PRIUS PRIME_OM_OM47C77U_(U)
2373. Instrument cluster
3
Instrument cluster
■Checking history
When each screen is selected, past records from the following
ranges can be displayed by pressing or of the meter con-
trol switches.
●If the above number of records is exceeded, the oldest informa-
tion is deleted.
● To reset the history, perform “Hi story Reset” in the “Meter Cus-
tomize” settings ( P. 246). (“Daily” and “Monthly” information
can be reset independently.)
■ Calendar setting
P. 249
The clock settings can be
changed.
Displayed screenDisplayed informationStored information
“Daily”
4 reports
Up to 32 reports
(8 screens)
“Monthly”Up to 24 reports (6 screens)
Clock setting display
ItemSetting result
Adjusts the clock.
( P. 197)
Sets the minutes to
“00”. ( P. 198)
340
PRIUS PRIME_OM_OM47C77U_(U)
5-2. Driving procedures
■Meter display
When the power switch is turned off, each display will turn off as follows.
● The shift position indicator will turn off after approximately 2 seconds.
● The multi-information display, clock, etc. will turn off after approximately 30
seconds. (Each display will also turn off immediately if a door is locked
before 30 seconds has elapsed.)
■ If the smart key system has been d eactivated in a customized setting
P. 700
WARNING
■ When starting the hybrid system
Always start the hybrid system while sitting in the driver’s seat. Do not
depress the accelerator pedal while starting the hybrid system under any
circumstances.
Doing so may cause an accident resulting in death or serious in jury.
■ Stopping the hybrid system in an emergency
● If you want to stop the hybrid system in an emergency while driving the
vehicle, press and hold the power switch for more than 2 second s, or
press it briefly 3 times or more in succession. ( P. 653)
However, do not touch the power switch while driving except in an emer-
gency. Turning the hybrid system off while driving will not cause loss of
steering or braking control, however, power assist to the steer ing will be
lost. This will make it more difficult to steer smoothly, so you should pull
over and stop the vehicle as soon as it is safe to do so.
● If the power switch is operated while the vehicle is running, a warning
message will be shown on the multi-information display and a buzzer
sounds.
● When restarting the hybrid system after an emergency shutdown w hile
driving, press the power switch. When restarting the hybrid sys tem after
stopping the vehicle, change the shift position to P and then press the
power switch.
783Alphabetical index
PRIUS PRIME_OM_OM47C77U_(U)
Main display ............................. 209
MaintenanceDo-it-yourself maintenance ... 582
General maintenance ........... 578
Maintenance data ................. 718
Maintenance requirements ... 575
Malfunction indicator lamp ..... 662
Master warning light................ 672
Meter ......................................... 192 Clock adjustment .................. 197
Combination meter ............... 192
Head-up display .................... 251
Indicators .............................. 204
Instrument cluster light control................................. 194
Main display .......................... 209
Multi-information display ....... 218
Warning lights ....................... 202
Warning messages ............... 672
Microphone
*1, 2......................... 76
Mirrors Inside rear view mirror .......... 308
Outside rear view mirror defoggers ................... 504, 515
Outside rear view mirrors...... 310
Vanity mirrors........................ 540
MP3 disc
*1
Multi-information display ........ 218
Air conditioning system settings screen ................... 239
Audio system-linked display ................................ 238
BSM (Blind Spot Monitor) ..... 421
Display contents ................... 218
Drive information................... 220
Driving assist system
information.......................... 243
Dynamic radar cruise control with full-speed range .......... 403 Energy monitor ..................... 221
Intuitive parking assist .......... 434
Language.............................. 246
LDA (Lane Departure Alert
with steering control) .......... 397
Navigation system-linked display ................................ 238
Parking Support Brake
function............................... 448
Pre-collision warning ............ 381
S-APGS (Simple Advanced Parking Guidance
System) .............................. 459
Settings................................. 244
Warning message................. 243
Navigation system
*2
Noise from under vehicle ........... 8
Odometer ................................. 211
Oil Engine oil .............................. 722
Opener Back door ............................. 285
Fuel filler door ....................... 370
Garage door ......................... 555
Hood ..................................... 585
Outside rear view mirrors ....... 310
Adjustment............................ 310
BSM (Blind Spot Monitor) ..... 421
Folding .................................. 310
Outside rear view mirror defoggers ................... 504, 515
Outside temperature
display.................................... 209
Overhead console ................... 535
Overheating ............................. 709
M
N
O
*1: Refer to “MULTIMEDIA OWNER’S MANUAL”.
*2: Refer to “NAVIGATION S YSTEM OWNER’S MANUAL”.
