2021 LEXUS RX350 tire type

3997-2. Steps to take in an emergency
7
When trouble arises
Turn automatic mode off. (P.184)
From the front (AWD models)
Use a towing dolly under the rear
wheels.
From the rear
Use a towing dolly under the front
wheels. When using a flat-bed truck to trans-
port the vehicle, use tire strapping
belts. Refer to the owner's manual of
the flat-bed truck for the tire strapping
method.
In order to suppress vehicle movement
during transportation, set the parking
brake and turn the engine switch off.
If a tow truck is not available in an
emergency, your vehicle may be tem-
porarily towed using cables or chains
secured to the emergency towing eye-
lets. This should only be attempted on
hard surfaced roads for at most 50
miles (80 km) at under 18 mph (30
km/h).
A driver must be in the vehicle to steer
and operate the brakes. The vehicle’s
wheels, drive train, axles, steering and
brakes must be in good condition.
To have your vehicle towed by another
NOTICE
■Towing with a sling-type truck
Do not tow with a sling-type truck to pre-
vent body damage.
2WD models
AWD models
Using a flatbed truck
Emergency towing (vehicles
with towing eyelets)
Emergency towing procedure
(vehicles with towing eyelets)

4488-1. Specifications
*: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50 kgf) while
the engine is running.
Type A
Brake pad wear limit0.04 in. (1.0 mm)
Fluid typeFMVSS No. 116 DOT 3 or SAE J1703
FMVSS No. 116 DOT 4 or SAE J1704
Steering
Free playLess than 1.2 in. (30 mm)
Tires and wheels
Tire size235/65R18 106V, T165/90D18 107M (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Front tire
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Rear tire
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Spare tire
60 psi (420 kPa, 4.2 kgf/cm
2 or bar)
Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)
Add 5 psi (30 kPa, 0.3 kgf/cm
2 or bar) to the front and rear
tires. Never exceed the maximum cold tire inflation pres-
sure indicated on the tire sidewall.
Wheel size18  8J, 18  4T (spare)
Wheel nut torque76 ft•lbf (103 N•m, 10.5 kgf•m)

4498-1. Specifications
8
Vehicle specifications
Type B
A: Wedge base bulbs (amber)
B: Wedge base bulbs (clear)
*1: Vehicles with sing le-beam headlights
*2: Vehicles without door trim ornament lights
Tire size235/55R20 102V, T165/90D18 107M (spare)
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Front tire
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Rear tire
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Spare tire
60 psi (420 kPa, 4.2 kgf/cm
2 or bar)
Driving at high speeds (above 100 mph [160 km/h]) (in
countries where such speeds are permitted by law)
Add 11 psi (70 kPa, 0.7 kgf/cm
2 or bar) to the front and rear
tires. Never exceed the maximum cold tire inflation pres-
sure indicated on the tire sidewall.
Wheel size20  8J, 18  4T (spare)
Wheel nut torque76 ft•lbf (103 N•m, 10.5 kgf•m)
Light bulbs
Light bulbsBulb No.WType
Exterior
Front side marker lights*1W5W5B
Front turn signal lights*17444NA28/8A
Rear turn signal lights*1WY21W21A
Back-up lights*192116B
InteriorDoor courtesy lights*25B
Vanity lights8B

4538-1. Specifications
8
Vehicle specifications
A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply tire.
TUBELESS or TUBE TYPE
A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire has a
tube inside the tire and the tube maintains the air pressure.
Load limit at maximum cold tire inflation pressure ( P.366)
Maximum cold tire inflation pressure ( P.448)
This means the pressure to which a tire may be inflated.
Uniform tire quality grading
For details, see “Uniform Tire Quality Grading” that follows.
Summer tires or all season tires ( P.366)
An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire.
“TEMPORARY USE ONLY”
A compact spare tire is identified by the phrase “TEMPORARY USE ONLY” molded on its
sidewall. This tire is designed for temporary emergency use only.
Type A
DOT symbol
*
Tire Identification Number (TIN)
Tire manufacturer’s identification
mark
Tire size code
Manufacturer’s optional tire type
code (3 or 4 letters)
Manufacturing week
Manufacturing year
*: The DOT symbol certifies that the tire conforms to applicable Federal Motor
Vehicle Safety Standards.
Type B
DOT symbol
*
Tire Identification Number (TIN)
Tire manufacturer’s identification
mark
Manufacturer’s code
Manufacturing week
Manufacturing year
*: The DOT symbol certifies that the tire conforms to applicable Federal Motor
F
G
H
I
J
K
Typical DOT and Tire Identifica-
tion Number (TIN)
A
B
C
D
E
F
G
A
B
C
D
E
F

