3315-6. Using the other interior features
5
Interior features
The coat hooks are provided with the
rear assist grips.
The GPS clock's time is automatically
adjusted by utilizing GPS time infor-
mation.
For details, refer to “NAVIGATION AND
MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
Please use as a power supply for elec-
tronic goods that use less than 12
VDC/10 A (power consumption of
120 W).
Observe the following when using
electronic goods:
Make sure that the power consump-
tion of all the connected power out-
lets on the instrument panel and in
the luggage compartment is less
than 120 W.
 Make sure that the power consump-
tion of all the connected power out-
lets inside the console box is less
than 120 W.
On the instrument panel
Remove the cap.
Inside the console box
Open the lid.
NOTICE
■To prevent damage to the assist grip
Do not hang any heavy object or put a
heavy load on th e assist grip.
Coat hooks
WARNING
■Items that must not be hung on the
hook
Do not hang coat hangers or other hard
or sharp objects on the hook. If the SRS
curtain shield airbags deploy, these items
may become projectiles, causing death
or serious injury.
Clock
Power outlets

4277-2. Steps to take in an emergency
7
When trouble arises
WARNING
• PCS (Pre-Collision System)
• LTA (Lane Tracing Assist)
• RSA (Road Sign Assist) (if equipped)
•Automatic High Beam
• AFS (Adaptive Front-lighting System) (if equipped)
• Tire pressure warning system
• Intuitive parking assist (if equipped)
• PKSB (Parking Support Brake) (if equipped)
• Lexus parking assist monitor (if equipped)
• Panoramic view monitor (if equipped)
• BSM (Blind Spot Monitor) (if equipped)
• Navigation system (if equipped)
Also, not only can the following system
not be utilized fully, but it may even nega-
tively affect the drive-train components:
• AWD system (AWD models)
■Speed limit when using the compact
spare tire
Do not drive at speeds in excess of 50
mph (80 km/h) when a compact spare
tire is installed on the vehicle.
The compact spare tire is not designed
for driving at high speeds. Failure to
observe this precaution may lead to an
accident causing deat h or serious injury.
■After using the tools and jack
Before driving, make sure all the tools
and jack are securely in place in their
storage location to reduce the possibility
of personal injury during a collision or
sudden braking.
NOTICE
■Be careful when driving over bumps
with the compact spare tire installed
on the vehicle
The vehicle becomes lower when driving
with the compact spar e tire compared to
when driving with standard tires. Be
careful when driving over uneven road
surfaces.
■Driving with tire chains and the com-
pact spare tire
Do not fit tire chains to the compact
spare tire. Tire chains may damage the
vehicle body and adversely affect driving
performance.
■When replacing the tires
When removing or fitting the wheels,
tires or the tire pr essure warning valve
and transmitter, contact your Lexus
dealer as the tire pressure warning valve
and transmitter may be damaged if not
handled correctly.
■When stowing the flat tire (RX350L)
●Ensure that there is no object caught
between the tire and the vehicle
underbody.
●Securely tighten the spare tire clamp
bolt to hold the spare wheel carrier by
the hook.
●Stow the flat tire in the spare tire loca-
tion. Failure to do so may cause dam-
age to the spare tire carrier. Proper
storage reduces the possibility of injury
in a collision or during sudden braking.
●Have the flat tire repaired and the
spare tire replaced with it as soon as
possible.

4618-2. Customization
8
Vehicle specifications
8-2.Customization
■Changing by using the Remote
Touch
1 Press the “MENU” button on the
Remote Touch.
2 Select “Setup” on the menu screen
and select “Vehicle”.
3 Select “Vehicle Customization” or
“Drive Mode Customization”.
Various setting can be changed. Refer to
the list of settings that can be changed for
details.
This system can also be operated by the
touch screen.
For details on the Remote Touch, refer
to the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MAN- UAL”.
■Changing by using the meter con-
trol switches
1 Press or to select .
2 Operate the meter control
switches to select the desired item
to be customized.
3 According to the display, select the
desired setting and then press
.
To go back to the previous screen or exit
the customize mode, press .
Some function settings are changed simultaneously with other functions being cus-
tomized. Contact your Lexus dealer for further details.
Settings that can be changed using the Remote Touch
Settings that can be changed using the meter control switches
Settings that can be changed by your Lexus dealer
Definition of symbols: O = Available, — = Not available
Customizable features
Your vehicle includes a variety of
electronic features that can be per-
sonalized to suit your preferences.
The settings of these features can
be changed by using the meter con-
trol switches, the Remote Touch, or
at your Lexus dealer.
Customizing vehicle features
WARNING
■During customization
As the engine needs to be running
during customization, ensure that the
vehicle is parked in a place with ade-
quate ventilation. In a closed area such as
a garage, exhaust gases including harm-
ful carbon monoxide (CO) may collect
and enter the vehicle. This may lead to
death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that
the engine is running while customizing
features.
Customizable Features
A
B
C

