5299-1. Specifications
COROLLA_U
9
Vehicle specifications
*: The fluid capacity is a reference quantity.
If replacement is necessary, contact your Toyota dealer.
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
Electrical system (battery)
Open voltage at 68°F (20°C):
12.3 V or higher
(Turn the engine switch off and turn on the
high beam headlights for 30 seconds.)
Charging rates
Quick charge
Slow charge
15 A max.
5 A max.
Continuously variable transmission
Fluid capacity*
1.8 L 4-cylinder (2ZR-FAE) engine
7.9 qt. (7.5 L, 6.6 Imp. qt.)
2.0 L 4-cylinder (M20A-FKS) engine
9.0 qt. (8.5 L, 7.5 Imp. qt.)
Fluid typeToyota Genuine CVT Fluid FE
NOTICE
■Continuously variable transmission fluid type
Using continuously variable transmissi on fluid other than “Toyota Genuine
CVT Fluid FE” may cause deterioration in shift quality, locking up of trans-
mission accompanied by vibration and, ultimately, damage to the vehicle’s
transmission.
Manual transmission
Gear oil capacity (Reference)
1.8 L 4-cylinder (2ZR-FAE) engine
2.5 qt. (2.4 L, 2.1 Imp. qt.)
2.0 L 4-cylinder (M20A-FKS) engine
1.6 qt. (1.5 L, 1.3 Imp. qt.)
Gear oil type“TOYOTA Genuine Manual Transmission
Gear Oil LV GL-4 75W” or equivalent
