7048-2. Steps to take in an emergency
PRIUS PRIME_OM_OM47C77U_(U)
Connect the jumper cables according to the following procedure:Connect a positive jumper cable clamp to the positive (+) batte ry
terminal on your vehicle.
Connect the clamp on the other end of the positive cable to the
positive (+) battery termi nal on the second vehicle.
Connect a negative cable clamp to the negative (-) battery term i-
nal on the s econd vehicle.
Connect the clamp at the other e nd of the negative cable to a
solid, stationary, unpainted metallic point away from the 12-vo lt
battery and any movin g parts, as shown in the illustration.
Start the engine of the second v ehicle. Increase the engine speed
slightly and maintain at that lev el for approximately 5 minutes to
recharge the 12-volt battery of your vehicle.
Maintain the engine speed of the second vehicle and start the
hybrid system of your vehicle by turning the power switch to ON
mode.
Make sure the “READY” indicator comes on. If the indicator ligh t
does not come on, contac t your Toyota dealer.
Once the hybrid system has started, remove the jumper cables in
the exact reverse order from which they were connected.
To install the engine cover, conduct the removal procedure in
reverse. After installing, check that the fixed pins are inserted
securely.
Once the hybrid system starts, have the vehicle inspected at yo ur
Toyota dealer as soon as possible.3
1
2
3
4
4
5
6
7
8

7128-2. Steps to take in an emergency
PRIUS PRIME_OM_OM47C77U_(U)
After stopping the hybrid system and waiting for 5 minutes or
more, start the hybrid system again and check if “Hybrid System
Overheated” is shown on the multi-information display.
If the message d oes not disappear:
Stop the hybrid system and contact your Toyota dealer.
If the message is not displayed:
The hybrid system temperature has dropped and the vehicle may
be driven normally.
However, if the message appears again frequently, contact your Toyota
dealer.
WARNING
■ To prevent an accident or injury when inspecting under the hood of
your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot.
● After the hybrid system has been turned off, check that the “Ac cessory”,
“Ignition ON” or mileage display ( P. 210) on the main display and the
“READY” indicator are off.
When the hybrid system is operating, the gasoline engine may au tomati-
cally start, or the cooling fans may suddenly operate even if the gasoline
engine stops. Do not touch or approach rotating parts such as the fan,
which may lead to fingers or clothing (especially a tie, a scarf or a muffler)
getting caught, resulting in serious injury.
● Do not loosen the coolant reservoir caps while the hybrid syste m and radi-
ator are hot.
High temperature steam or coolant could spray out.
6

722
PRIUS PRIME_OM_OM47C77U_(U)
9-1. Specifications
■Oil capacity (Drain and refill [Reference*])
*: The engine oil capacity is a reference quantity to be used when changing
the engine oil. Park the vehicle on level ground. After warming up the
engine and turning off the hybrid system, wait more than 5 minu tes, and
check the oil level on the dipstick.
■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat isfy
the following grade and viscosity.
Oil grade: API SN/RC multigrade engine oil
Recommended viscosity: SAE 0W-16
SAE 0W-16 is the best choice
for good fuel economy and
good starting in cold weather.
If SAE 0W-16 is not available,
SAE 0W-20 oil may be used.
However, it must be replaced
with SAE 0W-16 at the next oil
change.
Oil viscosity (0W-16 is expl ained here as an example):
• The 0W in 0W-16 indicates the characteristic of the oil which allows cold startability. Oils wi th a lower value before the W allow
for easier starting of the engine in cold weather.
• The 16 in 0W-16 indicates the vi scosity characteristic of the oil
when the oil is at high temperature. An oil with a higher visco sity
(one with a higher value) may be better suited if the vehicle i s
operated at high speeds, or un der extreme load conditions.
Lubrication system
With filter4.4 qt. (4.2 L, 3.7 Imp.qt.)
Without filter4.1 qt. (3.9 L, 3.4 Imp.qt.)
Outside temperature

