Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-14584335) -
2021 - CRC - 11/23/20
418 CONNECTED SERVICES
Connected Services
Connected Services
Navigation . . . . . . . . . . . . . . . . . . . . . . . . 418
Connections . . . . . . . . . . . . . . . . . . . . . . 419
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . 420
Connected Services
Navigation
Navigation requires a specific OnStar
or connected service plan.
Press
Qto receive Turn-by-Turn
directions or have them sent to the
vehicle’s navigation screen,
if equipped.
Turn-by-Turn Navigation
1. PressQto connect to an Advisor.
2. Request directions to be downloaded to the vehicle.
3. Follow the voice-guided commands.
Using Voice Commands During a
Planned Route
Functionality of the Voice Command
button, if equipped, may vary by
vehicle and region. For some vehicles,
press
=to open the OnStar app on
the infotainment display. For other
vehicles press
=as follows. Cancel Route
1. Press
=. System responds: “OnStar
ready,” then a tone.
2. Say “Cancel route.” System
responds: “Do you want to cancel
directions?”
3. Say “Yes.”System responds: “OK,
request completed, thank you,
goodbye.”
Route Preview
1. Press
=. System responds: “OnStar
ready,” then a tone.
2. Say “Route preview.” System
responds with the next three
maneuvers.
Repeat
1. Press
=. System responds: “OnStar
ready,” then a tone.
2. Say “Repeat.” System responds with
the last direction given, then
responds with “OnStar ready,” then
a tone.
Get My Destination
1. Press
=. System responds: “OnStar
ready,” then a tone.
Page 420 of 434
Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-14584335) -
2021 - CRC - 11/23/20
CONNECTED SERVICES 419
2. Say“Get my destination.” System
responds with the address and
distance to the destination, then
responds with “OnStar ready,” then
a tone.
Send Destination to Vehicle
Directions can be sent to the vehicle’s
navigation screen, if equipped.
Press
Q, then ask the Advisor to
download directions to the vehicle’s
navigation system, if equipped. After
the call ends, the navigation screen
will provide prompts to begin driving
directions. Routes that are sent to the
navigation screen can only be
canceled through the navigation
system.
See www.onstar.com (U.S.) or
www.onstar.ca (Canada).
Connections
The following services help with
staying connected.
For coverage maps, see
www.onstar.com (U.S.) or
www.onstar.ca (Canada). Ensuring Security
.Change the default passwords for
the Wi-Fi hotspot and myCadillac
mobile app. Make these passwords
different from each other and use a
combination of letters and numbers
to increase the security.
.Change the default name of the
SSID (Service Set Identifier). This is
your network’s name that is visible
to other wireless devices. Choose a
unique name and avoid family
names or vehicle descriptions.
Wi-Fi Hotspot (If Equipped)
The vehicle may have a built-in Wi-Fi
hotspot that provides access to the
Internet and web content at 4G LTE
speed. Up to seven mobile devices can
be connected. A data plan is required.
Use the in-vehicle controls only when
it is safe to do so. 1. To retrieve Wi-Fi hotspot information, press
=to open the
OnStar app on the infotainment
display, then select Wi-Fi Hotspot.
On some vehicles, touch Wi-Fi or
Wi-Fi Settings on the screen. 2. The Wi-Fi settings will display the
Wi-Fi hotspot name (SSID),
password, and on some vehicles,
the connection type (no Internet
connection, 3G, 4G, 4G LTE), and
signal quality (poor, good,
excellent). The LTE icon shows
connection to Wi-Fi. It is possible
that the icon may not illuminate
even though the vehicle has an
active connection.
3. To change the SSID or password, press
Qor call 1-888-4ONSTAR to
connect with an Advisor. On some
vehicles, the SSID and password
can be changed in the Wi-Fi
Hotspot menu.
After initial set-up, your vehicle’s
Wi-Fi hotspot will connect
automatically to your mobile devices.
Manage data usage by turning Wi-Fi
on or off on your mobile device, by
using the myCadillac mobile app,
or by contacting an OnStar Advisor.
On some vehicles, Wi-Fi can also be
managed from the Wi-Fi
Hotspot menu.
