The rear storage compartment is located under
the taillight. To access the storage compartment,
open the storage compartment lid by turning the
storage compartment knob 1/4 turn counterclock-
wise.
When storing any documents in the storage com-
partments, be sure to wrap them in a plastic bag
so that they will not get wet. When washing the
ATV, be careful not to let any water enter the stor-
age compartments.
Do not exceed the load limit of 0.5 kg (1 lb) for
the front storage compartment, 4.0 kg (9 lb) for
the center storage compartment or 2.0 kg (4 lb)
for the rear storage compartment.
 Do not exceed the maximum load of 240.0 kg
(530 lb) for the ATV.
1. Rear storage compartment lid
2. Rear storage compartment knob
3. Open.
2
1 3
1. Rear storage compartment
1
UBDE60E0.book Page 24 Monday, April 22, 2019 4:12 PM

5-25
5
TIPA drain plug is fitted at the bottom of each storage
compartment. If any water collects in a storage
compartment, remove the drain plug, drain the
water, and then install the drain plug. 1. Front storage compartment drain plug
1. Center storage compartment drain plug
1. Rear storage compartment drain plug
1
1
UBDE60E0.book Page 25 Monday, April 22, 2019 4:12 PM

5-26
5
EBU18964Front carrierDo not exceed the load limit of 50.0 kg (110 lb)
for the front carrier.
 Do not exceed the maximum load of 240.0 kg
(530 lb) for the ATV.EBU18974Rear carrierDo not exceed the load limit of 90.0 kg (198 lb)
for the rear carrier.
 Do not exceed the maximum load of 240.0 kg
(530 lb) for the ATV.EBU1914AFront and rear shock absorbers The spring preload can be adjusted to suit the rid-
er’s weight and the riding conditions.
WARNING
EWB00401Always adjust the shock absorber assemblies
on the left and right side to the same setting.
Uneven adjustment can cause poor handling
and loss of stability, which could lead to an ac-
cident. Adjust the spring preload as follows. Turn the spring preload adjusting ring in direction
(a) to increase the spring preload and thereby
harden the suspension, and in direction (b) to de-
crease the spring preload and thereby soften the
suspension.
Align the appropriate notch in the adjusting ring
with the position indicator on the shock absorber.
TIPA special wrench can be obtained at a Yamaha
dealer to make this adjustment. 1. Spring preload adjusting ring
2. Position indicator
UBDE60E0.book Page 26 Monday, April 22, 2019 4:12 PM

5-27
5
1. Special wrench
Front spring preload setting:Minimum (soft):1
Standard: 2
Maximum (hard): 5
Rear spring preload setting: Minimum (soft):1
Standard: 2
Maximum (hard): 5
UBDE60E0.book Page 27 Monday, April 22, 2019 4:12 PM

5-28
5
EBUM0303Winch (equipped models)
WARNING
EWBM0041To reduce the risk of injury or death, read and
follow the Basic Guide to Winching Techniques
prior to use. Never let anyone come between
the winch and pulled object or the winch and
anchor point. Do not use the winch unless allbystanders are a safe distance away. Use hook
strap to keep hands away from fairlead when
winding the winch rope.
NOTICEECBM0051Prolonged winching can overheat the winch
motor and can drain the vehicle’s battery, even
when the engine is idling. Allow the winch mo-
tor to cool and the battery to recharge between
uses. EBU28972Trailer hitch This ATV is equipped with a 5 cm (2 in) trailer hitch
receiver.
Trailer towing equipment can be obtained at a
Yamaha dealer. (See page 7-6 for precaution in- formation.)
1. Winch
2. Hook
3. Hook strap
4. Fairlead
1
3
2
4
UBDE60E0.book Page 28 Monday, April 22, 2019 4:12 PM

5-29
5
EBU19186Auxiliary DC jack
1. Trailer hitch receiver
1
1. Auxiliary DC jack cap
2. Auxiliary DC jackAuxiliary DC jack system capacity:10.0 A (120 W) (BDE3, BDEK)
6.0 A (72 W) (BDE2, BDE7, BDEA, BDEE,
BDEJ)
21
UBDE60E0.book Page 29 Monday, April 22, 2019 4:12 PM

5-30
5
NOTICEECB03760Do not use any single electrical accessory or
combination of accessories that require more
than the stated capacity at any one time. This
may overload the circuit and cause the fuse to
blow. TIPWhen using a winch or other electrical accesso-
ries, the power taken from the DC jack must be re-
duced accordingly. A 12-V accessory, such as a work light or radio
with the proper adapter, can be used when the
main switch is turned on. However, to prevent bat-
tery drain, use when the engine is running and the
headlights are turned off.1. Start the engine.
2. Turn the headlights off.
3. Turn the accessory off.
4. Open the auxiliary DC jack cap.
5. Insert the accessory power plug into the jack.
6. Turn the accessory on.
TIP When inserting or removing the accessory pow-
er plug, turn the accessory off.
 When the auxiliary DC jack is not being used,
cover it with the cap. NOTICEECB00122If accessories are used with the engine off or
with the headlights on, the battery may dis-
charge to the point that the engine will not
start.
 Do not use an automotive cigarette lighter or
other accessory with a plug that gets hot.
The DC jack may be damaged.
UBDE60E0.book Page 30 Monday, April 22, 2019 4:12 PM

6-1
6
EBU19203
PRE-OPERATION CHECKS
EBU19226Inspect your vehicle each time you use it to make sure the vehicle is in safe operating condition. Always
follow the inspection and maintenance procedures and schedules described in the Owner’s Manual.
WARNING
EWB00482Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equip-
ment damage. Do not operate the vehicle if you find any problem. If a problem cannot be corrected
by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:
ITEMROUTINE PAGE
Fuel • Check fuel level in fuel tank,
and add recommended fuel if neces-
sary.
• Check fuel line for leakage. Correct if necessary. 5-20, 6-3
Engine oil • Check oil level in engine, and add recommended oil to specified
level if necessary.
• Check ATV for oil leakage. Correct if necessary. 6-3, 9-20
Final gear oil • Check ATV for oil leakage. Correct if necessary. 6-3, 9-25
Differential gear oil • Check ATV for oil leakage. Correct if necessary. 6-3, 9-27
Coolant • Check coolant level in reservoir, and add recommended coolant to
specified level if necessary.
• Check cooling system for leakage. Correct if necessary. 6-3, 9-29
UBDE60E0.book Page 1 Monday, April 22, 2019 4:12 PM