777Alphabetical index
PRIUS PRIME_OM_OM47C77U_(U)
Clock ......................................... 192Adjustment ............................ 197
Coat hooks ............................... 553
Combination meter .................. 192 Clock adjustment .................. 197
Main display .......................... 209
Multi-information display ....... 218
Warning lights and
indicators ............................ 201
Condenser ................................ 594
Console box ............................. 532
Consumption screen ....... 263, 269
Coolant ..................................... 592 Capacity ................................ 723
Checking ............................... 592
Preparing and checking before winter....................... 495
Cooling system ........................ 592 Engine overheating ............... 709
Hybrid system overheating ... 711
Cruise control Dynamic radar cruise control with full-speed range .......... 403
Cup holders.............................. 533
Curtain shield airbags ............... 36
Customizable features ............ 741
Daytime running light system .................................... 353
Deck board ............................... 536
Defogger Outside rear view
mirrors ........................ 504, 515
Rear window ................. 504, 515
Windshield .................... 504, 514 Dimension ................................ 718
Dinghy towing.......................... 335
Display
BSM (Blind Spot Monitor) ..... 421
Drive information .................. 220
Dynamic radar cruise control with full-speed range .......... 403
Energy monitor ..... 221, 260, 266
Head-up display.................... 251
Intuitive parking assist .......... 434
LDA (Lane Departure Alert
with steering control) .......... 397
Main display.......................... 209
Multi-information display ....... 218
Parking Support Brake function............................... 448
Pre-collision warning ............ 381
S-APGS (Simple Advanced
Parking Guidance
System) .............................. 459
Warning messages ............... 672
Do-it-yourself maintenance .... 582
Door courtesy lights ............... 528 Location ................................ 528
Wattage ................................ 726
Doors ................................ 279, 285 Automatic door locking
and unlocking system......... 282
Back door ............................. 285
Door glasses......................... 312
Door lock .............................. 279
Open door warning buzzer ... 283
Open door warning light ....... 664
Outside rear view mirrors ..... 310
Rear door child-protectors .... 282
Side doors ............................ 279
Side windows........................ 312
D
*: Refer to “MULTIMEDIA OWNER’S MANUAL”.

779Alphabetical index
PRIUS PRIME_OM_OM47C77U_(U)
EngineAccessory mode ................... 338
Compartment ........................ 588
Engine switch........................ 336
Exhaust gas precautions ........ 56
Hood ..................................... 585
How to start the hybrid system ......... ....................... 336
Identification number ............ 720
If the hybrid system will not start .................................... 697
If your vehicle has to be stopped in an emergency ... 653
Ignition switch (power
switch) ................................ 336
Overheating .......................... 709
Power switch......................... 336
Engine coolant ......................... 592 Capacity ................................ 723
Checking ............................... 592
Preparing and checking before winter....................... 495
Engine oil ................................. 589
Capacity ................................ 722
Checking ............................... 589
Oil pressure warning light ..... 662
Preparing and checking before winter....................... 495
Engine switch (power switch) .................................... 336
Auto power off function ......... 338
Changing the power switch modes................................. 338
If your vehicle has to be stopped in an emergency ... 653
Starting the hybrid system .... 336 EPS (Electronic Power
Steering) ................................ 490
Function ................................ 490
Warning light......................... 663
EV auto mode ............................ 87
EV driving range ...................... 108
EV mode ..................................... 87
EV/HV mode selection
switch ....................................... 90
Event data recorder (EDR)........ 11
Exhaust gas precautions .......... 56
Flat tire ..................................... 680
Floor mats .................................. 26
Fluid Brake .................................... 725
Transmission ........................ 724
Washer ................................. 600
Fog lights ................................. 360
Replacing light bulbs ............ 648
Switch ................................... 360
Footwell lights ......................... 528
Front doors .............................. 279
Front fog lights ........................ 360
Replacing light bulbs ............ 648
Switch ................................... 360
Front passenger occupant classification system .............. 50
Front passenger’s seat
belt reminder light................. 664