497Alphabetical Index
Front turn signal lightsReplacing light bulbs................... 385, 387
Turn signal lever ...........................................182
Wattage.......................................................... 449
Fuel Capacity ......................................................... 444
Fuel gauge ........................................................ 77
Fuel pump shut off system .................... 402
Information ....................................................450
Refueling ........................................................200
Type.................................................................. 444
Warning light ...............................................406
Fuel consumption Average fuel economy .............................. 82
Current fuel consumption........................ 82
Fuel filler door If the fuel filler door cannot be opened.........................................................................430
Refueling ........................................................200
Fuel gauge .......................................................... 77
Fuel pump shut off system........................ 402
Fuses .................................................................. 381
G
Garage door opener ................................. 334
Gauges ................................................................ 77
G-force............................................................... 84
Glove box .........................................................314
Glove box light ...............................................314
Grocery bag hooks ..................................... 318
H
Hands Free Power Back Door ............... 106
Head restraints ...............................................136
Headlight aim ................................................ 382
Headlights Adaptive Front-lighting System (AFS).......................................................................... 190
Automatic High Beam system............... 191
Light switch .................................................... 188
Replacing light bulbs............................... 385 Head-up display..............................................88
Driving information display area .......... 88
Eco Driving Indicator.................................. 92
HUD (Head-up display) switch ............89
Navigation system-linked display ..........91
Settings...............................................................90
Heated steering wheel .............................. 306
Heaters Front automatic air conditioning system.......................................................................... 292
Heated steering wheel ........................... 306
Outside rear view mirrors..................... 294
Rear automatic air conditioning system
......................................................................... 303
Seat heaters ................................................. 306
High mounted stoplight Replacing light bulbs ............................... 385
Hill-start assist control ............................... 275
Hood Open................................................................357
Hooks Cargo hooks..................................................317
Cargo net hooks ..........................................317
Coat hooks .................................................... 331
Front passenger footwell hooks.........333
Grocery bag hooks................................... 318
Retaining hooks (floor mat) ..................... 24
Horn ....................................................................139
HUD (Head-up display) switch ................ 89
I
I/M test ............................................................ 354
Identification Engine.............................................................. 443
Vehicle ............................................................443
If your vehicle has to be stopped in an emergency .................................................. 394
Ignition switch (engine switch)................. 174 Auto power off function............................ 177
Changing the engine switch modes .. 177
If your vehicle has to be stopped in an emergency .................................................394

499Alphabetical Index
Interior lights list..........................................309
Rear interior lights .....................................309
Rear personal lights................................... 310
Replacing light bulbs............................... 385
Turn signal lever ...........................................182
Vanity lights .................................................. 333
Wattage.......................................................... 449
Lock steering column .................................. 175
LTA (Lane Tracing Assist) Operation........................................................ 216
Warning messages .................................. 224
Luggage cover .............................................. 318
M
Maintenance Do-it-yourself maintenance .................355
General maintenance ...............................351
Maintenance data...................................... 442
Maintenance requirements ................. 350
Malfunction indicator lamp ..................... 404
Master warning light .................................. 409
Menu icons..........................................................81
Meter Clock ................................................................... 77
Indicators ...........................................................74
Instrument panel light control ................80
Meter control switches .............................. 82
Meters ................................................................. 77
Multi-information display ............................81
Settings .............................................................. 85
Units .................................................................... 84
Warning lights .............................................403
Warning message....................................... 412
Micro dust and pollen filter ..................... 299
Mirrors Inside rear view mirror............................. 140
Outside rear view mirror defoggers294
Outside rear view mirrors ........................141
Vanity mirrors.............................................. 333
Moon roof Door lock linked moon roof operation........................................................................... 147 Door lock linked panoramic moon roof
operation ..................................................... 150
Jam protection function ............................147
Operation ....................................................... 146
Multi-information display ..............................81 Audio system-linked display ...................85
AWD Control ................................................83
Drive information .......................................... 82
Driving assist system information .........85
Driving information display ...................... 82
Dynamic radar cruise control with full-speed range ...................................... 227
Eco Driving Indicator..................................83
G-force ..............................................................84
LTA (Lane Tracing Assist) ...................... 221
Menu icons ....................................................... 81
Meter control switches .............................. 82
Navigation system-linked display ........85
Pop-up display ................................................ 81
Settings...............................................................85
Suggestion function .....................................86
Tire pressure ................................................ 367
Units.....................................................................84
Warning message .......................................412
N
Navigation system-linked display..... 85, 91
Noise from under vehicle ...............................6
O
“ODO TRIP” switch ...................................... 80
Odometer ......................................................... 80
Odometer and trip meter display Display items .................................................. 80
“ODO TRIP” switch ................................... 80
Pop-up display .............................................. 80
Oil Engine oil........................................................ 444
Rear differential oil......... ..................... ....... 447
Opener Fuel filler door ............................................. 200

505Alphabetical Index
Winter driving tips.......................................280
Wireless charger ......................................... 323
Wireless remote controlBattery-Saving Function ........................... 116
Locking/Unlocking ..................................... 97
Replacing the battery............................... 379
For information regarding the equipment listed below, refer to
the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S
MANUAL”.
· Navigation system
· Audio/visual system
· Panoramic view monitor
· Lexus parking assist monitor