Page 424 of 434
Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-14584335) -
2021 - CRC - 11/23/20
INDEX 423
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . 358
ChargingWireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Charging System Light . . . . . . . . . . . . . . 97
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . . . . . 97
Child Restraints Infants and Young Children . . . . . . . 60
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . . . . . 65
Older Children . . . . . . . . . . . . . . . . . . . . . 59
Securing . . . . . . . . . . . . . . . . . . . . . . . . 72, 74
Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . 331
Cleaning Exterior Care . . . . . . . . . . . . . . . . . . . . . . 370
Interior Care . . . . . . . . . . . . . . . . . . . . . . 375
Climate Control Systems Dual Automatic . . . . . . . . . . . . . . . . . . . 196
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Cluster, Instrument . . . . . . . . . . . . . . 88, 90
Collision Damage Repair . . . . . . . . . . . 406
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Competitive Driving Mode . . . . . . . . . 246
Composite Materials . . . . . . . . . . . . . . . . 218 Compressor Kit, Tire Sealant . . . . . . . 360
Connected Services
Connections . . . . . . . . . . . . . . . . . . . . . . . 419
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . 420
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . 418
Connections Connected Services . . . . . . . . . . . . . . . 419
Control Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . . . . . . 239
Control of a Vehicle . . . . . . . . . . . . . . . . 204
Controls
Steering Wheel . . . . . . . . . . . . . . . . . . . . 137
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . 23
Coolant Engine Temperature Gauge . . . 94, 95
Engine Temperature Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
Cooling System . . . . . . . . . . . . . . . . . . . . . 317
Cornering Lamps . . . . . . . . . . . . . . . . . . . 130
Courtesy Lamps . . . . . . . . . . . . . . . . . . . . . 130
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . 405
Coverage Explanations . . . . . . . . . . . . . 163
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 248
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Cruise Control, Adaptive . . . . . . . . . . . 251 Cruise Control, Super . . . . . . . . . . . . . . . 260
Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Customer Assistance . . . . . . . . . . . . . . . 402
Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 401
Text Telephone (TTY) Users . . . . . 402
Customer Information Publications Ordering
Information . . . . . . . . . . . . . . . . . . . . . . 408
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . 399
Cybersecurity . . . . . . . . . . . . . . . . . . . . . . . . 410
D
Damage Repair, Collision . . . . . . . . . . . 406
Danger, Warning, and Caution . . . . . . . . 2
Data Collection Infotainment System . . . . . . . . . . . . . 412
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
Data Recorders, Event . . . . . . . . . . . . . . 411
Database Coverage Explanations . . . . . . . . . . . . . . . . . . . . . . 163
Daytime Running Lamps (DRL) . . . 128
Defensive Driving . . . . . . . . . . . . . . . . . . . 204
Delayed Locking . . . . . . . . . . . . . . . . . . . . . 17
Destination . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Diagnostics Connected Services . . . . . . . . . . . . . . . 420
Differential, Limited-Slip . . . . . . . . . . . 248
Page 429 of 434
Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-14584335) -
2021 - CRC - 11/23/20
428 INDEX
N
NavigationConnected Services . . . . . . . . . . . . . . . 418
Destination . . . . . . . . . . . . . . . . . . . . . . . . 155
Using the System . . . . . . . . . . . . . . . . . 150
Navigation Symbols . . . . . . . . . . . . . . . . 154
New Vehicle Break-In . . . . . . . . . . . . . . . 218
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312
Engine Oil Life System . . . . . . . . . . . 314
Pressure Light . . . . . . . . . . . . . . . . . . . . . 104
Older Children, Restraints . . . . . . . . . . . 59
Online Owner Center . . . . . . . . . . . . . . . 402
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
OnStar Additional Information . . . . 414
OnStar Emergency . . . . . . . . . . . . . . . . . . 414
OnStar Overview . . . . . . . . . . . . . . . . . . . . 413
OnStar Security . . . . . . . . . . . . . . . . . . . . . 414
OnStar System . . . . . . . . . . . . . . . . .149, 160
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 Overheating, Engine . . . . . . . . . . . . . . . . 322
