372
PRIUS PRIME_OM_OM47C77U_(U)
5-4. Refueling
After refueling, turn the fuel tank
cap until you hear a click. Once
the cap is released, it will turn
slightly in the opposite direction.
Closing the fuel tank cap
WARNING
■When replacing the fuel tank cap
Do not use anything but a genuine Toyota fuel tank cap designed for your
vehicle. Doing so may cause a fire or other incident which may result in
death or serious injury.
792
PRIUS PRIME_OM_OM47C77U_(U)
GAS STATION INFORMATION
Auxiliary catch leverFuel filler door
P. 585 P. 370
Fuel filler door openerHood lock release
leverTire inflation pressure
P. 370 P. 585P. 725
Fuel tank capacity
(Reference)11.4 gal. (43 L, 9.5 Imp.gal.)
Fuel type
Unleaded gasoline only P. 720
Cold tire inflation
pressure P. 7 2 5
Engine oil capacity
(Drain and refill —
reference)With filter
Without filter
4.4 qt. (4.2 L, 3.7 Imp.qt.)
4.1 qt. (3.9 L, 3.4 Imp.qt.)
Engine oil type “Toyota Genuine Motor Oil” or equivalent
Oil grade: API SN/RC multigrade engine oil
P. 722