4578-1. Specifications
8
Vehicle specifications
RimA metal support for a tire or a tire and tube assem-
bly upon which the tire beads are seated
Rim diameter (Wheel diameter)Nominal diameter of the bead seat
Rim size designationRim diameter and width
Rim type designationThe industry manufacturer’s designation for a rim
by style or code
Rim widthNominal distance between rim flanges
Vehicle capacity weight (Total load
capacity)The rated cargo and luggage load plus 150 lb. (68
kg) times the vehicle’s designated seating capacity
Vehicle maximum load on the tire
The load on an individual tire that is determined by
distributing to each axle its share of the maximum
loaded vehicle weight, and dividing by two
Vehicle normal load on the tire
The load on an individual ti re that is determined by
distributing to each axle its share of curb weight,
accessory weight, and normal occupant weight
(distributed in accor dance with Table 1
* below), and
dividing by two
Weather sideThe surface area of the rim not covered by the
inflated tire
Bead
The part of the tire that is made of steel wires,
wrapped or reinforced by ply cords and that is
shaped to fit the rim
Bead separationA breakdown of the bond between components in
the bead
Bias ply tire
A pneumatic tire in which the ply cords that extend
to the beads are laid at alternate angles substan-
tially less than 90 degrees to the centerline of the
tread
CarcassThe tire structure, except tread and sidewall rubber
which, when inflated, bears the load
ChunkingThe breaking away of pieces of the tread or sidewall
CordThe strands forming the plies in the tire
Cord separationThe parting of cords from adjacent rubber com-
pounds
Tire related termMeaning

491What to do if... (Troubleshooting)
Is the engine switch in IGNITION
ON mode?
If you cannot release the shift lever by
depressing the brake pedal with the engine
switch in IGNITION ON mode ( P.179)
It is locked automatically to prevent
theft of the vehicle. ( P.175)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( P.146)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not running) for
a period of time. ( P.177)
 The seat belt reminder light is flash-
ing
Are the driver and the passengers wearing
the seat belts? ( P.406)
 The parking brake indicator is on
Is the parking brake released? ( P.183)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.403, 412)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.68)
Do one of the following to stop the
alarms:
 Unlock the doors.
 Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.412)
 When a warning light turns on or a
warning message is displayed, refer
to P.403, 412.
The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed
When a problem has occurred
If you have a flat tire

501Alphabetical Index
Head restraints .............................................136
Seat heaters ..................................................306
Rear side marker lights Light switch .................................................... 188
Replacing light bulbs............................... 385
Rear turn signal lights Replacing light bulbs................... 385, 389
Turn signal lever ...........................................182
Wattage.......................................................... 449
Rear view mirror Inside rear view mirror............................. 140
Outside rear view mirrors ........................141
Rear window defogger ............................. 294
Rear window wiper.......................................199
Refueling Capacity ......................................................... 444
Fuel types....................................................... 444
If the fuel filler door cannot be opened.........................................................................430
Opening the fuel tank cap ....................200
Remote Touch .............................................. 286
Replacing Electronic key battery.............................. 379
Fuses ................................................................. 381
Light bulbs.....................................................384
Tires ....................................................................416
Resetting the message indicating mainte- nance is required ...................................... 350
Rev indicator .................................................... 78
Rev peak..............................................................79
Road Sign Assist .......................................... 225
RSA (Road Sign Assist) ............................ 225
S
Seat belt reminder ligh t............................. 406
Seat belts............................................................ 26 Automatic Locking Retractor ................ 28
Child restraint system installation ......... 46
Cleaning and maintaining the seat belt......................................................................... 347
Emergency Locking Retractor .............. 28
How to wear your seat belt ......................27 How your child should wear the seat belt
............................................................................. 27
Pregnant women, proper seat belt use ............................................................................. 26
Reminder light and buzzer .................. 406
Seat belt extender......................................... 27
Seat belt pretensioners .............................. 29
SRS warning light...................................... 404
Seat heaters ................................................... 306
Seat position memory..................................133
Seat ventilators ............................................. 306
Seating capacity.............................................162
Seats Adjustment ............................................. 121, 123
Adjustment precautions .................. 121, 122
Child seats/child restraint system installa-tion .................................................................... 45
Cleaning ......................................................... 347
Driving position memory ........................ 133
Folding down the rear seatbacks ........123
Head restraints............................................. 136
Power easy access system .................... 133
Properly sitting in the seat ........................ 25
Seat heaters ................................................. 306
Seat position memory .............................. 133
Seat ventilators ........................................... 306
Sensor Automatic headlight system .................. 188
Automatic High Beam system ............... 191
Inside rear view mirror ............................. 140
Intuitive parking assist .............................. 244
LTA (Lane Tracing Assist) ......................216
Parking Support Brake function (rear-crossing vehicles) ...................... 267
Parking Support Brake function (static objects) ........................................................ 262
Radar sensor ................................... 203, 238
Rain-sensing windshield wipers ...........197
RCTA............................................................... 252
Service reminder message .....................350
Shift lever Automatic transmission ........................... 178

508
GAS STATION INFORMATION
Auxiliary catch lever (P.357)
Fuel filler door ( P.201)
Hood lock release lever ( P.357)
Tire inflation pressure ( P.448)
Fuel tank capacity (Ref-
erence)19.2 gal. (72.5 L, 15.9 Imp. gal.)
Fuel typeUnleaded gasoline onlyP.444
P.450
Cold tire inflation pres-
sureP.448
Engine oil capacity
(Drain and refill  ref-
erence)
P.444
Engine oil typeP.444
A
B
C
D