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Instrument Panel . . . . . . . . . . . . . . . . . . . . 4
P
ParkShifting Into . . . . . . . . . . . . . . . . 223, 224
Shifting Out of . . . . . . . . . . . . . . . . . . . . 225
Park Assist . . . . . . . . . . . . . . . . . . . . . . . . . . 277
Parking Brake and P (Park)Mechanism Check . . . . . . . . . . . . . . . 327
Extended . . . . . . . . . . . . . . . . . . . . . . . . . . 226
Over Things That Burn . . . . . . . . . . . 226
Parking or Backing Assistance Systems . . . . . . . . . . . . . . . 277
Passenger Airbag Status
Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Passenger Sensing System . . . . . . . . . . 53
Pedestrian Ahead Indicator . . . . . . . . 102
Perchlorate Materials
Requirements, California . . . . . . . . . 306
Performance Shifting Light . . . . . . . . 101
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117 Phone
Apple CarPlay and
Android Auto . . . . . . . . . . . . . . . . . . . . 174
Bluetooth . . . . . . . . . . . . . . . . . . . . 169, 170
Port USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Positioning
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Power Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . 17
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Protection, Battery . . . . . . . . . . . . . . . . 133
Retained Accessory (RAP) . . . . . . . . 223
Seat Adjustment . . . . . . . . . . . . . . . . . . . 32
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Pregnancy, Using Seat Belts . . . . . . . . . 46
Privacy Vehicle Data Recording . . . . . . . . . . 410
Problems with Route Guidance . . . . 162
Program Courtesy Transportation . . . . . . . . . 405
Prohibited Fuels . . . . . . . . . . . . . . . . . . . . 294
Proposition 65 Warning,
California . . . . . . . . . . . . . . .305, 326, 366,
Back Cover
Page 431 of 434
Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-14584335) -
2021 - CRC - 11/23/20
430 INDEX
SeatsHead Restraints . . . . . . . . . . . . . . . . . . . . 31
Heated and Ventilated Front . . . . . . 37
Lumbar Adjustment, Front . . . . . . . . 32
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Power Adjustment, Front . . . . . . . . . 32
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Reclining Seatbacks . . . . . . . . . . . . . . . 33
Securing Child Restraints . . . . . . . 72, 74
Security Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 414
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Vehicle Alarm . . . . . . . . . . . . . . . . . . . . . . 20
Self-Sealing Tires . . . . . . . . . . . . . . . . . . . 341
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201 Accessories andModifications . . . . . . . . . . . . . . . . . . . . 306
Doing Your Own Work . . . . . . . . . . . 306
Maintenance Records . . . . . . . . . . . . 394
Maintenance, General Information . . . . . . . . . . . . . . . . . . . . . . 379
Parts Identification . . . . . . . . . . . . . . . 395
Scheduling Appointments . . . . . . . . 405
Service Electric Parking Brake
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Services Special Application . . . . . . . . . . . . . . . 388 Servicing System . . . . . . . . . . . . . . . . . . . . 163
Servicing the Airbag . . . . . . . . . . . . . . . . . 57
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
Shifting
Into Park . . . . . . . . . . . . . . . . . . . . 223, 224
Out of Park . . . . . . . . . . . . . . . . . . . . . . . . 225
Side Blind Zone Alert (SBZA) . . . . . . 289
Signals, Turn and Lane-Change . . . . 129
Software Updates . . . . . . . . . . . . . . . . . . . 140
Special Application Services . . . . . . . 388
Specifications and Capacities . . . . . . 396
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . 93
StabiliTrak
OFF Light . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Start Assist, Hill . . . . . . . . . . . . . . . . . . . . 238
Start Vehicle, Remote . . . . . . . . . . . . . . . 13
Starting the Engine . . . . . . . . . . . . . . . . . 220
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205 Heated Wheel . . . . . . . . . . . . . . . . . . . . . . 82
Wheel Adjustment . . . . . . . . . . . . . . . . . 82
Wheel Controls . . . . . . . . . . . . . . . . . . . . 82
Steering Wheel Controls . . . . . . . . . . . 137
Stop/Start System . . . . . . . . . . . . . . . . . . 221
Storage Areas Cargo Management System . . . . . . . 80
Center Console . . . . . . . . . . . . . . . . . . . . . 79
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Umbrella . . . . . . . . . . . . . . . . . . . . . . . . . . . 79 Storage Compartments . . . . . . . . . . . . . . 78
