Vehicle care2196. Close the bonnet.
Wiper blade replacement Windscreen
Switch off the ignition.
Within 1 minute after switching off the ignition, operate the wiper lever to
positon the wiper blades vertically on
the windscreen.
Lift the wiper arm until it stays in the
raised position, disengage and
remove the wiper blade.
Attach the wiper blade to the wiper
arm and push until it engages.
Lower the wiper arm carefully.
Rear window
Lift the wiper arm. Disengage the
wiper blade as shown in the
illustration and remove.
Attach the wiper blade slightly angled
to the wiper arm and push until it
engages.
Lower the wiper arm carefully.
Bulb replacement
Switch off the ignition and switch off
the relevant switch or close the doors.
Only hold a new bulb at the base. Do not touch the bulb glass with bare
hands.
Use only the same bulb type for
replacement.
Replace headlight bulbs from within
the engine compartment.
Bulb check
After a bulb replacement switch on
the ignition, operate and check the
lights.
Halogen headlights Front turn lights 3 224.
Illustrations show the right headlight
unit.

Vehicle care237Directional tyresDirectional tyres should be mounted
so that they rotate in the correct
direction. The proper rotation
direction is indicated by a symbol (e.g. an arrow) on the sidewall.
Tyre pressure
Check the pressure of cold tyres at
least every 14 days and before any
long journey. Do not forget the spare
wheel. This also applies to vehicles
with tyre pressure monitoring system.
Tyre pressure 3 271.
The tyre pressure data refers to cold
tyres. It applies to summer and winter tyres.
Always inflate the spare tyre to the
pressure specified for full load.
Incorrect tyre pressures will impair
safety, vehicle handling, comfort and
fuel economy and will increase tyre
wear.Tyre pressures differ depending on
various options. For the correct tyre
pressure value, follow the procedure
below:
1. Identify the engine identifier code.
Engine data 3 268.
2. Identify the respective tyre.
The tyre pressure tables show all
possible tyre combinations 3 271.
For the tyres approved for your
vehicle, refer to the EEC Certificate of Conformity provided with your vehicle
or other national registration
documents.
The driver is responsible for correct
adjustment of tyre pressure.9 Warning
If the pressure is too low, this can
result in considerable tyre warm-
up and internal damage, leading to tread separation and even to tyre
blow-out at high speeds.
9 Warning
For specific tyres the
recommended tyre pressure as
shown in the tyre pressure table may exceed the maximum tyre
pressure as indicated on the tyre.
Never exceed the maximum tyre
pressure as indicated on the tyre.
Temperature dependency
The tyre pressure depends on the
temperature of the tyre. During
driving, tyre temperature and
pressure increase. Tyre pressure
values provided on the tyre
information label and tyre pressure
chart are valid for cold tyres, which means at 20 °C.
The pressure increases by nearly
1.5 psi for a 10 °C temperature
increase. This must be considered
when warm tyres are checked.

Vehicle care2411.Pull speed limit label from the tyre
repair kit and place it in driver's
visible area.
2. Pull the electrical cable and air hose out of the compartments on
the underside of the kit.
3. Turn selector A to the "sealant"
position. Check that switch B is in
position J.
4. Uncoil the air hose fully and
unscrew the cap from the end of
the hose. Connect hose to the
valve of the defective tyre.
5. Connect the electrical cable to the
vehicle's 12 V front power
outlet 3 97.
To avoid discharging the battery,
we recommend running the
engine.
6. Set the rocker switch on the compressor to I. The tyre is filled
with sealant.
7. The compressor pressure gauge briefly indicates up to
600 kPa (6 bar) whilst the sealant
cartridge is emptying (approx.
30 s). Then the pressure starts to
drop.

285Particulate filter........................... 160
Performing work ........................212
Peripheral lighting .......................137
Power button .............................. 153
Power outlets ............................... 97
Power seat adjustment ................49
Power sliding doors ......................30
Power windows ............................ 41
Preheating ................................. 112
Puncture ..................................... 245
R Radio Frequency Identification (RFID) ..................................... 280
Radio (Infotainment system)....... 123
Radio remote control ...................22
Rain sensor ................................ 114
REACH ....................................... 276
Reading lights ............................ 135
Rear doors .................................... 30
Rear fog light .............114, 133, 225
Rear seats ................................... 52
Rear view camera ...................... 199
Rear windows .............................. 42
Rear window wiper and washer ..96
Recommended fluids and lubricants ........................ 262, 266
Refuelling ................................... 204 Registered trademarks ...............276
Reversing lights .........................134Ride control systems ..................170
Roadside assistance ..................127
Roller blinds ................................. 44
Roof .............................................. 45
Roof bars ...................................... 89
Roof load ...................................... 90
Roof rack ..................................... 89
S Safety net .................................... 83
Seat adjustment ............................. 7
Seat belt ........................................ 8
Seat belt reminder .....................109
Seat belts ..................................... 56
Seat folding .................................. 50
Seat heating ................................. 51
Seat position ................................ 47
Selective catalytic reduction .......161
Selective ride control ..................171
Selector lever.............................. 165
Service ............................... 150, 259
Service display .......................... 108
Service information ....................259
Service vehicle soon .................. 111
Side airbag system ......................63
Side blind spot alert ............115, 194
Sidelights .................................... 129
Side turn lights ........................... 228
Sliding doors ................................ 30
Sliding side doors .........................30SOS............................................ 127
Spare wheel ............................... 245
Speed limiter....................... 115, 176
Speedometer ............................. 104
Starting and operating ................152
Starting off ................................... 18
Starting the engine ....................154
Steering ...................................... 152
Steering column controls ..............94
Steering wheel .............................. 94
Steering wheel adjustment ......9, 93
Steering wheel controls ...............93
Stop engine ................................ 111
Stop-start system........................ 156
Storage ......................................... 77
Storage compartments .................77
Sunvisor lights ........................... 136
Sun visors .................................... 44
Symbols ......................................... 4
System check ............................. 111
T
Table............................................. 86
Tachometer ............................... 106
Tailgate ......................................... 32
tailgate window ............................. 42
Tail lights ................................... 225
Three-point seat belt .................... 57
Tools .......................................... 234
torch............................................ 134
