing and checking before winter........................................................................... 291
Warning light .................................................419
Engine oil maintenance data .................. 373 Engine switch (power switch) ................. 184
If your vehicle has to be stopped in an emergency .................................................. 410
EPS (Electric Power Steering) .............. 284 Warning light .................................................421
EV drive mode............................................... 189
EV indicator .......................................................67
Event data recorder (E DR) ........................... 8
F
Flat tire
Tire pressure warning system .............382
Vehicles with a spare tire....................... 432
Floor mats .......................................................... 24
Fluid Brake ............................................................... 465
Hybrid transmission................................. 465
Washer ...........................................................375
Fog lights Switch.............................................................. 206
Footwell light ...................................................321
Front automatic air conditioning system .......................................................................... 304
Front fog lights Replacing light bulbs ............................... 400
Front passenger footwell hooks ............ 345
Front passenger occupant classification system .............................................................. 39
Front seats Adjustment ....................................................... 131
Cleaning ........................................................ 359
Correct driving posture ............................ 25
Driving position memory .........................142
Head restraints............................................. 145
Memory recall function.............................143
Power easy access system .....................142
Seat heaters ................................................... 318
Seat position memory ...............................142
Seat ventilators ............................................. 318
Front side marker light Light switch .................................................. 200
Replacing light bulbs ............................... 400

517Alphabetical Index
Front side marker lightsReplacing light bulbs............................... 400
Wattage..........................................................468
Front turn signal lights Replacing light bulbs................... 400, 402
Turn signal lever ...........................................194
Wattage..........................................................468
Fuel Capacity ......................................................... 462
Fuel gauge ....................................................... 83
Information .................................................... 469
Refueling ............................................................211
Type.................................................................. 462
Warning light ................................................. 421
Fuel consumption Average fuel economy .............................. 90
Current fuel consumption........................ 90
Fuel filler door If the fuel filler door cannot be opened......................................................................... 446
Refueling ............................................................211
Fuel gauge ......................................................... 83
Fuses ................................................................. 395
G
Garage door opener ................................. 346
Gauges ............................................................... 83
G-force................................................................. 91
Glove box ....................................................... 326
Glove box light ............................................. 326
Grocery bag hooks .................................... 330
H
Hands Free Power Back Door ................. 116
Head restraints ...............................................145
Headlight aim ................................................ 397
Headlights Adaptive Front-lighting System (AFS)......................................................................... 202
Automatic High Beam system............ 203
Light switch ...................................................200 Replacing light bulbs ............................... 400
Head-up display.............................................. 95 Driving information display area ...........95
HUD (Head-up display) switch ............ 96
Hybrid System Indicator ........................... 99
Navigation system-linked display ........98
Settings............................................................... 97
Heated steering wheel ............................... 318
Heaters Front automatic air conditioning system......................................................................... 304
Heated steering wheel ............................. 318
Outside rear view mirrors.................... 306
Rear automatic air conditioning system
........................................................................... 315
Seat heaters ................................................... 318
High mounted stoplight Replacing light bulbs ............................... 400
High-voltage components ......................... 69
Hill-start assist control ............................... 284
Hood Open............................................................... 369
Hooks Cargo hooks................................................329
Cargo net hooks ........................................329
Coat hooks ...................................................343
Front passenger footwell hooks.........345
Grocery bag hooks................................. 330
Retaining hooks (floor mat) ..................... 24
Horn ................................................................... 148
HUD (Head-up display) switch ................ 96
Hybrid battery (traction battery) Location ............................................................. 69
Specification ................................................. 462
Warning message ........................................ 72
Hybrid battery (traction battery) air vents ............................................................................... 71
Hybrid system .................................................. 66 Acoustic Vehicle Alerting System .......68
Emergency shut off system...................... 72
Energy monitor/consumption screen99
EV drive mode............................................. 189

518Alphabetical Index
High voltage components ....................... 69
Hybrid system precautions ..................... 69
If the hybrid system will not start ........ 444
Overheating.................................................456
Power (ignition) switch............................ 184
Regenerative braking ................................. 67
Starting the hybrid system...................... 184
Hybrid System Indicator......................85, 99
Hybrid transmission....................................... 191 M mode ............................................................193
Paddle shift switches ....................... 192, 193
Hybrid vehicle driving tips ....................... 289
I
I/M test ............................................................ 366
Identification Engine ...............................................................461
Vehicle ............................................................460
If your vehicle has to be stopped in an
emergency ................................................... 410
Ignition switch (power switch) ................ 184 Auto power off function ...........................187
Changing the power switch modes ..187
If your vehicle has to be stopped in an
emergency ................................................. 410
Immobilizer system .........................................73
Indicators ........................................................... 80
Initialization Items to initialize ......................................... 493
Maintenance .................................... 362, 373
Power windows............................................153
Tire pressure warning system ............ 385
Inside rear view mirror ................................149
Instrument panel light control ................... 87
Interior lights....................................................321 Front interior light ........................................ 321
Rear interior light ......................................... 321
Intuitive parking assist.....................253, 255 Function .......................................................... 255
Warning message..................................... 257
J
JackPositioning a floor jack ........................... 369
Vehicle-equipped jack ...........................433
Jack handle .................................................... 433
Jam protection function Electronic sunshade .................................. 159
Moon roof ...................................................... 156
Panoramic moon roof .............................. 159
Power back door.......................................... 119
Power windows ........................................... 153
Rear seats ........................................................132
K
Keyless entrySmart access system with push-button start ................................................................. 125
Wireless remote control ......................... 107
Keys Battery-saving function.............................126
Electronic key ............................................... 106
If the electronic key does not operate properly ....................................................... 447
If you lose your keys .................................446
Key number plate ....................................... 106
Keyless entry ....................................... 107, 125
Mechanical key ............................................ 106
Power switch................................................. 184
Replacing the battery ...............................393
Warning buzzer .......................................... 125
Wireless remote control ......................... 107
Knee airbags .................................................... 30
L
Lane Tracing Assist (LTA) Operation ...................................................... 227
Warning messages...................................235
Language (multi-information display) ... 92
LATCH anchors ............................................. 54