Storing the Tire Sealant and
Compressor Kit . . . . . . . . . . . . . . . . . . . . 366
Struts Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 328
Stuck Vehicle . . . . . . . . . . . . . . . . . . . . . . . 214
Summer Tires . . . . . . . . . . . . . . . . . . . . . . . 341
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Super Cruise . . . . . . . . . . . . . . . . . . . . . . . . 260
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Navigation . . . . . . . . . . . . . . . . . . . . . . . . . 154
System Brake Pad Life . . . . . . . . . . . . . . . . . . . . . 324
Engine Air Filter Life . . . . . . . . . . . . . 315
Forward Collision Alert (FCA) . . . . 283
Global Positioning . . . . . . . . . . . . . . . . 161
Infotainment . . . . . . . . . . . . . . . . . . . . . . 412
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Systems Driver Assistance . . . . . . . . . . . . . . . . . 275
T
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Teen Driver . . . . . . . . . . . . . . . . . . . . . . . . . . 184
Text Telephone (TTY) Users . . . . . . . 402
Theft-Deterrent Systems . . . . . . . . . . . . 23
Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . 22
Page 432 of 434
Cadillac CT4 Owner Manual (GMNA-Localizing-U.S./Canada-14584335) -
2021 - CRC - 11/23/20
INDEX 431
Thigh Support Adjustment . . . . . . . . . . 33
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 339All-Season . . . . . . . . . . . . . . . . . . . . . . . . . 339
Buying New Tires . . . . . . . . . . . . . . . . . 354
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
Designations . . . . . . . . . . . . . . . . . . . . . . 343
Different Size . . . . . . . . . . . . . . . . . . . . . . 356
If a Tire Goes Flat . . . . . . . . . . . . . . . . 359
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . 352
Low Profile . . . . . . . . . . . . . . . . . . . . . . . . 341
Pressure . . . . . . . . . . . . . . . . . . . . . 346, 347
Pressure Light . . . . . . . . . . . . . . . . . . . . . 104
Pressure Monitor Operation . . . . . . 349
Pressure Monitor System . . . . . . . . 348
Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . 352
Run-Flat . . . . . . . . . . . . . . . . . . . . . . . . . . . 340
Sealant and Compressor Kit . . . . . 360
Sealant and Compressor Kit,Storing . . . . . . . . . . . . . . . . . . . . . . . . . . . 366
Self-Sealing . . . . . . . . . . . . . . . . . . . . . . . . 341
Sidewall Labeling . . . . . . . . . . . . . . . . . 342
Terminology and Definitions . . . . 344
Uniform Tire Quality Grading . . . . 356
Wheel Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . . . . . . 357
Wheel Replacement . . . . . . . . . . . . . . 357 Tires (cont'd)
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 353
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 340
Top Tier Fuel . . . . . . . . . . . . . . . . . . . . . . . . 293
Towing Driving Characteristics . . . . . . . . . . . 297
Equipment . . . . . . . . . . . . . . . . . . . . . . . . 302
General Information . . . . . . . . . . . . . . 297
Recreational Vehicle . . . . . . . . . . . . . . 370
Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 369
Track Events and Competitive Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Traction Control System
(TCS)/StabiliTrak Light . . . . . . . . . 103
Limited-Slip Differential . . . . . . . . . . 248
Off Light . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . . . . . 239
Trademarks and License Agreements . . . . . . . . . . . . . . . . . . . . . . . . 187
Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300 Transmission
Automatic . . . . . . . . . . . . . . . . . . . 227, 229
Fluid, Automatic . . . . . . . . . . . . . . . . . . 315
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . . . . . . 405
Trip Odometer . . . . . . . . . . . . . . . . . . . . . . . 93
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Turn and Lane-Change Signals . . . . 129
U
Umbrella Storage . . . . . . . . . . . . . . . . . . . . 79
Uniform Tire Quality Grading . . . . . . 356
Universal Remote System . . . . . . . . . . 122 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Programming . . . . . . . . . . . . . . . . . . . . . . 122
Updates Map Data . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Software . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
USB Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Using the Navigation System . . . . . . 150
Using the System . . . . . . . . . . . . . . . . . . . 137
Using This Manual . . . . . . . . . . . . . . . . . . . . 2
